Vibration is a common issue on ships that can cause increased stresses, energy losses, wear, and fatigue. There are two main types of vibration - free vibration that occurs when a system is set in motion and allowed to vibrate at its natural frequency, and forced vibration caused by an external alternating force. Ship vibrations are typically from engines, propellers, and wave/sea motion. Reducing vibration through proper design and maintenance can increase machinery life by lowering dynamic forces and vibration amplitudes. Vibration monitoring is used to detect potential issues early through measuring characteristics like frequency, displacement, velocity, and acceleration.
Ship vibrations can originate from internal or external sources. Internal sources include unbalanced machinery like engines or rotating equipment. External sources include hydrodynamic loads on propellers or slamming forces.
The ship responds to excitation forces with both local and hull vibrations. Hull vibrations involve the entire ship and include bending, twisting, and shearing modes similar to a beam. Natural frequencies associated with these modes increase with the number of nodes.
To avoid dangerous hull vibrations, exciting forces should be avoided at frequencies close to the ship's natural frequencies, which can be estimated using beam theory formulas involving properties like length, mass, and stiffness.
