This document discusses the mathematics required for data science. It is divided into two parts. Part I discusses the core mathematics of probability and statistics, calculus, linear algebra, and optimization. Part II discusses common algorithms in data science including regression, classification, and clustering algorithms and the relevant math concepts. Regression algorithms covered are linear regression, logistic regression and neural networks. Classification algorithms discussed are decision trees, random forests, naive Bayes, support vector machines and k-nearest neighbors. Clustering algorithms covered are k-means clustering and association rules. The document emphasizes understanding mathematical intuitions rather than specific equations.

1. How Does Math
Matter in Data
Science?
Prepared by Mutia Ulfi

2. Outline
Part I
Required Math in
Data Science
Part II
Algorithm Used in
Data Science

3. What Actually Data Science Is?
HACKING
SKILLS
DATA
SCIENCE
Math &
Stats
SUBSTANSIVE
EXPERTISE
DANGER
ZONE! TRADITIONAL
RESEARCH

4. What Are Needed in Data Science?

5. Part I
Required
Mathematics in
Data Science

6. 25% 15%
35%
15%
10%
Required Mathematics in Data
Science

7. Probability and Statistics

9. Why Probability & Statistics?
• To understand
whether data is meaningful,
including:
• optimization,
• inference,
• testing,
• and other methods.
• Therefore, we are able to
analyze patterns
in data and using them to
predict, understand, and
improve results.
Prob: to
predict
likelihood
of future
Stats: to
analyze
frequency
of past
events

10. Calculus

11. Why Calculus?
Calculus:
to find
values
that
maximize
or
minimize
outcomes
Optimizing cost for online dating

12. Optimization

13. Why Optimization?
Opt: to
find values
that
maximize or
minimize
outcomes

14. Linear Algebra

15. Why Linear Algebra?
Linear
Algebra: to
simplify
codes by
understandi
ng matrix
algebra and
eigenvalues

16. Part II
Algorithms Used in
Data Science

17. Regression
Supervised Learning
Task Given
Probs & Stats
Linear Algebra
• Linear Regression
• Logistic Regression
• Neural Network
Optimization

18. Linear Regression
• Purpose  to estimate real values based on
continuous variables (e.g. forecasting)
• Mathematically speaking
𝑦 = dependent variable
𝑎 = slope
𝑥 = independent variable
𝑏 = intercept
𝑦 = 𝑎𝑥 + 𝑏

19. Linear Regression
• The Code

20. Logistic Regression
• Purpose  to estimate the probability of a
binary response based on ≥ 1 predictor
variables (features)
• Mathematically speaking
𝑦 = dependent variable
𝑎 = slope
𝑥 = independent variable
𝑏 = intercept
Ɛ = error
𝑦 = {0 𝑒𝑙𝑠𝑒
1 𝑎𝑥+𝑏+Ɛ

21. Logistic Regression
• The Code

22. Neural Network
• Purpose  to find out the output of
complex input by modeling the
relationship
• To find patterns in data (pattern
recognition)
• To predict sampled functions given no form
of the functions (function estimation)
• Mathematically speaking
Let input and
weight, then activation,
a = =
𝑥1, 𝑥2, 𝑥3, … , 𝑥 𝑛 𝑤1, 𝑤2, 𝑤3, … , 𝑤 𝑛
𝑖=1
𝑛
𝑥𝑖 𝑤𝑖𝑥1 𝑤1 + 𝑥2 𝑤2 + 𝑥3 𝑤3 + ⋯ + 𝑤 𝑛

23. Classification
• Decision Tree
• Random Forest
• Naïve Bayes
• Support Vector
Machine
• k-Nearest Neighbor
• Neural Network
Supervised Learning
Task Given
Probs & Stats
Linear Algebra
Calculus

24. Decision Tree
•Categorical
•Continuous

25. Decision Tree
• Purpose  to model the relationships among the
features and the possible outcomes in tree structures
• Mathematically speaking
• Gini impurity
• Information gain
• Variance reduction

26. Decision Tree
• The Code

27. Random Forest
• Purpose  to model the relationships among the
features and the possible outcomes in tree structures
(but bigger features than decision tree, weights are
also varied: BOOSTING)
• Mathematically speaking
• Predictions,
With , if 𝑥𝑖 is one of the 𝑘’ points in the
same leaf as 𝑥’ , and 0 otherwise.

28. Random Forest

29. Naïve Bayes
• Purpose  to describe the probability of
events and how probabilities should be revised
in the light of additional information.
• Mathematically speaking

30. Naïve Bayes

31. Support Vector Machine
• Purpose  to create flat boundary called a
hyperplane, which divides the space to create
fairly homogeneous partition on either side.
• Mathematically Speaking
Kernel 𝐾 𝑥𝑖, 𝑥𝑗 = 𝑥𝑖, 𝑥𝑗
2

32. Support Vector Machine

33. k-Nearest Neighbor
• Purpose  to classify one of data into a class based
on its similarity to its nearest neighbor
• Mathematically speaking
𝑦 = argmax
𝑦
𝑝 𝑦|𝑥, 𝐷
𝑦 = majority vote (predictor)
D = a set of points in the circle
𝑝 𝑦|𝑥, 𝐷 = portion of points in k-nearest points
We intend to find a class for
question-tagged object. HOW?
x
y
1. Make a circle to get k-nearest neighbors of object (it’s a majority vote of k-nearest points, refer to the figure).
2. Repeat the process
3. Calculate the distance between object and its nearest neighbors
4. Find the probability of object by portion of points in k-nearest points (refer to figure: portion of A and B in the
circles) , or we can write it mathematically as above.

34. k-Nearest Neighbor

35. Clustering
Supervised Learning
Task Given
Probs & Stats
Linear Algebra
• k-Means Clustering
• Association Rules

36. k-Means Clustering
• Purpose  to minimize the
differences within each cluster
and maximize the differences
between the clusters.
• Mathematically speaking
• Data assignment
𝑐𝑖 = collection of centroids
𝐶𝑖 = set of 𝑐𝑖
𝑥 = data point
• Centroid update step
𝑐𝑖 = collection of centroids
𝑆𝑖 = set of data point assignments for each 𝑖 𝑡ℎ
cluster centroid
𝑥𝑖 = data point

37. k-Means Clustering

38. • Purpose  to give suggestion
of possible outcome by
predicting historical input
(e.g. recommendation of a
product to buy)
• Mathematically speaking
Association Rules

39. Reinforcement Learning
Supervised Learning
Task Given
Probs & Stats
Linear Algebra
Calculus
Optimization

40. Tired of seeing
mathematical
equation?
me too

41. It’s not about equation
BUT
Mathematical intuitions
• Choose the right algorithms for problem
• Make good choices on parameter settings, validation strategies
• Recognize underfitting or overfitting
• Troubleshoot poor or ambiguous results
• Put appropriate bounds of confidence or uncertainty on results
• Do a better job of coding algorithms or incorporating them into
more complex analysis pipelines

42. And the most important thing is…
Understand the concept
NOT
The packages

43. Want to deep dive in particula
algorithm?
Simply request! :D

44. References
• https://courses.washington.edu/css490/2012.Winter/lecture_slides/0
2_math_essentials.pdf
• https://www.quora.com/How-do-I-learn-mathematics-for-machine-
learning
• https://www.analyticsvidhya.com
• https://en.wikipedia.org/wiki/Decision_tree_learning
• http://csyue.nccu.edu.tw/ch/Cartoon%20Statistics.pdf
• https://www.datascience.com/blog/k-means-clustering
