Operationalizing yara
- 1. OPERATIONALIZING YARA JUNE 2015 CIRCLE CITY CON 2015
- 2. CircleCityCon 2015 -‐ TLP:WHITE “YARA is to files what Snort is to network traffic.” -- Victor Manual Alvarez, YARA Developer
- 3. Bio CircleCityCon 2015 -‐ TLP:WHITE Chad Robertson Threat Researcher Fidelis Cybersecurity YARA Exchange since 2012 CCE, GCIH Gold, GPEN Gold, GCFA Gold, CISA Prior incident response lead Authored research papers on HIPS, memory forensics, and malicious PDF obfuscation
- 4. Agenda CircleCityCon 2015 -‐ TLP:WHITE YARA Atoms Malware indicators: Network StaTc Memory
- 5. CircleCityCon 2015 -‐ TLP:WHITE YARA Atoms
- 6. CircleCityCon 2015 -‐ TLP:WHITE YARA -‐ Atoms Atoms are undivided substrings found in a regexps and hex strings. { 01 02 03 04 05 ?? 06 07 08 [1-2] 09 0A } /abc.*ed[0-9]+fgh/ Source: https://code.google.com/p/yara-project/source/browse/trunk/libyara/atoms.c?r=261
- 7. CircleCityCon 2015 -‐ TLP:WHITE YARA -‐ Atoms Source: https://code.google.com/p/yara-project/source/browse/trunk/libyara/atoms.c?r=261
- 8. CircleCityCon 2015 -‐ TLP:WHITE YARA -‐ Atoms
- 9. CircleCityCon 2015 -‐ TLP:WHITE YARA -‐ Atoms /(abc|efg)/ Sometimes a single atom is enough (like in the previous example "abc" is enough for finding /abc.*ed[0-9]+fgh/), but sometimes a single atom isn't enough like in the regexp /(abc|efg)/. In this case YARA must search for both "abc" AND "efg" and fully evaluate the regexp whenever one of those atoms is found. Source: https://code.google.com/p/yara-project/source/browse/trunk/libyara/atoms.c?r=261
- 10. CircleCityCon 2015 -‐ TLP:WHITE YARA -‐ Atoms Atom Tree: /Look(at|into)this/ -AND |- "Look" | |- OR | | | |- "at" | - "into" | - "this” In the regexp /Look(at|into)this/ YARA can search for "Look", or search for "this", or search for both "at" and "into". Source: https://code.google.com/p/yara-project/source/browse/trunk/libyara/atoms.c?r=261
- 11. CircleCityCon 2015 -‐ TLP:WHITE YARA -‐ Atoms {00 00} {01 01 01 01} {01 02 03 04} Source: https://code.google.com/p/yara-project/source/browse/trunk/libyara/atoms.c?r=261
- 12. CircleCityCon 2015 -‐ TLP:WHITE YARA -‐ Atoms {00 00} Atom 00 00 has a very low quality, because it's only two bytes long and both bytes are zeroes. {01 01 01 01} Atom 01 01 01 01 is better but still not optimal, because the same byte is repeated. {01 02 03 04} Atom 01 02 03 04 is an optimal one. Source: https://code.google.com/p/yara-project/source/browse/trunk/libyara/atoms.c?r=261
- 13. CircleCityCon 2015 -‐ TLP:WHITE YARA -‐ Atoms The worse strings are those that contain no atoms at all: /d.*d/ /[A-Za-z]{50,100}w+/ Source: https://code.google.com/p/yara-project/source/browse/trunk/libyara/atoms.c?r=261
- 14. CircleCityCon 2015 -‐ TLP:WHITE YARA -‐ Atoms FASTEST - only one atom is generated $s1 = "cmd.exe" (ascii only) $s2 = "cmd.exe" ascii (ascii only, same than $s1) $s3 = "cmd.exe" wide (UTF-16 only) FAST - two atoms will be generated $s4 = "cmd.exe" ascii wide (both ascii and UTF-16) SLOW - many atoms will be generated $s5 = "cmd.exe" nocase (all different cases, e.g. "Cmd.exe", "cMd.exe", "cmD.exe" .. https://gist.github.com/Neo23x0/e3d4e316d7441d9143c7
- 15. CircleCityCon 2015 -‐ TLP:WHITE Malware Network Indicators
- 16. CircleCityCon 2015 -‐ TLP:WHITE C2
- 17. CircleCityCon 2015 -‐ TLP:WHITE B1 1C 6C B1 F4 10 22 11
- 18. CircleCityCon 2015 -‐ TLP:WHITE rule demo { strings: $a1 = {b11c6cb1f4102211} condition: all of them } B1 1C 6C B1 F4 10 22 11
- 19. CircleCityCon 2015 -‐ TLP:WHITE rule demo_adv { strings: $a1 = {b11c6cb1f4102211} condiAon: ($a1 in (0..11)) and filesize < 32 } $ yara demo.yar pcaps/ demo pcaps//0471c3cf5192f2ff76adae77a087d3ef533e160d4686ff132569d99ec2ad6ba2 demo pcaps//d4ee1078b9545c876662d942e32024cfa1f63df3bQ401db60404f4359e73f16 demo pcaps//5a445083067de28f42e799594ecdc72a51ec27333e31b71dc25623aaa12e2003 demo pcaps//5a56ad8b79d505013e964c3725fefc4fa03f565482bee3cf0c3ecbfef146d639 $ yara demo.yar flows/ demo flows//010.000.002.015.01044-‐209.126.109.113.00443 demo flows//010.000.002.015.01057-‐005.254.115.009.00777 demo flows//010.000.002.015.01056-‐005.254.098.040.00777 demo flows//010.000.002.015.01043-‐209.126.109.113.00443 demo flows//010.000.002.015.01055-‐005.254.115.009.00443 demo flows//010.000.002.015.01044-‐209.239.122.212.00443 demo flows//010.000.002.015.01048-‐209.239.122.212.00443 demo flows//010.000.002.015.01051-‐005.254.115.024.00443 demo flows//010.000.002.015.01049-‐209.239.122.212.00443 demo flows//010.000.002.015.01050-‐005.254.115.009.00443 demo flows//010.000.002.015.01055-‐005.254.098.040.00777 demo flows//010.000.002.015.01047-‐209.126.109.113.00443 demo flows//010.000.002.015.01053-‐209.239.122.212.00443 demo flows//010.000.002.015.01054-‐209.239.122.212.00443 demo flows//010.000.002.015.01045-‐209.126.109.113.00777 $ yara demo-‐adv.yar pcaps/ $ yara demo-‐adv.yar flows/ demo_adv flows//010.000.002.015.01044-‐209.126.109.113.00443 demo_adv flows//010.000.002.015.01056-‐005.254.098.040.00777 demo_adv flows//010.000.002.015.01043-‐209.126.109.113.00443 demo_adv flows//010.000.002.015.01044-‐209.239.122.212.00443 demo_adv flows//010.000.002.015.01048-‐209.239.122.212.00443 demo_adv flows//010.000.002.015.01047-‐209.126.109.113.00443 demo_adv flows//010.000.002.015.01055-‐005.254.098.040.00777 demo_adv flows//010.000.002.015.01053-‐209.239.122.212.00443 demo_adv flows//010.000.002.015.01054-‐209.239.122.212.00443 B1 1C 6C B1 F4 10 22 11
- 20. CircleCityCon 2015 -‐ TLP:WHITE Malware StaTc Indicators
- 21. CircleCityCon 2015 -‐ TLP:WHITE
- 22. CircleCityCon 2015 -‐ TLP:WHITE B1 1C 6C B1 F4 10 22 11
- 23. CircleCityCon 2015 -‐ TLP:WHITE B1 1C 6C B1 F4 10 22 11
- 24. CircleCityCon 2015 -‐ TLP:WHITE rule staAc { strings: $a1 = { b1 1c 6c b1 ?? ?? ?? f4 10 22 11 } condiAon: all of them } 26 matches: demo:6bd9715444Q8e24e41147231afd6bec508cb068615a1bbaf92c0cafc6b3412c demo:0022ee274f8faece15b65783b0119ffc04f93debde5456e8261ae8e4905550d6 demo:158b53bbc5327dac2d046b476a0ea060b651855ff26bd4e4376b94e1bc723aed demo:45bcc20a5d87198cff82418c2cc9a8face30060454fe4b9b89607b6ef578a57b demo:5d085b2449dee95646c8783d150dbe4d4792943f841e560410399708de3b01e7 demo:c35e22fc93691a8594db4db66c36eba5b9c860bd01cbac510868fa4d9c6e36a8 demo:005418c326f23c8db33d337c242a87297f3e7d736120b1286f48ee01de3123e2 demo:7eaW76de4b17cb9bf25324d2c35b3294bf77c6b3483eea6f193efc62f6f159 demo:0c388c0308663bd90de9bf75cb2267087c8f08fe57bb359a095e679b2cbdf151 demo:f1e18d0d3b90f141eee92ae826a0b51e964e6c11521d2f49506d8920584af8b3 demo:db324b966d63eda1a78a346b0327b9c89675aa2a668bc58e3a15ef3d4e7a4b78 demo:9ed9f814e00de3Q30a569323a2602fdbf0dee6f29cde13d6afe632461cbfaea demo:91e7fd3bc60abf1a8521d20181356a636d552b327dade0f2aea9138844caf0b2 demo:f38798096456a264d758d686fd7c6a7a23a0fa97eca1e44cae9fdd4e41d707fc demo:2f9294b516d7edf639ddb38d994afc218f05423c7a869edb1b0a9aa715092a75 demo:1644130e603d418493c89cad8bf6f4de4b9ad761248d3481e16304a64c58f66d demo:1950b0a07cabc27f34c7ef3b7356460f145818f4760bbe94fd5ddeec0454Q84 demo:dfa32564b9f35225fd7f83812ef046d142af0aQ428050ced67ae628498e09f2 demo:4aeeaaec315b4856594ff823898e7603bb7d050397aaa8a7e3484b09b2f0a5ab demo:fef057e51a7e914bf84688c4df7428770bbd22b7156b8989cb84895f4fe6b62c demo:f81e5b770eee63b4cbf026df01209724d89a6f92fed4b63885a1020dd9003e16 demo:32d09412aa6b9d1b772b266723fd520bdea5846ac6f7b16a2b4fe1b0ae2839ab demo:d6981c7a03505a67e020c97e345097248b455b65206efae768cce72a4b71cba7 demo:b85aa01d4818b397cc4a0c7274fda01697b4aac5d396155391b424e84eccb970 demo:5a56ad8b79d505013e964c3725fefc4fa03f565482bee3cf0c3ecbfef146d639 demo:45a1ece87537ed1ba89ba5caeff536462895a86d7eacf59ed9c48fceb3fd5cd5 B1 1C 6C B1 F4 10 22 11
- 25. CircleCityCon 2015 -‐ TLP:WHITE rule staAc { strings: $a1 = { b1 1c 6c b1 ?? ?? ?? f4 10 22 11 } condiAon: all of them } B1 1C 6C B1 F4 10 22 11
- 26. CircleCityCon 2015 -‐ TLP:WHITE Malware Memory Indicators
- 27. CircleCityCon 2015 -‐ TLP:WHITE $ yara -‐s demo.yar preso.mem demo preso.mem 0x7e236036:$a1: B1 1C 6C B1 F4 10 22 11 0x7e483036:$a1: B1 1C 6C B1 F4 10 22 11 0x7e48b036:$a1: B1 1C 6C B1 F4 10 22 11 0x7e493036:$a1: B1 1C 6C B1 F4 10 22 11 0x7e49b036:$a1: B1 1C 6C B1 F4 10 22 11 0x7e4bb036:$a1: B1 1C 6C B1 F4 10 22 11 0x7faa1200:$a1: B1 1C 6C B1 F4 10 22 11 rule network { strings: $a1 = {b11c6cb1f4102211} condition: all of them } B1 1C 6C B1 F4 10 22 11
- 28. CircleCityCon 2015 -‐ TLP:WHITE $ yara -‐s staAc.yar preso.mem demo preso.mem 0x16a304ee:$a1: B1 1C 6C B1 C7 46 06 F4 10 22 11 0x1e141aae:$a1: B1 1C 6C B1 C7 46 06 F4 10 22 11 0x1fafab96:$a1: B1 1C 6C B1 C7 46 06 F4 10 22 11 0x1fe42b96:$a1: B1 1C 6C B1 C7 46 06 F4 10 22 11 0x45aeeb96:$a1: B1 1C 6C B1 C7 46 06 F4 10 22 11 0x48d90f96:$a1: B1 1C 6C B1 C7 46 06 F4 10 22 11 rule staAc { strings: $a1 = { b1 1c 6c b1 ?? ?? ?? f4 10 22 11 } condiAon: all of them } B1 1C 6C B1 F4 10 22 11
- 29. CircleCityCon 2015 -‐ TLP:WHITE Summary YARA atoms Malware Indicators -‐> Network -‐> StaTc -‐> Memory
- 30. CircleCityCon 2015 -‐ TLP:WHITE YARA 3.3 Modules PE ELF Cuckoo Magic Hash Math
- 31. Input a directory of malware samples and it outputs Yara rules that try to avoid known goodware strings and a[empts to use blacklisted strings from PE Studio YarGen hYps://github.com/Neo23x0/yarGen CircleCityCon 2015 -‐ TLP:WHITE
- 32. CircleCityCon 2015 -‐ TLP:WHITE References YARA Exchange: http://www.deependresearch.org/2012/08/yara-signature- exchange-google-group.html MD5s: demo:6bd9715444Q8e24e41147231afd6bec508cb068615a1bbaf92c0cafc6b3412c demo:0022ee274f8faece15b65783b0119ffc04f93debde5456e8261ae8e4905550d6 demo:158b53bbc5327dac2d046b476a0ea060b651855ff26bd4e4376b94e1bc723aed demo:45bcc20a5d87198cff82418c2cc9a8face30060454fe4b9b89607b6ef578a57b demo:5d085b2449dee95646c8783d150dbe4d4792943f841e560410399708de3b01e7 demo:c35e22fc93691a8594db4db66c36eba5b9c860bd01cbac510868fa4d9c6e36a8 demo:005418c326f23c8db33d337c242a87297f3e7d736120b1286f48ee01de3123e2 demo:7eaW76de4b17cb9bf25324d2c35b3294bf77c6b3483eea6f193efc62f6f159 demo:0c388c0308663bd90de9bf75cb2267087c8f08fe57bb359a095e679b2cbdf151 demo:f1e18d0d3b90f141eee92ae826a0b51e964e6c11521d2f49506d8920584af8b3 demo:db324b966d63eda1a78a346b0327b9c89675aa2a668bc58e3a15ef3d4e7a4b78 demo:9ed9f814e00de3Q30a569323a2602fdbf0dee6f29cde13d6afe632461cbfaea demo:91e7fd3bc60abf1a8521d20181356a636d552b327dade0f2aea9138844caf0b2 demo:f38798096456a264d758d686fd7c6a7a23a0fa97eca1e44cae9fdd4e41d707fc demo:2f9294b516d7edf639ddb38d994afc218f05423c7a869edb1b0a9aa715092a75 demo:1644130e603d418493c89cad8bf6f4de4b9ad761248d3481e16304a64c58f66d demo:1950b0a07cabc27f34c7ef3b7356460f145818f4760bbe94fd5ddeec0454Q84 demo:dfa32564b9f35225fd7f83812ef046d142af0aQ428050ced67ae628498e09f2 demo:4aeeaaec315b4856594ff823898e7603bb7d050397aaa8a7e3484b09b2f0a5ab demo:fef057e51a7e914bf84688c4df7428770bbd22b7156b8989cb84895f4fe6b62c demo:f81e5b770eee63b4cbf026df01209724d89a6f92fed4b63885a1020dd9003e16 demo:32d09412aa6b9d1b772b266723fd520bdea5846ac6f7b16a2b4fe1b0ae2839ab demo:d6981c7a03505a67e020c97e345097248b455b65206efae768cce72a4b71cba7 demo:b85aa01d4818b397cc4a0c7274fda01697b4aac5d396155391b424e84eccb970 demo:5a56ad8b79d505013e964c3725fefc4fa03f565482bee3cf0c3ecbfef146d639 demo:45a1ece87537ed1ba89ba5caeff536462895a86d7eacf59ed9c48fceb3fd5cd5
