The document summarizes a webinar about redefining storage value through a business-savvy storage strategy. It discusses how the Intelligent Storage Element (ISE) architecture provides cost efficiency by eliminating hot spare drives and maximizing usable capacity. It provides performance efficiency through striping at the drive-head level to maintain consistent performance regardless of utilization. It ensures reliability efficiency by monitoring drive telemetry and replacing failed drive heads instead of entire drives to reduce downtime. The ISE approach aims to optimize capacity, performance, and reliability for the lowest overall cost.

1. Business-Savvy StorageStrategy in ChallengingEconomic Times Audio is via dial-in from WebEx Main Page Communicate > Teleconference > Join Teleconference

2. Webinar Logistics Content delivery will be approximately 50 minutes 2 Presentations Jon Toigo, Principal of Toigo Partners International Roger Kelly, Principal Storage Architect, Xiotech Corportation Q & A to follow This webinar will be recorded and available for playback. You will receive an email tomorrow with this information. Please submit questions via online Q&A to “Host”. Questions will be answered online and/or at the completion of the webinar – time permitting. Due to the number of participants, your line is muted.

3. Redefining Storage Value:Business-Savvy StorageStrategy in ChallengingEconomic TimesRob PeglarVP, TechnologyXiotech Corporation

4. Redefining Storage Value Q: Why? … A: Economy! Q: A: The Old Cliché’: You can have Performance, Reliability or Cost, Performance, or Low Cost—Pick Any Two! Over the past 25 years the storage foundation has been fundamentally unchanged.

5. Redefining Storage Value Q: How? Q: Focus on the Fundamentals Cost efficiencies Performance efficiencies Reliability efficiencies Intelligent Storage Element (ISE)

6. Redefining Storage ValueStorage Fundamentals

7. Cost Efficiency

9. Partly due to potential for drive to change location

12. May be because of current or future software options they want to sell you

13. Might be because performance takes a hit if you fill drives too full

14. “Hold back” ranges from 20%-70% of capacity after RAID

16. User purchases eight drives, Xiotech adds two drives (16 heads)

17. 8 drive capacity is striped over all 10 drives (80 heads)

18. 20% of each drive is reserved to equal 2 added drives = (16 of 80 heads)

19. Purchased capacity (8 drives) can reach 100% usable capacity (after RAID) without a performance hit partly because 10 physical drives are only 80% full

20. No required “feature holdback” allows ISE to reclaim of 20%-70% wasted space over conventional storage

22. Performance Efficiency

23. Redefining Storage ValuePerformance Efficiency? Conventional Storage: An inverse relationship between performance and drive utilization for most systems Performance suffers as drive utilization increases Leads to buying more drives to achieve performance target

24. Redefining Storage ValueTrue Performance Efficiency ISE utilizes a patented process of striping data. One of two methods of striping can be employed For extreme performance, active data can be constrained to outer perimeter whereas less active or inactive data retained on inner platter. Drive is 100% full but benefits of “short stroking” are available for active data All areas of the platter can be used for all data. Performance stays constant regardless of whether the drive is 1% full or 100% full Method used for SPC-1 and SPC-2 benchmarking

25. Each ISE has two Active-Active RAID controllers Each ISE has 1GB cache Performance scales linearly Two ISEs perform twice as fast as one, three, three times as fast, etc. 6,000 Very Heavy Exchange 2007 users on 20 spindles Can be virtualized under Xiotech controllers or numerous third party Virtualized Storage Controllers Striping method gives user 10 hard drive spindles for the price of eight Redefining Storage ValueTrue Performance Efficiency

26. Reliability Efficiency

27. Redefining Storage ValueTrue Reliability Efficiency ISE monitors Seagate proprietary drive telemetry.If a drive “sneezes” it becomes subject to advanced diagnostics The drive may be reset or power cycled multiple times. If that fails to clear the problem: Data is copied non-disruptively from each head to other heads in the array Once the drive is empty it is subjected to remanufacture process: Reload drive firmware Refresh Servos and Tracks Reformat drive Rewrite Servos and Tracks If a head or heads are determined to be unsalvageable the head(s) are deactivated, the drive Geometry is reset to a smaller drive, lost capacity is replaced from reserve area.

29. ISE carries the industry’s ONLY five-year hardware warranty. Xiotech’s exclusive five-year warranty can save tens of thousands of dollars over other storage systems. Other vendors also may use shorter warranties and expensive maintenance renewals to force you into a new storage system before you really need it. Redefining Storage ValueTrue Reliability Efficiency

30. Storage Value – the Value Equation V = C x P x R / $ Based on public SPC-1 results – not marketing BS C = tested capacity in TB over which I/O was actually performed – not raw space P = measured performance in IOPS R = warranty period in years $ = tested unit price

31. Redefining Storage ValueStorage Fundamentals

32. Nothing is as powerful as an idea whose time has come. Victor Hugo
