The word "Reactive" can be confusing. As the founder of the Reactive Amsterdam meetup, I can tell there are two main topics here: Functional Reactive Programming (here with reference to Android) and "Reactive" in the sense of the Reactive Manifesto.

1. Reactive in Android & beyond Rx
Fabio Tiriticco / @ticofab
DAUG Meetup 23 August 2016

2. A little info about myself
Android Engineer
Backend Architect

3. The Reactive Amsterdam meetup
Reactive Amsterdam
• cross-technology
• cross-domain

4. “Reactive” in the vocabulary
Reactive (adjective):
Tending to act in response to an agent or influence

5. Reactive Confusion
Functional Reactive Programming
Reactive in the context of the “Reactive Manifesto”
OR

6. Reactive Programming

7. Why Functional?
More supportive of reasoning about problems in concurrent and
parallelised applications.
• encourages use of pure functions - minimise side effects
• encourages immutability - state doesn’t get passed around
• higher-order functions - reusability and composability

8. Hello, RxJava!
Mobile engineering is hard and there are high expectations.
RxJava is cool because
• it makes it super easy to switch between threads
• lets us deal with data as a stream
• brings us some degree of functional programming

9. Hello, RxJava!
RxJava
RxJs
RxClojure
RxSwift
…
• Asynchronous programming
• Observable streams
Open source libraries for

10. RxJava goes hand in hand with Java8’s Lambdas
new Func1<String, Integer>() {
@Override
public Integer call(String s) {
return s.length();
}
}
(String s) -> {
return s.length();
}
s -> s.length();
Retrolamba plugin for
Android < N

11. RxJava: dealing with a stream of items
class Cat {
...
public String getName()
public Color getColor()
public Picture fetchPicture()
...
}

12. RxJava: dealing with a stream of items
Observable.from(myCats);
cat -> Timber.d(cat.getName())
List<Cat> myCats;
Observable obs =
obs.subscribe( );
Observable.from(myCats)
.subscribe(cat -> Timber.d(cat.getName()));

13. RxJava: work on the stream
Observable.from(myCats)
.subscribe(color -> Timber.d(color));
map: function that takes T => outputs R
.map( )cat -> cat.getColor()

14. RxJava: operators to manipulate the stream
Observable.from(myCats)
.distinct()
.delay(2, TimeUnit.SECONDS)
.filter(cat -> cat.getColor().isWhite())
.map(cat -> cat.getName())
.subscribe(name ->
Timber.d(“a unique, delayed white cat called ” + name));

15. Observable.from(myCats)
.subscribe(
cat -> Timber.d(cat.getName()),
error -> error.printStackTrace(),
() -> Timber.d(“no more cats”)
);
RxJava: subscriber interface
Observable.from(myCats)
.subscribe(
onNext<T>, // next item T
onError, // throwable
onComplete // void
);

16. Observable.from(myCats)
.subscribe(cat -> Timber.d(“cat”));
RxJava: unsubscribe
Subscription subs =
subs.unsubscribe();

17. RxJava: threading
Observable.from(myCats)
.map(cat -> cat.fetchPicture())
.map(picture -> Filter.applyFilter(picture))
.subscribe(
filteredPicture -> display(filteredPicture)
);
.subscribeOn(Schedulers.newThread())
.observeOn(AndroidSchedulers.mainThread())

18. RxJava: other ways of creating Observables
// emits on single item and completes
Observable.just
// emits one item after a certain delay
Observable.timer
// emits a series of integers at regular pace
Observable.interval
.. plus many others, and you can create your own
— BUT TRY NOT TO -

19. RxJava: a few disadvantages
• debugging is more difficult
• methods with side effects
• powerful abstraction - lot of stuff under the hood

20. RxJava: demo with Retrofit & Meetup Streams
http://stream.meetup.com/2/rsvp
Meetup Streaming API

21. RxJava: demo with Meetup Streams

22. RxJava: demo with Retrofit & Meetup Streams
interface MeetupAPI {
@GET("http://stream.meetup.com/2/rsvp")
@Streaming
Observable<ResponseBody> meetupStream();
}

23. RxJava: demo with RSVP Meetup Streams
meetupAPI.meetupStream()
...
.flatMap(responseBody -> events(responseBody.source()))
.map(string -> gson.fromJson(string, RSVP.class))
...
.subscribe(rsvp -> ...);
map: T => R
flatMap: T => Observable<R>

24. RxJava: demo with Meetup Streams

25. RxJava: demo with Meetup Streams
https://github.com/ticofab/android-meetup-streams

26. 2006 2016
Servers ~10 The sky is the limit.
Response time seconds milliseconds
Offline maintenance hours what?
Data amount Gigabytes Petabytes
Machines Single core, little distribution
Must work across async
boundaries (location, threads)
Kind of data Request - response Streams (endless)
Reactive in the sense of the Reactive Manifesto

27. Evolution of internet usage

28. The Reactive traits
A reactive computer system must Trait
React to its users Responsive
React to failure and stay available Resilient
React to varying load conditions Elastic
Its components must react to inputs Message-driven

29. Reactive traits: Responsive
• A human who visits a website
• A client which makes a request to a server
• A consumer which contacts a provider
• . . .
A Reactive system responds to inputs and usage from its user.

30. Reactive traits: Elastic
• Scale OUT and IN: use just the right amount
• Elasticity relies on distribution
• Ensure replication in case of failure
Scale on demand to react to varying load

31. Reactive traits: Resilient
It doesn't matter how great your application is if it doesn't work.
FAULT TOLERANCE RESILIENCEVS

32. Reactive traits: Message Driven
Reactive systems design concentrates on Messages.
Asynchronous messaging enables:
• Separation between components
• Error containment - avoid chain failures
• Domain mapping closer to reality

33. The Reactive Manifesto

34. Reactive Patterns
Design patterns to achieve Reactive principles.
Toolkits exist to implement these patterns.

35. Reactive Pattern: Simple Component Pattern
“One component should do only one thing but do it in full. The aim is to
maximise cohesion and minimise coupling between components.”

36. Reactive Pattern: Simple Component Pattern
Actor 1
Actor 3
Actor 2
• contains state
• has a mailbox to receive
and send messages
• contains behaviour logic
• has a supervisor
Actor model Supervisor

37. Example: Synchronous DB access
Activity DB service DB
List<Cat> cats = new ArrayList<Cat>();
try {
cats = dbService.getAllCats();
} catch (ExampleException e) {
// TODO
}

38. Example: DB access with callback
dbService.getAllCats(new OnCompleted() {
@Override
public void onDataRetrieved(List<Cat> cats) {
// TODO
}
});
Activity DB service DB

39. Example: Async Messaging with Actors
Activity
actor
DB Actor DB

40. Example: Async Messaging with Actors - messages
// message to ask for cats
public class GetCats {
}
// message to send results back
public class Results {
ArrayList<Cat> mCats;
public Results(ArrayList<Cat> cats) {
mCats = cats;
}
}

41. Example: Async Messaging with Actors - behaviour
// db actor pseudocode
@Override
public void onReceive(Message message) {
}
if (message is GetCats) {
}
// retrieve cats from database
c = contentResolver.query(...)
...
// send cats to the Activity
Results result = new Results(cats);
activityAddress.tell(result)

42. Reactive Patterns: Let it crash!
"Prefer a full component restart to complex internal failure handling".
• failure conditions WILL occur
• they might be rare and hard to reproduce
• it is much better to start clean than to try to recover
• …which might be expensive and difficult!

43. Reactive Patterns: Let it crash!
Actor supervision example
Actor 1
Actor 2
Supervisor
WhateverException!
X
Fix or
Restart

44. Reactive Patterns: Let it crash!
• the machine only
accepts exact change

45. Reactive Patterns: Let it crash!
Scenario 1:
The user inserts wrong
amount of coins
X
Error

46. Reactive Patterns: Let it crash!
Scenario 2:
The machine is out of
coffee beans
Failure
( != error)

47. Reactive Patterns: Let it crash!

48. Recap
• Tried to clarify the Reactive Confusion
• Examples of FRP in Android
• Reactive principles from the Reactive Manifesto
• A couple of Design Patterns to achieve them
• (with a glimpse of pseudo implementation)
Reactive Amsterdam

49. Thanks!
@ticofab
All pictures belong
to their respective authors
AMSTERDAM 11-12 MAY 2016

50. Resources
https://github.com/ReactiveX/RxJava/wiki RxJava documentation & wiki
http://rxmarbles.com RxJava operators explained visually
http://www.reactivemanifesto.org The reactive manifesto
https://www.youtube.com/watch?v=fNEZtx1VVAk
https://www.youtube.com/watch?v=ryIAibBibQI
https://www.youtube.com/watch?v=JvbUF33sKf8
The Reactive Revealed series: awesome webinars by the
creators of the Reactive Manifesto.
https://www.manning.com/books/reactive-design-patterns
https://www.youtube.com/watch?v=nSfXcSWq0ug
Reactive design patterns, book and webinar.
