Workshop Apps with ReactNative II: - React Native short Recap - Navigation in React Native Apps - Tabs & Other Architectural Components - Lists & Other Presentational Components - OpenSource Important Components Presentado por ingenieros Raúl Delgado y Marc Torrent

1. Front End Workshops
React Native Part II:
Components
Raul Delgado
Marc Torrent
rdelgado@visual-engin.com
mtorrent@visual-engin.com

2. React Native short Recap

3. React Native: is a library to generate
native apps for iOS and Android mobile devices capable,
programmed in javascript.
React Native uses the actual native components of each
platform (currently iOS and Android).
Useful Native APIs
React Native Part I

4. Navigation in React Native Apps

5. Navigator: Intro
Navigator handles the transition
between different scenes in your app.
It is implemented in JavaScript and is
available on both iOS and Android.
renderScene: It is the prop that got a
function that is responsible for,
according to the name or index of the
route, we will render a view or
another.

6. Navigator: Intro
Navigator handles the transition
between different scenes in your app.
It is implemented in JavaScript and is
available on both iOS and Android.
renderScene: It is the prop that got a
function that is responsible for,
according to the name or index of the
route, we will render a view or
another.
renderScene(route, navigator) {
switch (route.name) {
case 'Login':
return (
<Login {...route.props}
navigator={navigator} route={route} />
);
case 'Dashboard':
return (
<Dashboard {...route.props}
navigator={navigator} route={route} />
);
default:
return null;
}
}
How navigate:
const route = {
title: 'Title,
name: 'NameComponent',
passProps: {propsToPass: true}
}
this.props.navigator.replace(route);
this.props.navigator.push(route);
this.props.navigator.pop( );

7. Navigator: Transitions
We can configure the navigation bar
properties, through the routeMapper
configureScene :
Optional function where you can
configure scene animations and
gestures.
Available scene configutation options
are:
Navigator.SceneConfigs.PushFromRight (default)
Navigator.SceneConfigs.FloatFromRight
Navigator.SceneConfigs.FloatFromLeft
Navigator.SceneConfigs.FloatFromBottom
Navigator.SceneConfigs.FloatFromBottomAndroid
Navigator.SceneConfigs.FadeAndroid
Navigator.SceneConfigs.HorizontalSwipeJump
Navigator.SceneConfigs.HorizontalSwipeJumpFromRigh
t
Navigator.SceneConfigs.VerticalUpSwipeJump
Navigator.SceneConfigs.VerticalDownSwipeJump
<Navigator
configureScene={(route) => {
return
Navigator.SceneConfigs.FloatFromBottom;
}}
navigationBar={
<Navigator.NavigationBar
routeMapper={NavigatorBarRouterMapper} />
}
/>

8. Navigator: Transitions
We can configure the navigation bar
properties, through the routeMapper
configureScene :
Optional function where you can
configure scene animations and
gestures.
Available scene configutation options
are:
Navigator.SceneConfigs.PushFromRight (default)
Navigator.SceneConfigs.FloatFromRight
Navigator.SceneConfigs.FloatFromLeft
Navigator.SceneConfigs.FloatFromBottom
Navigator.SceneConfigs.FloatFromBottomAndroid
Navigator.SceneConfigs.FadeAndroid
Navigator.SceneConfigs.HorizontalSwipeJump
Navigator.SceneConfigs.HorizontalSwipeJumpFromRigh
t
Navigator.SceneConfigs.VerticalUpSwipeJump
Navigator.SceneConfigs.VerticalDownSwipeJump
<Navigator
configureScene={(route) => {
return
Navigator.SceneConfigs.FloatFromBottom;
}}
navigationBar={
<Navigator.NavigationBar
routeMapper={NavigatorBarRouterMapper} />
}
/>
const NavigatorBarRouterMapper = {
LeftButton: (route, navigator, index) => {
return (
<TouchableHighlight onPress={() => {
navigator.pop();
} }>
<Text>Back</Text>
</TouchableHighlight>
);
},
RightButton: (route, navigator, index) => {
return null;
},
Title: (route, navigator, index) => {
return (
<Text >{route.name}</Text>
);
},
};

9. Tabs & Other Architectural
Components

10. TabBarIOS & TabBarIOS.Item
<TabBarIOS style={{backgroundColor: '#ffffff'}} >
<TabBarIOS.Item
title="Tab Bar 1"
selected={this.state.selectedTab === 'TabBar1'}
icon={{uri: iconGame1, scale:4 }}
onPress={() => {
this.setState({ selectedTab: TabBar1' });
}}
>
<DashboardView navigator={this.props.navigator} />
</TabBarIOS.Item>
<TabBarIOS.Item
title="Tab Bar 2"
selected={this.state.selectedTab === 'TabBar2'}
icon={{uri: iconGame1, scale:4 }}
onPress={() => {
this.setState({ selectedTab: 'TabBar2' });
}}
>
<DashboardView navigator={this.props.navigator} />
</TabBarIOS.Item>
</TabBarIOS>

11. ViewPagerAndroid
<ViewPagerAndroid
style={{flex: 1}}
initialPage={0}>
<View >
<Component1 navigator={this.props.navigator} />
</View>
<View>
<Component2 />
</View>
<View style={{backgroundColor: 'rgba(0,0,0,.8)', flex: 1}}>
<Text>ola</Text>
</View>
</ViewPagerAndroid>
One of the many alternatives to android tabs:
ViewPagerAndroid:

12. ScrollableTabView - Universal
$ npm install react-native-scrollable-tab-view
Tabbed navigation that you can swipe between, each tab
can have its own ScrollView and maintain its own scroll
position between swipes.
<ScrollableTabView>
<Componente1 tabLabel="comp1" />
<Componente2 tabLabel="comp2" />
<Componente3 tabLabel="comp3" />
</ScrollableTabView>

13. Lists & Other Presentational
Components

14. ListView
Use ListView to render a list of components.
Use a ListViewDataSource as the source of your ListView.
The ListViewDataSource has two main methods:
- rowHasChanged: function that handles if a row has to be re-rendered
- cloneWithRows: the datasource used by ListView is inmutable. So,
ListViewDataSource provides this method in order to clone the pre-existing
or new data list.
The ListView has the renderRow and renderSectionHeader props that are functions
that we provide to the ListView in order to render the cells.
renderRow (rowData, sectionID, rowID, highlightRow)
rowData → The data we will use to render our component inside this cell
sectionID, rowID → if we need to change our component from positioning

15. ListView - example
constructor(props) {
super(props);
this.state = {
dataSource: new ListView.DataSource({
rowHasChanged: (row1, row2) => row1 !== row2
})
};
}
fetchData(_newData) {
this.setState({
dataSource: this.state.dataSource.cloneWithRows(_newData)
});
}
render() {
return (
<ListView
dataSource={this.state.dataSource}
renderRow={(data, sectionID, rowID) => <MyCustomView {...data} />}
style={styles.listview} />
);
}

16. ...
render() {
return (
<ListView
dataSource={this.state.dataSource}
renderRow={(data, sectionID, rowID) => <MyCustomView {...data} />}
renderScrollComponent={props => <RecyclerViewBackedScrollView {...props} />}
style={styles.listview} />
);
}
ListView - renderScrollComponent
renderScrollComponentallows setting wich component will render the scrolling
part of our list. By default ListView uses ScrollView.
For performance it’s better to use RecyclerViewBackedScrollView.
Also, you’ll find a lot of scrollable components such as InfiniteScrollView,
InvertibleScrollView, ScrollableMixin, ScrollableDecorator

17. OpenSource Important Components:
https://js.coach/react-native
https://react.parts/native

18. UI Components
Swiper: npm i react-native-swiper --save
Drawer: npm install --save react-native-drawer
Swipeout Buttons: npm install --save react-native-swipeout
Button: npm install react-native-button --save
Video: npm install react-native-video
Camera: npm install react-native-camera
Vector Icons: npm install react-native-vector-icons --save
Native Navigation: npm install react-native-navigation --save

19. Utilities & Architectural Components
Reactotron: npm install reactotron --save-dev
Internationalizatoin: npm install react-native-i18n --save
FileSytem: npm install react-native-fs --save
Push Notifications: npm install react-native-push-notification
Code Push: npm install --save react-native-code-push
CSS/SASS: npm install react-native-css -g
Device Info : npm install react-native-device-info --save
Redux Persist: npm i --save redux-persist

20. Thanks for your time!
Give your questions on the comments section
