RISC Vs CISC Computer architecture and design

1. RISC Vs CISC

2. Classification of
Microprocessors:
• The classification based on
– the word length,
– the architecture i.e. Instruction Set of the
microprocessor.
• These are categorized into RISC and CISC.

3. Before start !
RISC is the way to make hardware simpler
whereas CISC is the single instruction that
handles multiple work.

4. RISC
• Definition
– stands for Reduced Instruction Set Computers.
– is a type of microprocessor architecture that utilizes a
small, highly-optimized set of instructions,
– The main idea behind this, is
• to simplify hardware by using an instruction set composed
of a few basic steps for loading, evaluating, and storing
operations just like
– a load command will load data,
– a store command will store the data.
• Examples: SPARC, POWER PC, etc.

5. Characteristics of RISC
• Simpler instruction, hence simple instruction
decoding.
• Instruction comes undersize of one word.
• Instruction takes a single clock cycle to get
executed.
• More general-purpose registers.
• Simple Addressing Modes.
• Fewer Data types.
• A pipeline can be achieved.

6. Advantages of RISC
• Simpler instructions:
• RISC processors use a smaller set of simple
instructions,
• which makes them easier to decode and execute quickly.
• This results in faster processing times.
• Faster execution:
• Because RISC processors have a simpler instruction
set,
• they can execute instructions faster than CISC processors.
• Lower power consumption:
• RISC processors consume less power than CISC
processors,
• making them ideal for portable devices.

7. Disadvantages of RISC
• More instructions required:
• RISC processors require more instructions to
perform complex tasks than CISC processors.
• Increased memory usage:
• RISC processors require more memory to store
the additional instructions needed to perform
complex tasks.
• Higher cost:
• Developing and manufacturing RISC processors
can be more expensive than CISC processors.

8. Complex Instruction Set
Architecture (CISC)
• The main idea is that a single instruction
will do all loading, evaluating, and storing
operations just like
– a multiplication command will do stuff like
• loading data,
• evaluating,
• storing it,
– hence it’s complex.
• Examples: Intel architecture, AMD

9. Characteristics of CISC
• Complex instruction, hence complex
instruction decoding.
• Instructions are larger than one-word size.
• Instruction may take more than a single clock
cycle to get executed.
• Less number of general-purpose registers as
operations get performed in memory itself.
• Complex Addressing Modes.
• More Data types.

10. Advantages of CISC
• Reduced code size:
• CISC processors use complex instructions that can perform
multiple operations,
• reducing the amount of code needed to perform a task.
• More efficient memory:
• Because CISC instructions are more complex,
• they require fewer instructions to perform complex tasks,
• This can result in more memory-efficient code.
• Widely used:
• CISC processors have been in use for a longer time than
RISC processors,
• so they have a larger user base and more available
software.

11. Disadvantages of CISC
• Slower execution:
• CISC processors take longer to execute instructions
because
• they have more complex instructions and
• need more time to decode them.
• More complex design:
• CISC processors have more complex instruction sets,
• which makes them more difficult to design and
manufacture.
• Higher power consumption:
• CISC processors consume more power than RISC
processors
• because of their more complex instruction sets.

12. Example:
Multiplying Two Numbers in Memory
• The figure in the next slide is a diagram representing the
storage scheme for a generic computer.
• The main memory is divided into locations numbered from
(row) 1: (column) 1 to (row) 6: (column) 4.
• The execution unit is responsible for carrying out all
computations.
• However, the execution unit can only operate on data that
has been loaded into one of the six registers (A, B, C, D, E,
or F).

14. Example:
Multiplying Two Numbers in Memory
• Let's say we want to find the product of two
numbers
– one stored in location 2:3 and another stored in location 5:2
– then store the product back in the location 2:3.

15. Cont. example:
The CISC Approach
• The primary goal of CISC architecture is to complete
a task in as few lines of assembly as possible.
• This is achieved by building processor hardware
– that is capable of understanding and executing a series of
operations.
• For this particular task,
– a CISC processor would come prepared with a specific instruction
(we'll call it "MULT").
• When executed, this instruction
– loads the two values into separate registers,
– multiplies the operands in the execution unit,
– stores the product in the appropriate register.
• Thus, the entire task of multiplying two numbers
can be completed with one instruction:
– MULT 2:3, 5:2

16. • For instance,
– if we let "a" represent the value of 2:3 and "b" represent
the value of 5:2, then this command is identical to the C
statement "a = a * b."
• One of the primary advantages of this system is
– that the compiler has to do very little work to translate a
high-level language statement into assembly.
• Because the length of the code is relatively short,
– very little RAM is required to store instructions.
• The emphasis is put on building complex instructions
directly into the hardware.
Cont. example:
The CISC Approach

17. • RISC processors only use simple instructions that
can be executed within one clock cycle.
• Thus, the "MULT" command described above could
be divided into three separate commands
– "LOAD," which moves data from the memory bank to a
register,
– "PROD," which finds the product of two operands located
within the registers, and
– "STORE,“ which moves data from a register to the memory
banks.
Cont. example:
The RISC Approach

18. • In order to perform the exact series of
steps described in the CISC approach,
a programmer would need to code four
lines of assembly:
– LOAD A, 2:3
– LOAD B, 5:2
– PROD A, B
– STORE 2:3, A
Cont. example:
The RISC Approach

19. • At first, this may seem like a much less
efficient way of completing the
operation.
– Because there are more lines of code,
• more RAM is needed to store the assembly level
instructions.
– The compiler must also perform more
work to convert a high-level language
statement into code of this form.
Cont. example:
The RISC Approach

20. • However, the RISC strategy also brings some very
important advantages.
– 1 Because each instruction requires only one clock
cycle to execute,
• the entire program will execute in approximately the same
amount of time as the multi-cycle "MULT" command.
• These RISC "reduced instructions" require less transistors of
hardware space than the complex instructions, leaving
more room for general purpose registers.
• Because all of the instructions execute in a uniform amount
of time (i.e. one clock), pipelining is possible.
Cont. example:
The RISC Approach

21. • 2- Separating the "LOAD" and "STORE"
instructions actually reduces the amount of
work that the computer must perform.
Cont. example:
The RISC Approach

22. • 3- After a CISC-style "MULT" command is
executed,
– the processor automatically erases the registers.
– If one of the operands needs to be used for
another computation,
• the processor must re-load the data from the memory
bank into a register.
– In RISC, the operand will remain in the register
until another value is loaded in its place.
Cont. example:
The RISC Approach

23. Difference between CISC and RISC
• Here, are important differences between CISC
vs. RISC

24. Difference between CISC and RISC
• RISC • CISC
Focus on software Focus on hardware
Uses only Hardwired control unit
Uses hardwired
& microprogrammed control
unit
Fixed sized instructions Variable sized instructions
An instruction fit in one word.
(mostly 32-bits)
Instructions are larger than the
size of one word
Requires more number of
registers
Requires less number of registers

25. Difference between CISC and RISC
RISC CISC
Simple addressing formats are
supported.
Only base and displacement
addressing is allowed.
Multiple formats are supported for
specifying operands.
A memory operand specifier can
have many different combinations
of displacement, base, and index
register.
Simple and limited addressing
modes.
Complex and more addressing
modes.

26. Difference between CISC and RISC
RISC CISC
It consumes low power. It consumes more/high power.
RISC is highly pipelined. CISC is less pipelined.
RISC required more RAM for
storing codes for storing codes.
CISC required less RAM for storing
codes.
Code size is large Code size is small
An instruction executed in a single
clock cycle
Instruction takes more than one
clock cycle

27. CISC and RISC Convergence
• Because a number of advancements are used by
both RISC and CISC processors,
– the lines between the two architectures have begun
to blur.
• In fact, the two architectures almost seem to
have adopted the strategies of the other.
• Because processor speeds have increased,
– CISC chips are now able to execute more than one
instruction within a single clock.
– This also allows CISC chips to make use of pipelining.

28. CISC and RISC Convergence
• With other technological improvements,
– it is now possible to fit many more transistors on a single chip.
– This gives RISC processors enough space to incorporate more
complicated, CISC-like commands.
• RISC chips also make use of more complicated hardware,
– making use of extra functional units for superscalar execution.
• All of these factors have led some groups to argue that we
are now in a "post-RISC" era,
– in which the two styles have become so similar that
distinguishing between them is no longer relevant.

29. CISC and RISC Convergence
• However, it should be noted that RISC chips still
retain some important behaviors.
• RISC chips
– strictly utilize uniform, single-cycle instructions.
– They also retain the register-to-register, load/store
architecture.
– despite their extended instruction sets,
• RISC chips still have a large number of general purpose
registers.

30. RISC Roadblocks
• Despite the advantages of RISC based
processing,
– RISC chips took over a decade to gain a foothold in the
commercial world.
– This was largely due to a lack of software support.
• although Apple's Power Macintosh line
featured RISC-based chips and Windows NT
was RISC compatible,
– Windows 3.1 and Windows 95, and later versions were
designed with CISC processors in mind.
– Many companies were unwilling to take a chance with the
emerging RISC technology.

31. RISC Roadblocks
• Without commercial interest,
– processor developers were unable to manufacture RISC
chips in large enough volumes to make their price
competitive.
• Another major setback was the presence of
Intel.
– Although their CISC chips were becoming increasingly
awkward and difficult to develop,
• Intel had the resources to plow through development and
produce powerful processors.
– Although RISC chips might surpass Intel's efforts in
specific areas,
• the differences were not great enough to persuade buyers to
change technologies.

32. EPIC
• It stands for Explicitly Parallel Instruction Computing
• The best features of RISC and CISC processors are
combined in the architecture.
• It implements parallel processing of instructions rather
than using fixed-length instructions.
• The working of EPIC processors is supported by using
– a set of complex instructions that contain both basic
instructions as well as the information of execution of
parallel instructions.
• It substantially increases the efficiency of these
processors.
