1. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Trial e CRT:
uno sguardo critico al passato,
un occhio al presente e cosa ci riserva il futuro
Dott. Giuseppe Arena
Direttore U.O.C. UTIC-Cardiologia
USL 1 Massa Carrara
2. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
CRT: nascita ed evoluzione
• Scompenso Cardiaco: patologia cardiovascolare in aumento
tra le più disabilitanti, mortali e costose
3. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
CRT: nascita ed evoluzione
• Scompenso Cardiaco: patologia cardiovascolare in aumento
tra le più disabilitanti, mortali e costose
2%2%
2.7%2.7%
4.9%4.9%
1990
2010
2030
Kelly DT, Circulation 1997
PREVALENZA CRESCENTE
4. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
CRT: nascita ed evoluzione
• Scompenso Cardiaco: patologia cardiovascolare in aumento
tra le più disabilitanti, mortali e costose
2%2%
2.7%2.7%
4.9%4.9%
1990
2010
2030
1. Framingham Heart Study (1948 – 1988) in Atlas of Heart Diseases.
2. American Heart Association. Heart Disease and Stroke Statistics—2003 Update. Dallas, Tex.
100100
9090
8080
7070
6060
5050
4040
3030
2020
1010
00
Probabilityofsurvival,%
Men (n = 237)
Women (n = 230)
Time after CHF diagnosis, years
00 22 44 66 88 1010
80% of men and 70% of
women who have CHF will
die within 8 years.2
80% of men and 70% of
women who have CHF will
die within 8 years.2
5. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Numero di Ricoveri per Scompenso Cardiaco
negli Ospedali Italiani: DRG 127
0,000
40,000
80,000
120,000
160,000
200,000
1996 1997 1998 1999 2000 2001 2002 2003
127.043
190.340
Dati del Ministero della Salute
177.276
+50%+50%
6. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
CRT: nascita ed evoluzione
• Scompenso Cardiaco: patologia cardiovascolare in aumento
tra le più disabilitanti, mortali e costose
• 1 su 3 pazienti con SC: contrazione ventricolare dissincrona
7. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Curry CW, et al.
Mechanical dyssynchrony in dilated cardiomyopathy with intraventricular
conduction delay as depicted by 3D tagged magnetic resonance imaging.
Normal Dilated Cardiomyopathy
Abnormal local
wall motion & strain
8. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
CRT: nascita ed evoluzione
• Scompenso Cardiaco: patologia cardiovascolare tra le più
disabilitanti, mortali e costose
• 1 paziente con HF su 3: contrazione ventricolare dissincrona
• Ottimizzazione della terapia farmacologica: buoni risultati ma
ancora elevato tasso di mortalità e bassa qualità della vita
9. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
CRT: nascita ed evoluzione
• Scompenso Cardiaco: patologia cardiovascolare tra le più disabilitanti, mortali e costose
• 1 paziente con HF su 3: contrazione ventricolare dissincrona
• Ottimizzazione della terapia farmacologica: buoni risultati ma ancora elevato tasso di mortalità e bassa
qualità della vita
Bristow et al N Eng J Med 2004; 350: 2140
10. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
CRT: nascita ed evoluzione
• Scompenso Cardiaco: patologia cardiovascolare tra le più disabilitanti,
mortali e costose
• 1 paziente con HF su 3: contrazione ventricolare dissincrona
• Ottimizzazione della terapia farmacologica: buoni risultati ma ancora
elevato tasso di mortalità e bassa qualità della vita
• 1994: primo impianto di sistema di stimolazione biventricolare
11. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
54 aa. CMPD e CHF refrattario
PR 200 ms
BBS (QRS 200 ms)
Blocco interatriale (90 ms dx-sn)
Four Chamber Pacing in Dilated Cardiomyopathy
S. Cazeau, P. Ritter, S. Bakdach, A. Lazarus, M. Limousin, L. Henao, O. Mundler, J.C. Daubert, J. Mugica
Pace Clin Electrophysiol 1994;17(Pt II):1974-1079c
12. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
CRT: nascita ed evoluzione
• Scompenso Cardiaco: patologia cardiovascolare tra le più disabilitanti,
mortali e costose
• 1 paziente con HF su 3: contrazione ventricolare dissincrona
• Ottimizzazione della terapia farmacologica: buoni risultati ma ancora
elevato tasso di mortalità e bassa qualità della vita
• 1994: primo impianto di sistema di stimolazione biventricolare
• 20 anni dopo: sviluppo tecnologico della CRT, messa a punto e
miglioramento delle linee guida sulla CRT, ampliamento delle indicazioni
CRT in pazienti HF
13. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Domanda:
• Quali possono essere allo stato attuale gli obiettivi nell’ambito
della CRT:
1) aumentare il rate dei pazienti responder alla terapia CRT
2) estendere il trattamento a pazienti che potrebbero
beneficiare della terapia CRT
3) ridurre le possibili controindicazioni alla terapia CRT
4) selezionare con maggiore accuratezza i pazienti candidati
14. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Prevalence of Ventricular
Dyssynchrony in Heart Failure
Left Bundle Branch Block More Prevalent
with Impaired LV Systolic Function
38%
24%
8%
Moderate/Severe
HF (2)
Impaired LVSF
(1)
Preserved LVSF
(1)
1. Masoudi, et al. JACC 2003;41:217-23
2. Aaronson, et al. Circ 1997;95:2660-7
15. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Elements of Cardiac Dyssynchrony
Atrio-
ventricular
Inter-
ventricular
Intra-
ventricular
Cazeau, et al. PACE 2003; 26[Pt. II]: 137–143
16. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Deleterious Effects of Ventricular
Dyssynchrony on Cardiac Function
Reduced diastolic filling time 1
+ Weakened contractility 2
+ Protracted mitral regurgitation 2
+ Post systolic regional contraction 3
= Diminished stroke volume
1. Grines CL, et al Circulation 1989;79: 845-853
2. Xiao HB, et al Br Heart J 1991;66: 443-447
3. Søgaard P, et al. J Am Coll Cardiol 2002;40:723–730
Courtesy of Ole-A. Breithardt, MD
17. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Deleterious Effects of Ventricular
Dyssynchrony on Survival
Long Term--45 Months
34%
49%
QRS <
120 ms
QRS >
120 ms
Iuliano et al. AHJ 2002;143:1085-91
N=669
P < 0.001
Moderate Term--1 Year
11%
16%
QRS <
120 ms
QRS >
120 ms
P < 0.001
Baldasseroni S, et al. Am Heart J 2002;143:398-405
N=5,517
19. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Domanda:
• Quale può essere il marker di dissincronia validato per
qualificare i pazienti candidati alla CRT:
1) Dissincronia meccanica
2) Frazione d’eiezione del ventricolo sinistro
3) Durata QRS
4) Percentuale di stimolazione del ventricolo destro
20. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Domanda:
• Quali possono essere stati i maggiori criteri di inclusione dei
pazienti nei primi trials sulla resincronizzazione cardiaca:
1) Classe NYHA II e III, ritmo sinusale, QRS ≥ 120 ms
2) QRS ≥ 120 ms, LVEF ≤ 25 %
3) Terapia farmacologica ottimizzata, NYHA III e IV, QRS ≥ 120
ms, LVEF ≤ 35%
4) Ritmo sinusale, QRS ≥ 120 ms, terapia farmacologica in atto
21. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Cumulative Enrollment in Cardiac Resynchronization
Randomized Trials
22. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Heart Failure Trial Progression
Symptoms/quality of life
Measures of disease progression
Transvenous system
Pilot
Mortality and morbidity
1996
2005
Mounting evidence
23. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Early Trials
Feasibility and safety
Relief of symptoms
Trials with hard end-points
Mortality
Morbidity
Path-CHF
MUSTIC
MIRACLE
Companion
CARE-HF
Heart Failure Trial Progression
24. Multicenter controlled randomized crossover trial
AIM of the STUDY
Evaluation of CRT compared to best single
chamber pacing (acutely tested) and no pacing
Pacing Therapy for Congestive Heart Failure
25. Acute hemodynamic testing
Randomization 1:1
CRT
Best chronic mode
4 weeks
8 weeks
One year
No CRT
Implant
Best unichamber
Best unichamber
No CRT
CRT12 weeks
PATH-CHF
Study Design
Inclusion Criteria
NYHA III/IV
Sinus Rhythm
QRS width > 120 msec
PR >150 msec
42 pts
randomized
26. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
PATH-CHF
• Primary endpoints
– Peak VO2
– VO2 uptake at anaerobic threshold
– Six-minute walk distance
• Secondary endpoints
– Minnesota Living with Heart Failure score
– NYHA class
– Hospitalization
– Improvement in prognostic and hemodynamic parameters
Endpoints
Aurricchio A, Stellbrink C, Sack S, et al. The pacing therapies for congestive heart failure (PATH-CHF) study: rationale, design, and endpoints of a prospective
randomized multicenter study. Am J Cardiol. 1999;83:130D-135D.
27. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
PATH-CHF
Aurricchio A, Stellbrink C, Sack S, et al. The pacing therapies for congestive heart failure (PATH-CHF) study: rationale, design, and endpoints of a prospective
randomized multicenter study. Am J Cardiol. 1999;83:130D-135D.
28. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
PATH-CHF
Chronic peak VO2
0.5
0.75
1
1.25
1.5
Pre-implant 12 months
PeakVO2(l/min)
0.97+0.26
1.19+0.34
N=14
P=0.019
Improvement
Aurricchio A, Stellbrink C, Sack S, et al. Long-term benefit as a result of pacing resynchronization in congestive heart failure: results of the Path-CHF trial.
Circulation. 2000;102(suppl II):II-693. Abstract 3352.
29. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
PATH-CHF
Chronic VO2 AT
0.5
0.75
1
Pre-implant 12 months
VO2AT(l/min)
0.76+0.21
0.91+0.31
N=18
P=0.018
Improvement
Aurricchio A, Stellbrink C, Sack S, et al. Long-term benefit as a result of pacing resynchronization in congestive heart failure: results of the Path-CHF trial.
Circulation. 2000;102(suppl II):II-693. Abstract 3352.
30. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
PATH-CHF
Chronic six-minute walk distances
300
350
400
450
500
Pre-implant 12 months
six-minutewalk(m)
357+101
446+74
N=25
P<0.001
Improvement
Aurricchio A, Stellbrink C, Sack S, et al. Long-term benefit as a result of pacing resynchronization in congestive heart failure: results of the Path-CHF trial.
Circulation. 2000;102(suppl II):II-693. Abstract 3352.
31. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
PATH-CHF
Chronic NYHA
1
2
3
4
Pre-implant 12 months
NYHAfunctionalclass
3.05+0.16
1.90+0.76
N=29
P<0.001
Improvement
Aurricchio A, Stellbrink C, Sack S, et al. Long-term benefit as a result of pacing resynchronization in congestive heart failure: results of the Path-CHF trial.
Circulation. 2000;102(suppl II):II-693. Abstract 3352.
32. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
PATH-CHF
Chronic quality of life
10
20
30
40
50
60
Pre-implant 12 months
Qualityoflife(points)
49+23
20+22
N=28
P<0.001
Improvement
Aurricchio A, Stellbrink C, Sack S, et al. Long-term benefit as a result of pacing resynchronization in congestive heart failure: results of the Path-CHF trial.
Circulation. 2000;102(suppl II):II-693. Abstract 3352.
33. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
PATH-CHF
Aurricchio A, Stellbrink C, Sack S, et al. Long-term benefit as a result of pacing resynchronization in congestive heart failure: results of the Path-CHF trial.
Circulation. 2000;102(suppl II):II-693. Abstract 3352.
P=0.003
34. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
MUSTIC
• 137 patients across 17 centers in Europe
• Designed to evaluate the safety and clinical
efficacy of multi-site biventricular pacing in
patients with severe CHF, chronic LV
dysfunction and a wide QRS complex
• Resulted in improvement in exercise tolerance
and decrease in hospitalization rates during
biventricular phase
Cazeau S, Leclercq C, Lavergne T, et al. Effects of multisite biventricular pacing in patients with heart failure and intraventricular conduction Delay. N
Engl J Med. 2001;344:12:873-80.
Multi-Site Stimulation in Cardiomyopathy
35. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
MUSTIC
1 year follow-up
1 month
2 weeks
3 months
3 months CRT on
CRT off
CRT off
CRT on
Implant success
Randomization
NYHA class III-IV
LVEDD > 60 mm
QRS > 150 ms
Six-minute walk < 450 meters
EF < 35%
36. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Six-minute walk distances
MUSTIC
Cazeau S, Leclercq C, Lavergne T, et al. Effects of multisite biventricular pacing in patients with heart failure and intraventricular conduction delay. N
Engl J Med. 2001;344:12:873-80.
• During the active phase (pacing turned on), the mean
distance walked in six minutes was 23% longer
(P < 0.001) than during the inactive phase
37. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Quality of life scores
MUSTIC
Cazeau S, Leclercq C, Lavergne T, et al. Effects of multisite biventricular pacing in patients with heart failure and intraventricular conduction delay. N
Engl J Med. 2001;344:12:873-80.
• Minnesota Living with Heart Failure scores decreased by
a mean of 32% (P < 0.001) with active pacing (pacing is
on)
38. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
MUSTIC
Cazeau S, Leclercq C, Lavergne T, et al. Effects of multisite biventricular pacing in patients with heart failure and intraventricular conduction delay. N
Engl J Med. 2001;344:12:873-80.
6 min walking test + 23% p=0.0001
Peak VO2 +8% p=0.015
QoL Minnesota - 30% p=0.0002
Reduced Hospitalization
Patient’s preference
CRT 86%
no pacing 4% p=0.001
no preference 10%
6 months mortality 5%
39. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Domanda:
• Quale maggiore aspetto critico presentavano i primi studi?
1) Periodo di follow-up breve
2) Disomogeneità della popolazione in esame
3) Terapia farmacologica non ottimizzata
4) Sottodimensionamento della popolazione
40. William T. Abraham, M.D., Westby G. Fisher, M.D., Andrew L. Smith, M.D.,William T. Abraham, M.D., Westby G. Fisher, M.D., Andrew L. Smith, M.D.,
David B. Delurgio, M.D., Angel R. Leon, M.D., Evan Loh, M.D., Dusan Z.David B. Delurgio, M.D., Angel R. Leon, M.D., Evan Loh, M.D., Dusan Z.
Kocovic, M.D., Milton Packer, M.D., Alfredo L. Clavell, M.D., David L.Kocovic, M.D., Milton Packer, M.D., Alfredo L. Clavell, M.D., David L.
Hayes, M.D., Myrvin Ellestad, M.D., and John Messenger, M.D., for theHayes, M.D., Myrvin Ellestad, M.D., and John Messenger, M.D., for the
MIRACLE Study GroupMIRACLE Study Group
N Engl J MedN Engl J Med 2002;346:1845-18532002;346:1845-1853
MIRACLE Trial ResultsMIRACLE Trial Results
Cardiac ResynchronizationCardiac Resynchronization
in Chronic Heart Failurein Chronic Heart Failure
41. • Moderate or severe heart failureModerate or severe heart failure
– NYHA Functional Class III or IVNYHA Functional Class III or IV
• QRS durationQRS duration ≥≥ 130 msec130 msec
• LVEFLVEF ≤≤ 35%35%
• LVEDDLVEDD ≥≥ 55 millimeters (echo measure)55 millimeters (echo measure)
• 6 minute walk distance6 minute walk distance ≤≤ 450 meters450 meters
• Stable optimal HF medical regimenStable optimal HF medical regimen
forfor ≥≥ 1 month1 month
– ACE-I or ARB, if toleratedACE-I or ARB, if tolerated
– β-blocker - stable regimenβ-blocker - stable regimen
forfor ≥≥ 3 months3 months
Abraham WT, Fisher WG, Smith AL, et al.Abraham WT, Fisher WG, Smith AL, et al. N Engl J MedN Engl J Med 2002;346:1845-18532002;346:1845-1853
Study PopulationStudy Population
42. Study EndpointsStudy Endpoints
• Primary Efficacy:Primary Efficacy:
– NYHA Functional ClassNYHA Functional Class
– Quality of life (Minnesota Living with Heart Failure)Quality of life (Minnesota Living with Heart Failure)
– 6-minute Walk Distance6-minute Walk Distance
• Secondary Efficacy Included:Secondary Efficacy Included:
– Peak VOPeak VO22, Exercise Time, LVEF, LVEDD, MR, QRS, Exercise Time, LVEF, LVEDD, MR, QRS
Duration, Clinical Composite ResponseDuration, Clinical Composite Response
• Other Protocol Specified Endpoints:Other Protocol Specified Endpoints:
– Death or Worsening Heart FailureDeath or Worsening Heart Failure (Safety)(Safety)
– # Days Spent in Hospital# Days Spent in Hospital (Health Care Utilization)(Health Care Utilization)
Abraham WT, Fisher WG, Smith AL, et al.Abraham WT, Fisher WG, Smith AL, et al. N Engl J MedN Engl J Med 2002;346:1845-18532002;346:1845-1853
44. Completed 6-MonthCompleted 6-Month
Follow-upFollow-up
(n = 201)(n = 201)
Completed 6-MonthCompleted 6-Month
Follow-upFollow-up
(n = 215)(n = 215)
1616 DeathDeath 1212
22 Heart transplantHeart transplant 00
11 Infection/explantInfection/explant 11
55 Missed 6M FUMissed 6M FU 00
ControlControl
(n = 225)(n = 225)
CRTCRT
(n = 228)(n = 228)
RandomizedRandomized
6-Month Protocol6-Month Protocol
(n = 453)(n = 453)
Abraham WT, Fisher WG, Smith AL, et al.Abraham WT, Fisher WG, Smith AL, et al. N Engl J MedN Engl J Med 2002;346:1845-18532002;346:1845-1853
Enrollment and Follow-upEnrollment and Follow-up
45. CRT Improves Submaximal ExerciseCRT Improves Submaximal Exercise
Distance Walked in 6 MinutesDistance Walked in 6 Minutes
Change from Baseline*Change from Baseline*
00
1010
2020
3030
4040
5050
6060
00 33 66
Follow-up Period (Month)Follow-up Period (Month)
MetersMeters
11
* Paired median change* Paired median change
Error bars are 95% CI.Error bars are 95% CI.
P=0.004P=0.004
P=0.003P=0.003
P=0.005P=0.005
Baseline (meters)Baseline (meters)
291 ± 101
305 ± 85
Abraham WT, Fisher WG, Smith AL, et al.Abraham WT, Fisher WG, Smith AL, et al. N Engl J MedN Engl J Med 2002;346:1845-18532002;346:1845-1853
CRTCRT
ControlControl
46. CRT Improves Patients’ Quality of LifeCRT Improves Patients’ Quality of Life
Minnesota Living with Heart Failure QuestionnaireMinnesota Living with Heart Failure Questionnaire
Baseline (score)Baseline (score)
59 ± 21
59 ± 20
Abraham WT, Fisher WG, Smith AL, et al.Abraham WT, Fisher WG, Smith AL, et al. N Engl J MedN Engl J Med 2002;346:1845-18532002;346:1845-1853
* Paired median change* Paired median change
Error bars are 95% CI.Error bars are 95% CI.
Change from Baseline*Change from Baseline*
00
55
1010
1515
2020
2525
00 33 66
Follow-up Period (Month)Follow-up Period (Month)
ScoreImprovement(points)ScoreImprovement(points)
11
P=0.001P=0.001
P<0.001P<0.001
P<0.001P<0.001
CRTCRT
ControlControl
47. CRT Improves NYHA Functional ClassCRT Improves NYHA Functional Class
00
2020
4040
6060
8080
100100
120120
NumberofPatientsNumberofPatients
Improved 2 orImproved 2 or
more classesmore classes
Improved 1Improved 1
classclass
No ChangeNo Change WorsenedWorsened
ControlControl CRTCRT
6%6%
32%32%
59%59%
4%4%
16%16%
52%52%
30%30%
2%2%
P<0.001P<0.001
Abraham WT, Fisher WG, Smith AL, et al.Abraham WT, Fisher WG, Smith AL, et al. N Engl J MedN Engl J Med 2002;346:1845-18532002;346:1845-1853
48. Secondary Efficacy ResultsSecondary Efficacy Results
Abraham WT, Fisher WG, Smith AL, et al.Abraham WT, Fisher WG, Smith AL, et al. N Engl J MedN Engl J Med 2002;346:1845-18532002;346:1845-1853
49. Paired median change at 6 months from baseline.Paired median change at 6 months from baseline.
Error bars are 95% CI.Error bars are 95% CI.
Improvement in Peak VOImprovement in Peak VO22
-0.5-0.5
0.00.0
0.50.5
1.01.0
1.51.5
2.02.0
ControlControl
(n=145)(n=145)
CRTCRT
(n=158)(n=158)
ml/kg/minml/kg/min
P=0.009P=0.009
Improvement inImprovement in
Total Exercise TimeTotal Exercise Time
00
3030
6060
9090
120120
ControlControl
(n=146)(n=146)
CRTCRT
(n=159)(n=159)
secondsseconds
P=0.001P=0.001
BaselineBaseline
(ml/kg/min)(ml/kg/min)
13.7 ± 3.8
14.0 ± 3.5
BaselineBaseline
(secondsseconds)
462 ± 217
484 ± 209
Abraham WT, Fisher WG, Smith AL, et al.Abraham WT, Fisher WG, Smith AL, et al. N Engl J MedN Engl J Med 2002;346:1845-18532002;346:1845-1853
CRT Improves Metabolic ExerciseCRT Improves Metabolic Exercise
50. Change in MR Jet AreaChange in MR Jet Area
-4-4
-3-3
-2-2
-1-1
00
11
ControlControl
(n=118)(n=118)
CRTCRT
(n=116)(n=116)
cmcm22
P<0.001P<0.001 P=0.009P=0.009
Change in LVEDDChange in LVEDD
-6-6
-4-4
-2-2
00
22
ControlControl
(n=118)(n=118)
CRTCRT
(n=116)(n=116)
mmmm
P<0.001P<0.001
Absolute Change in LVEFAbsolute Change in LVEF
-2-2
00
22
44
66
88
ControlControl
(n=146)(n=146)
CRTCRT
(n=155)(n=155)
%%
Baseline (mm)Baseline (mm)
69 ± 10
70 ± 10
Baseline (cmBaseline (cm2
)
7.2 ± 4.9
7.6 ± 6.4
Baseline (%)Baseline (%)
22 ± 6
22 ± 6
Paired median change from baseline at 6 months. Error bars are 95% CI.Paired median change from baseline at 6 months. Error bars are 95% CI.
Abraham WT, Fisher WG, Smith AL, et al.Abraham WT, Fisher WG, Smith AL, et al. N Engl J MedN Engl J Med 2002;346:1845-18532002;346:1845-1853
CRT Improves Cardiac Function and StructureCRT Improves Cardiac Function and Structure
51. Abraham WT, Fisher WG, Smith AL, et al.Abraham WT, Fisher WG, Smith AL, et al. N Engl J MedN Engl J Med 2002;346:1845-18532002;346:1845-1853
Effect of CRT on Composite ResponseEffect of CRT on Composite Response
39%39%
34%34%
27%27%
67%67%
17%17% 16%16%
0%0%
20%20%
40%40%
60%60%
ImprovedImproved No ChangeNo Change WorsenedWorsened
ProportionProportion
Control N=225Control N=225 CRT N=228CRT N=228
P < 0.001P < 0.001
Chi-square test
52. Safety and Health Care UtilizationSafety and Health Care Utilization
EndpointsEndpoints
Abraham WT, Fisher WG, Smith AL, et al.Abraham WT, Fisher WG, Smith AL, et al. N Engl J MedN Engl J Med 2002;346:1845-18532002;346:1845-1853
53. HF IV medHF IV med
HF hospitalizationHF hospitalization
Death/HF hosp/HF IVDeath/HF hosp/HF IV
Death/HF hospitaliz.Death/HF hospitaliz.
Death—all causeDeath—all cause
00 11 22
Relative RiskRelative Risk
0.50.5 1.51.5
Favors CRTFavors CRT Favors ControlFavors Control
P=0.40P=0.40
P=0.03P=0.03
P=0.02P=0.02
P=0.02P=0.02
P<0.01P<0.01
Abraham WT, Fisher WG, Smith AL, et al.Abraham WT, Fisher WG, Smith AL, et al. N Engl J MedN Engl J Med 2002;346:1845-18532002;346:1845-1853
CRT (n=228)CRT (n=228)
Control (n=225)Control (n=225)
Adverse Clinical EventsAdverse Clinical Events
During Double-blind PeriodDuring Double-blind Period
54. 83
363
↓↓ 77%77%
ControlControl
n=34n=34
CRTCRT
n=18n=18
Abraham WT, Fisher WG, Smith AL, et al.Abraham WT, Fisher WG, Smith AL, et al. N Engl J MedN Engl J Med 2002;346:1845-18532002;346:1845-1853
Adverse Clinical EventsAdverse Clinical Events
Total Days Hospitalized for Heart FailureTotal Days Hospitalized for Heart Failure
55. – is safe and well toleratedis safe and well tolerated
– improves quality of life, functional class, andimproves quality of life, functional class, and
exercise capacityexercise capacity
– Improves cardiac function and structureImproves cardiac function and structure
– improves heart failure composite responseimproves heart failure composite response
– may have a favorable effect on combinedmay have a favorable effect on combined
measures of morbidity and mortalitymeasures of morbidity and mortality
In NYHA Class III and IV systolic heart failureIn NYHA Class III and IV systolic heart failure
patients with intraventricular conduction delays,patients with intraventricular conduction delays,
cardiac resynchronization therapy:cardiac resynchronization therapy:
Abraham WT, Fisher WG, Smith AL, et al.Abraham WT, Fisher WG, Smith AL, et al. N Engl J MedN Engl J Med 2002;346:1845-18532002;346:1845-1853
ConclusionsConclusions
56. ControlControl 225225 214214 204204 197197 191191 179179 7070
CRTCRT 228228 218218 213213 209209 204204 201201 9999
Patients At RiskPatients At Risk
70%70%
75%75%
80%80%
85%85%
90%90%
95%95%
100%100%
00 11 22 33 44 55 66
Months After RandomizationMonths After Randomization
EventFreeSurvival(%)EventFreeSurvival(%)
CRTCRT
ControlControl
P = 0.033P = 0.033
Relative risk = 0.60;Relative risk = 0.60;
95% CI (0.37, 0.96)95% CI (0.37, 0.96)
Abraham WT, Fisher WG, Smith AL, et al.Abraham WT, Fisher WG, Smith AL, et al. N Engl J MedN Engl J Med 2002;346:1845-18532002;346:1845-1853
Time to Death or Worsening Heart FailureTime to Death or Worsening Heart Failure
Requiring HospitalizationRequiring Hospitalization
57. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
• Parallel, randomized
• OPT
1
• OPT
• CRT
+
2
• OPT
• CRT-D
+
2
Randomization
Study design
COMPANION
(COmparison of Medical Therapy, Pacing, ANd DefibrillatION
in Heart Failure)
N°pts planned: 2200
N°pts enrolled: 1520
58. 542-12-#65
COMPANION: Endpoints (1)COMPANION: Endpoints (1)
• Primary Endpoint
– Composite of time to first all-cause mortality
or all-cause hospitalization analyzed from
randomized
• Hospital emergency or outpatient (unscheduled
administration of IV inotropes or vasoactive drugs
for more than 4 hours were considered a
hospitalization primary endpoint)
HFSA Late-Breaker Sept 24, 2003
62. 542-12-#69
COMPANION: ConclusionsCOMPANION: Conclusions
When added to optimal pharmacological
therapy in patients with moderate-severe LV
dysfunction, NYHA Class III or IV symptoms
and QRS lengthening
• CRT or CRT-D reduces mortality + hospitalization
• CRT-D reduces mortality
– 2/3 of the effect size can be attributed to CRT
HFSA Late-Breaker Sept 24, 2003
63. The CARE-HF Study
CArdiac REsynchronisation in Heart Failure
John GF Cleland - Kingston-upon-Hull. UK
Jean-Claude Daubert – Rennes. France
Erland Erdmann – Cologne. Germany
Nick Freemantle – Birmingham. UK
Daniel Gras – Nantes. France
Lukas Kappenberger – Lausanne. Switzerland
Werner Klein – Graz. Austria
Luigi Tavazzi – Pavia. Italy
on behalf of the CARE-HF Study Investigators
64. Main Inclusion & Exclusion Criteria
• Heart failure for at least 6 weeks requiring loop diuretics
• Currently in NYHA class III/IV
• A high standard of pharmacological therapy
• LV systolic dysfunction and dilation
– EF ≤35%; EDD ≥30mm/height in metres
• QRS ≥120 ms
– Dyssynchrony confirmed by echo if QRS 120-149 ms
• Aortic pre-ejection delay >140ms
• Interventricular mechanical delay >40 ms
• Delayed activation of postero-lateral LV wall
• Patients with AF or requiring pacing excluded
N° pts enrolled: 813
65. Primary & Principal Secondary Endpoints
Primary composite endpoint
• All-cause mortality or unplanned hosp. for a major
CVS event (time to first event analysis)
– Hospitalisations adjudicated by a blinded EP committee
Principal secondary endpoint
• All-cause mortality
66. Primary Endpoint
(All-cause Mortality or Unplanned Hosp. for Major CVS Event)
348118232292404Medical Therapy
768166273323409CRT
Number at risk
0 500 1000 1500
0.00
0.25
0.50
0.75
1.00
Event-freeSurvival
Days
Medical
Therapy
67. Primary Endpoint
(All-cause Mortality or Unplanned Hosp. for Major CVS Event)
348118232292404Medical Therapy
768166273323409CRT
Number at risk
0 500 1000 1500
0.00
0.25
0.50
0.75
1.00
HR 0.63 (95% CI 0.51 to 0.77)
Event-freeSurvival
Days
P < .0001
CRT
Medical
Therapy
68. Primary Endpoint
(All-cause Mortality or Unplanned Hosp. for Major CVS Event)
348118232292404Medical Therapy
768166273323409CRT
Number at risk
0 500 1000 1500
0.00
0.25
0.50
0.75
1.00
HR 0.63 (95% CI 0.51 to 0.77)
Event-freeSurvival
Days
P < .0001
CRT
Medical
TherapyNo statistical significant
heterogeneity in subgroups
76. REsynchronization reVErses Remodeling in
Systolic left vEntricular dysfunction:
Results of the REVERSE Trial
Cecilia Linde, Stockholm, Sweden
William T. Abraham, Columbus, U.S
Michael R. Gold, Charleston, U.S.
Jean-Claude Daubert, Rennes, France
On Behalf of the REVERSE
Investigators and Coordinators
77. • To determine the effects of CRT with or
without an ICD on disease progression over
12 months in patients with asymptomatic and
mildly symptomatic heart failure and
ventricular dysynchrony
• Randomized, double-blind, parallel-controlled
clinical trial
Purpose and DesignPurpose and Design
78. • NYHA Class II or I (previously
symptomatic)
• QRS ≥ 120 ms; LVEF ≤ 40%;
LVEDD ≥ 55 mm
• Optimal medical therapy (OMT)
• Without permanent cardiac pacing
• With or without an ICD indication
Inclusion CriteriaInclusion Criteria
79. Baseline Assessment
Successful
CRT Implant
Randomized 1:2
CRT OFF
(OMT ± ICD)
CRT ON
(OMT ± ICD)
U.S., Canada: at 12 Months, all patients recommended CRT ON
Europe: at 24 Months, all patients recommended CRT ON
1
2
12 Months
Study SchematicStudy Schematic
80. • Primary: HF Clinical Composite Response,
comparing the proportion of patients worsened
in CRT OFF vs. CRT ON groups
• Composite includes: all-cause mortality, HF hospitalizations,
crossover due to worsening HF, NYHA class, and the patient
global assessment assessed in double blind manner
• Prospectively Powered Secondary: Left
Ventricular End Systolic Volume Index (LVESVi)
comparing CRT OFF vs. CRT ON subjects
• LVESVi is assessed by two core labs (1 in Europe, 1 in U.S)
End PointsEnd Points
81. 684 Enrolled (2004-2006)
642 Implant Attempts
610 Patients Randomized
U.S. 343 (56%); Europe 262 (43%); Canada 5 (<1%)
CRT OFF 191 Patients CRT ON 419 Patients
- 594/598 completed 12 month follow-up
- 12 deaths (2%)
- 0 lost to follow-up, 0 exits
-21 unsuccessful implant
621 Successful CRT Implants
(97%)
-42 ineligible or withdrew
-11 exits after successful implant
Enrollment and RandomizationEnrollment and Randomization
82. 40%
54%
39%
30%
16%21%
0%
20%
40%
60%
80%
100%
CRT
OFF
CRT ON
Improved /
Unchanged
Pre-Specified Analysis
Proportion Worsened
Conventional Analysis
Distribution Worsened/Unchanged
/Improved
Worsened
Unchanged
Improved
P=0.004
Primary End Point:Primary End Point:
Clinical Composite ResponseClinical Composite Response
79% 84%
16%21%
0%
20%
40%
60%
80%
100%
CRT OFF CRT ON
P=0.10
Worsened
85. 360
370
380
390
400
410
420
430
440
Baseline 12 Mo
CRT OFF
∆=18.7
CRT ON
∆=12.7
15
17
19
21
23
25
27
29
31
33
35
Baseline 12 Mo
CRT OFF
∆=-6.7
CRT ON
∆=-8.4
MN LWHF
P=0.26
6-Min Walk Test
P=0.26
NYHA
P=0.06
Other Secondary EndpointsOther Secondary Endpoints
32%
65%
57%
13% 11%
22%
0%
20%
40%
60%
80%
100%
CRT OFF CRT ON
Improved
Same
Worse
86. 0%
5%
10%
15%
0 3 6 9 12
%ofPatientsHo
Number at Risk
CRT OFF 191 187 181 176 119
CRT ON 419 415 411 409 251
P=0.03 Hazard Ratio=0.47
CRT OFF
CRT ON
Months Since Randomization
Time to First HF HospitalizationTime to First HF Hospitalization
87. REVERSE is the first large, randomized, double-blind study
to show that CRT in asymptomatic and mildly symptomatic
heart failure patients on optimal medical therapy:
• Reverses LV remodeling
• Reduces the risk of heart failure hospitalization
• May improve clinical outcome as assessed by the
clinical composite response measure
Note: FDA has not yet reviewed the clinical data to determine whether or not CRT
systems are safe and effective in this patient population.
ConclusionConclusion
88. MADIT-CRTMADIT-CRTEntry Criteria:Entry Criteria:
Ischemic NYHA I-IIIschemic NYHA I-II
or non-ischemic NYHA class IIor non-ischemic NYHA class II
EFEF ≤≤0.300.30
QRSQRS >>130 msec130 msec
Sinus RhythmSinus Rhythm
Optimal pharmacologic therapy:Optimal pharmacologic therapy:
B-b (>3 mo.); ACE/ARB (>1 mo.);B-b (>3 mo.); ACE/ARB (>1 mo.);
statins in IHDstatins in IHD
Exclusions:Exclusions:
NYHA III-IV <90 days PTENYHA III-IV <90 days PTE
Acute MI, CABG, PCI <3 monthsAcute MI, CABG, PCI <3 months
Existing ICD or CRT deviceExisting ICD or CRT device
AF; PRAF; PR>>250ms; 2250ms; 2ndnd
or 3or 3rdrd
degreedegree
HBHB
BUN >70mg/dl or creatinineBUN >70mg/dl or creatinine
>3.0mg/dl>3.0mg/dl
RandomizationRandomization
N=1,820N=1,820
CRT-DCRT-D
N=1,089N=1,089
ICM NYHA I/II and NICM NYHA IIICM NYHA I/II and NICM NYHA II
EFEF << 0.300.30
QRSQRS >>0.13sec0.13sec
ICD onlyICD only
N=731N=731
89. Kaplan-Meier Estimates of the Probability of
Survival Free of Heart Failure
Moss AJ et al. N Engl J Med 2009;361:1329-1338
90. HRHR (95% CI)(95% CI) PP
ValueValue
Heart failure or DeathHeart failure or Death 0.660.66 (0.52–0.84)(0.52–0.84) 0.0010.001
Heart failure onlyHeart failure only 0.590.59 (0.47–0.74)(0.47–0.74) <0.001<0.001
Death at any timeDeath at any time 1.001.00 (0.69–1.44)(0.69–1.44) 0.990.99
Hazard Ratio for CRT-D vs. ICD only in MADIT-Hazard Ratio for CRT-D vs. ICD only in MADIT-
CRTCRT
91. Changes in Mean Echocardiographic Left Ventricular
Volumes and Ejection Fraction between Baseline and 1-Year
Follow-up
Moss AJ et al. N Engl J Med 2009;361:1329-1338
92. Effects of CRT-D by QRSEffects of CRT-D by QRS
Morphology in MADIT-CRTMorphology in MADIT-CRT
LBBB;
1281; 70%
RBBB; 228;
13%
IVCD; 306;
17%
Non-Non-
LBBBLBBB
534, 30%534, 30%
93. Cumulative Probability ofCumulative Probability of Heart Failure (HF) Event or DeathHeart Failure (HF) Event or Death
by Treatment (CRT-D vs. ICD only) in patients with LBBB andby Treatment (CRT-D vs. ICD only) in patients with LBBB and
Non-LBBB QRS Pattern in MADIT-CRT PatientsNon-LBBB QRS Pattern in MADIT-CRT Patients
LBBBLBBB Non-LBBBNon-LBBB
94. RBBBRBBB IVCDIVCD
Cumulative Probability ofCumulative Probability of Heart Failure (HF) Event or DeathHeart Failure (HF) Event or Death
by Treatment (CRT-D vs. ICD only) in patients with RBBB andby Treatment (CRT-D vs. ICD only) in patients with RBBB and
IVCD QRS Pattern in MADIT-CRT PatientsIVCD QRS Pattern in MADIT-CRT Patients
95. LBBBLBBB Non-LBBBNon-LBBB
Cumulative Probability ofCumulative Probability of DeathDeath by Treatment (CRT-D vs. ICDby Treatment (CRT-D vs. ICD
only) in patients with LBBB and Non-LBBB QRS Patternonly) in patients with LBBB and Non-LBBB QRS Pattern
in MADIT-CRT Patientsin MADIT-CRT Patients
96. Endpoint LBBB
n=1,281
Non-
LBBB
n=536
P value
for Inter-
action
Heart Failure Event HR 0.47 1.24
or Death 95% CI 0.37,0.61 0.85,1.81
P value <0.001 0.257 <0.001
Heart Failure Event HR 0.41 1.23
95% CI 0.31,0.54 0.76,1.68
P value <0.001 0.559 <0.001
Death HR 0.75 1.79
95% CI 0.49,1.16 0.90,3.57
P value 0.196 0.097 0.037
Hazard Ratios for Clinical Endpoints by QRS MorphologyHazard Ratios for Clinical Endpoints by QRS Morphology
* The model adjusted for sex, ischemic or nonischemic cardiomyopathy, prior* The model adjusted for sex, ischemic or nonischemic cardiomyopathy, prior
hospitalizations for heart failure, ejection fraction, QRS>150, left ventricularhospitalizations for heart failure, ejection fraction, QRS>150, left ventricular
ejection fraction, left ventricular end-systolic volume.ejection fraction, left ventricular end-systolic volume.
97. Endpoint LBBB
n=1,281
Non-
LBBB
n=536
P value
for Inter-
action
VT/VF HR 0.67 1.11
95% CI 0.52,0.87 0.77,1.60
P value 0.002 0.574 0.028
VF HR 0.54 1.24
95% CI 0.33,0.87 0.58,2.66
P value 0.011 0.585 0.070
VT/VF/Death HR 0.69 1.21
95% CI 0.55,0.87 0.87,1.69
P value 0.002 0.254 0.006
Hazard Ratios for Clinical Endpoints by QRS MorphologyHazard Ratios for Clinical Endpoints by QRS Morphology
* The model adjusted for sex, ischemic or nonischemic cardiomyopathy, prior* The model adjusted for sex, ischemic or nonischemic cardiomyopathy, prior
hospitalizations for heart failure, ejection fraction, QRS>150, left ventricularhospitalizations for heart failure, ejection fraction, QRS>150, left ventricular
ejection fraction, left ventricular end-systolic volume.ejection fraction, left ventricular end-systolic volume.
98. 0,0
0,5
1,0
1,5
2,0
2,5
HF or Death HF Death VT/VF/Death VF/Death
LBBB
Non-LBBB
RBBB
IVCD
Hazard Ratios for Primary and Secondary EndpointsHazard Ratios for Primary and Secondary Endpoints
by QRS Morphology in MADIT-CRTby QRS Morphology in MADIT-CRT
**p<0.05p<0.05
****
****
99. Hazard Ratios for Primary Endpoint by QRS Morphology andHazard Ratios for Primary Endpoint by QRS Morphology and
Duration by GenderDuration by Gender
MalesMales FemalesFemales
nn HRHR P valueP value nn HRHR P valueP value
QRS DurationQRS Duration
<140 ms<140 ms 240240 1.691.69 0.0630.063 6161 0.200.20 0.0080.008
140-159 ms140-159 ms 465465 0.770.77 0.1640.164 178178 0.310.31 0.0010.001
160-179 ms160-179 ms 417417 0.510.51 0.0030.003 153153 0.420.42 0.0360.036
≥≥180 ms180 ms 242242 0.500.50 0.0190.019 6161 0.330.33 0.1000.100
QRS MorphologyQRS Morphology
LBBB*LBBB* 887887 0.560.56 <0.001<0.001 394394 0.250.25 <0.001<0.001
Non-LBBBNon-LBBB 477477 1.251.25 0.2730.273 5959 1.551.55 0.5160.516
RBBBRBBB 210210 0.940.94 0.8410.841 1818 NANA
IVCDIVCD 267267 1.491.49 0.1330.133 4141 1.311.31 0.7010.701
* p=0.006 for interaction comparing HR = 0.56 in males vs. HR = 0.25 in females* p=0.006 for interaction comparing HR = 0.56 in males vs. HR = 0.25 in females
100.
101.
102. -23
-35
12
-16
-26
9
-40
-30
-20
-10
0
10
20
LVEDV LVESV EF
LBBB
Non-LBBB
Mean Change in EchocardiographicMean Change in Echocardiographic
Parameters from Enrollment to 12 months inParameters from Enrollment to 12 months in
CRT-D PatientsCRT-D Patients
**
**
**
* p<0.001 when comparing* p<0.001 when comparing
LBBB and Non-LBBBLBBB and Non-LBBB
patientspatients
(all changes within(all changes within
subgroups were significant)subgroups were significant)
103. MADIT-CRT ConclusionsMADIT-CRT Conclusions
1.1. Heart failure patients with NYHA class I or II andHeart failure patients with NYHA class I or II and
ejection fractionejection fraction ≤30% who present with LBBB≤30% who present with LBBB
derive substantial benefit from CRT-D: reductionderive substantial benefit from CRT-D: reduction
in heart failure progression and reduction in thein heart failure progression and reduction in the
risk of ventricular tachyarrhythmias.risk of ventricular tachyarrhythmias.
2.2. No evidence of CRT-D benefit was observed inNo evidence of CRT-D benefit was observed in
patients with Non-LBBB QRS pattern: RBBB orpatients with Non-LBBB QRS pattern: RBBB or
IVCD regardless of their QRS duration.IVCD regardless of their QRS duration.
3.3. Beneficial effect of CRT-D in LBBB patients wasBeneficial effect of CRT-D in LBBB patients was
observed in all studied subjects: males andobserved in all studied subjects: males and
females, ischemic and non-ischemic, QRS>150 andfemales, ischemic and non-ischemic, QRS>150 and
QRS<150 ms.QRS<150 ms.
104. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Indicazioni CRT
• Linee guida ESC CRT (2010)
Dickstein K. et al., 2010 Focused Update of ESC Guidelines on device therapy
in heart failure. Eur Heart J. 2010; 31, 2677–2687
COMPANION
CARE-HF
MADIT CRT
105. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Indicazioni CRT
• Linee guida ESC CRT
(update 2013)
Brignole M. et al., 2013 ESC Guidelines on cardiac pacing and cardiac resynchronization therapy.
Eur Heart J. 2013; 34, 2281–2329
106. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Indicazioni CRT
• Linee guida ESC CRT
(update 2015)
Priori S. et al., 2015 2015 ESC Guidelines for the management of patients with ventricular arrhythmias and the prevention of sudden cardiac death Eur Heart J. 2015
107. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Domanda
•Quale importante trial clinico sulla CRT ha permesso di
identificare meglio i pazienti candidati e dal quale è nata la
necessità di un aggiornamento delle linee guida?
1.CARE-HF
2.COMPANION
3.MADIT-CRT
4.RAFT
108. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
QUESTIONI APERTE
• Pazienti con classe NYHA II
• CRT-P vs CRT-D
109. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
CRT-P vs. CRT-D
• Argomento ancora molto dibattuto
• EF compromessa → CRT + ICD
• Scelta guidata spesso da fattori geografici,
economici, ...
• Superiorità del CRT-D vs. CRT-P
– non sempre dimostrata
– con differenze nei risultati non sempre statisticamente
significative
– periodi di follow-up brevi
Exner D. et al., Contemporary and future trends in cardiac resynchronization therapy to enhance response. Heart Rhythm, Vol 9, No 8S, August Supplement 2012
110. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
CRT-P vs. CRT-D
Considerazioni:
1.Recupero della EF > 35% dopo 6-12 mesi di CRT
2.Maggiori rischi device-related per la CRT-D (longevità inferiore,
complicanze leads) e costi
3.Rischio di shock inappropriati: 13 ÷ 17% pz. (MADIT II, SCD-
HeFT)
4.Possibilità di considerare il downgrade da CRT-D a CRT-P in
pazienti con EF normalizzata (> 50%)
Exner D. et al., Contemporary and future trends in cardiac resynchronization therapy to enhance response. Heart Rhythm, Vol 9, No 8S, August Supplement 2012
111. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
CRT-P vs. CRT-D
Martin H. Ruwald MH, Solomon SD, Foster E, et al. Left Ventricular Ejection Fraction
Normalization in Cardiac Resynchronization Therapy and Risk of Ventricular Arrhythmias and
Clinical Outcomes: Results from the MADIT-CRT Trial. Circ, 2014
112. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
QUESTIONI APERTE
• Pazienti con classe NYHA II
• CRT-P vs CRT-D
• Percentuali Responders
113. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
CRT Responder
Brignole M. et al., 2013 ESC Guidelines on cardiac pacing and cardiac resynchronization therapy. Eur Heart J. 2013; 34, 2281–2329
114. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
CRT Responder
Exner D. et al., Contemporary and future trends in cardiac resynchronization therapy to enhance response. Heart Rhythm, Vol 9, No 8S, August Supplement 2012
Barsheshet A, Goldenberg I, Moss AJ, et al. Response to preventive cardiac resynchronization therapy in patients with ischaemic and nonischaemic cardiomyopathy in MADIT-CRT. Eur
Heart J 2011;32:1622–1630.
115. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Domanda
•Quale percentuale di stimolazione biventricolare risulta efficace
per la riduzione significativa del tasso di mortalità in pazienti con
terapia CRT?
1.> 85%
2.> 90%
3.> 95%
4.> 98%
116. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
QUESTIONI APERTE
• Pazienti con classe NYHA II
• CRT-P vs CRT-D
• Percentuali Responders
• QRS stretto
117. From: Impact of QRS Duration on Clinical Event Reduction With Cardiac Resynchronization
Therapy: Meta-analysis of Randomized Controlled Trials
Arch Intern Med. 2011;171(16):1454-1462. doi:10.1001/archinternmed.2011.247
Figure 4. Meta-regression analysis examining the impact of baseline QRS duration on the effect of cardiac resynchronization therapy (CRT) on composite clinical events. Each circle represents a QRS subgroup within a trial. The sizes of the circles are proportional to the sample size in each subgroup. The dashed line corresponds to a log risk ratio (RR) of 0 (ie, RR, 1.00), where there is no net benefit or harm. The further the circles are below the 0 line, the larger the clinical benefit for prevention of composite of
adverse clinical events. There was a statistically significant relationship between the QRS duration at baseline and log RR (slope, 0.07 [95% confidence interval, 0.10 to 0.04]; z = 4.60) (P < .001). Accordingly, groups with QRS ranges below 150 milliseconds did not benefit from CRT (black circles, log risk ratio close to 0). Clinical benefit appeared when cases with QRS intervals of 150 milliseconds or greater were included (gray circles) and became more prominent with increasing QRS width (white circles).− − − −
CARE-HF indicates Cardiac Resynchronization-Heart Failure; COMPANION, Comparison of Medical Therapy, Pacing, and Defibrillation in Heart Failure; CRT, cardiac resynchronization therapy; MADIT-CRT, Multicenter Automatic Defibrillator Implantation Trial–Cardiac Resynchronization Therapy; RAFT, Resynchronization-Defibrillation for Ambulatory Heart Failure Trial; REVERSE, Resynchronization Reverses Remodeling in Systolic Left Ventricular Dysfunction.
118. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
QRS stretto: EchoCRT
Ruschitzka F. et al., Cardiac-Resynchronization Therapy in Heart Failure with a Narrow QRS Complex, N Engl J Med 2013;369:1395-405
• CRT ON vs. CRT OFF (Control Group)
- 809 pazienti con QRS stretto (QRS < 130 ms)
- classe NYHA III o IV
- EF ≤ 35%
- dissincronia meccanica LV valutata con ecocardiografia
- follow-up: 19 mesi
• CRT non riduce il tasso di mortalità o di
ospedalizzazione per HF
• Possibilità che la CRT in tali pazienti incrementi la
mortalità
119. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Direzioni future della CRT
120. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
Direzioni future della CRT
• Trial CRT:
- rafforzare le conoscenze derivanti da precedenti trial
- sondare l’efficacia della CRT sugli aspetti meno investigati della
patologia HF
- individuare sottogruppi di pazienti con criteri di inclusione non
testati nei precedenti studi per verificare l’efficacia della CRT in
questi pool
- dimostrare il reale beneficio delle nuove tecnologie dei device
CRT per la riduzione della morbidità e mortalità della
popolazione HF
121. E-Day 19 Settembre 2015
GiuseppeArena
DirettoreU.O.CUTIC–CardiologiaUSL1MassaCarrara
La ricerca futura...
• Criteri di aggiudicazione degli endpoint sempre più uniformi (es. definizione di
ospedalizzazione)
• Metodi di raggiungimento, definizione e mantenimento della terapia
farmacologica ottimizzata standardizzati
• Valutazione del rapporto costo-efficacia CRT
• Identificazione dei pazienti super-responder
• Ottimizzazione della programmazione dei device CRT, follow-up ambulatoriale
e remoto
• Maggiore comprensione patofisiologica della dissincronopatia a livello
meccanico ed elettrico
Approccio multidisciplinare alla cura dei pazienti HF
Editor's Notes
David Kass, MD and Elliot McVeigh, MD developed a technique that uses tagged magnetic resonance imaging (MRI) to track the circumferential shortening of the myocardium. They use MRI to magnetically stain the left ventricle with parallel stripes and then the strain patterns of the ventricle are reconstructed.
On the left is a control patient with a normal heart, on the right a patient with severe DCM. The strain maps are shown in the posterior view, the apex is on the bottom and the base on top. The septum is to the right and identified by a small green dot. The red color indicates the myocardium at its end-diastolic length. When an area shortens it becomes blue. If an area is stretched it becomes yellow.
In the normal heart, contraction is synchronous with symmetric distribution of the stain pattern. There are no areas stretched from their end-diastolic lengths. In the DCM heart, the distribution of wall strain is non-uniform during systole. The septum shortens first and there is stretching on the opposite lateral wall. As the septum finishes contracting, the lateral wall shortens and stretches the septum. The lateral wall is excessively preloaded by the earlier septal shortening. At the end of the contraction, the lateral wall is over-stretching the septum. The ventricle is pumping ineffectively and there is non-uniform wall strain in the myocardium.
It is possible, not proven, that these areas are hot spots with increased wall stress which can potentially damage the myocardium. Somehow the local activation patterns need to be changed. If the lateral wall is pre-excited, perhaps this pattern could be corrected.
Masoudi and colleagues used retrospective medical chart data of 19,710 pts Medicare beneficiaries hospitalized w/ HF and for whom LV systolic function was confirmed. LBBB present in 8% of those with preserved LV systolic function (diastolic HF) and in 24% of those with EF &lt; 50% (p&lt;0.001).
Aaronson developed and validated a multivariable survival model for ambulatory advanced heart failure patients wait listed for a heart transplant. IVCD (QRS &gt; 120 ms) present in 27% of the 268 pts in derivation sample, and in 53% of the 199 pts in validation sample. IVCD identified as contributing risk factor.
Other studies have shown that fro the entire HF population about 15% have a wide QRS.
Main purpose: Illustrate for referral clinicians how the leads are placed to achieve cardiac resynchronization. Many outside the implant world may not be entirely aware of how the device is placed.
Key messages:
The implant procedure, while typically of longer duration, is similar to that of a standard pacemaker or implantable defibrillator implantation.
A key difference is the placement of a left ventricular lead via the coronary sinus opening.
Coronary venous anatomy varies significantly between patients. In a small percentage of cases it may not be possible to place the left ventricular lead transvenously. Some centers are opting for an epicardial approach if the transvenous approach is unsuccessful.
Additional information:
Standard pacing leads are placed in the right atrium and right ventricle. The LV lead is placed via the coronary sinus in a cardiac vein, preferably a lateral or postero-lateral vein in the mid part of the LV. The successful deployment of this lead to physician-guided development of left-heart delivery systems, and new LV leads to meet varying patient
Main purpose: Illustrate for referral clinicians how the leads are placed to achieve cardiac resynchronization. Many outside the implant world may not be entirely aware of how the device is placed.
Key messages:
The implant procedure, while typically of longer duration, is similar to that of a standard pacemaker or implantable defibrillator implantation.
A key difference is the placement of a left ventricular lead via the coronary sinus opening.
Coronary venous anatomy varies significantly between patients. In a small percentage of cases it may not be possible to place the left ventricular lead transvenously. Some centers are opting for an epicardial approach if the transvenous approach is unsuccessful.
Additional information:
Standard pacing leads are placed in the right atrium and right ventricle. The LV lead is placed via the coronary sinus in a cardiac vein, preferably a lateral or postero-lateral vein in the mid part of the LV. The successful deployment of this lead to physician-guided development of left-heart delivery systems, and new LV leads to meet varying patient
Main purpose: Show that a large number of patients have been studied in completed and ongoing randomized controlled studies of CRT. Use in conjunction with previous slide.
Key messages:
Over 3000 patients have been enrolled in randomized controlled clinical trials presented to date.
When CARE-HF, another landmark trial assessing mortality and hospitalization, is reported, close to 4,000 patients will have been studied.
The first CRT pilot studies were intended to test the concept of CRT using a thoracotomy approach. As technology advanced, a transvenous system emerged. Early CRT studies focused on symptoms and quality of life indicators. Current CRT trials are evaluating disease progression, mortality and morbidity.
In order to assess the results of CRT, prospective randomized trials were required. Early Trials investigated feasibility and safety of CRT in selected populations and clinical results related symptoms, functional capability and quality of life. Recent and ongoing trials were designed for different end points, as the impact of CRT on mortality and results in patients with less selective indications.
The primary goal of the study was to compare the relative benefit of pacing versus no pacing using objective measures of maximum oxygen consumption, oxygen consumption at anaerobic threshold, six-minute walk distance, quality of life score, LVEF and NYHA class. Another objective of the study was to compare univentricular and biventricular pacing.
The primary goal of the study was to compare the relative benefit of pacing versus no pacing using objective measures of maximum oxygen consumption, oxygen consumption at anaerobic threshold, six-minute walk distance, quality of life score, LVEF and NYHA class. Another objective of the study was to compare univentricular and biventricular pacing.
After 12 months, peak VO2 increased from 0.97 to 1.19 l/min and was found to be statistically significant change.
VO2 AT reached statistical significance and increased from 0.76 to 0.91 l/min after 12 months of therapy.
The increase in six-minute walk distances (from 357 to 446 m) was found to be statistically significant after 12 months.
NYHA class improved significantly from class III to II after 12 months of therapy.
The Minnesota Living with Heart Failure scores decreased from 49 to 20 after 12 months, demonstrating improvement in quality of life.
After 12 months, peak VO2 increased from 0.97 to 1.19 l/min and was found to be statistically significant change.
The Multi-Site Stimulation in Cardiomyopathy (MUSTIC) study included 17 European centers and 137 patients. The study was designed to evaluate safety and clinical efficacy of multi-site biventricular pacing in patients with severe CHF, chronic LV dysfunction and a wide QRS complex. Patients either received biventricular therapy or no therapy. The patients acted as their own control because they were not aware if pacing was on or off. The study showed an increase in exercise tolerance and decrease in hospitalization rates during the biventricular therapy phase.
During the active phase (pacing turned on), the mean distance walked in six minutes was 23% longer (P &lt; 0.001) than during the inactive phase.
The Minnesota Living with Heart Failure scores decreased by a mean of 32% (P &lt; 0.001) with active pacing (pacing is on).
The Minnesota Living with Heart Failure scores decreased by a mean of 32% (P &lt; 0.001) with active pacing (pacing is on).
Key Points:
Adult, moderate to severe systolic heart failure patients with evidence of ventricular dysynchrony (QRS of 130 ms or more).
Stable heart failure medical regimen was required.
If on a beta-blocker, a therapeutic dose for 3-months prior to enrollment was necessary.
Patients with an existing indication for a pacemaker or an ICD were excluded.
Other Information:
Other exclusion criteria include:
Unstable angina, acute MI, coronary artery revascularization/coronary angioplasty within last 3 months
Chronic atrial arrhythmias, cardioversion from arrhythmia within previous month, paroxysmal atrial arrhythmia within previous month
Supine systolic blood pressure &lt; 80 mm Hg or &gt; 170 mm Hg
Supine resting rate &gt; 140 bpm
Cerebral vascular event with previous 3 months
Cardiac allograph (patients on heart transplant list not excluded)
Serum creatine &gt; 3.0 mg/dL
Serum hepatic function 3 times upper limit of normal
Primary severe uncorrected valvular disease
Enrollment in concurrent study that may confound results
Reference:
Abraham WT. J Card Fail 2000;369-380.
Key Point:
MIRACLE was designed to assess the treatment effect of cardiac resynchronization by minimizing the bias associated with a device-based therapy trial.
Other Information:
Following a period of stable medical therapy and a baseline assessment to determine eligibility, patients underwent an implant attempt.
Implant included an InSync cardiac resynchronization device
Three pacing leads. Standard right atrial and right ventricular; special left ventricular lead implanted transvenously via the coronary sinus
Randomization at pre-discharge to Control group (no pacing) and depicted in white, or CRT (atrial-synchronized biventricular pacing mode) depicted in yellow.
Randomization occurred in permuted blocks to help ensure balance between groups by center.
Patient and heart failure specialist were blinded.
HF specialist made decisions about heart failure management.
Performed efficacy study evaluations.
Electrophysiologist served as an unblinded third party.
Evaluations at 1, 3 and 6 months.
Crossover to CRT prohibited, except for patients who developed a bradyarrhythmia.
Maintenance of background HF medication.
Control group patients crossed over to cardiac resynchronization therapy after 6 months.
Requirement to follow patients ended with device approval in August 2001.
Intention to treat analysis; patients who crossed over were analyzed according to their original treatment assignment.
All are inter-group comparisons (Control vs. CRT).
To minimize bias, core laboratories assessed neurohormonal (Mayo Clinic), echocardiographic (U of Penn), and cardiopulmonary exercise (U of Cincinnati) test results.
Key Points:
NYHA functional class, Quality of Life using the validated Minnesota Living with Heart Failure Questionnaire, and the distance walked in 6 minutes are standard measures of clinical outcome in clinical trials of patients with moderate to severe heart failure symptoms.
Other important secondary efficacy endpoints—Peak VO2, Exercise Duration during cardiopulmonary exercise, Left Ventricular Ejection Fraction (LVEF), Left Ventricular End Diastolic Dimension (LVEDD), Mitral Regurgitation (MR) were specified to provide insight into the mechanisms. These endpoints were assessed by core laboratories to reduce bias.
The Clinical Composite Response is a relatively new method to assess outcome. Unlike other previously listed endpoints that include only patients who complete the randomization period, this measure takes into account all study participants.
Other Information:
For the primary efficacy variables, the study was to be declared as achieving its pre-specified objective if all three endpoints had a P&lt;0.05, or 2 had at P&lt;0.025, or 1 had a P&lt;0.0167.
Each of these endpoints has been validated on its own and have standard definitions and instructions for use. This reduces the bias associated with the evaluator and allows a comparison to other trials.
Key Points:
Enrollment occurred between November 1998 and December 2000 at 45 centers in the US and Canada.
Of a total of 571 patients who signed an informed consent and had an implant attempted, 528 patients were successfully implanted for an implant success rate of 92.4%.
Primary reasons for unsuccessful implants were inability to cannulate the coronary sinus, dislodgement or unstable position of the LV lead, and inability to obtain a distal location.
Of those, 4 patients were not randomized. 2 patients developed bradycardia, and 2 others had unstable medical conditions.
71 of the patients randomized were part of the initial evaluation that included a 3 month randomization period, leaving 453 who were randomized in the 6 month randomization protocol.
Key Points:
Overall, the attrition rate for this study was very low.
Of the 453 patients who participated in the 6 month study protocol, 225 were randomized to control, and 228 to cardiac resynchronization (CRT).
Of those, 201 Control group patients and 215 CRT group patients completed their 6 month follow-up visit.
Additional information:
7 patients did not maintain their assignment to cardiac resynchronization: 4 due to brady indication, 3 due to worsening HF. Data included based on intention to treat principle, therefore these patients are considered in the Control group for the analysis.
Key Points:
No statistically significant differences in baseline characteristics between groups.
A third of the patients were female, a relatively high proportion for trials of systolic heart failure.
Approximately 10% of patients were in NYHA Functional Class IV.
Key Points:
No statistically significant differences in baseline characteristics between groups.
Baseline beta-blocker usage is high for moderate to severe heart failure patients of this era—November 1998 to December 2000.
Enrollment period pre-dates publication of the results of the COPERNICUS study (NEJM 2001; 344:1651-8).
Key Points:
Patients averaged 300 meters at baseline, consistent with NYHA Class III/IV heart failure.
There is a favorable treatment effect on this measure of sub-maximal exercise performance as early as one month that is sustained through the 6 month randomization period.
Additional Information:
Values displayed are paired median changes from baseline with the 95% upper and lower confidence intervals at the specified follow-up periods. Control is represented by the solid white circle, CRT by the solid yellow diamond. All data are paired; data for the same patients are shown for each time point.
P-values are based on the comparison of between group changes.
All 6 minute walk tests were supervised by a trained clinician who was blinded as to the patient’s randomization group.
Key Points:
At baseline, patients averaged a score of 59 out of a possible 105, the worst possible score, consistent with moderate to severe heart failure.
There is a favorable treatment effect on this measure of quality of life as early as one month that is sustained through the 6 month randomization period. The effect is highly statistically significant.
As expected with this or other interventions, there is a placebo effect that persists through 6 months.
Additional Information:
Values displayed are paired median changes from baseline with the 95% upper and lower confidence intervals at the specified follow-up periods. Control is represented by the solid white circle, CRT by the solid yellow diamond. All data are paired; data for the same patients are shown for each time point.
P-values are based on the comparison of between group changes.
All questionnaires were supervised by a trained clinician who was blinded as to the patient’s randomization group.
The Minnesota Living with Heart Failure questionnaire is a validated instrument, self-administered by the patient. It consists of 21 questions related to how a person’s heart failure prevented them from doing what they would like to do or from feeling the way they would like to feel. A response of zero indicated that no effect or limitation was experienced. A response of 1 indicated very little limitation, while a response of 5 indicated very much limitation.
Key Points:
68% of CRT patients improved by one or more functional class compared with 38% of Control patients. The difference is highly statistically significant.
An improvement in the Control group patients was expected. Drug trials, including the study of carvedilol in moderate to severe heart failure patients, show modest improvement in NYHA functional class for placebo group patients.1
Additional information:
The NYHA functional classification was determined by a physician who was blinded to how the patient was randomized.
Reference:
1. Packer M, et al for the PRECISE Study Group. Double-Blind, Placebo-Controlled Study of the Effects of Carvedilol in Patients With Moderate to Severe Heart Failure Circulation. 1996;94:2793-2799.
Key Points:
Pre-specified objective met as all primary efficacy endpoints had a P0.05.
The magnitude of the effect on the primary efficacy endpoints was not affected by the use of a beta-blocker, by whether the heart failure was of ischemic or non-ischemic origin, whether the intraventricular conduction delay was a left or right bundle branch pattern, or by the duration of the QRS.
Key Points:
Results of other important secondary efficacy endpoints—Peak VO2, Exercise Duration during cardiopulmonary exercise, Left Ventricular Ejection Fraction (LVEF), Left Ventricular End Diastolic Dimension (LVEDD), Mitral Regurgitation (MR) are presented in this section. These endpoints were assessed by core laboratories to reduce bias.
The Clinical Composite Response results are also included in this section.
Key Points: (Note – a subset of the 453 patients provide the paired data)
Peak VO2 had virtually no change in the Control group of patients compared with a 1.1 ml/kg/min improvement for CRT group patients. The treatment effect was statistically significant.
Total exercise time during the cardiopulmonary exercise test showed similar results. A modest average improvement by Control group patients was overshadowed by an increase of over 1 minute by the patients receiving CRT.
Other Information:
Cardiopulmonary exercise results were assessed by a core laboratory (University of Cincinnati).
All data are paired; data for the same patients are shown for each time point.
Key Points: (Note – a subset of the 453 patients provide the paired data)
Measures of both cardiac function and cardiac structure showed improvement with cardiac resynchronization.
A 4.6 percentage point improvement in LVEF within the CRT group of patients contrasted significantly with a reduction of 0.2 percentage points in the Control group.
Likewise, patients receiving CRT showed a reduction in mitral regurgitation (-2.7 cm2)that was statistically significantly greater than the modest improvement (-0.5 cm2) observed within the Control group of patients.
The reduction in left ventricular end diastolic diameter of 3.5 mm for CRT patients was significant compared with no change on average for Control group patients.
Other Information:
Echocardiographic results are from a single observer at a core laboratory (University of Pennsylvania).
All data are paired; data for the same patients are shown for each time point.
While ventricular pacing spikes were often observed on the simultaneously recorded ECG, each echo study was blinded with regard to identity and analyzed individually and without reference to echocardiographic images or knowledge of measurements from other studies of the same patient.
Key Point:
67% of the CRT patients showed improvement in their composite response at 6-months compared to 39% of the Control patients. The difference is statistically significant.
Additional Information:
Unlike previous endpoints reported that analyze only those patients completing the 6 month randomization period, this measure accounts for the status of all patients randomized.
The Composite Response has emerged as an important secondary endpoint of this study. It is the only endpoint, other than mortality, that takes into account all 453 patients.
A patient is defined as improved if they improved 1 or more functional classes (by blinded physician), or if the patient indicated a moderate or marked improvement in the patient global assessment score.
With the global assessment, the patient answers how they felt since the InSync system was implanted. There are seven possible responses:
Markedly Improved, Moderately Improved, Mild Improvement, No Change, Slightly Worse, Moderately Worse, Markedly Worse.
A patient is said to have worsened if they died, were hospitalized for worsening heart failure since implant, if they crossover from their assigned group because of worsening heart failure, if they withdraw consent, if they had a worsening of NYHA Functional Class, or if they indicated a moderate/markedly worse ranking on the global assessment.
A patient is said to have not changed if the improved or worsened conditions are not met.
Reference:
Packer M. Proposal for a new clinical endpoint to evaluate the efficacy of drugs and devices in the treatment of chronic heart failure. J Card Fail 2001;7:176-182.
This section reports the results of safety measures—procedure related complications, complications associated with the implanted system post-implant, death, adverse events related to worsening heart failure—as well as the number of days hospitalized for worsening heart failure as a measure of health care utilization.
Key Points:
Adverse events experienced during the implant procedure are summarized here.
The low procedure related mortality is comparable with that of the implant of dual chamber pacemakers 1.
The risk of coronary dissections or perforations is incremental with the implant attempt of a left ventricular lead. In this study all dissections and perforations requiring an intervention were resolved without patient sequelae.
Other Information:
Median duration of the implantation procedure was 2.7 hours (range 0.9 to 7.3).
Implant success rate of 92.4% equivalent with or higher than other studies of resynchronization system implants 2,3.
References
Link MS, et al. J Interv Card Electrophysiol 1998;2:175-179.
Cazeau S, et al. N Engl J Med 2001;344:873-880.
Pürerfellner H, Nesser HJ, Winter S, et al. Transvenous Left Ventricular Lead Implantation with the EASYTRAK Lead System: The European Experience. Am J Cardiol 2000;86(Suppl):157K–164K.
Key Points:
Chart summarizes the results listed in table 3 of the Abraham article cited on this slide.
There is no difference between groups in the risk of death through 6 months.
When death is combined with hospitalization for worsening heart failure, there is a risk reduction of 40% associated with CRT.
Other Information:
Events are not mutually exclusive. Relative risk ratios are based on Cox proportional hazards regression models applied to a time-to-first event analysis. The error bars are the 2-sided 95% Confidence Interval.
The number of patients with the specified event are listed below:
Death for any reason. Control=16, CRT=12
Death or worsening heart failure requiring hospitalization. Control 44, CRT 28
Death or worsening heart failure requiring hospitalization or IV treatment. Control 55, CRT 36
Hospitalized for worsening heart failure. Control = 34, CRT=18
Worsening heart failure leading to use of an IV medication for heart failure. Control = 35, CRT = 16. IV diuretic was the most common, followed by use of an IV vasodilator or positive inotropic agent.
Key Points:
Total days hospitalized for worsening failure was a pre-specified measure of health care utilization.
34 Control group patients were hospitalized a total of 363 days for worsening heart failure during the 6 month randomization period. This compares with 18 CRT group patients who were hospitalized for a total of 83 days, 77% fewer days than those in the Control group.
Other Information:
The decision to hospitalize patients for worsening heart failure was usually made by a heart failure physician who was blinded to the treatment assignment.
The MIRACLE Clinical Events Review committee adjudicated reasons for hospitalization. Committee members were blinded as to the treatment assignment of patients in the study.
The MIRACLE study was not powered to study mortality. However, you can conclude from the results here that cardiac resynchronization does not worsen survival.
All patients in the study are on OPT. The ratio for randomization is 1:2:2. For every 5 patients, 1 is randomized to OPT alone, 2 are randomized to OPT with CRT, and the remaining 2 are randomized to OPT with CRT with defibrillation. The total enrollment for the COMPANION study will be up to 2,200 patients.
This slide shows the main inclusion/exclusion criteria. A full list of these criteria has been published (J.G.F. Cleland, J.C. Daubert, E. Erdmann et al. The CARE-HF study [CArdiac REsynchronisation in Heart Failure] study: rationale, design and end-points. Eur J Heart Fail 2001;3:481-9).
Patients with NYHA III/IV heart failure were selected because these patients have a heavy burden of symptoms and a high morbidity and mortality. Therefore, if intervention was effective in improving well-being and prognosis it should be obvious in this group of patients. Also, patients with few symptoms and a relatively good prognosis may have been unwilling to have a device implanted. Congestive signs and symptoms requiring control with diuretics is a bad prognostic sign. The higher the dose required the worse the prognosis. Requiring patients to be on loop diuretics excluded patients with few symptoms and a good prognosis.
A 6 week rather than 12 week duration of persistent symptoms was required because the prognosis of this group of patients is poor. Shortening the period of symptoms meant that more high-risk patients would be enrolled and any benefit might be observed sooner.
A low LVEF is a marker of a poor prognosis and cardiac dyssynchrony occurs predominantly in patients with severe LVSD and LV dilatation.
The following trials of pharmacological therapy guided recommendations for pharmacological therapy (CONSENSUS and SOLVD for ACE inhibitors, US carvedilol trial, MERIT and CIBIS-II for beta-blockers and RALES for spironolactone). The following trials were reported only AFTER recruitment had started (COPERNICUS, COMET, CHARM and EPHESUS). Patients were therefore required to be on ACE inhibitors and beta-blockers and spironolactone was strongly recommended for more severe patients. Investigators were encouraged to review medications frequently during the study to maintain and increase appropriate pharmacological therapy.
The MUSTIC trial (a positive trial) used a QRS cut-off &gt;150msec, MIRACLE (a positive trial) a cut-off of &gt;130msec and CONTAK (a neutral trial) used a cut-off of &gt;120msec. The prevalence of cardiac dyssynchrony increases as QRS becomes longer as noted previously. Accordingly, patients with QRS &gt;150msec did not require additional validation of dyssynchrony but patients with a QRS 120-149msec required additional echocardiographic evidence as shown on the slide.
Patients with AF were excluded as there was little evidence of benefit with CRT in this group of patients when CARE-HF was designed. Also, these patients could not benefit from atrio-ventricular resynchronisation.
Device implantation is a substantial procedure for patients to undergo and therefore the events that the device can prevent should be of sufficient severity to warrant device therapy. It was considered that the major effect of CRT would be to improve LV function and symptoms leading to a reduction in hospitalisations for heart failure. It was thought possible that CRT could reduce arrhythmias and possibly other CVS events. Moreover, many patients are hospitalised for a combination of arrhythmias, ischaemic events and heart failure and it becomes difficult to classify patients accurately. However, improved LV function, a reduction in worsening heart failure and in other major CVS events would also be expected to reduce mortality.
Accordingly, the primary endpoint of the study was all-cause mortality or an unplanned (i.e. emergency) admission to hospital for a major CVS event. Emergency heart transplants were counted as deaths (and would have been part of the composite primary endpoint anyway). Elective heart transplants were censored 7 days after transplant, as deaths after this time are more likely to reflect complications of the transplant than the patients pre-operative state. Patients randomised to device implantation were admitted to hospital for the procedure and during this time cannot be admitted for another CVS problem (since they are already in hospital). This could have biased the trial in favour of the device. Therefore, only death and not hospitalisation could count towards the primary endpoint in the first 10 days because most patients randomised to a device would spend a few days in hospital for the procedure during this period. Planned admissions were defined as ones where there was at least 24 hours between the decision to admit and admission. All others were considered unplanned. Two expert cardiologists, blinded to randomisation, independently adjudicated all admissions (unless they were definitely planned) and decided whether the admission was cardiovascular or non-cardiovascular. Cardiovascular hospitalisations were then classified as admission for symptoms without a major event (e.g.:- chest pain without evidence of myocardial infarction, palpitations without syncope or evidence of arrhythmia), admission for ‘minor’ cardiovascular events (e.g.:- transient ischaemic attack, new onset well tolerated atrial fibrillation) or ‘major’ cardiovascular events (e.g.:- myocardial infarction, stroke, pulmonary oedema).
All-cause mortality was the principal secondary endpoint. It is the most robust outcome measure in an unblinded study.
55% of patients died or had a major cardiovascular event requiring an emergency admission to hospital over an average of 2.5 years follow-up.
The primary composite end-point (death or an unplanned admission to hospital for a major cardiovascular event) was reduced substantially by CRT. There was no early hazard from device implantation as had been planned for. The curves began to separate within the first 90 days and showed progress separation thereafter. The absolute difference in the number of patients reaching this endpoint over the 29.5 months of study was 16%.
12 patients in the CRT group and 10 in the control group had an unplanned admission for a major cardiovascular event in the 10 day period after randomisation that were not included in the primary endpoint. Including these events would not have an important effect on the results.
There was no heterogeneity in effect in any of the pre-specified subgroups. In particular, benefit was observed in older patients, women, patients with ischaemic heart disease, in patients above and below median LVEF and in patients receiving or not receiving beta-blockers and spironolactone (there were too few patients not receiving an ACE inhibitor or ARB and therefore this analysis was not included in the statistical analysis plan).
Mortality in the control group of CARE-HF was lower than expected (12.6%) and lower than observed in COMPANION (control group 19% at one year) and RALES (active treatment 17% at one year). This may reflect the recruitment of somewhat milder patients or good management.
The one year mortality is similar to that of patients in the SOLVD-treatment study receiving enalapril (12.3%) or the placebo arm of the MERIT-HF study (11%) which are generally considered to have recruited patients with mild to moderate heart failure. The one year mortality in the active arm of MERIT was 7.2% and in COPERNICUS 11.4% (v 18.5% in control).
There was a striking reduction in mortality in the CRT group. The absolute difference between control and CRT was 10%. Again, there was no early hazard and the curves begin to separate within the first 6 months of randomisation. A reduction in both sudden deaths and deaths due to worsening heart failure was observed. There were only 29 sudden deaths out of 82 in the CRT group.
The benefits of CRT are in addition to those of the above pharmacological therapy. The absolute difference in mortality at 2 years was 7.1%. This compares to 5.2% with enalapril in the SOLVD-treatment study and is similar to the estimated two-year mortality difference between placebo and bisoprolol in the CIBIS-II study or the 8.8% difference between placebo and carvedilol in COPERNICUS (which using the method of trial duration used in our study had a duration of about 15 months).
The hazard ratio of the effect of CRT in CARE-HF (0.64; 95% confidence interval 0.48 to 0.85; p=0.0019) was similar to that of CRT-D compared to control in the COMPANION trial (0.64, 95% confidence interval, 0.48 to 0.86; P=0.003) . The absolute estimated difference at 2 years in the COMPANION study between CRT-D and control was about 8% with CRT and CRT-D having similar effects in that study.
Figure 1. Change in LV volumes and LVEF after 6 months of CRT or no pacing.
Figure 2. Effect of CRT on composite clinical response at 6 months.
Figure 2. Kaplan-Meier Estimates of the Probability of Survival Free of Heart Failure. There was a significant difference in the estimate of survival free of heart failure between the group that received cardiac-resynchronization therapy plus an implantable cardioverter-defibrillator (CRT-ICD) and the group that received an ICD only (unadjusted P&lt;0.001 by the log-rank test).
Figure 4. Changes in Mean Echocardiographic Left Ventricular Volumes and Ejection Fraction between Baseline and 1-Year Follow-up. Paired-sample analyses involved 746 patients who received cardiac-resynchronization therapy plus an implantable cardioverter-defibrillator (CRT-ICD) and 620 patients who received an ICD only. LVEDV denotes left ventricular end-diastolic volume, LVEF left ventricular ejection fraction, and LVESV left ventricular end-systolic volume. The height of each bar indicates the average change in the measure from baseline to 1 year, the vertical lines represent 95% confidence intervals, and P values reflect the significances of the difference in average changes between the two groups.
