This document discusses enabling technologies for energy routing monitoring, network installation, and predictive maintenance. It describes a system architecture using infrared thermography, augmented reality, thermal simulation software, and data mining algorithms. Thermography is used for installation testing and predictive maintenance, while augmented reality can be applied to training and verifying equipment status. Thermal simulation software models indoor and outdoor energy distribution to support design, verification, and predictive maintenance based on performance comparisons. Data mining algorithms like k-means clustering and neural networks further analyze sensor and image data for predictive maintenance.
