1. Unlock Your Project-Potential
Introduction
to Project Management
What you absolutely need to
All right reserved - b.genotte@mypc-academy.com
know in order to run
successful project
Baudouin Genotte, PMP
2. Unlock Your Project-Potential
Objectives
Provide an overview of how a project can be performed in
a professional way using a industry recognized
All right reserved - b.genotte@mypc-academy.com
methodologies
Explain the value of performing projects this way
Introduction to Project Management 3
3. Unlock Your Project-Potential
Agenda
The broad context of projects
The project context
All right reserved - b.genotte@mypc-academy.com
Project management methodologies
The project manager survival kit
Exercise
Introduction to Project Management 4
4. Unlock Your Project-Potential
All right reserved - b.genotte@mypc-academy.com
THE BROAD CONTEXT OF PROJECTS
Introduction to Project Management 5
5. Unlock Your Project-Potential
The Organizational Context of Portfolio
Management
All right reserved - b.genotte@mypc-academy.com
The Standard for Portfolio Management – 2nd Edition page 9
Introduction to Project Management 6
6. Unlock Your Project-Potential
Portfolio Management Life Cycle
CREATE SELECT PLAN MANAGE
New Organization Resource Strategy
All right reserved - b.genotte@mypc-academy.com
Projects / Ideas Strategy Constraints Execution
Portfolio Portfolio Portfolio
Value Prioritization Planning Delivery
Assessment & & &
Selection Scheduling Execution
Status from Project Review Dependencies
Active Projects Teams Schedule Constraints
RE-ASSESS
Introduction to Project Management 7
7. Unlock Your Project-Potential
Project Management Office(s)
All right reserved - b.genotte@mypc-academy.com
«A Project Management Office is an
organizational body or entity that has
various responsibilities related to the
centralized and coordinated management
of the projects under its domain»
Introduction to Project Management 8
8. Unlock Your Project-Potential
All right reserved - b.genotte@mypc-academy.com
THE PROJECT CONTEXT
Introduction to Project Management 9
9. Unlock Your Project-Potential
What is a Project ?
A project is A project is a temporary
a temporary endeavor organization that is
All right reserved - b.genotte@mypc-academy.com
undertaken to create a created for the
unique purpose of delivering
product, service, or one or more business
result. products according to
an agreed Business
Case
Introduction to Project Management 10
10. Unlock Your Project-Potential
Project Phases
Idea
All right reserved - b.genotte@mypc-academy.com
Problem
Opportunity Inputs Project Management Team
Phases Initial Plan) Intermediate(s) Closing
Project Charter Plan Acceptance
Management
Scope Baseline Approval
Outputs Statement Progress Closure
WBS
Project Product
Deliverables Service
Result
Introduction to Project Management 11
11. Unlock Your Project-Potential
Project Life Cycle
All right reserved - b.genotte@mypc-academy.com
A collection of generally sequential project phases
whose name and number are determined by the
control needs of the organization or organizations
involved in the project.
A life cycle can be documented with a
methodology
Introduction to Project Management 12
12. Unlock Your Project-Potential
Project Managers Interpersonal Skills
All right reserved - b.genotte@mypc-academy.com
Team Building
Leadership
Motivation
Management Efficient Communication
Introduction to Project Management 13
13. Unlock Your Project-Potential
Project Management Life Cycle
MONITOR &
CONTROL
All right reserved - b.genotte@mypc-academy.com
Project Health,
Change requests,
Performance Reports,
Accepted Deliverables
INITIATE PLAN EXECUTE CLOSE
Project Project Work Final Product Service
Charter, Plan Performance or result transition,
Stakeholders (Communication, Scope, Information, Lessons Learned
WBS, Schedule, Costs, Risks, Issues
Resources, Risks) Deliverables
Introduction to Project Management 14
14. Unlock Your Project-Potential
All right reserved - b.genotte@mypc-academy.com
PROJECT MANAGEMENT
METHODOLOGIES
Introduction to Project Management 15
16. Unlock Your Project-Potential
PMBOK in a nutshell
42 Processes
All right reserved - b.genotte@mypc-academy.com
5 Process Groups 9 Knowledge Areas
Introduction to Project Management 17
18. Unlock Your Project-Potential
Prince2 in a nutshell
Four integrated elements Business
Case
The 7 Principles
All right reserved - b.genotte@mypc-academy.com
Progress
The 7 Themes Organization
Prince2
The 7 Processes Processes
Change Quality
Tailoring Prince2 to the
Project Environment Risks Plans
Prince2 Themes
Prince2 Principles
Introduction to Project Management 19
19. Unlock Your Project-Potential
Prince2 in a nutshell – The Journey
Subsequent Final
Initiation
Pre-Project Delivery Delivery
Stage
Stage(s) Stage
All right reserved - b.genotte@mypc-academy.com
Directing
Directing a Project
SU
SB SB CP
Managing
IP CS CS
Delivering MP MP
SU : Starting Up a Project, DP : Directing a Project, IP : Initiating a Project, CP : Closing a Project
SB : Managing a Stage Boundary, CS : Controlling a Stage, MP : Managing Product Delivery
Introduction to Project Management 20
20. Unlock Your Project-Potential
All right reserved - b.genotte@mypc-academy.com
Initiation
Planning
Execution
Monitoring and Control
Closing
THE PROJECT MANAGER SURVIVAL KIT
Introduction to Project Management 21
21. Unlock Your Project-Potential
All right reserved - b.genotte@mypc-academy.com
The project manager survival kit
PROJECT INITIATION
Introduction to Project Management 22
22. Unlock Your Project-Potential
Project Charter
Mandate & Commitment
All right reserved - b.genotte@mypc-academy.com
Introduction to Project Management 23
23. Unlock Your Project-Potential
Project
Charter
All right reserved - b.genotte@mypc-academy.com
Introduction to Project Management 24
24. Unlock Your Project-Potential
Project Stakeholders
«Project stakeholders
are individuals and/or
All right reserved - b.genotte@mypc-academy.com
organizations that are
actively involved in the
project, or whose
interests may be
positively or negatively
affected as a result of
project execution or
project completion»
Introduction to Project Management 25
25. Unlock Your Project-Potential
Stakeholder Analysis
High Power
•B
All right reserved - b.genotte@mypc-academy.com
Keep Manage
Satisfied Closely
•A •E
Low Interest High Interest
•D
Monitor
Keep
(Minimum
Informed
Effort)
•C
Low Power
Introduction to Project Management 26
26. Unlock Your Project-Potential
Stakeholder Register & Mgt Strategy
All right reserved - b.genotte@mypc-academy.com
Introduction to Project Management 27
27. Unlock Your Project-Potential
Project Stakeholders
& Communication Planning
Determines the information and communication needs of
the stakeholders:
All right reserved - b.genotte@mypc-academy.com
who needs what information
when they will need it (frequency)
how it will be given to them, and by whom.
Identifying the informational needs of the stakeholders
and determining a suitable means of meeting those needs
is an important factor for project success
Determines the best communication method for each
situation
Introduction to Project Management 28
28. Unlock Your Project-Potential
Communication Management Plan
All right reserved - b.genotte@mypc-academy.com
Introduction to Project Management 29
29. Unlock Your Project-Potential
Project versus Project Management
Objectives and Success
Satisfied Balancing the competing
Users / Customers project constraints
Scope
All right reserved - b.genotte@mypc-academy.com
Value
&
Benefits
Satisfied
Business Stakeholders
Resources
Introduction to Project Management 30
30. Unlock Your Project-Potential
SMART Project Objectives
All right reserved - b.genotte@mypc-academy.com
Major Term Minor Term
S Specific Significant, Stretching, Simple
M Measurable Meaningful, Motivational, Manageable
A Agreed Appropriate, Achievable, Attainable, Assignable,
Actionable, Action-oriented
R Relevant Realistic, Results focused/oriented, Rewarding
T Time-Bound Time framed, Timeboxed, Timetabled, Trackable
Introduction to Project Management 31
31. Unlock Your Project-Potential
All right reserved - b.genotte@mypc-academy.com
The project manager survival kit
PROJECT PLANNING
Introduction to Project Management 32
32. Unlock Your Project-Potential
Scope, WBS, Baseline
Product scope and
Project scope
All right reserved - b.genotte@mypc-academy.com
Product scope : The
features and functions that
characterize a product,
service, or result
Project scope : The work
that needs to be
accomplished to deliver a
product, service, or result
with the specified features
and functions.
Introduction to Project Management 33
33. Unlock Your Project-Potential
WBS – Work Breakdown Structure
Project
All right reserved - b.genotte@mypc-academy.com
Phase 1 Phase 2
Deliverable Deliverable Deliverable Deliverable Deliverable
1.1 1.2 2.1 2.2 2.3
Work Package Work Package Work Package Work Package Work Package
1.1.1 1.2.1 2.1.1 2.2.1 2.3.1
Work Package Work Package Work Package Work Package Work Package
1.1.2 1.2.2 2.1.2 2.2.2 2.3.2
Work Package Work Package Work Package
1.1.3 2.1.3 2.2.3
Introduction to Project Management 34
34. Unlock Your Project-Potential
WBS & Work Package
Request
All right reserved - b.genotte@mypc-academy.com
Description
Acceptance
Criteria
Output
Deliverable
Introduction to Project Management 35
35. Unlock Your Project-Potential
Scope Baseline
Work Package Roles & Responsibility RACI / RASCI Dates Planned
Id + Description Responsible Accountable Consulted Support Informed Start Finish Costs
All right reserved - b.genotte@mypc-academy.com
WP 1.1.1
WP1.1.2
….
Introduction to Project Management 36
36. Unlock Your Project-Potential
Defining Responsibility with a RACI matrix
A RACI matrix [which is a form of a Responsibility Assignment
Matrix (RAM)] describes the participation by various roles in
All right reserved - b.genotte@mypc-academy.com
completing tasks or deliverables for a project or business
process.
It is especially useful in clarifying roles and responsibilities in
cross-functional/departmental projects and processes.
RACI is derived from the four key responsibilities : Responsible,
Accountable, Consulted, Informed
Introduction to Project Management 37
37. Unlock Your Project-Potential
RACI Roles
Code Role Description
R Responsible The individual(s) who actually completes the task, the doer(s).
All right reserved - b.genotte@mypc-academy.com
This person is responsible for action/implementation.
The responsibility can be shared.
The degree of responsibility is determined by the individual with a
«A»
A Accountable The individual who is ultimately responsible.
Includes a Yes/No authority and a Veto power.
Only one « A » can be assigned to a deliverable/task
In some case « A » can be combined with « R » => « A/R »
C Consulted The individual(s) to be consulted prior to a final decision or action.
This incorporates a two-way communication.
I Informed The individual(s) who needs to be informed after a decision or action
is taken.
This incorporates a one-way communication.
Introduction to Project Management 38
38. Unlock Your Project-Potential
Rules to keep in mind
when creating a RACI matrix
Only have one Accountable person.
More than one and the task may not get done due to confusion
All right reserved - b.genotte@mypc-academy.com
Try to limit the number of Responsible persons in a row to
one
More than this and there will likely be duplication of work
A Responsible person and an Accountable person must be
assigned to every row
Must be assigned to persons with lowest ranks
To avoid any confusion as to who is doing what, you should
have just one role assigned to a given person for each task in
the matrix.
One exception is that sometimes the Accountable person may also be
the Responsible person.
Introduction to Project Management 39
39. Unlock Your Project-Potential
High Level Responsibility per WP
Work Package Roles & Responsibility RACI / RASCI Dates Planned
Id + Description Responsible Accountable Consulted Support Informed Start Finish Costs
All right reserved - b.genotte@mypc-academy.com
WP 1.1.1
WP1.1.2
….
Introduction to Project Management 40
40. Unlock Your Project-Potential
Schedule Definition Steps
All right reserved - b.genotte@mypc-academy.com
Define Sequence Develop
Activities Activities Schedule
Estimate Activity
Estimate
Duration
Activity
Resources
Introduction to Project Management 41
41. Unlock Your Project-Potential
Realistic Schedule
Don’t plan to fail from the work?
start! Do you have a commitment
All right reserved - b.genotte@mypc-academy.com
for the resource utilization?
Accurate estimates
From the person who will do
Avoid domino effect
the work Build buffer into your plan
Consider the real resource Don’t disclose these buffers
availability (Student syndrome)
Full time is less than 100% Consider things beyond
No over-allocated resources
the control of the project
Do have critical resources? External constraints
Can you transfer part of their
Introduction to Project Management 42
42. Unlock Your Project-Potential
Schedule Baseline
Work Package Roles & Responsibility RACI / RASCI Dates Planned
Id + Description Responsible Accountable Consulted Support Informed Start Finish Costs
All right reserved - b.genotte@mypc-academy.com
WP 1.1.1
WP1.1.2
….
Introduction to Project Management 43
43. Unlock Your Project-Potential
Cost Estimation
All right reserved - b.genotte@mypc-academy.com
@ WP level
Cost Baseline
S-Curve
Introduction to Project Management 44
44. Unlock Your Project-Potential
Cost Baseline
Work Package Roles & Responsibility RACI / RASCI Dates Planned
Id + Description Responsible Accountable Consulted Support Informed Start Finish Costs
All right reserved - b.genotte@mypc-academy.com
WP 1.1.1
WP1.1.2
….
Introduction to Project Management 45
45. Unlock Your Project-Potential
All right reserved - b.genotte@mypc-academy.com
Refer to your textbook for more information
EXERCISE
Introduction to Project Management 46
46. Unlock Your Project-Potential
All right reserved - b.genotte@mypc-academy.com
The project manager survival kit
PROJECT EXECUTION
Introduction to Project Management 47
47. Unlock Your Project-Potential
Project Execution
Planning is about Execution is about
All right reserved - b.genotte@mypc-academy.com
PLAN THE WORK WORK THE PLAN
Introduction to Project Management 48
48. Unlock Your Project-Potential
The Tuckman Model
Five Stages of Team Building
Storming
All right reserved - b.genotte@mypc-academy.com
Norming
Forming
Conflict
Performing
Adjourning
Project Life Cycle
Team Guarded Confront Resolve Trust Regrets
Direction High High Less Self High
PM
Support High High Less High
Introduction to Project Management 49
49. Unlock Your Project-Potential
All right reserved - b.genotte@mypc-academy.com
The project manager survival kit
PROJECT MONITORING &
CONTROLLING
Introduction to Project Management 50
50. Unlock Your Project-Potential
Project Monitoring & Controlling
in a nutshell
Options Corrective
Plan
Evaluation actions
All right reserved - b.genotte@mypc-academy.com
Execution Root Cause Acceptable
Analysis Variances?
No Yes Doc Lessons
Results Learned
No
Acceptable
Analyze Monitor
Variances? Yes
Introduction to Project Management 51
51. Unlock Your Project-Potential
Project Monitoring & Controlling
Measuring Progress & Forecasting Future
Plan of a resource working full time
Past Future
All right reserved - b.genotte@mypc-academy.com
Baseline Man Days 10 md 30 md 20 md 33%
Reporting Worked 8 md Another 24 md to complete the delivery
27% 25%
Reality 4 md 4 md 4 md 4 md 4 md 4 md 4 md 4 md
Full Time is 80% Initial baseline duration of 6 weeks
in this case becomes actually a duration of 8 weeks
Start Date Status Date Finish Date
Work : 30 to 32 Man Days = + 2 Man Days
Duration : 6 to 8 weeks = + 2 weeks
Introduction to Project Management 52
52. Unlock Your Project-Potential
Earned Value Management
All right reserved - b.genotte@mypc-academy.com
BAC
PV
EV
AC
Introduction to Project Management 53
53. Unlock Your Project-Potential
Earned Value Management
& Management by Exception
Typical management
tolerances for CPI and SPI are
Danger Zone
All right reserved - b.genotte@mypc-academy.com
Index within 1 +/- 0,05
1,10
Index above 1 +/- 0,05 and
Time Performance
Assess and Adjust
within 1 +/- 0,10
1,05
OK Index above 1 +/- 0,10
1,00 Zone Index trending slowly in either
+/- 0,05 direction
0,95
Assess and Adjust
+/- 0,10
0,90 Index trending rapidly in
Assess & Take either direction
Corrective Actions
Assess & Take Corrective Actions
0,90 0,95 1,00 1,05 1,10
Cost Performance
Introduction to Project Management 54
54. Unlock Your Project-Potential
Performance
Report
All right reserved - b.genotte@mypc-academy.com
Introduction to Project Management 55
55. Unlock Your Project-Potential
Integrated Change Control
Lack of Change Real request for change,
Management is the first Corrective action,
All right reserved - b.genotte@mypc-academy.com
cause of troubled projects Preventive action,
Need for a communicated and defect repairs.
change control process Approved (real) changes
All change requests must baseline update
be in writing and be Corrective and preventive
justified actions do not normally
affect the project baselines,
Change Requests can only the performance
include against the baselines.
Introduction to Project Management 56
56. Unlock Your Project-Potential
Change
Request
All right reserved - b.genotte@mypc-academy.com
Introduction to Project Management 57
57. Unlock Your Project-Potential
All right reserved - b.genotte@mypc-academy.com
The project manager survival kit
PROJECT CLOSING
Introduction to Project Management 58
58. Unlock Your Project-Potential
Close Project or Phase
This includes all of the activities necessary for
administrative closure of the project or phase,
All right reserved - b.genotte@mypc-academy.com
Actions and activities necessary to satisfy completion or exit
criteria for the phase or project
Actions and activities necessary to transfer the project’s
products, services, or results to the next phase or to production
and/or operations
Activities needed to collect project or phase records, audit
project success or failure, gather lessons learned and archive
project information for future use by the organization.
Introduction to Project Management 59
59. Unlock Your Project-Potential
Lessons Learned
What did we do right? And How?
Lessons Learned
All right reserved - b.genotte@mypc-academy.com
What did we do wrong? And Why?
What were the KPIs (key performance indicators) and CSFs
(critical success factors)?
What future recommendations can be made?
How, when, and to whom should the information be
disseminated?
Introduction to Project Management 60
60. Unlock Your Project-Potential
Example of Lessons Learned Report
What Worked Well What Can Be Improved
Requirements definition and management
Scope definition and management
All right reserved - b.genotte@mypc-academy.com
Schedule development and control
Cost estimating and control
Quality planning and control
Human resource availability, team
development, and performance
Communication management
Stakeholder management
Reporting
Risk management
Procurement planning and management
Process improvement information
Product-specific information
Other
Introduction to Project Management 61
61. Unlock Your Project-Potential
We hope you will not experience the
following project phases…
Initiating Wild Enthusiasm Disillusionment
All right reserved - b.genotte@mypc-academy.com
Search for the Punishment of
Chaos
Guilty the Innocents
Praise and
Gather project
promotion of the
requirements
non participants
Introduction to Project Management 62
63. Unlock Your Project-Potential
All right reserved - b.genotte@mypc-academy.com
Some more information
APPENDIX
Introduction to Project Management 64
64. Unlock Your Project-Potential
P30 aligns Portfolios, Programmes and
Projects
All right reserved - b.genotte@mypc-academy.com
Introduction to Project Management 65
65. Unlock Your Project-Potential
Source : IIBA
Collect Requirements BABOK
Knowledge Areas
Business Analysis Planning and Monitoring
What do I need to do?
Specify the how the business analysis tasks will be performed
All right reserved - b.genotte@mypc-academy.com
Identify the deliverables produced
Describe how changes will be controlled and managed
Solution
Elicitation Requirements Assessment and
Enterprise Analysis
What do the Analysis Validation
Why are we doing
Stakeholders What must the Does the solution
this?
need? solution do? do what it is
suppose to do?
Requirements Management and Communication
Does everyone understand and agree?
Focus on presenting and communicating documented requirements to all
stakeholders to bring the group to a consensus on project scope.
Identify and manage changes
Introduction to Project Management 66
66. Unlock Your Project-Potential
Collect Requirements
All right reserved - b.genotte@mypc-academy.com
The purpose is
to reach
a common
understanding
Introduction to Project Management 67
67. Unlock Your Project-Potential
Change Log
All right reserved - b.genotte@mypc-academy.com
Introduction to Project Management 68
68. Unlock Your Project-Potential
Issue and Action Log
All right reserved - b.genotte@mypc-academy.com
Introduction to Project Management 69
69. Unlock Your Project-Potential
Decision Log
All right reserved - b.genotte@mypc-academy.com
Introduction to Project Management 70
70. Unlock Your Project-Potential
Assumption and Constraint Log
All right reserved - b.genotte@mypc-academy.com
Introduction to Project Management 71
71. Unlock Your Project-Potential
Risk Register
All right reserved - b.genotte@mypc-academy.com
Introduction to Project Management 72
72. Unlock Your Project-Potential
Team
Charter
All right reserved - b.genotte@mypc-academy.com
Introduction to Project Management 73
