The document describes the 6-step process for applying an external thermal insulation system from ISOMAT. The key steps include: 1) attaching an aluminum holding rail around the building, 2) applying adhesive to insulation boards, 3) attaching the insulation boards in overlapping layers, 4) mechanically fastening the boards with anchors, 5) applying a base coat of adhesive with mesh reinforcement, and 6) applying a plaster finish. The system provides energy savings, environmental benefits, and a durable, weather-resistant building facade.

1. www
isomat
eu
save energy
and live
comfortably
easy
application
in 6 steps
the system's
multiple
advantages
THE APPLICATION PROCESS
1
2
“I save energy & reduce my operating expences”
ANTY
WARR EMS
SYST
3
A
4
Next the adhesive (ISOMAT AK-T35/T55/T65)
is applied on the thermal insulation boards
(EPS, XPS, MINERAL WOOL) in 2 different
ways:
a) Uniformly, on the whole surface of the
board, using a notched trowel, if the
substrate is smooth.
b) Along the perimeter of the board and in 2
or more spots in its center, using a trowel,
if the substrate is uneven.
5
EXTERNAL THERMAL INSULATION SYSTEMS
ENJOY YOUR LIVING SPACE WHILE
YOU SAVE ENERGY
B
The aluminium holding rail is placed around
the building and parallel to the ground by
fastening it on the substrate with special
anchors (2 pieces/meter).
With the external thermal insulation system ISOMAT
THERMOSYSTEM you save energy by consuming less fuel for
heating during winter and less electrical power for airconditioning during summer. Thus, since the energy cost is
significantly reduced, the money invested in the installation of
ISOMAT THERMOSYSTEM is paid off at a great extent already
from the first years of the system's operation.
“I contribute to the environmental protection”
ISOMAT THERMOSYSTEM contributes to the protection of the
environment, as it reduces drastically the air pollution, which is
caused by the use of fuel for a building's heating or cooling.
Particularly, ISOMAT THERMOSYSTEM contributes to the
reduction of emission of carbon dioxide and other pollutants,
such as nitrogen and sulphur oxides, that are responsible for
the creation of the Greenhouse Effect.
The energy saving in buildings is an evergreen
topic, as it leads to the reduction of energy
consumption for heating and cooling, which
reduces radically both the households' expenses
and the air pollution.
The thermal insulation boards (EPS, XPS,
MINERAL WOOL) are then fixed by placing
them from bottom up, in horizontal
consecutive layers overlapping each other so
as to form a layout of crossed joints that will
prevent cracking of the overlaid plaster.
For this reason, ISOMAT has developed the
external thermal insulation system ISOMAT
THERMOSYSTEM, which contributes to great
energy saving by consuming less fuel for heating
during the winter and less electrical power for airconditioning during summer due to the excellent
thermo-insulation of the building. In this way you
save money and contribute to the environmental
protection, while you enjoy thermal comfort in your
living space during the whole year.
6
“I enjoy my living space”
ISOMAT THERMOSYSTEM eliminates the thermal bridges.
In this way the building remains thermal protected all-around
and ensures a stable as possible room temperature throughout
the year. Thus, you enjoy thermal comfort in your living space
during all seasons.
0712
“I renovate and protect my building”
The following day the thermal insulation
boards (EPS, XPS, MINERAL WOOL) are fixed
mechanically with collar head anchors, which
should have a length according to the
thickness of the board and the type of the
substrate. Next the base coat
(ISOMAT AK-T35/T55/T65) is applied
universally on the boards.
The base coat is applied with a notched
trowel in parts of width > 1m. Afterwards,
the fiberglass mesh is placed and pressed on
the still fresh layer of the base coat with a
smooth trowel.
CERTIFIED SYSTEM
After the base coat has fully dried, the
surface is primed with the primer of the
respective plaster that will be used. After the
primer has dried, the surface is then coated
with the pasty acrylic or silicone plasters
MARMOCRYL of ISOMAT.
THESSALONIKI, GREECE
17th km Thessaloniki - Ag. Athanasios Road
P. O. BOX 1043, 570 03 AG. ATHANASIOS, GREECE
Τ +30 2310 576 000, F +30 2310 722 475
ISOMAT S.A.
ΒUILDING CHEMICALS & MORTARS
www.isomat.eu
info@isomat.eu
ISOMAT THERMOSYSTEM has been
certified according to the requirements of
the European Standard EN 13499:
external thermal insulation composite
systems (ETICS) based on expanded
polystyrene.
This certification guarantees that the
system maintains a stable, long-term
performance.
ISOMAT THERMOSYSTEM constitutes a great solution for the
renovation of old constructions. The buildings acquire a new,
beautiful decorated façade thanks to the colored, high quality,
pasty plasters MARMOCRYL of ISOMAT, which are available in
305 unique colors. At the same time, the façade becomes
absolute weather resistant and waterproof, without losing its
vapor permeability.
“I finish work fast & easy”
ISOMAT THERMOSYSTEM is applied fast and easy. Its fast and
most cost-effective installation is assured only if it is done by a
trained installation crew. During the application of ISOMAT
THERMOSYSTEM, the tenants do not need to move out from
the house, while there is only a minimum disturbance for the
neighbours.

2. ISOMAT THERMOSYSTEM CLASSIC
ISOMAT THERMOSYSTEM PREMIUM
ISOMAT THERMOSYSTEM XPS
ISOMAT THERMOSYSTEM WOOL
ISOMAT THERMOSYSTEM CLASSIC is an affixed system of multiple layers, which consists of:
ISOMAT THERMOSYSTEM PREMIUM is an affixed system of multiple layers, which consists of:
ISOMAT THERMOSYSTEM XPS is an affixed system of multiple layers, which consists of:
ISOMAT THERMOSYSTEM WOOL is an affixed system of multiple layers, which consists of:
• Thermal insulation boards of expanded polystyrene (EPS).
• Supplementary parts (aluminium holding rail with embedded water drip, fiberglass mesh, corner profile with
mesh etc.)
• Special fiber-reinforced mortar used both as an adhesive for fixing the thermal insulation boards and for
creating the base coat before plastering.
• Acrylic, water-repellent, pasty plasters.
• Thermal insulation boards of expanded polystyrene (EPS).
• Supplementary parts (aluminium holding rail with embedded water drip, fiberglass mesh, corner profile with
mesh etc.)
• Special, high quality, fiber-reinforced mortar used both as an adhesive for fixing the thermal insulation boards
and for creating the base coat before plastering.
• Acrylic or silicone, water-repellent, vapor permeable, pasty plasters.
• Thermal insulation boards of extruded polystyrene (XPS).
• Supplementary parts (aluminium holding rail with embedded water drip, fiberglass mesh, corner profile with
mesh etc.)
• Special, high quality, fiber-reinforced mortar used both as an adhesive for fixing the thermal insulation boards
and for creating the base coat before plastering.
• Acrylic or silicone, water-repellent, pasty plasters.
• Thermal insulation boards of mineral wool.
• Supplementary parts (aluminium holding rail with embedded water drip, fiberglass mesh, corner profile with
mesh etc.)
• Special, high quality mortar used both as an adhesive for fixing the thermal insulation boards and for creating
the base coat before plastering.
• Silicone, water-repellent, pasty plasters.
ISOMAT THERMOSYSTEM CLASSIC is the most cost-effective thermal-insulation solution proposed by ISOMAT.
It is vapor-permeable, allowing the construction to breathe. It also constitutes an excellent solution for the renovation
of old constructions thanks to the colored, high quality, pasty plasters MARMOCRYL of ISOMAT, which are available in
305 unique colors.
ISOMAT THERMOSYSTEM PREMIUM is the ideal solution for constructions with high requirements in ageing
resistance and durability. It is vapor permeable, allowing the constructions to breathe. It constitutes an excellent
solution for the renovation of old constructions thanks to the colored, high quality, pasty plasters MARMOCRYL or
MARMOCRYL SILICONE of ISOMAT, which are available in 305 unique colors.
ISOMAT THERMOSYSTEM XPS is the ideal solution for constructions with very high requirements in durability,
resistance to ageing and impact-resistant facades. It allows the building to breath. It constitutes an excellent solution
for the renovation of old constructions thanks to the colored, high quality, pasty plasters MARMOCRYL or
MARMOCRYL SILICONE of ISOMAT, which are available in 305 unique colors.
ISOMAT THERMOSYSTEM WOOL is the ideal solution for constructions with high requirements in fire protection, as
mineral wool is highly fire-resistant. It is also very vapor-permeable, allowing the building to breathe, as well as sound
insulating. It constitutes an excellent solution for the renovation of old constructions thanks to the colored, high quality
plasters MARMOCRYL SILICONE of ISOMAT, which are available in 305 unique colors.
1
Fixing of thermal insulation boards
with ISOMAT AK-T35
2
Thermal insulation boards
of expanded polystyrene (EPS)
3
Reinforced layer (base coat) of ISOMAT AK-T35
with THERMOSYSTEM fiberglass mesh (145 g/m²)
4
1
2
Plastering with MARMOCRYL
3
Reinforced layer (basecoat) of ISOMAT AK-T55
with THERMOSYSTEM fiberglass mesh (160 g/m²)
4
2
Thermal insulation boards
of expanded polystyrene (EPS)
3
1
Fixing of thermal insulation boards
with ISOMAT AK-T55
1
Plastering with MARMOCRYL or
MARMOCRYL SILICONE
1
Plastering with MARMOCRYL or
MARMOCRYL SILICONE
RECOMMENDED PRODUCTS
MARMOCRYL Fine
MARMOCRYL Decor
MARMOCRYL GRANIT
ISOMAT AK-T55
MARMOCRYL Fine & Decor
Fiber-reinforced, cement-based
adhesive and base coat for
thermal insulation boards.
Consumption:
as adhesive: approx. 3,0-4,0 kg/m²
as base coat:
approx. 1,5 kg/m²/mm
Acrylic, white or colored, pasty
plaster. It is used for the creation
of colored, water-repellent
surfaces with smooth finish.
Consumption:
approx. 1,8 kg/m²/mm
Acrylic, white or colored, pasty
plaster. It is used for the creation
of colored, water-repellent
surfaces with coarse-textured
finish.
Consumption:
approx. 1,6 kg/m²/mm
Acrylic, pasty coating with colored
fillers. It is used for the creation of
decorative, water-repellent
surfaces with granite-like finish.
Consumption:
approx. 1,8 kg/m²/mm
High quality, fiber-reinforced,
cement-based adhesive and base
coat for thermal insulation boards.
Consumption:
as adhesive: approx. 3,0-4,0 kg/m²
as base coat:
approx. 1,5 kg/m²/mm
Acrylic, white or colored, pasty
plaster. It is used for the creation
of colored, water-repellent
surfaces with smooth or coarsetextured finish.
Consumption:
Fine: approx. 1,8 kg/m²/mm
Decor: approx. 1,6 kg/m²/mm
ML-PRIMER
BOARDS OF EXPANDED
POLYSTYRENE
THERMOSYSTEM
FIBERGLASS MESH 145 g/m²
Thermal insulation boards of
expanded polystyrene. Available in
several thicknesses.
Polyester cloth of 145 g/m², used
for reinforcing the base coat on
the thermal insulation boards.
ML-PRIMER
SILICONE PRIMER
High quality, colored, filled primer
for the adhesion of acrylic plasters.
Consumption:
approx. 150-300 g/m²
High quality primer for
the adhesion of silicone plasters.
Consumption:
approx. 100-200 g/m²
Silicone, white or colored, pasty
plaster. It is used for the creation
of colored, water-repellent
surfaces with smooth or coarsetextured finish.
Consumption:
Fine: approx. 1,8 kg/m²/mm
Decor: approx. 1,6 kg/m²/mm
4
MARMOCRYL GRANIT
ISOMAT AK-T55
MARMOCRYL Fine & Decor
High quality, fiber-reinforced,
cement-based adhesive and base
coat for thermal insulation boards.
Consumption:
as adhesive: approx. 3,0-4,0 kg/m²
as base coat:
approx. 1,5 kg/m²/mm
Acrylic, white or colored, pasty
plaster. It is used for the creation
of colored, water-repellent
surfaces with smooth or coarsetextured finish.
Consumption:
Fine: approx. 1,8 kg/m²/mm
Decor: approx. 1,6 kg/m²/mm
THERMOSYSTEM
FIBERGLASS MESH 160 g/m²
Thermal insulation boards of
expanded polystyrene. Available in
several thicknesses.
Polyester cloth of 160 g/m², used
for reinforcing the base coat on
the thermal insulation boards.
Plastering with MARMOCRYL SILICONE
2
3
4
4
Acrylic, pasty coating with colored
fillers. It is used for the creation of
decorative, water-repellent
surfaces with granite-like finish.
Consumption:
approx. 1,8 kg/m²/mm
BOARDS OF EXPANDED
POLYSTERENE
Reinforced layer (base coat) of ISOMAT AK-T65
with THERMOSYSTEM fiberglass mesh (160 g/m²)
1
3
RECOMMENDED PRODUCTS
MARMOCRYL SILICONE
Fine & Decor
Thermal insulation boards
of mineral wool
3
2
Fixing of thermal insulation boards
with ISOMAT AK-T65
2
1
4
ISOMAT AK-T35
High quality, colored, filled primer
for the adhesion of acrylic plasters.
Consumption:
approx. 150-300 g/m²
Reinforced layer (base coat) of ISOMAT AK-T55
with THERMOSYSTEM fiberglass mesh (160 g/m²)
4
3
Thermal insulation boards
of extruded polystyrene (XPS)
3
2
4
RECOMMENDED PRODUCTS
2
1
Fixing of thermal insulation boards
with ISOMAT AK-T55
ML-PRIMER
SILICONE PRIMER
High quality, colored, filled primer
for the adhesion of acrylic plasters.
Consumption:
approx. 150-300 g/m²
High quality primer for
the adhesion of silicone plasters.
Consumption:
approx. 100-200 g/m²
RECOMMENDED PRODUCTS
MARMOCRYL SILICONE
Fine & Decor
Silicone, white or colored, pasty
plaster. It is used for the creation
of colored, water-repellent
surfaces with smooth or coarsetextured finish.
Consumption:
Fine: approx. 1,8 kg/m²/mm
Decor: approx. 1,6 kg/m²/mm
MARMOCRYL GRANIT
ISOMAT AK-T65
MARMOCRYL SILICONE Fine
MARMOCRYL SILICONE Decor MARMOCRYL GRANIT
Acrylic, pasty coating with colored
fillers. It is used for the creation of
decorative, water-repellent
surfaces with granite-like finish.
Consumption:
approx. 1,8 kg/m²/mm
High quality, cement-based
adhesive and base coat for
thermal insulation boards.
Consumption:
as adhesive: approx. 3,0-4,0 kg/m²
as base coat:
approx. 1,5 kg/m²/mm
Silicone, white or colored, pasty
plaster. It is used for the creation
of colored, vapor permeable,
water-repellent surfaces with
smooth finish.
Consumption:
approx. 1,8 kg/m²/mm
Silicone, white or colored, pasty
plaster. It is used for the creation
of colored, vapor breathable,
water-repellent surfaces with
coarse-textured finish.
Consumption:
approx. 1,6 kg/m²/mm
SILICONE PRIMER
MINERAL WOOL
High quality primer for
the adhesion of silicone plasters.
Consumption:
approx. 100-200 g/m²
Thermal insulation boards of
mineral wool. Available in several
thicknesses.
THERMOSYSTEM
FIBERGLASS MESH 160 g/m²
BOARDS OF EXTRUDED
POLYSTERENE
THERMOSYSTEM
FIBERGLASS MESH 160 g/m²
Thermal insulation boards of
extruded polystyrene. Available in
several thicknesses.
Polyester cloth of 160 g/m², used
for reinforcing the base coat on
the thermal insulation boards.
Polyester cloth of 160 g/m², used
for reinforcing the base coat on
the thermal insulation boards.
Acrylic, pasty coating with colored
fillers. It is used for the creation of
decorative, water-repellent
surfaces with granite-like finish.
Consumption:
approx. 1,8 kg/m²/mm
