Internet protocol security (IPSec) is a protocol suite that authenticates and encrypts IP packets between communicating devices. It operates at the network layer and is transparent to applications. IPSec uses two security protocols: the Authentication Header protocol (AH) which provides data integrity and authentication, and the Encapsulating Security Payload (ESP) protocol which provides confidentiality, integrity, and authentication. IPSec can operate in either transport mode between hosts or tunnel mode between gateways to provide a virtual private network.

3. Benefits of Ipsec

4. Modes of operation

5. Security Protocols(Architecture)

11. authentication

12. confidentiality

13. key management

16. is resistant to bypass

17. is below transport layer, hence transparent to applications

18. can be transparent to end users

19. can provide security for individual users if desired

20. additionally in routing applications:

21. assure that router advertisments come from authorized routers

22. neighbor advertisments come from authorized routers

23. insure redirect messages come from the router to which initial packet was sent

25. Connectionless integrity

26. Data origin authentication

27. Rejection of replayed packets

28. a form of partial sequence integrity

29. Confidentiality (encryption)

32. IPsec in transport mode does not protect Ipheader.It protects what is delivered from the transport layer to the network layer.

33. In this mode,theIpsec header and tailer are added to the information coming from the transport layer.The IP header is added later.

36. Tunnel mode is used when either the sender or the receiver is not a host.

39. Security Parameters Index (SPI)

40. a bit string

41. IP Destination Address

42. only unicast allowed

43. could one-way relationship between sender & receiver that affords security for traffic flow

44. d be end user, firewall, router

45. Security Protocol Identifier

46. indicates if SA is AH or ESP

47. has a number of other parameters

48. seq no, AH & EH info, lifetime etc

51. It uses a hash function and a symmetric key to create message authentication code.

52. It can be considered analogous to the algorithms used to calculate checksums or perform CRC checks for error detection.

54. The destination device does the same calculation using the key the two devices share, which enables it to see immediately if any of the fields in the original datagram were modified (either due to error).

55. ICV does not change the original data.

59. Authentication header

63. ESP provides source authentication, data integrity and privacy(confidentiality) and also provides protection against replay attacks.

65. ESP packet is identified by the protocol field of an IPv4 header and the “Next Header” field of an IPv6 header. It’s IP protocol number is 50.

68. ENCAPSULATION SECURITY PAYLOAD (ESP)

72. IPSec services

75. IPsec does not stop traffic analysis.

76. Ipsec provides encryption without authentication using ESP which is very dangerous.

78. Computer networks by Andrew Tanenbaum

79. Cryptography and Network Security by William Stallings
