1. Formats for Exchanging Archival
Data
An Introduction to EAD, EAC-
CPF, and Archival Metadata
Standards
VII International Seminar of
Archives from Iberian Tradition

2. Michael Rush
Accessioning Archivist / EAD
Coordinator,
Beinecke Rare Book and Manuscript
Library, Yale University
Co-Chair, Technical Subcommittee
2 for Encoded Archival Description,

3. Assumptions and Definitions
3

4. Assumptions
 Familiarity with some ICA standards - ISAD (G),
ISAAR (CPF), ISDF, or ISDIAH
 Awareness of EAD, but little of no experience with
it
 Little or no experience with XML
4

5. Definitions
 EAD: Encoded Archival Description
 EAC-CPF: Encoded Archival Context – Corporate
bodies, Persons, and Families
 XML: Extensible Markup Language
5

6. Development History
6

7. EAD Development History
 Berkeley Finding Aid Project (1993-1995)
 EAD Alpha (1996)
 EAD Beta (1996)
 EAD 1.0 (1998)
 EAD 2002 (2002)
 EAD 2002 Schema (2007)
 EAD 2013?
7

8. EAC-CPF Development History
 Meeting at Yale University (1998)
 Meeting at University of Toronto (2001)
 EAC Beta (2004)
 EAC-CPF (2010)
8

9. Governance and Maintenance
9

10. Governance and Maintenance
 EAD
 EAD Working Group (1995-2010)
 Technical Subcommittee for EAD (2010- )
 EAC-CPF
 Ad hoc working group (2001-2004)
 EAC Working Group (2007-2011)
 Technical Subcommittee for EAC-CPF (2011- )
 Schema Development Team (2010- )
10

11. Design Goals and Applications
11

12. EAD Design Goals
 Represent hierarchical structure of finding aids
 SGML, then XML
 Flexibility, to encourage adoption.
 Compatibility with ISAD (G)
12

13. EAD Applications
 Delivery
 Standardization
 Sharing
 Transmission/Communication
 Repurposing
13

14. Example EAD Implementations
 Yale Finding Aid Database
 Online Archive of California (OAC)
 Northwest Digital Archive (NWDA)
 Archives Portal Europe (APEnet)
14

15. EAC-CPF Design Goals
 Close compatibility with ISAAR (CPF)
 A change from EAC Beta to current schema
 XML
 Philosophical neutrality
 Relatively simple and straightforward
 Extensible design
 Adaptability to relational database structures
15

16. EAC-CPF Applications
 Identity/Authority
 Description
 Relationships
 Aggregation
 Transmission/Communication
16

17. Oral history
interview with
Terry Sanford
UNC SOHP
Terry
Terry Sanford
Terry Sanford
papers, 1946- Sanford records and
papers, 1945-
1993
1998
UNC (#3531) (EAC- Duke University
CPF)
Terry Sanford’s
Governor’s
papers, 1959-
1965
NC State
Archives

18. Example EAC-CPF
Implementation
 The Social Networks and Archival Context Project
(SNAC)
18

19. Challenges
19

20. Challenges
 Data migration and/or creation
 Establishing encoding best
practices
 Delivery
 Indexing and search
 Display
 Data maintenance
 Sharing
20

21. Data migration/creation
 Methods
 Hand encoding
 Templates
 Scripting
 Outsourcing
 Export from databases (Archivists’ Toolkit, Archon,
ICA AtoM)
 Costs
 Staff time
 Staff training
 Consultant or outsourcing fees
21
 Software

22. Encoding Best Practices
 Local
 Yale EAD Encoding Best Practice
Guidelines [EAD]
 Consortial
 Northwest Digital Archives Best
Practice Guidelines [EAD]
 RLG Best Practice Guidelines for
Encoded Archival Description [EAD]
22

23. Delivery
 Indexing and search
 No single solution
 Popular tools include :
 XTF (eXtensible Text Framework)
 Fedora Commons Repository Software
 Display
 Transformation via XSLT (Exstensible
Stylesheet Language – Transformations)
 XML --> HTML
 XML --> PDF
23

24. XML
HTML
XSLT
CSS
24

25. Data Maintenance
 File management
 Version control
 Link maintenance
25

26. Sharing
 Consortia
 Bulk Aggregators
 ArchiveGrid
 Topical Aggregators
 U.S. National Library of Medicine,
History of Medicine Finding Aids
Consortium
26

27. Related Standards
27

28. Related Description Standards
 ICA standards:
 ISAD(G): General International Standard Archival
Description - Second edition
 ISAAR(CPF): International Standard Archival
Authority Record for Corporate Bodies, Persons
and Families, 2nd Edition
 ISDF: International Standard for Describing
Functions
 ISDIAH: International Standard for Describing
Institutions with Archival Holdings
 National Description Standards
 DACS: Describing Archives: A Content Standard
28 (USA)

29. EAD Data Structure
29

30. EAD: Basic Structure
<ead>*
<eadheader>*
<archdesc>*
<dsc>
30

31. EAD Header
<eadheader>*
<eadid>*
<filedesc>*
<profiledesc>
<revisiondesc>
31

32. File Description
<filedesc>*
<titlestmt>*
<titleproper>*
<author>
<publicationstmt>
<publisher>
32

33. Profile Description
<profiledesc>
<creation> - Creation
<langusage> - Language
Usage
<descrules> - Descriptive
Rules
33

34. Revision Description
<revisiondesc>
<change> - Change
<date> - Date
<item> - Item
34

35. EAD: Basic Structure
<ead>*
<eadheader>*
<archdesc>*
<dsc>
35

36. Hierarchical Encoding
 <archdesc>
 Top level of description.
 <dsc>
 Optional child of <archdesc>
 Consists of nested components
36

37. Components
 <c> - Component
(Unnumbered)
 Or
 <c01> - Component (First
Level)
<c02> - Component (Second
Level)
37 Through <c12> - Component

38. Levels of Description
 @level
[ISAD(G) 3.1.4]  subseries
 collection  file
 fonds  item
 class  Otherlevel
 recordgrp
 series  <archdesc
 subfonds level=“fonds”>
 subgrp  <c level=“series”>
38

39. Descriptive Elements
 Valid as at all levels of description
 <did> is required at each level of
description.
39

40. Descriptive Identification
 <did>*
 Always the first child of
<archdesc> and the component
elements.
 Wrapper element containing
elements with basic identifying
information.
 Must have one child element.
40

41. <did> Children
 <unitid> - Unit Identification
[ISAD(G) 3.1.1]
 <unittitle> - Unit Title
[ISAD(G) 3.1.2]
41

42. <did> Children (continued)
 <unitdate> - Unit Date
[ISAD(G) 3.1.3]
 <physdesc> - Physical
Description
[ISAD(G) 3.1.5]
42

43. <did> Children (continued)
<origination> - Origination
[ISAD(G) 3.2.1]
<langmaterial> - Language
of the Material [ISAD(G)
3.4.3]
43

44. <did> Children (continued)
 <note> - Note [ISAD(G) 3.6.1]
 <abstract> - Abstract
 <physloc> - Physical Location
 <materialspec> - Material
Specific Details
 <repository> - Repository
44

45. <did> Children (continued)
<did>
<container> - Container
<dao> - Digital Archival
Object
<daogroup> - Digital
Archival Object Group
45

46. <did> Siblings
 <bioghist> - Biography or History
[ISAD(G) 3.2.2]
 <custodhist> - Custodial History
[ISAD(G) 3.2.3]
 <acqinfo> - Acquisition Information
[ISAD(G) 3.2.3]
46

47. <did> Siblings
 <scopecontent> - Scope and
Content
[ISAD(G) 3.3.1]
 <accruals> - Accruals
[ISAD(G) 3.3.2]
 <appraisal> - Appraisal
[ISAD(G) 3.3.3]
 <arrangement> - Arrangement
47 [ISAD(G) 3.3.4]

48. <did> Siblings (continued)
 <accessrestrict> - Conditions
Governing Access [ISAD(G) 3.4.1]
 <userestrict> - Conditions
Governing Use
[ISAD(G) 3.4.2]
 <phystech> - Physical
Characteristics and Technical
Requirements [ISAD(G) 3.4.4]
48  <otherfindaid> - Other Finding Aid

49. <did> Siblings (continued)
 <originalsloc> - Location of
Originals
 [ISAD(G) 3.5.1]
 <altformavail> - Alternative Form
Available
[ISAD(G) 3.5.2]
 <relatedmaterial> - Related
Material
49 [ISAD(G) 3.5.3]

50. <did> Siblings (continued)
 <bibliography> - Bibliography
[ISAD(G) 3.5.4]
 <note> - Note
[ISAD(G) 3.6.1]
 <odd> - Other Descriptive Data
[ISAD(G) 3.6.1]
 <processinfo> - Processing
Information
50 [ISAD(G) 3.7.1]

51. <did> Siblings (continued)
 <prefercite> - Preferred Citation
 <controlaccess> - Control Access
 <fileplan> - File Plan
 <index> - Index
51

52. EAC-CPF Data Structure
52

53. EAC-CPF Concepts
SINGLE IDENTITY: one person (or corporate body or family) with a single identity
represented in one EAC-CPF instance. (Most common.)
MULTIPLE IDENTITY-MANY IN ONE: two or more identities (including official identities)
with each represented by distinct descriptions within one EAC-CPF instance. Can be
programmatically converted into Multiple Identity-One in Many. (Less common though
not
rare.)
MULTIPLE IDENTITY-ONE IN MANY: two or more identities (including official identities)
each represented in two or more interrelated EAC-CPF instances. Can be
programmatically
converted into Multiple Identity-Many in One. (Less common though not rare.)
ALTERNATIVE SET: derived EAC-CPF instance that is based on and incorporates two
or more
alternative EAC-CPF instances for the same entity. To be used by a consortia or a
utility
providing union access to authority records maintained in two or more systems by
two or more agencies. Alternative EAC-CPF instances may be in different languages
or in the same
53 language.

54. Basic structure
 <eac-cpf>*
<control>*
<cpfDescription>
<identity>
<description>
<relations>
54

55. Basic Structure
<control>: identity, creation, maintenance, status,
rules and authorities, and sources used to
generate the EAC-CPF instance.
<cpfDescription>: description of the EAC-CPF
entity
 <identity>: names
 <description>: formal and informal descriptive elements
 <relations>: relationships to other entities, resources
and function descriptions
55

56. Philosophical neutrality (1)
<eac-cpf>
<control></control>
<cpfDescription>
<identity></identity>
<description></description>
<relations>
<cpfRelation></cpfRelation>
<cpfRelation></cpfRelation>
</relations>
</cpfDescription>
</eac-cpf>
56

57. Philosophical neutrality (2)
<eac-cpf>
<control></control>
<multipleIdentities>
<cpfDescription></cpfDescription>
<cpfDescription></cpfDescription>
<cpfDescription></cpfDescription>
</multipleIdentities>
</eac-cpf>
57

58. <control>
 <recordId>*
 <maintenanceAgency>*
 <maintenanceStatus>*
 <maintenanceHistory>*
 <publicationStatus>
 <languageDeclaration>*
 <sources>*
 <conventionDeclaration>
 <otherRecordId>
 <localControl>
 <localTypeDeclaration>
58

59. <cpfDescription>/<identity>
 <entityType>*
 <nameEntry>**
 <nameEntryParallel>**
 <entityId>
 <descriptiveNote>
59

60. Basic Name Models
<nameEntry>
<part></part>
<useDates></useDates>
</nameEntry>
<nameEntryParallel>
<nameEntry></nameEntry>
<nameEntry></nameEntry>
</nameEntryParallel>
60

61. <cpfDescription>/<description>
 <existDates>
 <function>
 <generalContext>
 <legalStatus>
 <languageUsed>
 <mandate>
 <occupation>
 <place>
 <biogHist>
 <structureOrGenealogy>
 <localDescription>
61

62. <cpfDescription>/<relations>
 <cpfRelation>
 <functionRelation>
 <resourceRelation>
◦ @*RelationType
◦ <relationEntry>
◦ <objectBinWrap>
◦ <objectXMLWrap>
◦ <date>, <dateRange>, <dateSet>
◦ <place>
◦ <descriptiveNote>
62

63. <cpfRelation>: relation types
 @cpfRelationType
 identity
 hierarchical
 hierarchical-parent
 hierarchical-child
 temporal
 temporal-earlier
 temporal-later
 family
 associative
63

64. <resourceRelation>: relation
types
 @resourceRelationType
 creatorOf
 subjectOf
 other
64

65. <functionRelation>: relation types
 @functionRelationType
 controls
 owns
 performs
65

66. Future Development
66

67. EAD Revision Timeline
 Comment period complete (October 2010 –
February 2011)
 EAD Revision Forum (SAA Annual Meeting,
August 2011)
 TS-EAD Working Meeting (March 2012)
 Release draft schema (Fall 2012)
 Second comment period (Winter 2013)
 Finalize schema and documentation (Spring
2013)
 Release revised schema (August 2013)
67

68. EAD Revision Goals
 Clarify relationship with EAC-CPF
 Improve interoperability with databases
 Reconsider finding aids as documents or data
 Simplification
 To eliminate unnecessary complexity
 To make implementation easier
 Improve usability
 Enable profiles (schema subsets)
 Data-friendly
 Implementation-friendly (may or may not be the
same as data-friendly)
68

69. Future EAC Development
 EAC-CPF Implementation
 Review by 2016
 Companion EAC standards?
 EAC-Functions (EAC-F)?
 EAC-Institutions with Archival
Holdings (EAC-IAH)?
69

70. EAC-
CPF
EAC-
EAD EAD IAH
EAC-
F
70

71. EAD
EAC-
CPF
EAC- EAC-
F CPF
71

72. EAC-
F
EAC-
F
EAC-
EAD
CPF
72

73. Questions?
michael.rush@yale.edu
http://twitter.com/mike_rush
73
