1. Machine learning is a set of techniques that use data to build models that can make predictions without being explicitly programmed. 2. There are two main types of machine learning: supervised learning, where the model is trained on labeled examples, and unsupervised learning, where the model finds patterns in unlabeled data. 3. Common machine learning algorithms include linear regression, logistic regression, decision trees, support vector machines, naive Bayes, k-nearest neighbors, k-means clustering, and random forests. These can be used for regression, classification, clustering, and dimensionality reduction.

1. Machine Learning
Dr. G.Geetha
Professor & Head
DCSE/JCE

2. Data Mining
• Can cull existing information to highlight
patterns, and serves as foundation for AI and
machine learning.

3. Artificial Intelligence
Broad term for using data to offer solutions to
existing problems

4. Machine Learning
• Goes beyond AI, and offers data necessary for
a machine to learn & adapt

7. • Google’s self-driving cars and robots get a lot
of press, but the company’s real future is in
machine learning, the technology that enables
computers to get smarter and more personal.
• – Eric Schmidt (Google Chairman)

9. Machine Learning
“Machine Learning is the field of study that
gives computers the ability to learn without
being explicitly programmed.”
Arthur Samuel way back in 1959

10. Machine Learning
“A computer program is said to learn from
experience E with respect to some task T and
some performance measure P, if its
performance on T, as measured by P, improves
with experience E.
in 1997, Tom Mitchell

11. • Machine learning is a set of software techniques (at times referred
as algorithms) that automate the creation of models and the use of
these models in every day life. These models learn from data and
make predictions about data. This is why, at times, machine
learning is referred to as big data. Machine learning used to be
referred to as Artificial Intelligence (AI). There is not one machine
learning technique, rather there are numerous techniques each
better suited to specific applications. You might not realize it, but
you are experiencing machine learning every day in your digital life.
Netflix or Amazon suggests a movie or product recommendation?
Machine learning. VISA calls you because of a suspicious activity?
Machine learning. Google’s car drives by itself? You guessed it:
Machine learning! The smarts behind Kitchology’s app that profiles
consumers’ activities and matches food to activities? You already
know the answer.

12. Example
• Suppose your email program watches which
emails you do or do not mark as spam, and based
on that learns how to better filter spam. What is
the task T in this setting?
• Answer
• Classifying emails as spam or not spam.
• Explanation
• T := Classifying emails as spam or not spam.
E := Watching you label emails as spam or not
spam.
P := The number (or fraction) of emails correctly
classified as spam/not spam.

14. Examples of machine learning
problems
• “Is this cancer?”
• “What is the market value of this house?”
• “Which of these people are good friends with
each other?”
• “Will this rocket engine explode on take off?”,
“Will this person like this movie?”,
• “Who is this?”,
• “What did you say?”
• “How do you fly this thing?”

15. How exactly do we teach machines?

17. Machine Learning
• Supervised machine learning
• Unsupervised machine learning

24. • Supervised machine learning: The program is
“trained” on a pre-defined set of “training
examples”, which then facilitate its ability to
reach an accurate conclusion when given new
data.
• Unsupervised machine learning: The program
is given a bunch of data and must find
patterns and relationships therein.

25. Supervised Machine Learning
• supervised learning applications, the ultimate goal is to
develop a finely tuned predictor function h(x) (sometimes
called the “hypothesis”). “Learning” consists of using
sophisticated mathematical algorithms to optimize this
function so that, given input data x about a certain domain
(say, square footage of a house), it will accurately predict
some interesting value h(x) (say, market price for said
house).
• In practice, x almost always represents multiple data points.
So, for example, a housing price predictor might take not
only square-footage (x1) but also number of bedrooms (x2),
number of bathrooms (x3), number of floors (x4), year built
(x5), zip code (x6), and so forth. Determining which inputs
to use is an important part of ML design.

26. Classification Problems
• Under supervised ML, two major subcategories
are:
• Regression machine learning systems: Systems
where the value being predicted falls somewhere
on a continuous spectrum. These systems help us
with questions of “How much?” or “How many?”.
• Classification machine learning systems: Systems
where we seek a yes-or-no prediction, such as “Is
this tumer cancerous?”, “Does this cookie meet
our quality standards?”, and so on

27. Neural Networks

28. Unsupervised Machine Learning
• Unsupervised learning typically is tasked with
finding relationships within data. There are no
training examples used in this process.
Instead, the system is given a set data and
tasked with finding patterns and correlations
therein. A good example is identifying close-
knit groups of friends in social network data.

29. • clustering algorithms such as k-means,
• dimensionality reduction systems such as
principle component analysis

30. Supervised Learning
• How it works: This algorithm consist of a target /
outcome variable (or dependent variable) which
is to be predicted from a given set of predictors
(independent variables). Using these set of
variables, we generate a function that map
inputs to desired outputs. The training process
continues until the model achieves a desired level
of accuracy on the training data. Examples of
Supervised Learning: Regression, Decision Tree,
Random Forest, KNN, Logistic Regression etc.

31. Unsupervised Learning
• How it works: In this algorithm, we do not
have any target or outcome variable to predict
/ estimate. It is used for clustering population
in different groups, which is widely used for
segmenting customers in different groups for
specific intervention. Examples of
Unsupervised Learning: Apriori algorithm, K-
means.

32. Reinforcement Learning:
• How it works: Using this algorithm, the
machine is trained to make specific decisions.
It works this way: the machine is exposed to
an environment where it trains itself
continually using trial and error. This machine
learns from past experience and tries to
capture the best possible knowledge to make
accurate business decisions. Example of
Reinforcement Learning: Markov Decision
Process

33. List of Common Machine Learning
Algorithms
• Linear Regression
• Logistic Regression
• Decision Tree
• SVM
• Naive Bayes
• KNN
• K-Means
• Random Forest
• Dimensionality Reduction Algorithms
• Gradient Boost & Adaboost

34. • Andrew Ng, Associate Professor, Stanford
University;
• Machine Learning Recipes with Josh Gordon
• http://archive.ics.uci.edu/ml/
• https://www.youtube.com/watch?v=dcZvhP-
IqY4
• https://www.youtube.com/watch?v=IpGxLWO
IZy4

35. Supervised learning - introduction
• Probably the most common problem type in
machine learning
• Starting with an example
– How do we predict housing prices
• Collect data regarding housing prices and how they
relate to size in feet

36. • Example problem: "Given this data, a friend
has a house 750 square feet - how much can
they be expected to get?"

38. • What approaches can we use to solve
this?Straight line through data
– Maybe $150 000
• Second order polynomial
– Maybe $200 000
• One thing we discuss later - how to chose
straight or curved line?
• Each of these approaches represent a way of
doing supervised learning

39. • What does this mean? We gave the algorithm
a data set where a "right answer" was
provided
• So we know actual prices for houses
– The idea is we can learn what makes the price a
certain value from the training data
– The algorithm should then produce more right
answers based on new training data where we
don't know the price already
• i.e. predict the price

40. • We also call this a regression
problemPredict continuous valued output
(price)
• No real discrete delineation

41. • Another example
– Can we definer breast cancer as malignant or
benign based on tumour size

43. • Looking at data
Five of each
• Can you estimate prognosis based on tumor size?
• This is an example of a classification problem
– Classify data into one of two discrete classes - no in
between, either malignant or not
– In classification problems, can have a discrete number of
possible values for the output
• e.g. maybe have four values
– 0 - benign
– 1 - type 1
– 2 - type 2
– 3 - type 4
