This document provides a step-by-step guide for configuring Virtual Server host clustering with Virtual Server 2005 R2. It describes a simple scenario using a two-node cluster with one guest operating system. The scenario establishes dependencies between clustered resources like physical disks and scripts to ensure smooth failover of the guest. Prerequisites include qualified server hardware listed in the Windows Server Catalog and shared storage accessible to both nodes.
The document provides a step-by-step guide for configuring Virtual Server host clustering using Virtual Server 2005 R2 and Windows Server 2003 clustering, describing a simple scenario with two physical servers, one guest operating system, shared storage, and a script to ensure smooth failover of the guest between servers. Virtual Server host clustering allows consolidating servers onto fewer physical hosts while maintaining high availability through automatic failover of virtual machines between nodes if a host fails.
