1. Weathering
By Lisa Bolin

2. Weathering and Erosion
This is a monument called Cleopatra’s Needle. It was carved in Egypt around
1450B.C. The sides are carved with hieroglyphs, the writing of ancient
Egypt. It stood in the dry, hot Egyptian desert for over 3000 years. During
that time, the hieroglyphs remained distinct.

3. Weathering
• In 1800, the monument was moved to New York City. Almost immediately,
the hieroglyphs began to fade. In only a few years in the wet and variable
climate of New York, the Egyptian writing became indistinct!

4. • Cleopatra’s Needle was carved from granite, a hard tough, crystalline rock.
• Although it is tough, granite is changed by the atmosphere.
• Some of the minerals that make up granite change to clay.
• Chips and flakes of minerals break away from the granite surface.

5. Weathering
• Weathering is simply the chemical and/or
physical breakdown of a rock material--
weathering involves specific processes
acting on rock materials at or near the
surface of the Earth

6. Weathering
• In other rocks, minerals may slowly
dissolve.
• Eventually the surface of ALL rocks
crumbles, or weathers.

7. Types of Weathering
• Physical Weathering( mechanical)
– Takes place when rock is split or broken into
smaller pieces of the same material without
changing its composition.
Example: Breaking of a rock cliff into boulders
and pebbles

8. Weathering
Physical
• Common weathering processes:
– Frost action
– Wetting and drying
– Action of plants and animals
– Loss of overlying rock and soil

9. Types of Weathering
• Chemical (decomposition)
– takes place when the rock’s minerals are changed
into different substances.
– Water and water vapor are important agents of
chemical weathering.
Example: Formation of clay minerals from
feldspar

10. Types of Weathering
• The two processes of weathering,
mechanical and chemical seldom occur
alone!
• Since water vapor is present in the air
everywhere means that chemical
weathering occurs everywhere.

11. Types of Mechanical Weathering
• Frost action or Ice Wedging:
– Water takes up about 10% more space when
it freezes.
– This expansion puts great pressure on the
walls of a container.
– Water held in the cracks of rocks wedges the
rock apart when it freezes.
– Often occurs in places where temperatures
vary from below the freezing point of water to
above the freezing point.

12. Types of Mechanical Weathering
• Frost action or Ice Wedging con’t
• Occurs mostly in porous rocks and rocks
with cracks in them
– Bare mountaintops are especially subject to
ice wedging.

13. Types of Mechanical Weathering
• Frost action or Ice Wedging causes:
– Vast fields of large, sharp-cornered boulders
– Potholes on streets and highways

14. Types of Mechanical Weathering
• Repeated wetted and drying
• Especially effective at breaking up rocks
that contain clay.
• Clays swell up when wet and shrink when
dry.
• Causes rocks that contain clay, such as
shale, to fall apart.

15. Types of Mechanical Weathering
• Action of plants and animals:
– Lichens and mosses grow on rocks
• They wedge their tiny roots into spores and
crevices.
• When the roots grow, the rock splits.
• Action of plants and animals:
– Lichens and mosses grow on rocks
• They wedge their tiny roots into spores and
crevices.
• When the roots grow, the rock splits.
• Action of plants and animals:
– Lichens and mosses grow on rocks
• They wedge their tiny roots into spores and
crevices.
• When the roots grow, the rock splits.

16. Types of Mechanical Weathering

17. Types of Mechanical Weathering
• Action of plants and animals:
– Larger trees and shrubs may grow in the
cracks of boulders.
– Ants, earthworms, rabbits, woodchucks, and
other animals dig holes in the soil.
• These holes allow air and water to reach the
bedrock and weather it.

18. Types of Mechanical Weathering

19. Types of Mechanical Weathering

20. Types of Mechanical Weathering
• Loss of Overlying Rock and Soil
– Sheet jointing on a granite outcrop produces
cracks in the rock, thereby exposing more of
the rock surface to weathering.

21. Types of Mechanical Weathering
Granite exfoliation

22. Types of Chemical Weathering
• Results mainly from the action of
rainwater, oxygen, carbon dioxide, and
acids of plant decay.

23. Agents of Chemical Weathering

24. Agents of Chemical Weathering
• The chemical reaction of water with other
substances is called hydrolysis.
• Common materials undergoing hydrolysis:
– Feldspar
–
– Hornblende
– Augite

25. Agents of Chemical Weathering
• The chemical reaction of oxygen with
other substances is called oxidation.
– Iron-bearing minerals are the ones most
easily attacked by oxygen.
– Examples:
• Magnetite
• Pyrite
• Dark-colored ferromagnesian silicates

26. Agents of Chemical Weathering
• Oxidation of these minerals results in
kinds of rust, or iron oxides.

27. Agents of Chemical Weathering
• Carbon dioxide dissolves easily in water.
– It forms a weak acid called carbonic acid
– This is the same compound that is in
carbonated drinks.
– Attacks many common minerals such as
feldspar, hornblende, augite and biotite mica.
– The original mineral is changed into a clay
mineral.

28. Agents of Chemical Weathering
• Has the greatest effect on calcite than any
other mineral.
• It dissolves it completely, with no clay left
over.

29. Agents of Chemical Weathering
• Hollows out great caverns in limestone
bedrock.

30. Agents of Chemical Weathering
• Acids are formed from the decay of plants
and animals.
• These acids are dissolved by rainwater
and carried through the ground to the
bedrock.

31. Agents of Chemical Weathering
• Carbon dioxide and sulfur compounds
released by industries unite with water in
the atmosphere to form acid rain.
• Increasing amounts of acid rain in the
environment increase the rate of chemical
weathering.

32. Agents of Chemical Weathering

33. Chemical Weathering
• Occurs most quickly at the corners and
edges of rock outcrops and boulders.
• These areas are more exposed to
chemicals.
• This process rounds the rock and is called
spheroidal weathering.
• Boulders rounded this way are called
spheroidal boulders
