This document summarizes a research paper that presents Grid Beam Search (GBS), an algorithm that extends beam search to allow inclusion of pre-specified lexical constraints in the output sequence generation. The researchers demonstrate GBS can provide improvements in translation quality for interactive translation scenarios by incorporating user feedback as constraints. They also show GBS enables significant gains in domain adaptation without retraining by using terminology from the target domain as constraints.

1. Lexically Constrained
Decoding for Sequence
Generation Using Grid Beam
Search
Chris Hokamp, Qun Liu
(ACL 2017)
B4 勝又 智

2. Abstract
● They present Grid Beam Search (GBS), an algorithm which extends beam
search to allow the inclusion of pre-specified lexical constraints.
● They demonstrate the feasibility and flexibility of Lexically Constrained
Decoding by conducting 2 experiments.
○ Neural Interactive-Predictive Translation
○ Domain Adaptation for Neural Machine Translation
● Result
○ GBS can provide large improvements in translation quality in interactive scenarios.
○ even without any user input, GBS can be used to achieve significant gains in performance
in domain adaptation scenarios.
2

3. Introduction: What is this research?
● The output of many natural language processing model is a sequence of text.
→ Especially, they focus on machine translation usecases.†
○ such as Post-Editing (PE) and Interactive-Predictive MT
● Their goal is to find a way to force the output of a model to contain such lexical
constraints.
● In this paper, they propose a decoding algorithm which allows the specification
of subsequences to be present in a model’s output.
3
input model
output
(sequenc
e)
†: lexically constrained decoding is relevant to any
scenario where a model is asked to generate a
secuence given an input.
(image description, dialog generation, abstractive
summarization, question answering)

4. Background: Beam Search
4algorithm: Kyoto University Participation to WAT 2016. Cromieres et al., WAT2016

5. Grid Beam Search: Abstract
● their goal is to organize decoding in such a way that they can constrain the
search space to outputs which contain one or more pre-specified
sub-sequences.
○ want to place lexical constraints correctly and
to generate the parts of the output which are not covered by the constraints.
5time step (t)
Constraint
Coverage
(c)
constraints
is an array of sequences.
← constraints
= [[Ihre, Rechte, müssen],
[Abreise, geschützt]]
more detail on the next slides →

6. Grid Beam Search: Algorithm
6
numC: total number of tokens in all
constaints
k: beam window size
(this pseudo-code is for any model)
1. open hypotheses can either
generate from the model’s
distribution or start constraints
2. closed hypotheses can only
generate the next token for in a
currently unfinished constraint
1. open hypotheses (Grid[t-1][c]) may
generate continuations from the
model’s distribution
2. open hypotheses (Grid[t-1][c-1])
may start new constraints
3. closed hypotheses (Grid[t-1][c-1])
may continue constraints

7. Grid Beam Search: Deteil
7
time step (t)
Constraint
Coverage
(c)
a colored strip inside a beam box
represents an individual hypothesis
in the beam’s k-best stack.
Hypotheses with circles are closed,
all other hypotheses are open.
← conceptual drawing

8. Grid Beam Search: Multi-token Constraints
● By distinguishing between open and closed hypotheses,
→ allow for arbitrary multi-token phrases in the search.
● Each hypothesis maintains a coverage vector.
○ ensure that constraints cannot be repeated in a search path
(hypotheses which have already covered constrainti can only generate or start new constraints)
● Discontinuous lexical constraints such as phrasal verbs in En or Ge
○ it is easy to apply GBS by adding filters to the search ↓
8
constraint
ask <someone> out
constraint1 ask
constraint2 out
constraint1 cannot be
used before constraint0
there must be at least one
generated token between
the constraints.
use 2 filters

9. Grid Beam Search: Addressing unknown words
● their decoder can handle arbitrary constraints.
→ there is a risk that constraints will contain unknown tokens.
○ Especially in domain adaptation scenarios, some user-specified constraints are very likely to
contain unseen tokens.
→ Use Subword Units. (maybe Byte Pair Encoding...)
(In the experiments, they use this technique to ensure that no input tokens are unknown, even if a constraint contains
words which never appeared in the training data.)
9

10. Grid Beam Search: Effciency
● the runtime complexity of a naive implementation of GBS is O(ktc).
(standard time-based beam search is O(tk))
↓ some consideration must be given to the efficiency of this algorithm
● the beams in each column c of this Figure are independent.
→ GBS can be parallelized to allow all beams at each timestep to be filled
simultaneously.
● they find that the most time is spent
computing the states for the hyp candidates.
→ by keeping the beam size small,
they can make GBS significantly faster.
10

11. Experiments setup (including appendix)
● The models are SOTA NMT systems using our own implementation of NMT
with attention over the source sequence (Bahdnau et al., 2014).
○ bidirectional GRUs
○ AdaDelta
○ train all systems for 500,000 iterations, with validation every 5,000 steps,
best single model from validation is used.
○ use ℓ2 regularization (α = 1e^(-5))
○ Dropout is used on the output layers, rate is 0.5.
○ beam size is 10.
● corpus
○ English-German
■ 4.4M segments from the Europarl and CommonCrawl
○ English-French
■ 4.9M segments from the Europarl and CommonCrawl
○ English-Portuguese
■ 28.5M segments from the Europarl, JRC-Aquis and OpenSubtitles
● subword
○ they created a shared subword representation for each language pair
by extracting a vocabulary of 80,000 symbols from the concatenated source and target data. 11

12. Experiments: Pick-Revise for Interactive PE
● Pick-Revise is an interaction cycle for MT Post-Editing.
● they modify this experiments.
○ the user only provides sequences of up to three words
which are missing from the hypothesis from reference.
○ in this experiments, four cycles.
○ strict setting:
the complete phrase must be missing from the hypothesis.
○ relaxed setting:
only the first word must be missing.
○ when a 3-token phrase cannot be found,
they backoff to 2-token phrases, then to single tokens as constraints.
○ If a hypothesis already matches the reference, no constraints are added.
12fig1: PRIMT: A Pick-Revise Framework for Interactive Machine Translation. Cheng et al., NAACL HLT 2016

13. Result: Pick-Revise for Interactive PE
13

14. Experiments: Domain Adaptation via Terminology
● The requirement for use of domain-specific terminologies is common in real
world applications of MT.
→ provide the term as constraints.
● target domain data
○ Autodesk Post-Editing corpus
↑ focused upon sofware localization, very dfferent from train data.
● Extract Terminology
○ devide the corpus into approximately 100,000 training sents, 1,000 test segments.
automatically generate a terminology by computing PMI between source and target n-grams in
training set.
○ extract all n-grams from length 2-5 as terminology
candidates.
○ filter the candidates to only include pairs
whose PMI is >= 0.9 and where both src and tgt occur in at least 5 times.
→ make the set of the terminology.
14
normarized to
[-1, +1]

15. Results: Domain Adaptation via Terminology
● confirming that this improvements is caused
by the placement of the terms by GBS,
they evaluate the other inserting methods.
○ randomly inserting terms to the baseline output
○ prepending terms to the baseline output
● even an automatically created terminology
yield improvements.
○ manually created domain terminologies
are likely to lead to greater gains.
15
test set
src tgt
terminology
phrase
corrsponding
phrase
constraints
for that segmentsadd
↑ conceptual drawing for previous slide

16. Output Analysis
16
phrases added as constraints have global effects upon
trainslation quolity.

17. related work
● Most related work has presented modifications of SMT systems for specific
usecases. (focusing on prefix and sufix)
○ The largest body of work considers Interactive Machine Translation (IMT)
● some attention has also been given to SMT decoding with multiple lexical
constraints. (Cheng et al.,2016)
○ their approach relies upon the phrase segmentation provided by the SMT system.
○ the decoding algorithm can only make use of constraints that match phrase boundaries.
In contrast, GBS approach decodes at the token level.
● “To the best of our knowledge, ours is the first work which considers
general lexically constrained decoding for any model which outputs
sequences, without relying upon alignments between input and output, and
without using a search organized by coverage of the input.”
17

18. Conclusion
● Lexically constrained decoding is a flexible way to incorporate arbitrary
subsequences into the output of any model that generates output sequences
token-by-token.
● in interctive translation, user inputs can be used as constraints,
generating a new output each time a user fixes an error.
○ such a workflow can provide a large improvement in translation quality.
● using a domain-specific terminology to generate target-side constraints
○ a general domain model can be adapted to a new domain without anay retraining
● future work
○ evaluate GBS with models outside of MT, such as automatic summarization, image captioning
or dialog generation
○ introduce new constraint-aware models (via secondary attention mecanisms over lexical
constraints) 18

19. reference
● their implementation of GBS
○ https://github.com/chrishokamp/constrained_decoding
● Kyoto University Participation to WAT 2016. Cromieres et al., WAT2016
● PRIMT: A Pick-Revise Framework for Interactive Machine Translation. Cheng
et al., NAACL HLT 2016
19
