The document describes the SPADE algorithm for sequential pattern mining. SPADE aims to improve efficiency over previous algorithms by reducing the number of database scans and using a more compact vertical id-list database format. It works by decomposing the search space into equivalence classes based on common prefixes and processing each class independently with depth-first search.

1. Sequence mining algorithm
Monica Dăgădiţă
ISI

2.  Introduction
to sequence mining
 Why sequence mining?
 Sequence mining algorithms
 SPADE
 Motivation
 Definitions and examples
 Algorithm
 Implementation
Data Mining 11/8/2011 2

3.  Aim - finding statistically relevant patterns
between data examples where the values are
delivered in a sequence
 Originallyintroduced for market basket
analysis - customer behaviour predictions
2 types of sequence mining:
 string mining – biology (gene/protein sequences)
 itemset mining - marketing and CRM applications
Data Mining 11/8/2011 3

4.  Discovering patterns:
 Bookstore: 70% of the people who buy Jane
Austen’s “Pride and Prejudice” also buy “Emma”
within a month
 Website: finding sequences of most frequently
accessed pages
 Usage:
 Promotions
 Shelf placement
 Restructure the website
 Recommender systems
Data Mining 11/8/2011 4

5.  Apriori
 GSP (Generalized Sequential Pattern)
 FreeSpan (Frequent pattern-projected
Sequential pattern mining)
 PrefixSpan (Prefix-projected Sequential
pattern mining)
 SPADE (Sequential PAttern Discovery using
Equivalence classes)
Data Mining 11/8/2011 5

6.  Problems of existing solutions
 Repeated database scans
 Complex internal data structures
 Key features of SPADE:
 Fixed number of database scans
 Vertical id-list database format
 Decomposition of search space into smaller
pieces – processed independently
Data Mining 11/8/2011 6

7.  Itemset: set of m distinct items
I = {i1, i2, …, im }
 Event: non-empty collection of items
(i1,i2 … ik)
 Sequence : ordered list of events
< e1 -> e2 -> … -> en >
 K-sequence : sequence with k items
(B->AC) – 3-sequence
Data Mining 11/8/2011 7

8.  Subsequence: given two sequences α=<a1 a2 … an>
and β=<b1 b2 … bm>, α is called a subsequence of
β, denoted as α⊆ β, if there exist integers 1≤ j1 < j2
<…< jn ≤m such that a1 ⊆ bj1, a2 ⊆ bj2,…, an ⊆ bjn
 Examples:
1. (B->AC) is a subsequence of (AB->E->ACD)
2. (AB->E) is not a subsequence of (ABE)
Data Mining 11/8/2011 8

9. Data Mining 11/8/2011 9

10. Id-lists of the most frequent items (1-sequences)
Data Mining 11/8/2011 10

11.  D->BF->A
 Step 1: D->B
 Step 2: D->BF
Data Mining 11/8/2011 11

12.  D->BF->A
 Step 3 : D->BF->A
 Not space-efficient
 Solution: 2 columns - (sid,eid) for each sequence
 Eid – id of the sequence’s last item
Data Mining 11/8/2011 12

13.  D->BF->A (space-efficient id-list joins)
D->B
SID EID
1 15
1 20
4 20
D->BF->A D->BF
SID EID SID EID
1 25 1 20
4 25 4 20
Data Mining 11/8/2011 13

14.  Complete latice representation
Data Mining 11/8/2011 14

15. Data Mining 11/8/2011 15

16.  Decomposing the latice => smaller pieces
that can be solved independently
 Equivalence classes
2 sequences are in the same class (Θk) if they
share a common k length prefix
Example
k=1 : Θ1 -> {[A],[B],[D],[F]}
Data Mining 11/8/2011 16

17. Data Mining 11/8/2011 17

18. Data Mining 11/8/2011 18

19.  SPADE(min_sup,D)
//min_sup – minimum_support
//D –initial dataset
F1<- {frequent items or 1-sequences}
F2<- {frequent 2-sequences}
Ε <- {equivalence classes [X] Θ1 }
for all [X] in E
enumerate_frequent_seq([X],min_sup)
Data Mining 11/8/2011 19

20.  Enumerate_frequent_seq(S,min_sup)
for all Ai in S
Ti <- {}
for all Aj in S, with j≥i
R<- Ai v Aj (join)
if R satisfies min_sup
Ti <- Ti U {R}
end
Enumerate_frequent_seq(Ti , min_sup) //DFS
end
For all non-empty Ti
Enumerate_frequent_seq(Ti , min_sup) //BFS
Data Mining 11/8/2011 20

21.  The R Project for Statistical Computing
 developed at Bell Laboratories (formerly
AT&T, now Lucent Technologies) by John
Chambers and colleagues
 Different implementation of S language
 arulesSequences package
Data Mining 11/8/2011 21

22. Data Mining 11/8/2011 22
