Pipework
The little SDN container framework
that you should NOT use

Jérôme
Petazzoni
(@jpetazzo)
 Grumpy French DevOps
- Go away or I will replace you
with a very small shell script
 Runs everything in containers
- Docker-in-Docker
- VPN-in-Docker
- KVM-in-Docker
- Xorg-in-Docker
- ...

Use cases
● Performance
– Linux bridge, iptables, conntrack... Ohnoes!
● Integration into existing networks
– VLAN, bonding...
– IP addr management
● Work at L2/L3 instead of L4
– Ethernet/IP vs TCP, UDP

Modus Operandi
● Create network interfaces
● Move them to containers
(while they're running)
● Configure network interfaces
(from outside)
● Shell script

Upsides of /bin/sh
● Easy to understand
● Easy to rip out the bits you (don't) need
● Most things we do require exec anyway
(ip, route, brctl, etc)
● Complicated stuff is hard to implement
(avoid feature creep, e.g. IPAM)

Features
● Start a container:
docker run --name db mysql
● Give it an IP address:
pipework eth0 mysql 10.1.1.1/24

Features
● Start a container:
docker run --name db mysql
● Give it an IP address:
pipework eth0 mysql 10.1.1.1/24
^^^^
● Physical eth0 on the machine

Features
● Start a container:
docker run --name db mysql
● Give it an IP address:
pipework br0 mysql 10.1.1.1/24
^^^
● Pre-existing bridge

Features
● Start a container:
docker run --name db mysql
● Give it an IP address:
pipework ovsbr0 mysql 10.1.1.1/24
^^^^^^
● Open vSwitch bridge

Features
● Start a container:
docker run --name db mysql
● Give it an IP address:
pipework ovsbr0 mysql dhcp
^^^^
● DHCP

Features
● Start a container:
docker run --name db mysql
● Give it an IP address:
pipework ovsbr0 mysql dhcp @10
^^^
● VLAN

Features
● Fixed address or DHCP
● Random MAC or fixed MAC
● Change netmask, default route
● Linux bridges, OVS bridges
● IP over Infiniband
● Multiple interfaces

Pipework:
● Will not be integrated into Docker
(probably)
● Is not necessary anymore in many cases
(thanks to host networking)
● Is not actively maintained
(but I'll happily merge PRs)

What do?
● Use it as a big toolbox
● Understand how things work
● Possibly extract what you need
● Contribute to Docker instead

Possible improvements
● Don't require host-side tooling anymore
● Allow operation over Docker API
● A small POC is available at:
https://github.com/jpetazzo/plumber/

A brighter future
● Native Docker Multi-Host Networking
https://github.com/docker/docker/issues/8951
● Docker Network Drivers
https://github.com/docker/docker/issues/8952
