Building Consistent
RESTful APIs in a High-
Performance Environment
Yegor Borovikov, Software Architect
Brandon Duncan, Di...
Topics We’ll Cover

>   Examples of RESTful APIs
       What’s missing?
       Variety versus Uniformity
>   Domain Mode...
Examples of RESTful APIs
What if you want to get a person’s profile?
>   Use one of these…
    http://social.yahooapis.com...
Examples of RESTful APIs
What’s Missing?
>   Ability to get exactly what you need (variety)
       If you need more, may ...
Examples of RESTful APIs
Multiple Calls to Get What You Need
>   Want to get user’s friend’s profile? Do this…
       htt...
Examples of RESTful APIs
Multiple Calls to Get What You Need
>   … then make second call to get friend’s profile:
    http...
Typical Solution
Variety versus Uniformity
>   Solution: introduce another call

>   Desire for variety of responses
    u...
Domain Model as Foundation
Sample Domain Model
/people : Person[]     //   collection of Person resources
   /id : string ...
Domain Model as Foundation
Follow request URL to navigate through your model
>   To get a person’s profile:
    http://api...
Domain Model as Foundation
Fine-grained Request
>   What if you only need certain fields
    (e.g., name and photo)?
    h...
Domain Model as Foundation
Fine-grained Request
>   To get names and photos of one’s friends and
    their best friends:
 ...
Domain Model as Foundation
Fine-grained Request
>   Allows client to construct custom calls

>   Better than digging for t...
Domain Model as Foundation
Benefits
>   Provides a frame for both request and response
    semantics
>   Still allows for ...
Examples of LinkedIn APIs
HTTP GET - Read

   …/people/email=brandon@gmail.com/friends?sort=name

   …/people/123/friends;...
Examples of LinkedIn APIs
HTTP PUT - Update
>   Set the user’s name:                           /people[/id=123]
          ...
Examples of LinkedIn APIs
HTTP POST - Create
>   Add a friend                                              /people[/id=123...
Examples of LinkedIn APIs
HTTP DELETE - Remove
>   Remove a friend
DELETE http://api.linkedin.com/v2/people/123/friends/45...
Use Standard Headers

>   Content-Type
>   Last-Modified
>   Accept
>   Vary
>   Authorization
>   Cache-Control
>   Conte...
Incentive System

>   Multiple ways to get at the same data

>   Partner can ask for exactly what they need

>   Associate...
Real-World Example
Xobni Toolbar
>   Xobni makes ~20 million profile API calls per week
>   Default representation is ~2k ...
Yegor Borovikov
yborovik@linkedin.com
Brandon Duncan
bduncan@linkedin.com
blog.linkedin.com


                        21
Upcoming SlideShare
Loading in...5
×

Building Consistent RESTful APIs in a high-performance environment

27,111

Published on

This is one of two presentations given by LinkedIn engineers at Java One 2009.

This presentation was given by Brandon Duncan, Director of Engineering, and Yegor Borovikov, Software Architect at LinkedIn.

For more information, check out http://blog.linkedin.com/

2 Comments
71 Likes
Statistics
Notes
  • This is a pointless rebuttal, because it’s not about who contributed what, or how hard a chef worked, or whether their job was worth it. If you make a deal with someone for x amount of stock, or whatever, they get it. You don’t try to strong arm them into giving it back later on - that’s dishonest. It doesn’t matter if it’s worth 20 million or 20 cents. http://www.intour.com.vn/tour-du-lich-nha-trang-3-ngay.html

    http://www.intour.com.vn/da-lat-thanh-pho-ngan-hoa.html
       Reply
    Are you sure you want to  Yes  No
    Your message goes here
  • There are two approaches to developing REST APIs: top down and bottomup.
    In top down model, the REST APIs are defined using business taxonomy and Rest client needs. We then attempt to identify and develop REST resources and map them to existing domain models through sub-resources.
    In the bottom up approach, we take domain models and expose them as REST APIs.
    The JAX-RS annotation models provides a very good way to implement either approach.
       Reply
    Are you sure you want to  Yes  No
    Your message goes here
No Downloads
Views
Total Views
27,111
On Slideshare
0
From Embeds
0
Number of Embeds
6
Actions
Shares
0
Downloads
668
Comments
2
Likes
71
Embeds 0
No embeds

No notes for slide

Building Consistent RESTful APIs in a high-performance environment

  1. 1. Building Consistent RESTful APIs in a High- Performance Environment Yegor Borovikov, Software Architect Brandon Duncan, Director of Engineering LinkedIn Corporation http://blog.linkedin.com/
  2. 2. Topics We’ll Cover > Examples of RESTful APIs  What’s missing?  Variety versus Uniformity > Domain Model as Foundation  Provides Uniformity  Allows Flexibility > Examples of LinkedIn APIs > Using Incentives to Scale  Some LinkedIn production APIs metrics > Q&A 2
  3. 3. Examples of RESTful APIs What if you want to get a person’s profile? > Use one of these… http://social.yahooapis.com/v1/user/{guid}/profile http://api.linkedin.com/v1/people/{guid} http://www.orkut.com/social/rest/people/{guid}/@self <?xml version="1.0" encoding="UTF-8"?> <person> <id>111222</id> <first-name>Gertrude</first-name> <last-name>Stein</last-name> <headline>Author of Tender Buttons</headline> <connections total="76"> … </person> 3
  4. 4. Examples of RESTful APIs What’s Missing? > Ability to get exactly what you need (variety)  If you need more, may require multiple API calls (if they exist)  If you need less, resources are wasted > Consistency of responses (uniformity)  “Same” object returned by different APIs may have different structure  Once in production, hard to get consistent later 4
  5. 5. Examples of RESTful APIs Multiple Calls to Get What You Need > Want to get user’s friend’s profile? Do this…  http://social.yahooapis.com/v1/user/123/connections <connections yahoo:start="0" yahoo:count="1" yahoo:total="1"> <connection yahoo:uri="http://social.yahooapis.com/v1/user/123/connection/456? view=usercard"> <guid>456</guid> <contactId>4</contactId> </connection> </connections> 5
  6. 6. Examples of RESTful APIs Multiple Calls to Get What You Need > … then make second call to get friend’s profile: http://social.yahooapis.com/v1/user/456/profile <profile yahoo:uri="http://social.yahooapis.com/v1/user/456/profile"> <guid>456</guid> <birthdate>3/3</birthdate> <created>2008-08-4T17:13:56Z</created> ... </profile>  Latent, redundant data  Optimization requires stickiness 6
  7. 7. Typical Solution Variety versus Uniformity > Solution: introduce another call > Desire for variety of responses undermines uniformity of requests > Leads to RPC-like REST APIs > Many APIs + Great Documentation = Lots of Reading + Lack of Automation 7
  8. 8. Domain Model as Foundation Sample Domain Model /people : Person[] // collection of Person resources /id : string // primary key /name : string /email : string // unique key /photo : url /best-friend : Person /friends : Person[] /jobs : Job[] // collection of Job resources /company : Company /title : string /start-date : date /end-date : date … /companies : Company[] /name : string /ceo : Person … 8
  9. 9. Domain Model as Foundation Follow request URL to navigate through your model > To get a person’s profile: http://api.linkedin.com/v2/people/123 /people[/id=123] <person uri=“urn:linkedin:v2:people/123” key=“123”> /id <id>123</id> /name <name>Reid Hoffman</name> /email /photo <email>reid@linkedin.com</email> /best-friend <best-friend uri=“urn:linkedin:v2:people/456”/> /friends … /jobs /company </person> /title /start-date /end-date …  Conventional URL in request /companies /name  Default representation in response /ceo … 9
  10. 10. Domain Model as Foundation Fine-grained Request > What if you only need certain fields (e.g., name and photo)? http://api.linkedin.com/v2/people/123:(name,photo) <person> <name>Reid Hoffman</name> /people[/id=123] <photo>http://media.linkedin.com/photos/123.jpeg</photo> /id </person> /name /email /photo /best-friend /friends /jobs /company /title /start-date /end-date … 10
  11. 11. Domain Model as Foundation Fine-grained Request > To get names and photos of one’s friends and their best friends: …/v2/people/456/friends:(name,photo,best-friend: (name,photo)) /people[/id=456] /id <friends total=“66” start=“0”> /name <friend uri=“urn:linkedin:v2:people/123” key=“123”> /email /photo <name>Reid Hoffman</name> /best-friend <photo>http://media.linkedin.com/photos/123.jpeg</photo> /friends <best-friend uri=“urn:linkedin:v2:people/456” key=“456”> /123 /id <name>Brandon Duncan</name> /name <photo>http://media.linkedin.com/photos/456.jpeg</photo> /email /photo </best-friend> /best-friend </friend> /name <friend>…</friend> /photo /jobs </friends> … 11
  12. 12. Domain Model as Foundation Fine-grained Request > Allows client to construct custom calls > Better than digging for the closest matching API: http://social...com/v1/user/123/profile http://social...com/v1/user/123/profile/usercard http://social...com/v1/user/123/profile/tinyusercard > Allows optimization on the backend 12
  13. 13. Domain Model as Foundation Benefits > Provides a frame for both request and response semantics > Still allows for flexible syntax  Requests – path, query params, matrix params…  Responses – JSON, XML, POJOs, protobuff… > Helps to unify and automate many development tasks on both ends  Request / response creation, parsing, marshalling  Code (and documentation) generation  Discovery services 13
  14. 14. Examples of LinkedIn APIs HTTP GET - Read …/people/email=brandon@gmail.com/friends?sort=name …/people/123/friends;sort=name:(name,jobs;sort=start-date) …/people:(id,name,photo)?name=page&company=google …/people::(123,456) …/people::(123,456):(name,photo) 14
  15. 15. Examples of LinkedIn APIs HTTP PUT - Update > Set the user’s name: /people[/id=123] /id /name PUT http://api.linkedin.com/v2/people/123/name /email <name>Reid Hoffmann</name> /photo /best-friend … > Update the user’s profile - change name and best- friend and remove photo: PUT http://api.linkedin.com/v2/people/123 <person> /people[/id=123] <name>Reid Hoffman</name> /id /name <best-friend uri=“urn:linkedin:v2:people/999”/> /email <photo xsi:nil=“true”/> /photo </person> /best-friend … 15
  16. 16. Examples of LinkedIn APIs HTTP POST - Create > Add a friend /people[/id=123] /id POST http://api.linkedin.com/v2/people/123/friends /name /email <friend uri=“urn:linkedin:v2:people/888”/> /photo /best-friend 201 Created /friends /456 Location: http://api.linkedin.com/v2/people/123/friends/888 /888 … 16
  17. 17. Examples of LinkedIn APIs HTTP DELETE - Remove > Remove a friend DELETE http://api.linkedin.com/v2/people/123/friends/456 > Delete a company DELETE http://api.linkedin.com/v2/companies/exchange=NYSE&ticker=GM > Delete two companies DELETE http://api.linkedin.com/v2/companies::(664,665) 17
  18. 18. Use Standard Headers > Content-Type > Last-Modified > Accept > Vary > Authorization > Cache-Control > Content-MD5 > Location > Warning 18
  19. 19. Incentive System > Multiple ways to get at the same data > Partner can ask for exactly what they need > Associate cost with resources, system of accounting creates incentives for partners > Throttling by resource rather than API 19
  20. 20. Real-World Example Xobni Toolbar > Xobni makes ~20 million profile API calls per week > Default representation is ~2k on average > Using in-line filter brings average to ~1.5k  25% reduction in response size  ~11000 Mbits savings per day  11k Mbits out of LinkedIn datacenter  11k Mbits into Xobni datacenter  Saves both companies money 20
  21. 21. Yegor Borovikov yborovik@linkedin.com Brandon Duncan bduncan@linkedin.com blog.linkedin.com 21
