Евгений Бова: "Modularity in Java: introduction to Jigsaw through the prism of OSGI"
- 1. www.luxoft.com Modularity in Java: introduction to Jigsaw through the prism of OSGI Eugene Bova Software Developer at Luxoft July 2016
- 2. www.luxoft.com Short bio Java Developer at Luxoft 5 years of experience in Java Involved in the development of: - a huge OSGI based desktop application (600+ modules, 100+ thirdparty modules) - a middle-size web application
- 4. www.luxoft.com What is a module? com.example.alpha.Alpha com.example.alpha.AlphaFactory … com.example.alpha In Java modules are typically packaged as JAR files
- 5. www.luxoft.com SO, WHAT’S THE PROBLEM?
- 6. www.luxoft.com SO, WHAT’S THE PROBLEM? MODULES ARE NOTE ENCAPSULATED
- 7. www.luxoft.com Java Accessibility 1995-2016 public protected <package> private
- 8. www.luxoft.com Java Accessibility 1995-2016 public – accessible by every module protected – accessible by every module <package> - accessible by every module (unless package is sealed) private – accessible by current module
- 9. www.luxoft.com Problem statement Modules are not encapsulated - Non-API classes can be accessible by everyone Platform integrity can be violated - sun.misc.Unsafe – brings superpower. Classpath brings chaos - Class lookup is unintuitive - Class lookup is slow
- 11. www.luxoft.com
- 12. www.luxoft.com Goals of Jigsaw Reliable dependencies Strong encapsulation for modules Hide non-API types in JRE Improved performance A scalable Java SE Platform
- 13. www.luxoft.com Module Descriptor module com.example.alpha { } src/module-info.java src/com/example/alpha/Alpha.java src/com/example/alpha/AlphaFactory.java
- 14. www.luxoft.com module com.example.alpha { requires com.example.beta } com.example.alpha com.example.beta module com.example.beta { }
- 15. www.luxoft.com module com.example.alpha { requires com.example.beta } com.example.alpha com.example.beta module com.example.beta { exports com.example.beta.api // exports com.example.beta.internal.impl }
- 16. www.luxoft.com … Bundle-SymbolicName: com.example.alpha Require-Bundle: com.example.beta com.example.alpha com.example.beta … Bundle-SymbolicName: com.example.beta Export-Package: com.example.beta OSGI MANIFEST.MF
- 17. www.luxoft.com module com.example.alpha { requires com.example.beta requires java.sql } com.example.alpha java.sqlcom.example.beta
- 21. www.luxoft.com com.example.alpha java.sql java.logging java.sql.Driver d = … d.getParentLogger().log(…); package java.sql; public interface Driver { public java.util.Logger Logger getParentLogger(); // other methods //… }
- 22. www.luxoft.com com.example.alpha java.sql java.logging module com.example.alpha { requires java.sql; requires java.logging; }
- 23. www.luxoft.com com.example.alpha java.sql java.logging module java.sql { requires public java.logging; … } - reexports all accessible packages to downstream client - allows refactoring - in OSGI it’s called “reexport”
- 25. www.luxoft.com Qualified exports – exports for internal API module java.base { … exports sun.reflect; }
- 26. www.luxoft.com Qualified exports – exports for internal API module java.base { … exports sun.reflect to java.corba, java.logging, java.sql, java.sql.rowset, jdk.scripting.nashorn; } For modules collaborating at the implementation level Introduces tight couplings Can inadvertently make internal types accessible to modules other than those intended No analogy available in OSGI
- 27. www.luxoft.com Java Accessibility in JDK 9 public – accessible by every module public – accessible by specific module public – accessible within a module protected <package> private
- 30. www.luxoft.com Services module com.example.network.app { requires com.socket; } org.fastsocketcom.socket com.example.network.app
- 31. www.luxoft.com Services module com.example.network.app { requires com.socket; } org.fastsocketcom.socket com.example.network.app module com.socket { exports com.socket.api; exports com.socket.spi; uses com.socket.spi.NetworkSocketProvider } // com.socket.api.NetworkSocket.open(…) ServiceLoader<NetworkSocketProvider> sl = ServiceLoader.load(NetworkSocketProvider.class); Iterator<NetworkSocketProvider> it = serviceLoader.iterator();
- 32. www.luxoft.com Services module com.example.network.app { requires com.socket; } org.fastsocketcom.socket com.example.network.app module com.socket { exports com.socket.api; exports com.socket.spi; uses com.socket.spi.NetworkSocketProvider } module org.fastsocket { requires com.socket; provides com.socket.spi.NetworkSocketProvider with org.fastsocket.FastNetworkSocketProvider; } // com.socket.api.NetworkSocket.open(…) ServiceLoader<NetworkSocketProvider> sl = ServiceLoader.load(NetworkSocketProvider.class); Iterator<NetworkSocketProvider> it = serviceLoader.iterator();
- 33. www.luxoft.com A few advanced concepts…
- 34. www.luxoft.com Optional dependencies module org.joda.time { requires org.joda.convert; }
- 35. www.luxoft.com Optional dependencies module org.joda.time { requires static org.joda.convert; } Required at compile time Optional at runtime NoClassFoundException is possible Rarely used in OSGI. Not available in JDK build yet! http://mail.openjdk.java.net/pipermail/jpms-spec-experts/2016-June/000306.html - Discussion
- 36. www.luxoft.com Dynamic exports module org.example.app { requires hibernate.core; requires hibernate.entitymanager; exports com.example.app.model; }
- 37. www.luxoft.com Dynamic exports module org.example.app { requires hibernate.core; requires hibernate.entitymanager; exports dynamic com.example.app.model; } Package is accessible at runtime only Package presence is checked at compile time “exports dynamically … to ..” is possible No analogy available in OSGI. This is handled differently. Not available in JDK build yet! http://mail.openjdk.java.net/pipermail/jpms-spec-experts/2016-June/000307.html - Discussion
- 40. www.luxoft.com Compilation com.example.alpha com.example.beta $ javac -d mods/com.example.beta src/module-info.java src/com/example/beta/Beta.java
- 41. www.luxoft.com Compilation com.example.alpha com.example.beta $ javac -d mods/com.example.beta src/module-info.java src/com/example/beta/Beta.java $ javac -d mods/com.example.alpha -modulepath mods src/module-info.java src/com/example/alpha/Main.java
- 42. www.luxoft.com Launching $ java -modulepath mods -m com.example.alpha/com.example.alpha.Main module name main class
- 43. www.luxoft.com Things to take away - Jigsaw and OSGI aim to solve similar issues (sometimes in a similar way) - OSGI can’t solve Platform integrity issues - Jigsaw is static. OSGI is really dynamic. - OSGI has more features. Jigsaw is much simpler - It’s not a goal for Jigsaw to substitute OSGI!
- 44. www.luxoft.com WHAT ABOUT VERSIONING, DUDE???
- 46. www.luxoft.com More information http://openjdk.java.net/projects/jigsaw/ - OpenJDK project this has links to - related spec, requirements; - design overview; - quick start guide! http://openjdk.java.net/projects/jigsaw/ea - Early access build http://openjdk.java.net/projects/jigsaw/talks/ - Videos from Devoxx 2015
