1. As presented to
July 2009

2. Battery Management
Systems for Electric
Vehicles

3. Comparison:
Lead vs. Lithium in EVs
 Charging
 Lead-acid batteries charges well in a long string
 Over voltage in a cell is not good, but generally passes the current to the
next cell in an equalization cycle with little damage.
 Cell balancing can be done with a sophisticated charger (IUIa cycle)
 Lithium batteries OK in a string, but over voltage on a individual cell can
do serious cell damage.
 Individual cell charging is solution, or
 Balancing cells and charge in a string.
 Discharging
 Lead can tolerate discharging to 0% State of charge (SOC) with some
cycle life damage.
 Lithium will have serious damage when discharging below 2.0V, can be
completely ruined.

4. Lead-Acid Discharge Curve
http://www.trojanbattery.com/BatteryMaintenance/Testing.aspx
5.7
5.8
5.9
6
6.1
6.2
6.3
6.4
6.5
0
10
20
30
40
50
60
70
80
90
100
110
6V Lead Acid Battery Discharge Curve
Battery
Voltage
State of Charge

5. Lithium Discharge Curves
 Lithium Batteries have a fairly flat discharge curve with
sharp shoulders
http://enerdel.com/content/view/105/88/

6. Lithium BMS Challenges
1. Must not Over-Charge an individual cell
2. Must not Over-Discharge an individual
cell
3. Must not let cells get too hot during
charge or discharge

7. ENTER THE LITHIUM BMS
 Many thoughts and discussions on what constitutes a
Battery Management System (BMS):
 Monitor and Detect Cell Over-Charge, and cut off charger
 Monitor and Detect Cell Over-discharge and alert operator, or cut
off system power.
 Cell Balance for string charging
 Temperature Monitoring
 Remaining State of Charge determination
 This is done in your cell phone & laptop, why not in your
car?
 High voltages and high currents make it difficult
 Sparse BMS technology availability has held up Lithium
conversion projects.

8. BMS Topology: Distributed
 Put voltage monitor and
discharge balancer on
each cell, with digital
communications for
charger cutoff and status.
Advantages: Simpler design and construction and its potential for higher
reliability in an automotive environment.
Disadvantages: Large number of mini-slave printed circuit boards which are
needed and the difficulty of mounting them on some cell types.

9. BMS Topology: Modular
Advantages: Does not need printed circuit boards connected to individual
cells.
Disadvantages: Master-Slave isolated communications can be challenging in
an EV.
 Several Slave
controllers
consolidate data
to a master

10. BMS Topology: Centralized
 Centralized
Master Control
Unit
Advantages: Single installation point. No complex inter-vehicle communications
Disadvantages: Typical EV batteries are distributed in the vehicle, requiring
wiring to a central location.
Single source for balancer heat generation.
Central
Master
Control Unit
1

11. Li-Ion BMS Market options
 Investigate BMS solution for highway
capable EV conversion
 Needs to support typical DC system:
160 AH prismatic LiFeP04 (3.2V),
250A + systems
40-48 cells (128 to 153 volts)
Must monitor
Should manage, report and balance

12. Li-Ion BMS options
Company
(1)
Topology
(3)
No
of
cells
(4)
Balan.
(5)
Temper.
(6)
Display
Fuel
gauge
(8)
Over
Volt
Protection
Comm.
(9)
Case
(10)
Price,
48-cell
(11)
Agni
motors
Stybrook
Ltd
Distri
b.
1~200 ✓ - - - - Wire - ~$1000
Black
Sheep
Technolo
gy
Mod
ular
4~any ✓ ✓ - ✓ ✓ Seria
l
Plastic /
metal
~$2200
Elithion Distri
b.
1~255 ✓ ✓ ✓ ✓ ✓ Wire
CAN
RS23
2
- ~$2000 -
$4000
EV power Distri
b.
1~any ✓ - - - ✓ Wire Metal ~$1800*

13. Li-Ion BMS options (continued)
Company
(1)
Topology
(3)
No
of
cells
(4)
Balan.
(5)
Temper.
(6)
Display
Fuel
gauge
(8)
Over
Volt
Protection
Comm.
(9)
Case
(10)
Price,
48-cell
(11)
High Tech
Systems
(SSI?)
Distri
b.
1~any ✓ ✓ ? - ? Wire - ??
Ningbo
Yangming
Elite
Power
(BMS 50)
Mod
ular
Up to
50,
higher
available
✓ ✓ ✓ ✓ - ? Metal $1789
PackTrakr
from
KJHall
Motor Co
Mod
ular
6~40 - ✓ ✓ - - RS23
2
Plastic $710 (40
cells
only)
REAP
systems
Mod
ular
4~168 ✓ ✓ ✓ ✓ ✓ Bus - 697 x 4 =
$2788*
Volt
Blocher
Distri
b.
1~any ✓ - - - opt Opt
wire
- $864-
1008
assemble
d

14. BMS Honorable Mention
 Lithium Balance – No published specs or pricing
 Gary Goodrum – DIY BMS Ckt, 24 cell on Endless
Sphere, Low current device for bikes
 Metric Mind – Custom BMS, no pricing for BMS products
 Boundless – creates custom battery packs.
 Hot Juice Electric BEQ – Balance only
 Manzanita Micro – Partial solution, 4 cells for $250
 Open Source BMS projects – no resolutions

15. Small Print:
1. Company: A few other companies are getting ready to offer Li-Ion BMSs, but are not yet ready to be listed here.
2. Class:
• Simple: analog technology, just able to detect that some cell's voltage is too low or too high
• Fancy: sophisticated digital technology, able to measure and report every cell voltage, and to calculate SOC
3. Topology: See previous slides
4. Number of cells: this is the acceptable range in the number of cells in series. The number of cells in parallel does
not matter.
5. Balance: The BMS is able to remove energy just from the most charged cells, to allow the other cells to reach the
same level of charge.
6. Temperature: The BMS is able to measure and report individual cells' temperature.
7. Current sense: The BMS includes a current sensor or at least an input for a current sensor, to measure battery
current. This enables the BMS to react to excessive current, and to calculate the SOS or DOD.
8. "Fuel gauge": a.k.a.: "Gas Gauge". The BMS calculates the SOC (State Of Charge) or DOD (Depth Of Discharge),
by integrating the battery current.
9. Communications:
• Wire: separate wires are used, each with a single, specific function, such as to turn on the charger relay.
• CAN: CAN bus, common in vehicles and European industrial equipment.
• RS232: serial point-to-point communication, usually used only for initial set-up and testing, but some time also
available for communication during operation.
10. Case: Whether the BMS controller is enclosed (metal or plastic case), or it is an open PCB assembly. Unless
otherwise noted, any cell-mounted boards are assumed to be open PCB assemblies.
11. Price: from manufacturers' websites or discussion with their clients.

16. Hardy EV Flex BMS
 Centralized BMS Architecture
 Miniature In car display and operator alerts
 Battery monitoring for over-voltage, under voltage
 3 versions in production
 Up to 36 cells - For NEVs and small EVs
 Up to 48 cells – For DC systems
 Up to 84 cells – Prius plug-in conversions and AC systems
 Temperature monitoring
 Adjustable voltage and temperature thresholds
 Cell balancing with built-in thermal management
 Full diagnostic self test identifies faulty wiring
 Internal Log allows identification of problem batteries
 USB Log Option for detailed cell monitoring logs
 Current monitor option for state of charge determination
 Works with charger up to AC: 25A 240V
 Priced for EV conversions: $891 for 48 cell system
 Data logger option $50
 Current Monitor option $60
 www.ConvertTheFuture.com
