WIFI SOLUTION
by Phoenixmedia.com.vn
TSN Airport
Airport Capacity
Wifi Estimation
• Domestic Terminal: avg 500
concurrent users, peak 1000
concurrent users
• International Terminal: avg 350
concurrent users, peak 500
concurrent users
Wifi Challenges
• High density wifi network
• Controllable wifi network
• Congestion Protect
• Multi services
• Multi Zones with different guest
classes
Solution
• Establish a controllable wifi network
Solutions (cont.)
• Deploy a series of indoor and outdoor
access point (AP)
• All AP(s) are controlled by a
Controller for monitoring and
configuration
• Deploy multi SSIDs, each zone has
one SSID
4IPNET Controller
• Controllers have
advanced features such
as centralized AP
discovery, automatic AP
provisioning, load
balancing, and detailed
status monitoring
4IPNET Indoor AP
EAP767:
• Very high throughput
• 802.11 abgn/ac: Dual band
• Ready for high density environment
• POE, Enterprise grade
EAP767
4IPNET Controller
WHG405
• Manage up to 150 AP(s)
• Multi Service Zone: One wifi system –
multi wifi networks.
• Network administrators can configure
traffic shaping profiles, track previous
network usage, perform system
backup and restore, and much more
WHG405
Deploy multi SSID
With one wifi system, we can deploy
multi wifi network:
• Wifi Network for Staff
• Wifi Network for Admin
• Wifi Network for VIP
• Wifi Network for Guest (with
marketing)
Quotation
No. Item Desc Qty Price
(USSD)
Amount *
(USSD)
1 WHG405 4IPNET Wifi
Controller
01 2,100 2,100
2 EAP767 Enterprise grade
Indoor Access Point
60 350 21,000
3 FS970m/
24PS
Allied Telesis POE
Switch: provide
energy for AP
04 865 3,460
4 PM291G Gateway for Wifi
Marketing
1 5,000 5,000
Total : 31,560
*: VAT excluded
Useful approaches
PhoenixMedia
02 Thi Sách, phường Bến Nghé, quận 1, Tp Hồ Chí Minh
Tel: 08-668-111-83
Mail: khoadt@phoenixmedia.com.vn

Phoenix Media JSC-Phoenix wifi solution
