How to build shared understanding with example mapping

•

1 like•1,637 views

One of the primary responsibilities of business analysts, product owners, and all other product people is to build and maintain a shared understanding of the outcome your team seeks to deliver. Conversations are an effective way to build that shared understanding. You may find yourself wondering who should be included in those conversations, when do you have these conversations, what should you talk about, and how do you remember what you said? Join Kent McDonald as he introduces example mapping, a technique that helps you structure your conversations and build a shared understanding. You’ll learn how to determine the right people to include in your conversations, when the best time is to have those conversations, how to structure those conversations, and how to remember what you said.

How to build shared understanding with
example mapping
Kent J. McDonald
kent@kbp.media
@kbpmedia
https://www.kbp.media/go/sobarc-2019/
1

Why talk about examples?
BUILD SHARED
UNDERSTANDING
OF THE STORY
IDENTIFY AND
ANSWER
QUESTIONS TO
MINIMIZE
INTERUPTSDURING DELIVERY
GIVE TEAM A
JUMP START ON
TEST PLANNING
AND TESTING
INVOLVE
DIFFERENT
PERSPECTIVES
FOR A BETTER
RESULT
IDENTIFY AND
DISCUSS
ASSUMPTIONS
PROVIDE CLEARPICTURE OFBUSINESS INTENT
3

(At Least) Three Perspectives
USER
STORY
DEVELOPMENT
TESTING
BUSINESS
DO I HAVE
ENOUGH
INFO TO
SOLVE THIS
PROBLEM?
HAVE I
DESCRIBED
THE
PROBLEM I
WANT
SOLVED?
WHAT
HAPPENS
WHEN…
THE “THREE AMIGOS” 5

When should we
have these
conversations?
6

Just in Time
BY END OF SPRINT N, HAVE
ENOUGH STORIES DESCRIBED
FOR SPRINT N+1
USER STORIES FLOW
AS THEY ARE DESCRIBED (READY)
7

Discovery Board
POLICY:
USER STORY
POLICY:
• USER STORY
• (SOME)
ACCEPTANCE
CRITERIA
• SIZE
POLICY:
• USER STORY
• ACCEPTANCE
CRITERIA
• SIZE
• MOCKUPS
• EXAMPLES
• DEPENDENCIES
• STAKEHOLDER
POLICY:
• USER STORY
• (SOME)
ACCEPTANCE
CRITERIA
8
Getting things ready to rock is a great
time for these conversations

How do we
structure these
conversations?
9

Example Mapping
Outputs:
§ Examples
§ Refined rules/acceptance criteria
§ New/split stories
§ Shared understanding
§ Empathy
10
STORY RULE(ACCEPTANCECRITERIA)
QUESTION
(WHAT IF…)
EXAMPLE(THE ONEWHERE…)
https://speakerdeck.com/mattwynne/example-mapping
Y
R
B
G

STORY
RULE RULE RULE
QUESTION
EXAMPLE
RULE
QUESTION
EXAMPLE
EXAMPLE
EXAMPLE
EXAMPLE
Example
Mapping
11

Add a
Review
Can only
review
sessions in
own track
Can only
review a
session
once
Can’t
review
your own
session
What if
session
changes
tracks?
What if
reviewer is
added to
session as
co-
presenter?
The one
where
session is in
Reed’s track
The one
where
session is
not in Reed’s
track
The one
where Reed
is presenter
The one
where Reed
is co-
presenter
Example
Mapping – An
Example
12

Your turn.
In order to prevent
passwords from being
guessed,
Users must be forced to
create strong
passwords
13

What do we use
to remember
what we said?
14

Collaborative Modeling
15
AS REED
I CAN ADD A
REVIEW TO A
SESSION
SO THAT I CAN
PROVIDE
FEEDBACK TO
SAM

Sample Models
PROCESS FLOW
UI PROTOTYPE
REPORT MOCKUP 16

Acceptance Criteria
17
§ REVIEWERS MUST PROVIDE A TITLE
AND DESCRIPTION FOR THE REVIEW.
§ REVIEWERS MAY INDICATE WHETHER
THEY THINK THE SESSION SHOULD BE
INCLUDED IN THE PROGRAM.
§ REVIEWERS MAY PROVIDE DETAILS OF
ANY CONFLICTS OF INTEREST THEY
HAVE IN REVIEWING THE SESSION.
§ REVIEWERS MAY PROVIDE COMMENTS
FOR THE REVIEW COMMITTEE.
§ SUBMITTERS OF THE REVIEWED
SESSION CAN SEE ONLY THE TITLE
AND DESCRIPTION OF THE REVIEW.
§ SUBMITTERS MAY SEE ONLY
REVIEWS OF SESSIONS THAT THEY
HAVE SUBMITTED.
§ REVIEWERS MAY REVIEW ONLY
SESSIONS SUBMITTED TO TRACKS
ON WHICH THEY ARE REVIEWERS.
§ REVIEWERS MAY NOT REVIEW ANY
SESSION ON WHICH THEY ARE
PRESENTERS OR CO-PRESENTERS.
§ REVIEWERS MAY PROVIDE ONLY
ONE REVIEW FOR A SESSION.
§ THE TITLE OF THE REVIEW MUST
CONTAIN 95 CHARACTERS OR LESS.
As Reed
I can add a
review to a
session
So that I can
provide feedback
to Sam

Examples
18
AS REED
I CAN ADD A
REVIEW TO A
SESSION
SO THAT I CAN
PROVIDE
FEEDBACK TO
SAM
Gherkin format is helpful to
describe behavior of your product

Examples CALCULATE
EVALUATIONS
(SUM OF
EVALUATION
VALUES/COUNT)
19
Mocking up data in spreadsheets
is helpful for calculations

If you remember nothing else….
DISCUSSING
EXAMPLES
SPEEDS SHARED
UNDERSTANDING
DISCUSS
EXAMPLES
WHEN GETTINGSTORIES READY
INVOLVE
MULTIPLE
PERSPECTIVES
(THREE
AMIGOS)
USE MODELS,
ACCEPTANCE
CRITERIA, AND
EXAMPLES
21

Kent McDonald
kent@kbp.media
@kbpmedia
https://www.kbp.media/go/sobarc-2019/
22
