1. Computer
Programming in C
Input-Output
Instructions in C
By : Rahul Sharma
Subscribe channel on YouTube
Follow us on Facebook

2. Input-Output
Instruction in C
Subscribe our YouTube channel
Follow us on Facebook

3. Operators
Example: 5 + 6
Operator
Operands

4. Operators
5 * 5 + 3
28 40
BODMAS Rule is not apply in C language.

5. Bitwise Operators
❑ There are six types of bitwise operators
➢ Bitwise ‘AND’ (&)
➢ Bitwise ‘OR’ (|)
➢ Bitwise ‘XOR’ or Exclusive OR (^)
➢ Bitwise ‘NOT’ (~)
➢ Right Shift (>>)
➢ Left Shift (<<)

6. Unary Operators
❑ +, - , ++, --, sizeof( ).
❑ Unary operators are operators those required only one
operand to perform operations.

7. Unary Operators
➢ -a, -b, -c; Negative
➢ +a, +b, +c ; Positive
➢ --a, --b,--c; Decrement Operator
➢ ++a,++b,++c : Increment Operator
Unary Operator: Use will only 1
operand
Binary Operator: Use will only 2 operand
Ternary Operator: Use will only 3
operand

8. Unary Operators
➢ ++(Increment Operator)
• Post Increment Operator(x++)
• Pre Increment Operator(++x)
➢ --(Decrement Operator)
• Post Decrement Operator(x--)
• Pre Decrement Operator(--x)

9. Bitwise Operators
➢ Bitwise AND (&)
➢ Bitwise OR ( | )
➢ Bitwise XOR or Exclusive OR (^)
➢ Bitwise NOT ~
➢ Bitwise Right shift >>
➢ Bitwise Left shift <<

10. Bitwise Operators
Bitwise AND(&) : This operator work on binary numbers .
Operand Operator Operand Output
0 & 0 0
0 & 1 0
1 & 0 0
1 & 1 1
Ex:
Int x;
X= 23 & 56;
56 = 0000 0000 0011 1000
23= 0000 0000 0001 0111
16 = 0000 0000 0001 0000
16
2^9 2^8 2^7 2^6 2^5 2^4 2^3 2^2 2^1 2^0
9 8 7 6 5 4 3 2 1 0
If Both true then
O/P will be true

11. Bitwise Operators
Bitwise OR(|) : This operator work on binary numbers .
Operand Operator Operand Output
0 | 0 0
0 | 1 1
1 | 0 1
1 | 1 1
Ex:
Int x;
X= 23 & 56
56 = 0000 0000 0011 1000
23 = 0000 0000 0001 0111
63 = 0000 0000 0011 1111
1+2+4+8+16+32=
63
2^9 2^
8
2^7 2^6 2^5 2^4 2^3 2^2 2^1 2^0
9 8 7 6 5 4 3 2 1 0
If one value is
true then O/P will
be true.

12. Bitwise Operators
Bitwise XOR(^) : This operator work on binary numbers . If Both
operands are same than output will be 0 if different then 1.
Operand Operator Operand Output
0 ^ 0 0
0 ^ 1 1
1 ^ 0 1
1 ^ 1 0
Ex:
Int x;
X= 23 & 56
56 = 0000 0000 0011 1000
23 = 0000 0000 0001 0111
= 0000 0000 0010 1111
1+2+4+8+32=47
2^9 2^8 2^7 2^6 2^5 2^4 2^3 2^2 2^1 2^0
9 8 7 6 5 4 3 2 1 0
Both should be
different to get
true value.

13. Bitwise Operators
Bitwise Right shift (>>) : This operator work on binary numbers .
Here we have to add 00 in left side
Ex:
Int x;
X= 56>>2
56 = 0000 0000 0011 1000
Step 1: = 0000 0000 0000 1110 00
2+4+8=14
2^9 2^8 2^7 2^6 2^
5
2^4 2^3 2^2 2^1 2^0
9 8 7 6 5 4 3 2 1 0

14. Bitwise Operators
Bitwise Left shift (<<) : This operator work on binary numbers .
Here we have to add 00 in right side
Ex:
Int x;
X= 56<<2
56 = 0000 0000 0011 1000
Step 1: 56 = 00 0000 0000 1110 0000
32+64+128=448
2^9 2^8 2^7 2^6 2^5 2^4 2^3 2^2 2^1 2^0
9 8 7 6 5 4 3 2 1 0

15. Relational Operators
➢ <, >, <=,>= ( 1 )
➢ ==, != ( 2)
➢ Here priority of set-1 is greater than set-2.
➢ Relational Operators always Yields results either 0 or 1.
➢ Every Non-zero value is true and zero value is false
main()
{ int x;
clrscr();
x = 3>4;
printf(“%d”, x);
}
0
Ctrl+F9
Output :

16. Logical Operators
➢ NOT !
➢ And &&
➢ OR ||
❖ NOT !
▪ This an unary operator.
▪ Priority level is also same as unary operator.
▪ It inverts the truth value of statement .
▪ !T = F
▪ !F = T

17. Logical Operators
❖ NOT !
▪ This an unary operator.
▪ Priority level is also same as unary operator.
▪ It inverts the truth value of statement .
▪ !T = F
▪ !F = T

18. Logical Operators
❖ NOT !
▪ This an unary operator.
▪ Example:
main()
{ int x=5;
clrscr();
x = !x > 4; // 0>4==0
printf(“%d”, x);
}
0
Ctrl+F9
Output :

19. Logical Operators
❖ AND &&
▪ This an Binary operator.
▪ If both operand are non zero(true) then it becomes true.
Operand Operator Operand Output
F && F F
T && F F
T && F F
T && T T

20. Logical Operators
❖ AND &&
▪ This an Binary operator.
▪ Example: main()
{ int x=5, y;
clrscr();
y = x > 4 && x <10 ; // T && T==1
printf(“%d”, y);
}
1
Ctrl+F9
Output :

21. Logical Operators
❖ OR ||
▪ This an Binary operator.
▪ If any of the two operands is non-zero(true) then it becomes true.
Operand Operator Operand Output
F || F F
T || F T
T || F T
T || T T

22. Thank You
➢ For Detailed understanding,
Subscribe our channel on
You tube.
➢ Follow us on Facebook
✓ Page name : Digital Wave (
Link in Description Box)
