It is the slides for SITCON[1] 2013 Workshop[2]: "Git - The Version Control System You Must Know". [1]: http://sitcon.org/ [2]: http://www.openfoundry.org/tw/activities/details/415-the-open-source-way-coder

1. Learning Git with Workflows
Mosky

2. This slides
2

3. This slides
won't
explain every options of Git commands;
and the internal of Git.
2

4. This slides
won't
explain every options of Git commands;
and the internal of Git.
will
let you start to use Git immediately;
and learn the common Git workflows.
2

5. Mosky
3

6. Mosky
A Python engineer at Pinkoi
3

7. Mosky
A Python engineer at Pinkoi
An author of some Python packages
MoSQL, Clime, ...
3

8. Mosky
A Python engineer at Pinkoi
An author of some Python packages
MoSQL, Clime, ...
A speaker at several conferences
PyCon APAC 2013, COSCUP 2013,
PyCon TW 2013, ...
3

9. Mosky
A Python engineer at Pinkoi
An author of some Python packages
MoSQL, Clime, ...
A speaker at several conferences
PyCon APAC 2013, COSCUP 2013,
PyCon TW 2013, ...
A Python trainer
3

10. Mosky
A Python engineer at Pinkoi
An author of some Python packages
MoSQL, Clime, ...
A speaker at several conferences
PyCon APAC 2013, COSCUP 2013,
PyCon TW 2013, ...
A Python trainer
http://mosky.tw/
3

14. Outline
6

15. Outline
Setup Git
6

16. Outline
Setup Git
Routine
Core
Secondary
6

17. Outline
Setup Git
Routine
Core
Secondary
Branching
6

18. Outline
Setup Git
Routine
Core
Secondary
Branching
Remote Repository
6

19. Outline
Setup Git
Routine
Core
Secondary
Branching
Remote Repository
A Co-working Workflow
6

20. Setup Git

21. Get Git!
8

22. Get Git!
Ubuntu, Debian or any APT-based Linux
$ sudo apt-get install git-core
8

23. Get Git!
Ubuntu, Debian or any APT-based Linux
$ sudo apt-get install git-core
Mac
$ brew install git
http://brew.sh/
8

24. Get Git!
Ubuntu, Debian or any APT-based Linux
$ sudo apt-get install git-core
Mac
$ brew install git
http://brew.sh/
Windows
http://git-scm.com/download/win
8

25. Is Git there?
9

26. GUIs are available
10

27. GUIs are available
Thanks GitHub!
10

28. GUIs are available
Thanks GitHub!
"Github for Mac"
http://mac.github.com/
10

29. GUIs are available
Thanks GitHub!
"Github for Mac"
http://mac.github.com/
"Github for Windows"
http://windows.github.com/
10

30. GUIs are available
Thanks GitHub!
"Github for Mac"
http://mac.github.com/
"Github for Windows"
http://windows.github.com/
Other
http://git-scm.com/downloads/guis
10

31. Tell Git who you are
11

32. Tell Git who you are
$ git config --global user.name "Mosky Liu"
11

33. Tell Git who you are
$ git config --global user.name "Mosky Liu"
$ git config --global user.email mosky.tw@gmail.com
11

34. Other Git configs
12

35. Other Git configs
$ git config --global core.editor emacs
12

36. Other Git configs
$ git config --global core.editor emacs
$ git config --global merge.tool vimdiff
12

37. Other Git configs
$ git config --global core.editor emacs
$ git config --global merge.tool vimdiff
$ git config --list
12

38. Other Git configs
$ git config --global core.editor emacs
$ git config --global merge.tool vimdiff
$ git config --list
$ vim ~/.gitconfig
12

39. Other Git configs
$ git config --global core.editor emacs
$ git config --global merge.tool vimdiff
$ git config --list
$ vim ~/.gitconfig
http://j.mp/mosky-gitconfig
12

40. Core Routine

41. Create a repository
14

42. Create a repository
$ git init [<directory>]
14

43. Commit changes
15

44. Commit changes
$ git add <file> ...
15

45. Commit changes
$ git add <file> ...
$ git commit
15

46. Simplest Workflow
16

47. Simplest Workflow
(1) $ git init <directory>
16

48. Simplest Workflow
(1) $ git init <directory>
(2)
(modify file)
16

49. Simplest Workflow
(1) $ git init <directory>
(2)
(modify file)
(3) $ git add <file> ...
16

50. Simplest Workflow
(1) $ git init <directory>
(2)
(modify file)
(3) $ git add <file> ...
(4) $ git commit
16

51. Simplest Workflow
(1) $ git init <directory>
(2)
(modify file)
(3) $ git add <file> ...
(4) $ git commit
# Back 2
16

52. Simplest Workflow
(1) $ git init <directory>
(2)
(modify file)
(3) $ git add <file> ...
(4) $ git commit
# Back 2
The end of the core --- it's super easy!
16

53. Secondary Routine

54. Check status of files
18

55. Check status of files
$ git status
18

56. Check status of files
$ git status
18

57. Check what you changed
19

58. Check what you changed
$ git diff
19

59. Check what you changed
$ git diff
19

60. Check commits
20

61. Check commits
$ git log
20

62. Check commits
$ git log
20

63. Move between commits
21

64. Move between commits
$ git checkout <commit>
21

65. Move between commits
$ git checkout <commit>
<commit>
599d439fd3813298da16f12ed40f3a0
716872c30
599d439
HEAD
21

66. Name commit
22

67. Name commit
$ git tag <tagname>
$ git checkout 599d439
$ git tag v0.1
$ git checkout v0.1
22

68. Reset to a commit
23

69. Reset to a commit
$ git reset <commit>
Reset HEAD to <commit>.
23

70. Make a "reverse" commit
24

71. Make a "reverse" commit
$ git revert <commit>
Apply a "reverse" commit.
24

72. Reset to a commit
25

73. Reset to a commit
26

74. Make a "reverse" commit
27

75. Make a "reverse" commit
28

76. Branching

85. master

86. master
topic

87. HEAD
master
topic

88. HEAD
master
topic

89. master
topic
HEAD

90. master
topic
HEAD

91. master
topic
HEAD

92. Create a branch
32

93. Create a branch
$ git branch <branchname>
32

94. Create a branch
$ git branch <branchname>
$ git checkout <branchname>
32

95. Create a branch
$ git branch <branchname>
$ git checkout <branchname>
or
32

96. Create a branch
$ git branch <branchname>
$ git checkout <branchname>
or
$ git checkout -b <branchname>
32

97. Delete and list branch(es)
33

98. Delete and list branch(es)
$ git branch -d <branchname>
Delete branch.
33

99. Delete and list branch(es)
$ git branch -d <branchname>
Delete branch.
$ git branch
List branches.
33

100. Move between branches
34

101. Move between branches
$ git checkout <branchname>
34

102. Merge a branch back
35

103. Merge a branch back
$ git checkout <base-branch>
35

104. Merge a branch back
$ git checkout <base-branch>
$ git merge <topic-branch>
35

106. Branching Workflow
37

107. Branching Workflow
...
37

108. Branching Workflow
...
(1)
$ git branch <topic-branch>
37

109. Branching Workflow
...
(1)
$ git branch <topic-branch>
(2)
$ git checkout <topic-branch>
37

110. Branching Workflow
...
(1)
$ git branch <topic-branch>
(2)
$ git checkout <topic-branch>
(3)
(modify file)
37

111. Branching Workflow
...
(1)
$ git branch <topic-branch>
(2)
$ git checkout <topic-branch>
(3)
(modify file)
...
37

112. Branching Workflow
...
(1)
$ git branch <topic-branch>
(2)
$ git checkout <topic-branch>
(3)
(modify file)
...
(4)
$ git commit
37

113. Branching Workflow
...
(1)
$ git branch <topic-branch>
(2)
$ git checkout <topic-branch>
(3)
(modify file)
...
(4)
$ git commit
# Back 3 until finish "topic"
37

114. Branching Workflow
...
(1)
$ git branch <topic-branch>
(2)
$ git checkout <topic-branch>
(3)
(modify file)
...
(4)
$ git commit
# Back 3 until finish "topic"
(5)
$ git checkout <base-branch>
37

115. Branching Workflow
...
(1)
$ git branch <topic-branch>
(2)
$ git checkout <topic-branch>
(3)
(modify file)
...
(4)
$ git commit
# Back 3 until finish "topic"
(5)
$ git checkout <base-branch>
(6)
$ git merge <topic-branch>
37

116. Remote Repository

117. Clone a remote repository
39

118. Clone a remote repository
$ git clone <repos> <dir>
39

119. Clone a remote repository
$ git clone <repos> <dir>
<repos>
https://
github.com/torvalds/linux.git
39

120. Create a remote repository
40

121. Create a remote repository
$ git init --bare
40

122. Create a remote repository
$ git init --bare
or
40

123. Create a remote repository
$ git init --bare
or
https://github.com/repositories/new
40

124. Add, remove and list remotes
41

125. Add, remove and list remotes
$ git remote add <name> <url>
<url> can be a local path.
41

126. Add, remove and list remotes
$ git remote add <name> <url>
<url> can be a local path.
$ git remote remove <name>
41

127. Add, remove and list remotes
$ git remote add <name> <url>
<url> can be a local path.
$ git remote remove <name>
$ git remote
41

128. Push commits to remote
42

129. Push commits to remote
$ git push <repos> <refspec>...
42

130. Push commits to remote
$ git push <repos> <refspec>...
<refspec>
usually is branch or tag name
[+]<src>[:<dst>]
:<dst> to delete remote reference.
42

131. Pull commits from remote
43

132. Pull commits from remote
$ git pull <repos> <refspec>...
43

133. A Co-working Workflow

134. Three Principles
45

135. Three Principles
1. master is production.
45

136. Three Principles
1. master is production.
2. dev only includes stable and reviewed code.
45

137. Three Principles
1. master is production.
2. dev only includes stable and reviewed code.
3. Create topic branch to resolve issue all the time.
45

138. Three Phases
46

139. Three Phases
1. Resolving
Create a topic branch to resolve issue.
46

140. Three Phases
1. Resolving
Create a topic branch to resolve issue.
2. Reviewing
Review the code.
46

141. Three Phases
1. Resolving
Create a topic branch to resolve issue.
2. Reviewing
Review the code.
3. Cleanup
Merge into dev and remove topic branch.
46

142. 47

143. Assigner: "We need to resolve this issue."
47

144. Assigner: "We need to resolve this issue."
Assignee: "Yes, sir!"
47

145. Assigner: "We need to resolve this issue."
Assignee: "Yes, sir!"
Assignee (dev) $ git checkout -b topic
47

146. Assigner: "We need to resolve this issue."
Assignee: "Yes, sir!"
Assignee (dev) $ git checkout -b topic
Assignee (topic) $ (commit...)
47

147. Assigner: "We need to resolve this issue."
Assignee: "Yes, sir!"
Assignee (dev) $ git checkout -b topic
Assignee (topic) $ (commit...)
Assignee (topic) $ git push origin topic
47

148. Assigner: "We need to resolve this issue."
Assignee: "Yes, sir!"
Assignee (dev) $ git checkout -b topic
Assignee (topic) $ (commit...)
Assignee (topic) $ git push origin topic
Until resolve, call assigner for review.
47

149. 48

150. Assignee: "I resolved!"
48

151. Assignee: "I resolved!"
Assigner: "Let me review."
48

152. Assignee: "I resolved!"
Assigner: "Let me review."
Assigner (dev) $ git checkout -b topic
48

153. Assignee: "I resolved!"
Assigner: "Let me review."
Assigner (dev) $ git checkout -b topic
Assigner (topic) $ git pull origin topic
48

154. Assignee: "I resolved!"
Assigner: "Let me review."
Assigner (dev) $ git checkout -b topic
Assigner (topic) $ git pull origin topic
Assigner (topic) $ git diff ...dev
48

155. Assignee: "I resolved!"
Assigner: "Let me review."
Assigner (dev) $ git checkout -b topic
Assigner (topic) $ git pull origin topic
Assigner (topic) $ git diff ...dev
If it is not good enough, call assignee to fix.
48

156. 49

157. Assigner (topic) $ git checkout dev
49

158. Assigner (topic) $ git checkout dev
Assigner (dev) $ git merge topic
49

159. Assigner (topic) $ git checkout dev
Assigner (dev) $ git merge topic
Assigner (dev) $ git push origin dev
49

160. Assigner (topic) $ git checkout dev
Assigner (dev) $ git merge topic
Assigner (dev) $ git push origin dev
Assigner: "Good job!"
49

161. Assigner (topic) $ git checkout dev
Assigner (dev) $ git merge topic
Assigner (dev) $ git push origin dev
Assigner: "Good job!"
Assignee (dev) $ git branch -d topic
49

162. Assigner (topic) $ git checkout dev
Assigner (dev) $ git merge topic
Assigner (dev) $ git push origin dev
Assigner: "Good job!"
Assignee (dev) $ git branch -d topic
Assignee (dev) $ git push origin :topic
49

163. Assigner (topic) $ git checkout dev
Assigner (dev) $ git merge topic
Assigner (dev) $ git push origin dev
Assigner: "Good job!"
Assignee (dev) $ git branch -d topic
Assignee (dev) $ git push origin :topic
Assignee (dev) $ git pull origin dev
49

165. End

166. End
52

167. End
Use branch!
52

168. End
Use branch!
Workflow does matter.
52

169. End
Use branch!
Workflow does matter.
Git still has many magics.
52

170. End
Use branch!
Workflow does matter.
Git still has many magics.
Tips: http://j.mp/mosky-gitconfig
52

171. End
Use branch!
Workflow does matter.
Git still has many magics.
Tips: http://j.mp/mosky-gitconfig
Q&A
52
