1. Life Cycle of Metrics, Alerting, and
Performance Monitoring in
microservices
Good
Bad
Ugly

2. 2
Operations Life Cycle

3. 3
Operations Life Cycle: Incident
Incident

4. 4
Operations Life Cycle: Incident Management
•Monitoring
•Diagnosis
•Escalation
•Remediation
•Communication
Incident
R
esponse

5. 5
Operations Life Cycle: Resolution
R
esponse
•Monitoring
•Diagnosis
•Escalation
•Remediation
•Communication
Resolution

6. 6
Operations Life Cycle: Recovery
R
esponse
•Monitoring
•Diagnosis
•Escalation
•Remediation
•Communication
• Investigation
• Root Cause Analysis
• Incident RCA
• Problem RCA
• Incident Review/Post-Mortem
• Identification of Action Items
• Lessons Learned
Resolution
R
ecovery

7. 7
Operations Life Cycle: Prevention
R
esponse
R
ecovery
Prevention
•Monitoring
•Diagnosis
•Escalation
•Remediation
•Communication
• Investigation
• Root Cause Analysis
• Incident RCA
• Problem RCA
• Incident Review/Post-Mortem
• Identification of Action Items
• Lessons Learned
•Documentation Development
•Training
•Risk Mitigation
•Execution of AIs from prior incidents
•Production Readiness Reviews

8. 8
Operations Life Cycle: Preparation
R
esponse
R
ecovery
Prevention
Preparation
•Monitoring
•Diagnosis
•Escalation
•Remediation
•Communication
• Investigation
• Root Cause Analysis
• Incident RCA
• Problem RCA
• Incident Review/Post-Mortem
• Identification of Action Items
• Lessons Learned
•Documentation Development
•Training
•Risk Mitigation
•Execution of AIs from prior incidents
•Production Readiness Reviews
•System Development
•Risk Identification
•Monitoring Systems
•Tactical, Operational, Strategic KPIs
•Identify Meaningful KPIs
•KPIs to Notification and
Escalation Matrix
•Architecture Review

9. 9
Operations Life Cycle: Complacency Edition
Response
Recovery
Prevention
Preparation
"Stable"

10. 10
Operations Life Cycle: Complacency Edition
Response
Recovery
Prevention
Preparation
Steady-State
Undetected
Problem
Blissful
Ignorance
QuietBefore
theStorm

11. 11
Situational Awareness: Why

12. 12
Idea!
Software Life Cycle: IDEA!

13. 13
Idea!
Software Life Cycle: But it's not a bright idea, yet

14. 14
Software Life Cycle: Development Begins
Time
Prod
1) Idea!
R&D

15. 15
Software Life Cycle: Development Begins
Time
Prod
1) Idea!
R&D
Forever

16. 16
Software Life Cycle: Development Begins
Time
Prod
1) Idea!
R&D
Forever
(a.k.a. next week, month, or quarter)

17. 17
Software Life Cycle: Sprint to Prod!
Time
Prod
1) Idea!
2) Production Ready
R&D

18. 18
Software Life Cycle: Knowledge of Actual Process
Time
Prod
1) Idea!
2) Production Ready
R&D

19. 19
Software Life Cycle: Knowledge of Actual Process
Time
Prod
1) Idea!
2) Production Ready
R&D

20. 20
Software Life Cycle: Wisdom
Time
Prod
1) Idea!
2) Production Ready
R&D

21. 21
Software Life Cycle: Contrived Lifecycle
Time
Readiness
1) Idea!
2) Production Ready 3) End of Life
2.9) "It’ll be time to wind this service down
when ___ happens and ___ comes online."
R&D

22. 22
Software Life Cycle: Dose of Reality
Time
Production
1) Idea!
2) Production Ready
4) End of Life
"Production Supported"
3) "Oops"
R&D

23. 23
Software Life Cycle: Do NOT Pass Go, No $200
Time
Production
1) Idea!
N) End of Life
"Production Supported"
Forced to fix code or docs.
R&D

24. 24
Software Life Cycle: Why the fails?
Time
Production
1) Idea!
2) Production Ready
N) End of Life
"Production Supported"
"Drug feet to produce docs."
[3,M) "Oops"
R&D
N-1) "That’s it, we’ve had enough…"

25. 25
Software Life Cycle
Time
Production
1) Idea!
2) Production Ready
N) End of Life
"Production Supported"
[3,M) "Oops"
R&D
N-2) "That’s it, we’ve had enough…"
N-1) "Just support it until
the next version is out"

26. 26
Software Life Cycle: Detecting Problems Early
Time
Production
1) Idea!
2) Production Ready
4) End of Life
"Production Supported"
3) "Oops"
R&D
WTB Alerting Here

27. 27
Metrics

28. 28
Metrics: Direction: Push
statsd
sink

29. 29
Metrics: Direction: Push
statsd
sink
<metricname>:<value>|<type>

30. 30
Metrics: Direction: Push
statsd
sink
<metricname>:<value>|<type>
"Primitive"

31. 31
Metrics: Direction: Push
statsd
sink
<metricname>:<value>|<type>
Coordinated Endpoint for Firehose Data

32. 32
Metrics: Direction: Push
statsd
sink

33. 33
Metrics: Direction: Push
statsd
sink

34. 34
Metrics: Direction: Poll
http
agent
database

35. 35
Metrics: Direction: Poll
http
agent
database

36. 36
Metrics: Host Metrics
HTTP JSON
HTTP Trap
"Feature Rich"

37. 37
Metrics: Host Metrics

38. 38
Metrics: Host Metrics
HTTP JSON
Broker
(noit)

39. 39
Metrics: Alerting Pipeline
HTTP JSON
Broker
(noit)
stratcon
Message Queue
(fq) Rules Engine
(ernie)
Alerting
(bert)

40. Nomad
HASHICORP
Cluster Manager
Scheduler

41. Nomad
HASHICORP
Cluster Manager
Scheduler

42. HASHICORP
Schedulers map a set of work to
a set of resources

43. HASHICORP
CPU Scheduler
Web Server -Thread 1
CPU - Core 1
CPU - Core 2
Web Server -Thread 2
Redis -Thread 1
Kernel -Thread 1
Work (Input) Resources
CPU
Scheduler

44. HASHICORP
CPU Scheduler
Web Server -Thread 1
CPU - Core 1
CPU - Core 2
Web Server -Thread 2
Redis -Thread 1
Kernel -Thread 1
Work (Input) Resources
CPU
Scheduler

45. HASHICORP
Advantages
Higher Resource Utilization
Decouple Work from Resources
Better Quality of Service

46. HASHICORP
Advantages
Bin Packing
Over-Subscription
Job Queueing
Higher Resource Utilization
Decouple Work from Resources
Better Quality of Service

47. HASHICORP
Advantages
Abstraction
API Contracts
Standardization
Higher Resource Utilization
Decouple Work from Resources
Better Quality of Service

48. HASHICORP
Advantages
Priorities
Resource Isolation
Pre-emption
Higher Resource Utilization
Decouple Work from Resources
Better Quality of Service

49. Nomad
HASHICORP

50. Nomad
HASHICORP
Cluster Scheduler
Easily Deploy Applications
Operationally Simple
Built for Scale

51. job "redis" {
datacenters = ["us-east-1"]
task "redis" {
driver = "docker"
config { image = "redis:latest" }
resources {
cpu = 500 # Mhz
memory = 256 # MB
network {
mbits = 10
dynamic_ports = ["redis"]
}
}
}
}
example.nomad

52. HASHICORP
Job Specification
Declares what to run

53. HASHICORP
Job Specification
Nomad determines where and
manages how to run

54. HASHICORP
Job Specification
Nomad abstracts work
from resources

55. job “my-app" {
…
task “my-app" {
ephemeral_disk {
sticky = true
}
}
}
example.nomad

56. HASHICORP
Moves data between tasks on
the same machine

57. HASHICORP
Copies data between tasks on
different machines

58. 58
Why is this more difficult?

59. 59
Metrics: Direction: Poll
http
agent
database
Static Endpoint
Ephemeral Containers

60. 60
Metrics: Direction: Poll
http
agent
database
Static Endpoint
Ephemeral Containers
Function-as-a-Service

61. 61
Metrics: Push Metrics
HTTP JSON
HTTP Trap

62. 62
Metric Types

63. 63
Metrics: Counter
•Counter - Monotonic Number
•Bytes transmitted
•Number of 2XX requests

64. 64
Metrics: Gauge
•Counter - Monotonic Number
•Bytes transmitted
•Number of 2XX requests
•Gauge - Non-monotonic number
•Load average
•Number of services in a critical state

65. 65
Metrics: Gauge

66. 66
Metrics: Histogram
•Counter - Monotonic Number
•Bytes transmitted
•Number of 2XX requests
•Gauge - Non-monotonic number
•Load average
•Number of services in a critical state
•Histograms - Distribution of Streams of Values
•Latency of an individual request
•Disk IO latency
•Bytes per response

67. 67
Metrics: Concepts
•Interval - How often a metric is polled
•Samples - Per Interval

68. 68
Metrics: Averages

69. 69
Metrics: Long Tail

70. 70
Operations Life Cycle: Complacency Edition
Response
Recovery
Prevention
Preparation
Steady-State
Undetected
Problem
Blissful
Ignorance
QuietBefore
theStorm

71. 71
Metrics: Long Tail

72. 72
Metrics: Banded Latencies

73. 73
Data Sizes to Problem Specificity
AMOUNT OF DATA NECESSARY TO
ANSWER THE QUESTION
IPSUM
SCOPE OR SPECIFICITY OF THE QUESTION IS THERE A
PROBLEM?
WHERE IS THE
PROBLEM?
WHAT IS THE
PROBLEM?

74. 74
Histograms

75. 75
Histograms

76. 76
Histograms

77. 77
Histograms

78. 78
Histograms

79. 79
Histograms

80. 80
Metrics: Histogram Heat Map

81. 81
Metrics: Long Tail
Alert Because Something
Happened Out Here
Don't Celebrate
This Success

82. 82
Why is this hard?

83. Why is this hard?
Milliseconds

84. $ nomad status atlas-4119-b246fd8fa2
ID = atlas-4119-b246fd8fa2
Name = atlas-4119
Type = service
Priority = 50
Datacenters = dc1
Status = running
Periodic = false
Parameterized = false
Summary
Task Group Queued Starting Running Failed Complete Lost
console 0 0 1 0 0 0
frontend 0 0 2 0 0 0
worker 0 0 1 0 0 0
Allocations
ID Eval ID Node ID Task Group Desired Status Created At
24e12544 9fedfef9 b7d7483e console run running 01/25/17 23:14:28 UTC
87f46c82 9fedfef9 d6b60eb1 worker run running 01/25/17 23:14:28 UTC
d5ea84f2 9fedfef9 70ba3d96 frontend run running 01/25/17 23:14:28 UTC
eff8882a 9fedfef9 bbb7b28f frontend run running 01/25/17 23:14:28 UTC
WTF?

85. $ nomad status atlas-4119-b246fd8fa2
ID = atlas-4119-b246fd8fa2
Name = atlas-4119
Type = service
Priority = 50
Datacenters = dc1
Status = running
Periodic = false
Parameterized = false
Summary
Task Group Queued Starting Running Failed Complete Lost
console 0 0 1 0 0 0
frontend 0 0 2 0 0 0
worker 0 0 1 0 0 0
Allocations
ID Eval ID Node ID Task Group Desired Status Created At
24e12544 9fedfef9 b7d7483e console run running 01/25/17 23:14:28 UTC
87f46c82 9fedfef9 d6b60eb1 worker run running 01/25/17 23:14:28 UTC
d5ea84f2 9fedfef9 70ba3d96 frontend run running 01/25/17 23:14:28 UTC
eff8882a 9fedfef9 bbb7b28f frontend run running 01/25/17 23:14:28 UTC
WTF?

86. $ nomad alloc-status 87f46c82
ID = 87f46c82
Eval ID = 9fedfef9
Name = atlas-4119.worker[0]
Node ID = d6b60eb1
Job ID = atlas-4119-b246fd8fa2
Client Status = running
Client Description = <none>
Desired Status = run
Desired Description = <none>
Created At = 01/25/17 23:14:28 UTC
Task "worker" is "running"
Task Resources
CPU Memory Disk IOPS Addresses
47/256 MHz 218 MiB/2.0 GiB 0 B 0
Recent Events:
Time Type Description
01/25/17 23:19:36 UTC Started Task started by client
01/25/17 23:14:28 UTC Downloading Artifacts Client is downloading artifacts
01/25/17 23:14:28 UTC Received Task received by client

87. $ nomad alloc-status d5ea84f2
ID = d5ea84f2
Eval ID = 9fedfef9
Name = atlas-4119.frontend[1]
Node ID = 70ba3d96
Job ID = atlas-4119-b246fd8fa2
Client Status = running
Client Description = <none>
Desired Status = run
Desired Description = <none>
Created At = 01/25/17 23:14:28 UTC
Task "frontend" is "running"
Task Resources
CPU Memory Disk IOPS Addresses
370/1024 MHz 673 MiB/2.0 GiB 0 B 0 atlasfrontend: 10.151.2.227:80
Recent Events:
Time Type Description
01/25/17 23:19:18 UTC Started Task started by client
01/25/17 23:14:28 UTC Downloading Artifacts Client is downloading artifacts
01/25/17 23:14:28 UTC Received Task received by client
NOT STATIC

88. 88
Parting Thoughts

89. # Terraform and Circonus to the rescue
module "atlas" {
source = "../modules/atlas"
environment = "staging"
}

90. % cat ../modules/atlas/interface.tf
variable "atlas-worker-tags" {
type = "list"
default = [ "app:atlas", "app:atlas-worker", "source:nomad" ]
}
variable "environment" {
type = "string"
}

91. module "atlas-worker-job" {
source = "../nomad-job"
environment = "${var.environment}"
human_name = "Atlas Worker"
job_name = "atlas"
task_group = "worker"
job_tags = [ "app:atlas", "app:atlas-worker" ]
}

92. % cat ../modules/nomad-job/interface.tf
# *-description's taken from https://www.nomadproject.io/docs/agent/telemetry.html
variable "cpu-kernel-description" {
type = "string"
default = "Total CPU resources consumed by the task in the system space"
}
variable "cpu-throttled-periods-description" {
type = "string"
default = "Number of periods when the container hit its throttling limit (`nr_throttled`)"
}
variable "cpu-throttled-time-description" {
type = "string"
default = "Total time that the task was throttled (`throttled_time`)"
}
variable "cpu-total-percentage-description" {
type = "string"
default = "Total CPU resources consumed by the task across all cores"
}

93. variable "cpu-total-ticks-description" {
type = "string"
default = "CPU ticks consumed by the process in the last collection interval"
}
variable "cpu-user-description" {
type = "string"
default = "An aggregation of all userland CPU usage for this Nomad job."
}
variable "environment" {
type = "string"
}
variable "human_name" {
description = "The human-friendly name for this job"
type = "string"
}
variable "job_name" {
type = "string"
description = "The Nomad Job Name (or its prefix)"
}

94. variable "job_tags" {
type = "list"
description = "Tags that should be added to this job's resources"
}
variable "memory-cache-description" {
type = "string"
default = "Amount of memory cached by the task"
}
variable "memory-kernel-usage-description" {
type = "string"
default = "Amount of memory used by the kernel for this task"
}
variable "memory-max-usage-description" {
type = "string"
default = "Maximum amount of memory ever used by the kernel for this task"
}
variable "memory-kernel-max-usage-description" {
type = "string"
default = "Maximum amount of memory ever used by the tasks in this job."
}

95. variable "memory-rss-description" {
type = "string"
default = "An aggregation of all resident memory for this Nomad job."
}
variable "memory-swap-description" {
type = "string"
default = "Amount of memory swapped by the task"
}
variable "nomad-tags" {
type = "list"
default = [ "source:nomad" ]
}
variable "task_group" {
type = "string"
description = "The name of the task group"
}

96. % cat ../modules/nomad-job/stream-groups.tf
resource "circonus_stream_group" "cpu-kern" {
name = "${var.human_name} CPU Kernel"
description = "${var.cpu-kernel-description}"
group {
query = "*`${var.job_name}-${var.task_group}`cpu`system"
type = "average"
}
tags = [ "${var.nomad-tags}", "${var.job_tags}", "resource:cpu", "use:utilization" ]
# unit = "%"
}
resource "circonus_stream_group" "memory-rss" {
name = "${var.human_name} Memory RSS"
description = "${var.memory-rss-description}"
group {
query = "*`${var.job_name}-${var.task_group}`memory`rss"
type = "average"
}
tags = [ "${var.nomad-tags}", "${var.job_tags}", "resource:memory", "use:utilization" ]
}

97. resource "circonus_trigger" "rss-alarm" {
check = "${circonus_check.usage.checks[0]}"
stream_name = "${var.used_metric_name}"
if {
value {
absent = "3600s"
}
then {
notify = [
"${circonus_contact_group.circonus-owners-slack.id}",
"${circonus_contact_group.circonus-owners-slack-escalation.id}",
]
severity = 1
}
}
if {
value {
# SEV1 if we're over 4GB
more = "${4 * 1024 * 1024 * 1024}"
}
...

98. resource "circonus_contact_group" "job-owner-slack-escalation" {
name = "${var.appname} Owners (${title(var.environment)} Slack Escalation)"
slack {
channel = "${var.alert_slack_escalate_channel_name}"
team = "${var.alert_slack_team_id}"
username = "Circonus"
buttons = true
}
tags = [
"author:terraform",
"environment:${var.environment}",
"owner:${var.app-owner}",
]
}

99. resource "circonus_contact_group" "app-owners-slack" {
name = "${var.appname} Owners (${title(var.environment)} Slack)"
slack {
channel = "${var.alert_slack_channel_name}"
team = "${var.alert_slack_team_id}"
username = "Circonus"
buttons = true
}
aggregation_window = "5m"
alert_option {
severity = 1
reminder = "15m"
escalate_to = "${circonus_contact_group.app-owners-slack-escalation.id}"
escalate_after = "1h"
}
alert_option {
severity = 2
reminder = "1h"
escalate_to = "${circonus_contact_group.app-owners-slack-escalation.id}"
escalate_after = "6h"
}

100. Why?

106. 106
Parting Thoughts
•Be an engineer. Put rigid constraints around your app.
•Don't confuse static with rigid.
•Work top to bottom.
•Develop an error budget and prioritize.
•Be consistent in your observability regimen.

107. 107
Parting Thoughts
•Expose HTTP Endpoints for stats (both monotonic counters and gauges)
•Trap Metrics to a broker frequently to create a histogram (e.g. 100ms)
•Expose or export JSON Histograms
•Valuable metrics tend to record the behavior of edges, not vertices

108. 108
Parting Thoughts

109. 109
Demo Time
