2. ANNOTATION INFERENCE: AN OVERVIEW
Annotation Inference includes following steps:
Load external/previously inferred annotations from
specified sources (XML files, class files, annotation logs,
etc.)
Load descriptions of classes to analyze
Invoke inference algorithm on loaded classes and
annotations to produce set of inferred annotations
Update inferred annotations with propagation algorithm
to ensure extension to other methods in inheritance
hierarchy
Process conflicts between inferred and external
annotations
Inference process is parameterized with algorithms
which implement inference for specific kinds of
annotations (e.g. nullability):
Infer field annotations given its value
Infer method annotations given its bytecode
3. ANNOTATIONS STRUCTURE
Annotations are represented as a map from
annotation position to actual annotation values (e.g.
NULLABLE/NOT_NULL)
Annotation position consists of
Class member (field/method)
Declaration position – annotated component of class
member:
Field type position – annotates field type
Return type – annotates return type of the method
Parameter position – annotates type of method parameter
(given its index)
4. ANNOTATION LATTICE
Inference assumes that annotations form a lattice,
hence for any pair (a, b) of annotations of the same
kind (e.g. nullability) least upper LUB(a, b) and
greatest lower GLB(a, b) bounds are defined
Nullability: NOT_NULL < NULLABLE
Mutability: READ_ONLY < MUTABLE
Unification: given two annotations (a, b) and
declaration position p unified annotation unify(a, b,
p) is defined as:
LUB(a, b) if p is covariant
GLB(a, b) if p is contravariant
b if p is invariant (assuming a == b)
Unification is naturally extended to annotation sets
Annotation a (“parent”) subsumes annotation b
(“child”) at position p if unify(a, b, p) == a
5. FIELD/METHOD DEPENDENCY
Field dependency is a map which associates field
descriptions with pair (readers, writers) where
readers is a set of all methods (within given class set)
which access field value through GETFIELD or
GETSTATIC instructions
writers is a set of all methods (within given class set)
which mutate field value through PUTFIELD or
PUTSTATIC instructions
Method dependency is a graph with methods as
vertices. The graph contains egde (a, b) if one of
the following conditions holds:
If method a invokes method b through one of
INVOKE*** instructions
If there is a non-primitive field such that method a is its
reader and method b is its writer
6. ANNOTATION INFERENCE (WITHOUT PROPAGATION)
Input:
classSource: set of classes to analyze
externalAnn: external annotations (e. g. loaded from
classfiles/XMLs)
existingAnn: previously inferred annotations
Output:
inferredAnn: inferred annotations
inferredAnn := copy of existingAnn
fieldDep := build field dependency map for all classes in classSource
methDep := build method dependency graph for all classes in
classSource
depComps := list of SCCs of methDep ordered with the respect to
topological sorting
For each field f in fieldDep, use annotation-specific algorithm to infer
annotations from initial value of f and copy them to inferredAnn
For each component comp in components infer annotation for
methods within comp (see below)
7. INFER ANNOTATIONS ON DEPENDENCY GRAPH SCC
Input:
methods: set of methods which form dependency graph SCC
ann: current annotations (to be updated by the inference)
queue := new queue containing all items from methods
while (queue is not empty)
m := remove first method from queue
cfg := build control-flow graph of m
inferredAnn := Invoke annotation-specific inference algorithm (e.g.
nullability) for method m, graph cfg and predefined annotations ann
Copy all changed annotations from inferredAnn to ann
If (at least one annotation was changed/added/removed) then
Add to the queue:
all dependent methods of m which belong to the same SCC
as m itself
method m
8. PROPAGATION: AN OVERVIEW
Propagation algorithm extends given annotation set
to methods within the same inheritance hierarchy
Propagation proceeds in the following steps:
1. Resolve annotation conflicts
Parent and child method have conflicting annotations at
some position if child annotation does not subsumes parent
annotation. Conflicts are fixed by updating parent annotation
to be least upper bound of child annotation and previous
parent annotation
2. Unify parameter annotations
Methods in the same inheritance hierarchy are assigned
identical annotation at corresponding parameter. The
annotation is computed as least upper bound over
annotations already present at that parameter
3. Apply propagation overrides
Propagation override is an exception to unification algorithm
which states that given method and all its descendants must
have some specific annotation at given parameter
9. PROPAGATION: CONFLICT RESOLUTION
Input
leaves: set of “leaf” methods
lat: annotation lattice
ann: annotations (to be updated)
For each method leaf in leaves
propagatedAnn := Annotations(ann)
Perform breadth-first traversal of method hierarchy graph starting
from leaf (moving from child to parents) and
for each traversed method m and each parent method pm of m
and each annotation position ppos in pm
p := declaration position of ppos
pos := position corresponding to ppos in method m
child := propagatedAnn[p], parent := ann[pp]
If (child is defined) then
If (parent is defined) then
ann[pp] := lat.unify(child, parent, p)
else propagatedAnn[pp] := child
If (p == RETURN_TYPE) then ann[pp] := child
10. PROPAGATION: CONFLICT RESOLUTION EXAMPLE (I)
public class XHierarchyAnnotatedMiddle {
public interface Top1 {
@NotNull
Object m(@Nullable Object x);
}
public interface Top2 {
@NotNull
Object m(@Nullable Object x);
}
public interface Middle extends Top1, Top2 {
@Nullable
Object m(Object x);
}
public interface Leaf1 extends Middle {
Object m(@NotNull Object x);
}
public interface Leaf2 extends Middle {
Object m(Object x);
}
}
11. PROPAGATION: CONFLICT RESOLUTION EXAMPLE (II)
public class XHierarchyAnnotatedMiddle {
public interface Top1 {
@Nullable
Object m(@NotNull Object x);
}
public interface Top2 {
@Nullable
Object m(@NotNull Object x);
}
public interface Middle extends Top1, Top2 {
@Nullable
Object m(Object x);
}
public interface Leaf1 extends Middle {
Object m(@NotNull Object x);
}
public interface Leaf2 extends Middle {
Object m(Object x);
}
}
12. PROPAGATION: PARAMETER UNIFICATION
Input
methods: set of methods
lat: annotation lattice
ann: annotations (to be updated)
descriptors := set of method descriptors found in methods
For each method descriptor desc in descriptors
descMethods := subset of methods with descriptor desc
For each parameter declaration position p in desc
paramAnn := set of all annotations from ann defined at such
position pos that its method is from descMethods and its
declaration position is p
If (paramAnn is not empty) then
unifiedAnnotation := lat.unify(paramAnn, p)
For each method m in descMethods
pos := annotation position of m corresponding to
declaration position p
ann[pos] := unifiedAnnotation
13. PROPAGATION: PARAMETER UNIFICATION EXAMPLE (I)
public class XHierarchy {
public interface Top1 {
Object m(Object x, Object y);
}
public interface Top2 {
Object m(@NotNull Object x, Object y);
}
public interface Middle extends Top1, Top2 {
Object m(@Nullable Object x, @Nullable Object y);
}
public interface Leaf1 extends Middle {
Object m(Object x, Object y);
}
public interface Leaf2 extends Middle {
Object m(Object x, @Nullable Object y);
}
}
14. PROPAGATION: PARAMETER UNIFICATION EXAMPLE (II)
public class XHierarchy {
public interface Top1 {
Object m(@NotNull Object x, @Nullable Object y);
}
public interface Top2 {
Object m(@NotNull Object x, @Nullable Object y);
}
public interface Middle extends Top1, Top2 {
Object m(@NotNull Object x, @Nullable Object y);
}
public interface Leaf1 extends Middle {
Object m(@NotNull Object x, @Nullable Object y);
}
public interface Leaf2 extends Middle {
Object m(@NotNull Object x, @Nullable Object y);
}
}
15. PROPAGATION: OVERRIDING RULES
Input
graph: method hierarchy graph
overrides: annotations specifying overriding rules
ann: annotations (to be updated)
For each method annotation ann at position opos in overrides
method := method corresponding to annotation position opos
Perform breadth-first traversal of method hierarchy graph starting
from method (moving from parent to children) and
for each traversed method m
pos := position corresponding to opos in method m
ann[pos] := overrides[opos]
16. PROPAGATION: OVERRIDING RULE EXAMPLE (I)
Rule: Top1.m(Object, Object) at 0 is NULLABLE
public class XHierarchy {
public interface Top1 {
Object m(@NotNull Object x, @Nullable Object y);
}
public interface Top2 {
Object m(@NotNull Object x, @Nullable Object y);
}
public interface Middle extends Top1, Top2 {
Object m(@NotNull Object x, @Nullable Object y);
}
public interface Leaf1 extends Middle {
Object m(@NotNull Object x, @Nullable Object y);
}
public interface Leaf2 extends Middle {
Object m(@NotNull Object x, @Nullable Object y);
}
}
17. PROPAGATION: OVERRIDING RULE EXAMPLE (II)
Rule: Top1.m(Object, Object) at 0 is NULLABLE
public class XHierarchy {
public interface Top1 {
Object m(@Nullable Object x, @Nullable Object y);
}
public interface Top2 {
Object m(@Nullable Object x, @Nullable Object y);
}
public interface Middle extends Top1, Top2 {
Object m(@Nullable Object x, @Nullable Object y);
}
public interface Leaf1 extends Middle {
Object m(@Nullable Object x, @Nullable Object y);
}
public interface Leaf2 extends Middle {
Object m(@Nullable Object x, @Nullable Object y);
}
}
18. CONFLICT PROCESSING
Input:
existingAnn: predefined annotations
inferredAnn: inferred annotations
lat: annotation lattice
excPositions: set of excluded annotation positions
Output:
conflicts: list of triples (position, existing annotation, inferred
annotation)
conflicts := empty list
positions := set of all positions in existingAnn
For each annotation position pos in positions
inferred := inferredAnn[pos], existing := existingAnn[pos]
p := declaration position corresponding to pos
If (existing does not subsume inferred at p) then
If (pos in excPositions) then inferredAnn[pos] := existing
else add (pos, existing, inferred) to conflicts
19. CONFLICT PROCESSING: EXAMPLE
public class XHierarchy {
public interface Top1 {
Object m(Object x, Object y);
}
public interface Top2 {
Object m(@Nullable @NotNull Object x, Object y);
}
public interface Middle extends Top1, Top2 {
@NotNull
@Nullable
Object m(@Nullable Object x, @Nullable Object y);
}
public interface Leaf1 extends Middle {
Object m(Object x, Object y);
}
public interface Leaf2 extends Middle {
Object m(Object x, @Nullable Object y);
}
}
20. CONTROL-FLOW GRAPH
Method control-flow graph describes transitions
between bytecode instructions
Each instruction and transition has corresponding
frame state which describes content of local
variables and stack
Interesting stack values correspond to method
parameters
Also each instruction has one outcome value
which reflects possible terminations of outgoing
control-flow paths:
ONLY_RETURNS
ONLY_THROWS
RETURNS_AND_THROWS
Instruction outcomes are computed on demand
21. COMPUTATION OF INSTRUCTION OUTCOMES
Outcome of given instruction srcInsn is computed
by depth-first traversal of all instructions reachable
from srcInsn and merging outcomes of all visited
termination instructions such that
Outcome of any *RETURN instruction is
ONLY_RETURNS
Outcome of ATHROW instruction is ONLY_THROWS
Traversal can be stopped earlier if
RETURNS_AND_THROWS outcome is produced
Outcomes are merged according to the rules:
a+a=a
a + b = RETURN_AND_THROWS if a != b
23. MUTABILITY INFERENCE
Input:
method: method to be analyzed
cfg: control-flow graph of method
ann: predefined annotations set
Output:
inferredAnn: inferred annotations set
mutabilityMap := empty map from values to mutability annotations
For each invocation instruction insn in cfg
If (insn is invocation of some method m) then
If (insn is mutating invocation of some method m) then
Mark each possible value of m’s receiver as MUTABLE
For each parameter param of m
pos := annotation position corresponding to param of m
If (ann[pos] is MUTABLE) then mark each possible value of
param as MUTABLE
For each value v in mutabilityMap which is parameter of method
pos := annotation position corresponding to v in method
ann[pos] := convert mutabilityMap[v] to annotation value
24. MUTABILITY INFERENCE: VALUE MARKING
Input
value: stack value
mutabilityMap : map from values to mutability annotations (to be
updated)
mutabilityMap[value] := MUTABLE
If (value is created by method invocation instruction insn and insn
propagates mutability)
m := method invoked by insn
Recursively mark each possible values of m’s receiver as
MUTABLE
25. NULLABILITY INFERENCE: NULLABILITY VALUES
Inference process assigns nullability to stack
values:
UNKNOWN: not enough information to infer nullability
NULLABLE
NOT_NULL
NULL
UNREACHABLE: contradicting nullabilities (value is not
realizable)
Nullability merge rules:
a+a=a
a + CONFLICT = CONFLICT + a = a
a + NULL = NULL + a = NULLABLE
a + NULLABLE = NULLABLE + a = NULLABLE
NOT_NULL + UNKNOWN = UNKWNON + NOT_NULL
= UNKNOWN
26. NULLABILITY INFERENCE: NULLABILITY MAPS
Nullability map is used to keep association between
stack values and nullability. In particular, nullability map
is computed for each instruction and transition in
control-flow graph of a method
Additional structures:
Set of method annotation position
Set of existing annotations (external or previously inferred)
Declaration index (used to look up fields and methods by their
descriptors in bytecode)
Optional frame state:
In case of transition-related map it’s a state AFTER originating
instruction
In case of instruction-related map it’s a merged state BEFORE the
instruction
Assuming state is defined if some value is present in map, but
absent in its state, it’s said to be unreachable
Set of spoiled values (i.e. values which are no longer
associated with parameters due to assignment)
27. NULLABILITY INFERENCE: NULLABILITY MAP LOOKUPS
Stored: m.getStored(v)
Return actual nullability previously stored in map, or UNKNOWN if
nullability is not defined
Full: m[v]
If (v is lost) then return CONFLICT
If (some nullability x was previously stored for value v) then retun
x
If (v is created by some instruction insn) then
If (insn is NEW, NEWARRAY, ANEWARRAY,
MULTIANEWARRAY, or LDC) then return NOT_NULL
If (insn is ACONST_NULL) then return NULL
If (insn is AALOAD) then return UNKNOWN
If (insn is GETFIELD or GETSTATIC) then return nullability
corresponding to the field annotation (or UNKNOWN if
undefined)
If (insn is INVOKE***) then return nullability corresponding to
return value of the invoked method (or UNKNOWN if
undefined)
If (v is interesting) then return nullability corresponding to existing
annotation at position encoded by v
If (v is null) then return NULL
If (v is primitive) then return CONFLICT
Otherwise return NOT_NULL
28. NULLABILITY INFERENCE: MERGING NULLABILITY MAPS
Input:
srcMaps: Set of nullability maps
Output:
mergedMap: merged nullability map
mergedValues: set of values which have different nullability in at
least two maps in srcMaps
mergedMap := new empty nullability map
mergedValues := new empty set
affectedValues := set of all stack values in srcMaps key sets
For each map m in srcMaps
Add all values from m.spoiledValues to mergedMap.spoiledValues
For each value v in affectedValues
If (v is already in mergedMap keys) then
If (mergedMap[v] != m[v]) then add v to mergedValues
mergedMap[v] := merge m[v] with mergedMap[v]
else mergedMap[v] := m[v]
If (v is lost in m and m.getStored(v) != NOT_NULL) then
Add v to mergedMap.spoiledValues
29. NULLABILITY INFERENCE: INFER FROM FIELD VALUE
Input:
field: field description
Output:
ann: nullability annotation
If (field is final and field type is not primitive and field initial
value is not null) then
ann := NOT_NULL
else
ann := UNKWNOWN
30. NULLABILITY INFERENCE: INFER FROM METHOD
Input:
method: method to be analyzed
cfg: control-flow graph of method
ann: predefined annotations set
Output:
inferredAnn: inferred annotations set
ovrMap := new empty nullability map
mergedMap := new empty nullability map
returnValueInfo := UNKNOWN
fieldInfo := new empty map from fields to nullability values
For each instruction insn in cfg
insnMap := compute nullability map for insn
If (insn is *RETURN) then
Process return instruction (insn, mergedMap, returnValueInfo)
If (insn is PUTFIELD or PUSTATIC) then
Process field write (insn, fieldInfo)
inferredAnn := create annotations (ovrMap, mergedMap,
returnValueInfo, fieldInfo)
31. NULLABILITY INFERENCE: PROCESS RETURNS
Input:
insn: instruction
mergedMap: nullability map (to be updated)
returnValueInfo: return value nullability (to be updated)
Merge insnMap to mergedMap
If (insn is ARETURN) then
For each possible return value v
retValue := if ovrMap contains v then ovrMap[v] else
insnMap[v]
Merge retValue to returnValueInfo
32. NULLABILITY INFERENCE: PROCESS FIELD WRITE
Input:
insn: instruction
fieldInfo: map from fields to nullability values (to be updated)
field := field mutated by insn
If (field has reference type and is final) then
nullability := Merge all possible nullabilities of new field value in
insn
If (fieldInfo contains key field) then
fieldInfo[field] := fieldInfo[field] merge nullability
else
fieldInfo[field] := nullability
33. NULLABILITY INFERENCE: CREATE ANNOTATIONS
Input:
ovrMap: override nullability map
mergedMap: merged instruction nullability map
returnValueInfo: return value nullability
fieldInfo: map from fields to nullability values
Output
ann: annotations set
ann := new empty annotations set
ann[return type position] := convert returnValueInfo to annotation
For each interesting value v in mergedMap.keySet
pos := annotation position corresponding to v
If (v in ovrMap.keySet) then
nullability := ovrMap.getStored(v)
else If (v in mergedMap.spoiledValues)
nullability := NULLABLE
else nullability := mergedMap.getStored(v)
ann[pos] := convert nullability to annotation
34. COMPUTE INSTRUCTION NULLABILITY MAP
Input:
ann: existing annotations set
insn: instruction
cfg: control-flow graph
ovrMap: overriding nullability map (to be updated)
Output:
insnMap: instruction nullability map
insnMap, mergedValues := merge maps from incoming edges of insn
inheritedValues := insnMap.keySet – mergedValues
Process dereferencing (ann, insn, insnMap, cfg, ovrMap)
If (insn is null check) then
Process null-branching (insn, insnMap, cfg, ovrMap)
Else If (insn is equality check preceded by instanceof) then
Process instanceof-branching (insn, insnMap, cfg, ovrMap)
Else for each outgoing transition e of insn
e.nullabilityMap := Copy of insnMap with state replaced with e’s
own frame state
35. PROCESS DEREFERENCING INSTRUCTION
Input:
ann: existing set of annotations
insn: instruction
insnMap: instruction nullability map (to be updated)
cfg: control-flow graph
ovrMap: overriding nullability map (to be updated)
If (insn is invocation of some method m) then
Mark each possible value of m’s receiver as NOT_NULL
For each parameter param of m
pos := annotation position corresponding to param of m
If (ann[pos] is NOT_NULL) then mark each possible value
of param as NOT_NULL
If (insn is GETFIELD, ARRAYLENGTH, ATHROW,
MONITORENTER, MONITOREXIT, *ALOAD, *ASTORE, or
PUTFIELD) then
Mark each possible value of insn receiver as NOT_NULL
36. PROCESS NULL-BRANCHING INSTRUCTION
Input:
insn: instruction
insnMap: instruction nullability map (to be updated)
cfg: control-flow graph
ovrMap: overriding nullability map (to be updated)
For nullable transition e
e.nullabilityMap := Copy of insnMap with state replaced with e’s
own frame state and nullability of condition subjects replaced
according to the rule:
If CONFLICT or NOT_NULL then CONFLICT, otherwise NULL
For non-nullable transition e
Similar to above, but replacement rule is
If CONFLICT or NULL then CONFLICT, otherwise NOT_NULL
For each remaining transition e
e.nullabilityMap := Copy of insnMap with state replaced with e’s
own frame state
If (outcome of nullable transition target is ONLY_THROWS) then
For each possible value v of condition subject
ovrMap[v] := NOT_NULL
37. PROCESS INSTANCEOF-BRANCHING INSTRUCTION
Input:
insn: instruction (IFEQ/IFNE) preceded by INSTANCEOF
insnMap: instruction nullability map (to be updated)
cfg: control-flow graph
ovrMap: overriding nullability map (to be updated)
For instance-of (non-nullable) transition e
e.nullabilityMap := Copy of insnMap with state replaced with e’s
own frame state and nullability of condition subjects replaced
according to the rule:
If CONFLICT or NULL then CONFLICT, otherwise NOT_NULL
For not-instance-of (nullable) transition e
Similar to above, but replacement rule is
If UNKNOWN then NULLABLE, otherwise do not change
For each remaining transition e
e.nullabilityMap := Copy of insnMap with state replaced with e’s
own frame state
38. NULLABILITY VALUE MARKING
Input
value: stack value
inheritedValues: set of inherited values
insnMap: instruction nullability map (to be updated)
ovrMap: overriding nullability map (to be updated)
If (insnMap.getStored(value) is neither CONFLICT, nor NULL)
insnMap[value] := NOT_NULL
If (value is interesting and
inheritedValues is empty and
value is not in insnMap.spoiledValues) then
ovrMap[value] := NOT_NULL
