Thread vs Process, Multithreading, Concurrency, Thread Monitors

1. www.SunilOS.com 1
www.sunilos.com
www.raystec.com
Concurrency/Threads

2. Mother’s morning
www.SunilOS.com 2
Concurrency & Threads
1:
2:
3:
4:
6:
single threading
multi threading
1

3. Threading
www.SunilOS.com 3
Single Threading Multithreading
Thread
Thread
Thread
Thread
Thread
OS
OS

4. www.SunilOS.com 4
OS
CPU Cycle
Thread
Thread
Thread
Thread
Thread
Thread
Thread

5. HelloNoThread
1. public class HelloNoThread {
2. String name = null;
3. public HelloNoThread(String n) {
4. name = n;
5. }
6. public void run() {
7. for (int i = 0; i < 50; i++) {
8. System.out.println(i + name);
9. }
10. }
11.}
www.SunilOS.com 5

6. TestHelloNoThread
1. public class TestHelloNoThread {
2. public static void main(String[] args) {
3. HelloNoThread t1 = new HelloNoThread("Ram");
4. HelloNoThread t2 = new HelloNoThread("Shyam");
5. t1.run();
6. t2.run();
7. }
8. }
 0 Ram
 1 Ram
 2 Ram
 …..
 48 Ram
 49 Ram
 0 Shyam
 1 Shyam
 2 Shyam
 ……..
 48 Shyam
 49 Shyam
www.SunilOS.com 6
t1.run() t2.run()

7. Create Thread
www.SunilOS.com 7
Thread
+run()
+start()
+sleep()
MyThread HelloThread Other
+run() +run() +run()
extends

8. HelloThread
1. public class HelloThread extends Thread{
2. String name = null;
3. public HelloThread(String n) {
4. name = n;
5. }
6. public void run() {
7. for (int i = 0; i < 50; i++) {
8. System.out.println(i + name);
9. }
10. }
11.}
www.SunilOS.com 8

9. TestHelloThread
1. public class TestHelloThread{
2. public static void main(String[] args) {
3. HelloThread t1 = new HelloThread("Ram");
4. HelloThread t2 = new HelloThread("Shyam");
5. t1.start();
6. t2.start();
7. for (int i = 0; i < 50; i++) {
8. System.out.println(“main");
9. }
10. }
11.}
 0 Ram
 1 Ram
 2 Ram
 0 Shyam
 1 Shyam
 1 main
 2 main
 3 main
 3 Ram
 4 Ram
 2 Shyam
 3 Shyam
 4 main
 ……..
 48 Ram
 49 Ram
 48 Shyam
www.SunilOS.com 9

10. CPU Scheduling
CPU
Main
Ram
Shyam
T1 T2 T3

11. Pani puri –Thread scheduling
www.SunilOS.com 11
OS
CPU Cycle
Ready Thread Queue
Thread
Thread Thread Thread
Thread

12. Thread Priority
www.SunilOS.com 12

13. Priority range from 1-10
www.SunilOS.com 13
CPU Cycle
Priority

14. www.SunilOS.com 14
Set and get priority
 Thread t = new Thread(“Ram”);
o t.setPriority(9);
o int i = t.getPriority();
 Default priority is 5
 Priority constants are defined in Thread class:
o Thread.MIN_PRIORITY=1
o Thread.MAX_PRIORITY=10
o Thread.NORM_PRIORITY=5

15. Runnable interface
www.SunilOS.com 15
Runnable
+run()
Implements
ParentClass
extends
ChildClass
+run()

16. Runnable interface
1. public class HelloRunnable implements Runnable {
2. String name = null;
3. public HelloRunnable(String n) {
4. name = n;
5. }
6. public void run() {
7. for (int i = 0; i < 50; i++) {
8. System.out.println(i + name);
9. }
10. }
11.}
www.SunilOS.com 16

17. Test Runnable
 public class TestHelloRunnable {
 public static void main(String[] args) {
 Thread t1 = new Thread(new HelloRunnable("Ram"));
 Thread t2 = new Thread(new HelloRunnable("Shyam"));
 t1.start();
 t2.start();
 for (int i = 0; i < 500; i++) {
 System.out.println("Main");
 }
 }
 } www.SunilOS.com 17

18. www.SunilOS.com 18
Threads and Processes

19. Thread creation
A java program executed as thread inside JVM
A thread can create another thread.
Threads work concurrently.
If one thread dies, other will remain active in
memory
www.SunilOS.com 19

20. www.SunilOS.com 20
Thread Lifecycle - States
2: start()
finish run()
1: new
Born Blocked
Runnable
Dead
1. I/O available
2. notify()
3. wake up()
1. block on I/O
2. wait()
3. sleep()

21. www.SunilOS.com 21
Thread Methods
 start()
o Starts the thread and put into runnable queue
 run()
o Performs operation
 Thread.sleep(int m)/sleep(int m,int n)
o Sleeps the thread for given time in milliseconds and nanoseconds
 Thread.yield()
o Pauses currently executing thread and put at last in the runnable queue

22. www.SunilOS.com 22
Daemon Threads
 Daemon threads are supporting and background threads
 It provides services to normal threads
 Garbage Collector is a Daemon thread.
 t.setDaemon(true)
Daemon
Thread
Normal
Thread

23. Usage | multi user system
www.SunilOS.com 23
Web Application
Database

24. Race condition
www.SunilOS.com 24
Thread 1
Thread 2
Object

25. www.SunilOS.com 25
Race Condition
 Threads of a process can share common memory area
 When two threads simultaneously try to access and modify an
object, it is called race-condition
 The result of a program is affected by the order in which threads
are allocated CPU time and executed

26. www.SunilOS.com 26
Deposit in the Account
Account
Balance = 1000
Balance = 2000
getBalance():1000
setBalance(2000)
setBalance(2000)
getBalance():1000
getBalance()
CPU
getBalance()
setBalance()
setBalance()
User1 User 2
Deposit
Deposit

27. www.SunilOS.com 27
Synchronized access
Account
Balance = 1000
Balance = 3000
getBalance():1000
setBalance(2000)
setBalance(3000)
getBalance():2000
User1 User 2
Deposit Deposit
getBalance()
CPU
locked
setBalance()
setBalance()
getBalance()

28. www.SunilOS.com 28
Account
1. public class Account {
2. private int balance = 0;
3. public int getBalance() {
4. try {
5. Thread.sleep(200);
6. } catch (InterruptedException e) {}
7. return balance;
8. }
9. public void setBalance(int balance) {
10. try {
11. Thread.sleep(200);
12. } catch (InterruptedException e) {}
13. this.balance = balance;
14. }
15.

29. www.SunilOS.com 29
Account
1. public synchronized void deposit(String msg, int amt) {
2. int bal = getBalance();
3. bal = bal + amt;
4. setBalance(bal);
5. System.out.println(msg + " new balance " + bal);
6. }
7. }

30. www.SunilOS.com 30
RacingCondThread
public class RacingCondThread extends Thread {
public static Account data = new Account();
String name = null;
public RacingCondThread(String name) {
this.name = name;
}
public void run() {
for(int i=0;i<5;i++){
data.deposit(name, 1000);
}
}

31. www.SunilOS.com 31
TestRacingCondThread
public static void main(String[] args) {
RacingCondThread t1 = new RacingCondThread(“Ram");
RacingCondThread t2 = new RacingCondThread(“Shyam");
t1.start();
t2.start();
}

32. Output
 void deposit(..)
o Ram balance 1000
o Shyam balance 1000
o Ram balance 2000
o Shyam balance 2000
o Shyam balance 3000
o Ram balance 3000
o Shyam balance 4000
o Ram balance 4000
o Shyam balance 5000
o Ram balance 5000
 synchronized void deposit(..)
o Ram balance 1000
o Ram balance 2000
o Ram balance 3000
o Ram balance 4000
o Ram balance 5000
o Shyam balance 6000
o Shyam balance 7000
o Shyam balance 8000
o Shyam balance 9000
o Shyam balance 10000
www.SunilOS.com 32

33. www.SunilOS.com 33
Synchronization types
Method
public synchronized void deposit(String message, int amount)
{….}
Block
public void deposit(String message, int amount) {
synchronized (this){
int bal = getBalance() + amount;
setBalance(bal);
}
System.out.println(message + " Now Bal is " + bal);
}

34. www.SunilOS.com 34
Monitors / Locks
 It is a lock or token of an object
 The thread has lock, can access object
 Other threads will be in waiting queue
 One object has two monitors or tokens
o One for instance methods, called Object Monitor
o Second for static methods, called Class Monitor

35. www.SunilOS.com 35
Monitor Keys
Static Sync Methods
x
z
y
Instance Sync Methods
a
c
b
Thread1
Thread2
x() Class
Monitor
y()
a() Object
Monitor
b()
CLASS

36. Disclaimer
This is an educational presentation to enhance the skill
of computer science students.
This presentation is available for free to computer
science students.
Some internet images from different URLs are used in
this presentation to simplify technical examples and
correlate examples with the real world.
We are grateful to owners of these URLs and pictures.
www.SunilOS.com 36
