Tech Talk - Blockchain presentation
- 2. Introduction
- 3. Problem
- 4. Solution
- 5. Hyperledger History December 2015 the Linux Foundation announced the creation of the Hyperledger Project February 2016 The founding members of the project were announced In early 2016, the project began accepting proposals for incubation of codebases and other technologies as core elements. 12 July 2017 the project announced its production-ready Hyperledger Fabric 1.0 and it started to gain popularity July 2017 London Stock Exchange Group in a partnership with IBM announced that it will create a Blockchain platform designed for digitally issuing shares of Italian companies. Hyperledger Fabric will form the basis of the platform September 2017 The Royal Bank of Canada (RBC) have started using Hyperledger Fabric for its US - Canada interbank settlements.
- 7. Where are we now?
- 8. Benefits of Private Blockchains 1. 100% Uptime 2. Solves the Byzantium Generals problem for data synchronization 3. The data are Immutable / Incorruptible 4. The algorithm is Immutable / Incorruptible 5. Traceable
- 9. When do you need a blockchain?
- 10. When not to use Blockchain 1. The process stores a lot of static data, or the data is quite large 2. Rules of transactions change frequently 3. The use of external services to gather/store data
- 11. Bitcoin Ethereum Hyperledger Frameworks Cryptocurrency based Yes Yes No Permissioned No No Yes (in general) Pseudo-anonymous Yes No No Auditable Yes Yes Yes Immutable ledger Yes Yes Yes Modularity No No Yes Smart contracts No Yes Yes Consensus protocol PoW PoW Various** Comparing blockchains **Key Hyperledger consensus protocols are Apache Kafka in Hyperledger Fabric, PoET in Hyperledger Sawtooth, RBFT in Hyperledger Indy, Tendermint in Hyperledger Burrow, and Yet Another Consensus (YAC) in Hyperledger Iroha. For more details, see the Hyperledger Architecture, Volume 1 paper.
- 13. Other Hyperledger Tools Cello Composer Explorer Quilt Hyperledger Cello: Implement Blockchain-as-a-Service and contributed by IBM. Baohua Yang and Haitao Yue from IBM Research are committed part-time to developing and maintaining the project. Hyperledger Composer: Blockchain package management tooling contributed by IBM. Composer is a user-facing rapid prototyping tooling, running on top of Hyperledger Fabric, which allows the easy management of Assets (data stored on the blockchain), Participants (identity management, or member services) and Transactions (Chaincode, or Smart Contracts which operate on Assets on the behalf of a Participant). The resulting application can be exported as a package (a BNA file) which may be executed on a Hyperledger Fabric instance, with the support of a Node.js application (based on the Loopback application framework) and provide a REST interface to external applications. Hyperledger Explorer: Blockchain analytics tooling contributed by IBM, Intel, and DTCC. Hyperledger Quilt: Transfer value between and outside of distributed ledgers. Uses the ILP payments protocol.
- 16. Fabric: Key Points 1. Smart Contracts: A shared ledger and smart contracts implemented as ‘chaincode’ 2. Identity Management: Privacy and permissioning through membership services enables confidentiality. 3. Flexible: Modular architecture and flexible hosting options 4. Efficient processing: Practical Byzantine Fault Tolerant.
- 17. The Lifecycle of a Smart Contract Client Ordering Service Peers Creates the Smart Contract / Transaction Creates a Block Accepts the Block onto the Blockchain Peers Validates Transaction Client Signs Transaction
- 22. Set-up Open a Terminal from your desktop and move into the hyperledger directory: cd ~/hyperledger/my-network Then type: code . To open your IDE.
- 23. README.md Replace all the text in this directory with: # My Commodity Trading Network
- 24. package.json Change the text highlighted in Yellow below: "name": "my-network", "version": "0.1.6", "description": "My Commodity Trading network", "networkImage": "https://hyperledger.github.io/composer-sample- networks/packages/basic-sample-network/networkimage.svg", "networkImageanimated": "https://hyperledger.github.io/composer-sample-networks/packages/basic-sample- network/networkimageanimated.svg", "scripts": { "prepublish": "mkdirp ./dist ; composer archive create --sourceType dir -- sourceName . -a ./dist/my-network.bna",
- 25. Model File (.cto) A Hyperledger Composer CTO file is composed of the following elements: ● A single namespace. All resource declarations within the file are implicitly in this namespace. ● A set of resource definitions ● Assets ● Transactions ● Participants ● Events. ● Optional import declarations that import resources from other namespaces. CTO Language: https://hyperledger.github.io/composer/reference/cto_language.html
- 26. Model File (.cto) /** * Commodity trading network */ namespace org.acme.mynetwork asset Commodity identified by tradingSymbol { o String tradingSymbol o String description o String mainExchange o Double quantity --> Trader owner } participant Trader identified by traderId { o String traderId o String firstName o String lastName } transaction Trade { --> Commodity commodity --> Trader newOwner }
- 27. Transaction Processing File (.js) (aka the business logic) Transaction processor functions are automatically invoked by the runtime when transactions are submitted using the BusinessNetworkConnection API. /** * A transaction processor function description * @param {org.example.sampleTransaction} parameter-name A human description of the parameter * @transaction */ Document: https://hyperledger.github.io/composer/reference/js_scripts.html
- 28. Logic File (.js) /** * Track the trade of a commodity from one trader to another * @param {org.acme.mynetwork.Trade} trade - the trade to be * processed * @transaction */ function tradeCommodity(trade) { // set the new owner of the commodity trade.commodity.owner = trade.newOwner; return getAssetRegistry('org.acme.mynetwork.Commodity') .then(function (assetRegistry) { // persist the state of the commodity return assetRegistry.update(trade.commodity); }); }
- 29. Access Control Langage (acl) Hyperledger Composer differentiates between access control for resources within a business network (business access control) and access control for network administrative changes (network access control). Business access control and network access control are both defined in the access control file (.acl) for a business network. Network access control uses the system namespace, which is implicitly extended by all resources in a business network; and grants or denies access to specific actions as defined below, and is intended to allow for more nuanced access to certain network-level operations. Document: https://hyperledger.github.io/composer/reference/acl_language.html
- 30. Permissions (.acl) /** * Access control rules for mynetwork */ rule Default { description: "Allow all participants full access" participant: "ANY" operation: ALL resource: "org.acme.mynetwork.*" action: ALLOW } rule SystemACL { description: "System ACL to permit all access" participant: "org.hyperledger.composer.system.Participant" operation: ALL resource: "org.hyperledger.composer.system.**" action: ALLOW }
- 31. Hyperledger Composer Query Language Queries in Hyperledger Composer are written in a bespoke query language. Queries can be written with undefined parameters that must be supplied when running the query. For example, the following query returns all drivers where the age property is greater than the supplied parameter: query Q17 { description: "Select all drivers aged older than PARAM" statement: SELECT org.acme.Driver WHERE (_$ageParam < age) } Document: https://hyperledger.github.io/composer/reference/query-language.html
- 32. Queries (.qry) query selectCommoditiesByOwner { description: "Select all commodities based on their owner" statement: SELECT org.acme.mynetwork.Commodity WHERE (owner == _$owner) }
- 33. Generate our Business Network Archive (.bna) In the terminal type: npm install When this command is complete, move into the dist directory and deploy the network. cd dist composer network deploy -a my-network.bna -p hlfv1 -i PeerAdmin -s randomString Wait for ‘command succeeded’ (Extra Time: Ping the network) composer network ping -n my-network -p hlfv1 -i admin -s adminpw
- 35. Generate the Rest Server In the terminal type: composer-rest-server Answer the following questions: Enter your connection profile name: hlfv1 Enter your business network name: my-network Enter your enrollment ID: admin Enter your enrollment secret: adminpw Do you want namespaces? never use namespaces Enable auth for the REST API using Passport? No Enable event publication over web sockets? Yes Do you want enable TLS security? No Open the following URL: http://localhost:3000/explorer
- 36. Generate the App In a NEW terminal type: yo hyperledger-composer Answer the following questions: Type of Application: Angular Connect to a running Business Network? Yes Name of the application? my-app Description of the application: Commodities App Author name: user Author email: user@acme.org License: Apache-2.0 Business network identifier? my-network Connection profile? hlfv1 Enrollment id: admin Enrollment Secret: adminpw New REST API? Connect to an existing REST API REST Server Address?: http://localhost Port number? 3000 Use namespaces? Namespaces are not used
- 37. Generate the App After it’s finished, type: cd my-app npm start Open the following URL: http://localhost:4200
