1. Ashu Joshi
@AshuJoshi
Movinture
Accelerating your IoT Solution
1
#MovingTheFuture
IoT Systems
Technology, Architecture &
Performance

2. 3
About Movinture
http://www.movinture.com
#MovingTheFuture

3. 4
#MovingTheFuture
IoT Backend
Edge + Cloud
Data Fusion &
Integration Platform
Enabling Product as a Service
Connectivity
Data & Control
User + Device Management Business Logic Mapping
Application(s)
Enterprise (Integration)
Machine IntelligenceUse case optimized, business-model
driven IoT-applications to augment
physical products as a service.

4. 5
IoT Overview
#MovingTheFuture

5. 6
Anything that can be measured or connected or controlled, will
be.
WE NOW LIVE IN A CONNECTED
ECONOMY
yes, anything. and everything.
#MovingTheFuture

6. 7
“CEOs are moving from leading companies
that make cars, toasters, elevators,
construction equipment, washing machines
and more to companies that are, basically,
producing Internet-connected devices.” - Forrester
#MovingTheFuture
It is an opportunity to catapult your business and become
a technology company.

7. 8
#MovingTheFuture
Market Size is Huge.
Imagine when everything physical is
connected…
$6.2 Trillion Economic Opportunity by 2025
$7.6 Trillion Opportunity by 2025 in IIoT, $3.5 in Consumer

8. 9
“Things” in perspective
2015
Human
Population
# of
Devices
0
5
10
15
20
25
30
35
Billions
2016 2017 2018 2019 2020
Global Internet Users 2015 -
3.25B growing @ 7%
#MovingTheFutureSource/Credits: McKinsey, IDC, KPCB,
census.gov
The scale which we build for.

9. LayeredSecurity
10
Building IoT Apps takes software, lots of
software…and a good bit of hardware
#MovingTheFuture
Connectivity Compute Storage
Sensing Actuating
OS, Drivers, Application Mgmt Framework
Web & Mobile App(s)
Data and Control
App-based User & Device Management
Business Logic & Workflow Mapping
BillingIntegration
EnterpriseIntgr.
DataInterface
Analytics
Reporting
Visualization
Machine Learning
Sensor | Actuator | Thing
| Device | Node
Gateway | Edge | Fog Cloud
Data
Analytics
Machine Learning
IoT Apps are distributed

10. 11
Let’s dig deeper
#MovingTheFuture

11. 12
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Typical IoT Architecture
Partner / Customer
IoT Cloud(s)

12. 13
Typical IoT Architecture
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Partner / Customer
IoT Cloud(s)
Sensor:
Responsible for interfacing
the “physical” thing to the
“digital” world
Simple or Complex: A simple
temperature sensor or a
complex machine like a
Tractor or Washing Machine
Interfaces wirelessly or wired
using many different
protocols

13. 13
Typical IoT Architecture
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Partner / Customer
IoT Cloud(s)
Sensor:
Responsible for interfacing
the “physical” thing to the
“digital” world
Simple or Complex: A simple
temperature sensor or a
complex machine like a
Tractor or Washing Machine
Interfaces wirelessly or wired
using many different
protocols
Gateway or Edge:
Provides local/edge
processing
Rule Engine, Local Analytics
Local storage
Interfaces to the Sensors/
Things
Connects to the Cloud,
provides IP connectivity

14. 13
Typical IoT Architecture
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Partner / Customer
IoT Cloud(s)
Sensor:
Responsible for interfacing
the “physical” thing to the
“digital” world
Simple or Complex: A simple
temperature sensor or a
complex machine like a
Tractor or Washing Machine
Interfaces wirelessly or wired
using many different
protocols
Gateway or Edge:
Provides local/edge
processing
Rule Engine, Local Analytics
Local storage
Interfaces to the Sensors/
Things
Connects to the Cloud,
provides IP connectivity
Cloud:
Interfaces with all sensors/
things, collects data, and
controls/manages the things
interfaces with business
applications
provides interface for control,
visualization, reporting,
alerts/notifications

15. 13
Typical IoT Architecture
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Partner / Customer
IoT Cloud(s)
Sensor:
Responsible for interfacing
the “physical” thing to the
“digital” world
Simple or Complex: A simple
temperature sensor or a
complex machine like a
Tractor or Washing Machine
Interfaces wirelessly or wired
using many different
protocols
Gateway or Edge:
Provides local/edge
processing
Rule Engine, Local Analytics
Local storage
Interfaces to the Sensors/
Things
Connects to the Cloud,
provides IP connectivity
Cloud:
Interfaces with all sensors/
things, collects data, and
controls/manages the things
interfaces with business
applications
provides interface for control,
visualization, reporting,
alerts/notifications
Mobile Apps:
Mobile Apps - primarily
design to work @ system
level
Aiding in provisioning,
installing and monitoring
Consumer/Customer level
user interface to interact or
manage the system

16. 14
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Where are the “things”?
Partner / Customer
IoT Cloud(s)

17. 14
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Where are the “things”?
Partner / Customer
IoT Cloud(s)
10s of
Billions
Billions
100s of
Millions
10s-100s of
Thousands

18. 15
Software across Distributed Architecture
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Partner / Customer
IoT Cloud(s)

19. 15
Software across Distributed Architecture
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Partner / Customer
IoT Cloud(s)

20. 15
Software across Distributed Architecture
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Partner / Customer
IoT Cloud(s)
Primarily Embedded
Programming with C & C++
Node/JS and Python
gaining some traction, and
may continue to grow
Java-versions also present
Constrained level
programming, firmware
talent. Talent hard to come
by
Knowledge of hardware
benefits

21. 15
Software across Distributed Architecture
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Partner / Customer
IoT Cloud(s)
Primarily Embedded
Programming with C & C++
Node/JS and Python
gaining some traction, and
may continue to grow
Java-versions also present
Constrained level
programming, firmware
talent. Talent hard to come
by
Knowledge of hardware
benefits
Mix of Embedded/Firmware
and High Level Programming
Most Gateways support Linux
- Linux/Unix style OS
programming experience
helpful
Languages: C/C++/Node/
Python/Java
Connectivity Stack, Drivers,
Networking Protocols
Sockets, REST, Pub/Sub

22. 15
Software across Distributed Architecture
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Partner / Customer
IoT Cloud(s)
Primarily Embedded
Programming with C & C++
Node/JS and Python
gaining some traction, and
may continue to grow
Java-versions also present
Constrained level
programming, firmware
talent. Talent hard to come
by
Knowledge of hardware
benefits
Mix of Embedded/Firmware
and High Level Programming
Most Gateways support Linux
- Linux/Unix style OS
programming experience
helpful
Languages: C/C++/Node/
Python/Java
Connectivity Stack, Drivers,
Networking Protocols
Sockets, REST, Pub/Sub
Public Cloud: AWS, Azure,
Heroku, Bluemix, Google
Java,Node(Primary), Other:
Net,Golang
API Integration, Cloud to
Cloud, Pub/Sub, Messaging
Enterprise Integration
Remote Mgmt / Dev Mgmt
Visualization & Analytics

23. 15
Software across Distributed Architecture
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Partner / Customer
IoT Cloud(s)
Primarily Embedded
Programming with C & C++
Node/JS and Python
gaining some traction, and
may continue to grow
Java-versions also present
Constrained level
programming, firmware
talent. Talent hard to come
by
Knowledge of hardware
benefits
Mix of Embedded/Firmware
and High Level Programming
Most Gateways support Linux
- Linux/Unix style OS
programming experience
helpful
Languages: C/C++/Node/
Python/Java
Connectivity Stack, Drivers,
Networking Protocols
Sockets, REST, Pub/Sub
Public Cloud: AWS, Azure,
Heroku, Bluemix, Google
Java,Node(Primary), Other:
Net,Golang
API Integration, Cloud to
Cloud, Pub/Sub, Messaging
Enterprise Integration
Remote Mgmt / Dev Mgmt
Visualization & Analytics
Web technologies for Web
Apps
IOS / Android
Networking & Protocol
Programming

24. 16
#MovingTheFuture
Edge: Sensor - Gateway
Sensor | Actuator | Thing
| Device | Node Gateway | Edge | Fog
Sensing:
Accelerometer, Magnetometer, Gyroscope,
Pressure, Temperature, Altimeter, pH, Gas,
Proximity
Actuator
Embedded Processing: MCU, MPU, Hybrid
MPU, Network Processor, Graphics
Processor
OS/RTOS, Drivers, Network Stack, Security,
Remote Management, Provisioning
Connectivity
Display
Examples: Appliances, Vehicles, Machines,
Vending Machines, Aircraft, Drones, Toys,
Wearables, etc. List is endless!
Interfacing to the Sensors/Actuators
Support for the Connectivity
Connects to Multiple Sensors/Actuators
Higher End processors
Off the Shelf / DIY Example: Raspberry Pi,
Beaglebone etc.
Typically runs Linux or an RTOS, Drivers,
Network Stack, Security, Remote
Management, Provisioning
Connects to the Internet using 3G/LTE,
Ethernet, Wi-Fi etc.
Typically “many” things connected to a Gateway/Edge

25. 17
#MovingTheFuture
Gateway - Cloud
Gateway | Edge | Fog
Interfacing to the Sensors/Actuators
Support for the Connectivity
Connects to Multiple Sensors/Actuators
Higher End processors
Off the Shelf / DIY Example: Raspberry Pi,
Beaglebone etc.
Typically runs Linux or an RTOS, Drivers,
Network Stack, Security, Remote
Management, Provisioning
Connects to the Internet using 3G/LTE,
Ethernet, Wi-Fi, Satellite
etc.
Cloud:
Manages and communicates with multiple
gateways and devices/sensors
Data Management
Device & Gateway Management
Enterprise Integration
Billing & Payments
Analytics, Machine Intelligence, Predictive
Maintenance, Reporting, Visualization
etc.
AWS/Azure/GC/Bluemix, Data Center etc.
Typically many gateways to the cloud
Cloud, Data, ML/AI
MQTT
HTTP
WebSockets
DDS, XMPP
Other

26. Complex & Composite Devices
Each Car today (i.e. Non
Autonomous) has 100s may be
1000s of sensors, 40 to 50
Microprocessors, multiple
connectivity (buses) internally. And
many offer 3G/LTE connections to
the Cloud for Service &
Entertainment.
Autonomous cars will have Edge-
capable AI/ML engines
(happening today). And 10x more
sensors.
Fun Fact
High End Luxury cars have MORE
100 millions line of code, more
than a Dreamliner 787
18

27. 19
IoT Use Case: Smart Meters
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Partner / Customer
IoT Cloud(s)

28. 19
IoT Use Case: Smart Meters
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Partner / Customer
IoT Cloud(s)

29. 19
IoT Use Case: Smart Meters
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Partner / Customer
IoT Cloud(s)Multiple connectivity options
Sub GHz Wireless common
2G/3G
Newer LPWANs trying to compete such as
LoRaWAN & SigFox
Many are vendor-specific such as Sensus
Flexnet or SSN StarFish.
TRAFFIC PATTERN:
100s of Bytes, 15 Minutes intervals most
frequent, mostly monthly readings
Unidirectional: Meter to Gateway to Utility
Utilities: Gas, Water,
Electric
Metering Providers:
SSN, Sensus, Itron,
Elster etc.

30. 19
IoT Use Case: Smart Meters
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Partner / Customer
IoT Cloud(s)Multiple connectivity options
Sub GHz Wireless common
2G/3G
Newer LPWANs trying to compete such as
LoRaWAN & SigFox
Many are vendor-specific such as Sensus
Flexnet or SSN StarFish.
TRAFFIC PATTERN:
100s of Bytes, 15 Minutes intervals most
frequent, mostly monthly readings
Unidirectional: Meter to Gateway to Utility
Utilities: Gas, Water,
Electric
Metering Providers:
SSN, Sensus, Itron,
Elster etc.
WW Installed Base
(Electric Smart
Meters) by 2020:
~ 850 million 10s may be 100s of
companies dedicated
to providing analytics
for meter data!!!

31. 20
IoT Use Case: Smart Home
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Partner / Customer
IoT Cloud(s)

32. 20
IoT Use Case: Smart Home
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Partner / Customer
IoT Cloud(s)

33. 20
IoT Use Case: Smart Home
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Partner / Customer
IoT Cloud(s)
Nest Thermostat is a Complex Device - it
supports Wi-Fi, ZigBee and has a very
capable processor.
It is a mini Gateway + Sensor
Connectivity: Home Wi-Fi (can function
offline)
Traffic Pattern:
Frequent, in MB
BI DIRECTIONAL
Nest Cam is a complex device.
Sensor is the Camera, Microphone.
It is a mini Gateway + Sensor
Connectivity: Home Wi-Fi (can function
offline)
Traffic Pattern:
24x7 OR on Command
High Bandwidth, Gigabytes if 24x7
Low Bandwidth bidirectional - control and
speaker
Nest Protect - both constrained in some
respects, and complex.
Gas Sensing.
Communicates with the Nest Thermostat
over 802.15.4 / Thread network
Traffic pattern:
Continuous, mostly local. Critical traffic.
developer.nest.com - Fun fact - used to
run on AWS even after the Google
acquisition. Seems to have recently
moved away from AWS.
Nest works with Utilities to
run Energy Management
programs - such as
Demand / Response
“Works with Nest” program - Cloud to
cloud integration with other Smart &
Connected devices/appliances.

34. 21
IoT Use Cases: Smart Buildings
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Partner / Customer
IoT Cloud(s)

35. 21
IoT Use Cases: Smart Buildings
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Partner / Customer
IoT Cloud(s)
Sensors e.g. occupancy
Connected Lights
Smart Utility
Meters / Submeters
Building HVACs
Security & Surveillance
Building
Management
System
Building
Management
System
BACNet Controllers

36. 21
IoT Use Cases: Smart Buildings
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Partner / Customer
IoT Cloud(s)
Sensors e.g. occupancy
Connected Lights
Smart Utility
Meters / Submeters
Building HVACs
Security & Surveillance
Building
Management
System
Building
Management
System
BACNet Controllers
Multiple Protocols inside the building:
BACNet, ZigBee, LoRa, Wi-Fi, Bluetooth,
Other proprietary
Diversity of devices - constrained devices
like Occupancy Sensors. Gateways for
Lighting Control.
HVAC & Air Conditioning systems
Security and Surveillance - constrained
devices like Card Readers & complex
devices like HD Cameras

37. 22
Summary: Managing Diversity
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Partner / Customer
IoT Cloud(s)

38. 22
Summary: Managing Diversity
Devices (Constrained)
Sensors & Actuators
Enterprise
Integration
IoT-Cloud
Complex /
Composite
Devices
Gateways
Edge | Fog
User-facing IoT
Apps
Sensing | Telemetry
Actuation | Control
Partner / Customer
IoT Cloud(s)
Frequency
Monthly/Daily 24x7x365
Amount
Trickle / Few Bytes River/HD Video MB/GB
Latency
milliseconds
/forgiving
micro/nano
deterministic
Multiple Protocols
HTTP, MQTT, Web Sockets,
XMPP, etc.
Bidirectional traffic is
common. Deterministic &
low-latency is requirement
Running “Cloud” at the
“Edge” is necessary.
Federation between
Edge(s) and Cloud

39. 23
Wrap Up / Q&A / Demos
#MovingTheFuture
Ashu Joshi
@AshuJoshi
