PyConZA'17 Deep Learning for Computer Vision
- 1. Deep Learning for Computer Vision Executive-ML 2017/09/21 Neither Proprietary nor Confidential – Please Distribute ;) Alex Conway alex @ numberboost.com @alxcnwy PyConZA’17
- 2. Hands up!
- 3. Check out the Deep Learning Indaba videos & practicals! http://www.deeplearningindaba.com/videos.html http://www.deeplearningindaba.com/practicals.html
- 4. Deep Learning is Sexy (for a reason!) 4
- 5. Image Classification 5 http://yann.lecun.com/exdb/mnist/ https://github.com/fchollet/keras/blob/master/examples/mnist_cnn.py (99.25% test accuracy in 192 seconds and 70 lines of code)
- 7. Image Classification 7 ImageNet Classification with Deep Convolutional Neural Networks, Krizhevsky et. Al. Advances in Neural Information Processing Systems 25 (NIPS2012)
- 10. Object detection
- 11. Image Captioning & Visual Attention XXX 11 https://einstein.ai/research/knowing-when-to-look-adaptive- attention-via-a-visual-sentinel-for-image-captioning
- 16. 16 Original input Rear Window (1954) Pix2pix output Fully Automated Remastered Painstakingly by Hand https://hackernoon.co m/remastering-classic- films-in-tensorflow- with-pix2pix- f4d551fa0503
- 20. Deep learning is MagicDeep learning is MagicDeep learning is EASY!
- 21. 1. What is a neural network? 2. What is a convolutional neural network? 3. How to use a convolutional neural network 4. More advanced Methods 5. Case studies & applications 21
- 22. 1.What is a neural network?
- 23. What is a neuron? 24 • 3 inputs [x1,x2,x3] • 3 weights [w1,w2,w3] • Element-wise multiply and sum • Apply activation function f • Often add a bias too (weight of 1) – not
- 24. What is an Activation Function? 25 Sigmoid Tanh ReLU Nonlinearities … “squashing functions” … transform neuron’s output NB: sigmoid output in [0,1]
- 25. What is a (Deep) Neural Network? 26 Inputs outputs hidden layer 1 hidden layer 2 hidden layer 3 Outputs of one layer are inputs into the next layer
- 26. How does a neural network learn? 27 • We need labelled examples “training data” • We initialize network weights randomly and initially get random predictions • For each labelled training data point, we calculate the error between the network’s predictions and the ground-truth labels • Use ‘backpropagation’ (chain rule), to update the network parameters (weights + convolutional filters ) in the opposite direction to the error
- 27. How does a neural network learn? 28 New weight = Old weight Learning rate- Gradient of weight with respect to Error( )x “How much error increases when we increase this weight”
- 30. What is a Neural Network? For much more detail, see: 1. Michael Nielson’s Neural Networks & Deep Learning free online book http://neuralnetworksanddeeplearning.com/chap1.html 2. Anrej Karpathy’s CS231n Notes http://neuralnetworksanddeeplearning.com/chap1.html 31
- 31. 2. What is a convolutional neural network?
- 32. What is a Convolutional Neural Network? 33 “like a ordinary neural network but with special types of layers that work well on images” (math works on numbers) • Pixel = 3 colour channels (R, G, B) • Pixel intensity ∈[0,255] • Image has width w and height h • Therefore image is w x h x 3 numbers
- 33. 34 This is VGGNet – don’t panic, we’ll break it down piece by piece Example Architecture
- 34. 35 This is VGGNet – don’t panic, we’ll break it down piece by piece Example Architecture
- 37. New Layer Type: Convolutional Layer 38 • 2-d weighted average when multiply kernel over pixel patches • We slide the kernel over all pixels of the image (handle borders) • Kernel starts off with “random” values and network updates (learns) the kernel values (using backpropagation) to try minimize loss • Kernels shared across the whole image (parameter
- 38. Many Kernels = Many “Activation Maps” = Volume 39http://cs231n.github.io/convolutional-networks/
- 39. New Layer Type: Convolutional Layer 40
- 40. Convolutions 41 https://github.com/fchollet/keras/blob/master/examples/conv_filter_visuali zation.py
- 41. Convolutions 42
- 42. Convolutions 43
- 43. Convolutions 44
- 44. Convolution Learn Hierarchical Features 45
- 45. New Layer Type: Max Pooling 47
- 46. New Layer Type: Max Pooling • Reduces dimensionality from one layer to next • …by replacing NxN sub-area with max value • Makes network “look” at larger areas of the image at a time • e.g. Instead of identifying fur, identify cat • Reduces overfitting since losing information helps the network generalize 48http://cs231n.github.io/convolutional-networks/
- 47. New Layer Type: Max Pooling 49
- 48. Stack Conv + Pooling Layers and Go Deep 50 Convolution + max pooling + fully connected + softmax
- 49. 51 Stack Conv + Pooling Layers and Go Deep Convolution + max pooling + fully connected + softmax
- 50. 52 Stack These Layers and Go Deep Convolution + max pooling + fully connected + softmax
- 51. 53 Stack These Layers and Go Deep Convolution + max pooling + fully connected + softmax
- 52. 54 Flatten the Final “Bottleneck” layer Convolution + max pooling + fully connected + softmax Flatten the final 7 x 7 x 512 max pooling layer Add fully-connected dense layer on top
- 53. 55 Bringing it all together Convolution + max pooling + fully connected + softmax
- 54. Softmax Convert scores ∈ ℝ to probabilities ∈ [0,1] Final output prediction = highest probability class 56
- 55. Bringing it all together 57 Convolution + max pooling + fully connected + softmax
- 56. We need labelled training data!
- 57. ImageNet 59 http://image-net.org/explore 1000 object categories 1.2 million training images
- 58. ImageNet 60
- 59. ImageNet 61
- 60. ImageNet Top 5 Error Rate 62 Traditional Image Processing Methods AlexNet 8 Layers ZFNet 8 Layers GoogLeNe t 22 Layers ResNet 152 Layers SENet Ensamble TSNet Ensamble
- 61. 3. How to use a convolutional neural network
- 62. Using a Pre-Trained ImageNet-Winning CNN 64 • We’ve been looking at “VGGNet” • Oxford Visual Geometry Group (VGG) • ImageNet 2014 Runner-up • Network is 16 layers (deep!) • Easy to fine-tune https://blog.keras.io/building-powerful-image-classification- models-using-very-little-data.html
- 63. Example: Classifying Product Images 65 https://github.com/alexcnwy/CTDL_CNN_TALK_20 170620 Classifying products into 9 categories
- 64. 66 https://blog.keras.io/building-powerful-image-classification-models-using-very-little- data.html Start with Pre-Trained ImageNet Model Consumers vs Producers of Machine Lea
- 65. 67
- 66. “Transfer Learning” is a game changer
- 67. Fine-tuning A CNN To Solve A New Problem • Cut off last layer of pre-trained Imagenet winning CNN • Keep learned network (convolutions) but replace final layer • Can learn to predict new (completely different) classes • Fine-tuning is re-training new final layer - learn for new task 69
- 68. Fine-tuning A CNN To Solve A New Problem 70
- 71. Fine-tuning A CNN To Solve A New Problem • Fix weights in convolutional layers (set trainable=False) • Remove final dense layer that predicts 1000 ImageNet classes • Replace with new dense layer to predict 9 categories 73 88% accuracy in under 2 minutes for classifying products into categories Fine-tuning is awesome! Insert obligatory brain analogy
- 73. Visual Similarity 75 • Chop off last 2 VGG layers • Use dense layer with 4096 activations • Compute nearest neighbours in the space of these activations https://memeburn.com/2017/06/spree-image-search/
- 75. 77 Input Image not seen by model Results Top 10 most “visually similar”
- 76. 78 Final Convolutional Layer = Semantic Vector • The final convolutional layer encodes everything the network needs to make predictions • The dense layer added on top and the softmax layer both have lower dimensionality
- 78. Use a Better Architecture (or all of them!) 80 “Ensambles win” learn a weighted average of many models’ predictions
- 79. cs231n.stanford.edu/slides/2017/cs231n_2017_lecture11.pdf There are MANY Computer Vision Tasks
- 80. Long et al. “Fully Convolutional Networks for Semantic Segmentation” CVPR 2015 Noh et al. Learning Deconvolution Network for Semantic Segmentation. IEEE on Computer Vision 2016 Semantic Segmentation
- 82. http://blog.romanofoti.com/style_transfer/ Johnson et al. Perceptual losses for real-time style transfer and super-resolution. 2016 Style Transfer f ( ) =,
- 85. This image is 3.8 kb Super-Resolution
- 87. Image Captioning https://einstein.ai/research/knowing-when-to-look-adaptive-attention-via-a-visual-sentinel-for-image- captioning Karpathy & Li. IEEE Transactions on Pattern Analysis and Machine Intelligence, 39(4), pp. 664–676
- 91. king + woman – man ≈ queen 95 Frome et al. (2013) ‘DeViSE: A Deep Visual-Semantic Embedding Model’, Advances in Neural Information Processing Systems, pp. 2121–2129 CNN + Word2Vec = AWESOME
- 92. DeViSE: A Deep Visual-Semantic Embedding Model XXX 96 Before: Encode labels as 1-hot vector
- 93. DeViSE: A Deep Visual-Semantic Embedding Model XXX 97 After: Encode labels as word2vec vectors (FROM A SEPARATE MODEL) Can look these up for all the nouns in ImageNet 300-d word2vec vectors
- 94. DeViSE: A Deep Visual-Semantic Embedding Model wv(fish)+ wv(net) 98 https://www.youtube.com/watch?v=uv0gmrXSXVg 2 wv* = …get nearest neighbours to wv*
- 95. 5. Case Studies
- 96. Estimating Accident Repair Cost from Photos TODO 100 Prototype for large SA insurer Detect car make & model from registration disk Predict repair cost using learned
- 97. Image & Video Moderation TODO 101 Large international gay dating app with tens of millions of users uploading hundreds-of-thousands of photos per day
- 99. m Counting People TODO Count shoppers, segment on age & gender facial recognition loyalty is next
- 100. Counting Cars TODO
- 101. Detecting Potholes
- 102. Extracting Data from Product Catalogues
- 103. Real-time ATM Video Classification 107
- 105. We are hiring! alex @ numberboost.com
- 106. GET IN TOUCH! Alex Conway alex @ numberboost.com @alxcnwy
Editor's Notes
- SENet = Squeeze and Excitation Net. TSNet = Trimps-Soushen
- Gets 88% accuracy in classifying products into categories
