2. About Me
• Chhorn Chamnap
• Senior Developer at Yoolk Inc.
• Blog: http://chamnapchhorn.blogspot.com/
=> http://blog.placexpert.com/
• Twitter: @chamnap
• Email: chamnapchhorn@gmail.com
2
3. The 80/20 Performance Rule
• A theory from Vilfredo Pareto, an economist
in the early 1900s.
• 80% of the consequences come from 20% of
the causes.
• 80% of the time is spent in only 20% of the
code.
• Focus on the 20% that affects 80% of the end-
user response time.
• Start from the front end.
3
4. 1. Minimize HTTP Requests
• 80% of the end-user response time is spent on
the front-end
Loading http://www.yahoo.com/ Time spent loading popular web sites
4
5. 1. Minimize HTTP Requests
• Solutions
– Combined scripts and stylesheets
– CSS Sprites
– Image maps
– Browser Cache Usage - 40-60% of daily visitors to
your site come in with an empty cache.
5
6. Combined Scripts and Stylesheets
• Combining six scripts into one eliminates five HTTP requests
• http://stevesouders.com/examples/combo.php
6
7. Image maps
• Combine multiple images into a single image.
• client-side – preferred
<img usemap%="#map1" border=0 src="/images/imagemap.gif">
<map name="map1">
<area shape="rect" coords="0,0,31,31" href="home.html"
title="Home">
…
</map>
• drawbacks:
– must be contiguous
– defining area coordinates – tedious, errors
• http://www.w3.org/TR/html401/struct/objects.html#h-13.6
• http://stevesouders.com/examples/rule-min-http.php
7
8. CSS Sprites
• The preferred method for reducing the number of
image requests
• Combine into a single image and use background-
image and background-position properties to display.
<span style="
background-image: url('sprites.gif');
background-position: -260px -90px;">
</span>
• http://stevesouders.com/examples/sprites.php
8
10. 2. Use a Content Delivery Network
• The user's proximity has an impact on response
times.
• Solutions
– Use a CDN: Akamai Technologies, EdgeCast, Amazon
CloudFront, or level3.
– Distribute your static content before distributing your
dynamic content.
• At Yahoo!, using a CDN improved response times
>= 20%.
• http://stevesouders.com/examples/rule-cdn.php
10
11. 3. Add an Expires or a Cache-Control
Header
• Implement "Never expire" policy for all static
components.
• Avoids unnecessary HTTP requests on subsequent page
views after the first visit.
HTTP/1.1 200 OK
Expires: Thu, 31 Dec 2037 23:55:55 GMT
Cache-Control: max-age=315360000
Content-Length: 12195
• How to expire the cache?
yahoo_2.0.6.js
css_based.css?30042011
• http://stevesouders.com/examples/rule-expires.php
11
15. 4. Gzip Components
GET /i/yahoo.gif HTTP/1.1 HTTP/1.1 200 OK
Host: example.com Content-Length: 12195
Accept-Encoding: gzip Content-Encoding: gzip
• Reduces response times.
• The response size ~ 70% reduction.
• 90%+ of browsers support gzip.
• Compress any text responses
• Image and PDF files SHOULD NOT be gzipped.
• http://stevesouders.com/examples/rule-gzip.php
15
17. 5. Put Stylesheets at the Top
• Research at Yahoo! shows that moving
stylesheets to the HEAD makes pages appear to
be loading faster.
– It allows the page to render progressively.
• The user is stuck viewing a blank white page if
put at the bottom.
– The browser block rendering to avoid redrawing
elements.
• The HTML specification said the same thing.
• http://stevesouders.com/examples/rule-css-
top.php
17
18. 6. Put Scripts at the Bottom
• Download no > two in parallel per hostname.
• Block parallel downloads across all hostnames.
• Block rendering of everything below them in the
page.
• Never uses document.write.
• Script DEFER attribute is not asolution.
• http://stevesouders.com/examples/rule-js-
bottom.php
18
19. 7. Avoid CSS Expressions
• Powerful but dangerous way to set CSS
properties dynamically.
• Supported since IE5 but deprecated from IE8.
background-color: expression( (new Date()).getHours()%2 ?
"#B8D4FF" : "#F08A00" );
• Execute so many times (> 10,000)
– mouse move, key press, resize, scroll, etc.
• http://stevesouders.com/examples/rule-
expr.php
19
20. 8. Make JavaScript and CSS External
• Using external files produces faster pages. Why?
– Js and css files are cached.
– Inlined increases the document’s size.
– Many documents could re-use them.
• To reduce HTTP requests in the front page:
– inline JavaScript and CSS, but dynamically download
the external files after finished loading.
• http://stevesouders.com/examples/rule-
inline.php
20
22. 9. Reduce DNS Lookups
• 20-120 ms to lookup.
• Blocks the parrallel download.
• IE caches
– DnsCacheTimeout: 30 minutes
– KeepAliveTimeout: 1 minute
– ServerInfoTimeout: 2 minutes
• Firefox
– network.dnsCacheExpiration: 1 minute
– network.dnsCacheEntries: 20
– network.http.keep-alive.timeout: 5 minutes
• Reducing hostnames reduces the DNS lookups.
– But it reduces parallel downloads as well.
• The rule of thumbs is two per hostname.
• http://stevesouders.com/examples/rule-dns.php
22
25. 10. Minify JavaScript and CSS
• Minification reduces response time and the size.
• Two popular tools are:
– JSMin
– YUI Compressor
– Google Closure Compiler
• Obfuscation is an alternative optimization.
• Both methods achieves fairly the same size reduction.
• Should minified inline js and css as well (5% reduction)
• http://stevesouders.com/examples/rule-minify.php
25
26. 11. Avoid Redirects
• Redirects are accomplished using the 301 and 302
status codes.
HTTP/1.1 301 Moved Permanently
Location: http://example.com/newuri
Content-Type: text/html
• Redirects slow down the user experience.
– Nothing can be rendered
– Round-trip request
• Add Expires headers to cache redirects
• Make sure use the standard 3xx HTTP status codes.
• http://stevesouders.com/examples/rule-redir.php
26
27. Wasteful redirects
http://astrology.yahoo.com/astrology =>
http://astrology.yahoo.com/astrology/
• This is fixed in Apache by using Alias or
mod_rewrite, or the DirectorySlash
directive if you're using Apache handlers.
• Nginx
– rewrite ^(.*[^/])$ $1/ permanent;
27
28. 12. Remove Duplicate Scripts
• A typical problem
– 2 of 10 top sites contain duplicate
• Hurts performance
– extra HTTP requests (IE only)
– extra executions (even cached)
• http://stevesouders.com/examples/rule-js-
dupes.php
28
29. 13. Configure ETags
• ETags stands for Entity Tags.
• A unique identifier that is more flexible than the Last-
Modified date.
HTTP/1.1 200 OK
Last-Modified: Tue, 12 Dec 2006 03:03:59 GMT
ETag: "10c24bc-4ab-457e1c1f"
Content-Length: 12195
GET /i/yahoo.gif HTTP/1.1
Host: us.yimg.com
If-Modified-Since: Tue, 12 Dec 2006 03:03:59 GMT
If-None-Match: "10c24bc-4ab-457e1c1f"
HTTP/1.1 304 Not Modified
• Doesn’t works well for cluster of servers.
• To turn off in Apache,
FileETag none
• http://stevesouders.com/examples/rule-etags.php 29
30. 14. Make Ajax Cacheable
• Expires or Cache-Control header
• Adding a timestamp to the URL
– &t=1190241612
• When it has been modified, send with a new
timestamp.
• http://stevesouders.com/examples/rule-
ajax.php
30
31. 15. Flush the Buffer Early
• Don’t let the browser idle.
• In PHP, use flush() to send data partially.
• Good for busy backends or light frontends.
• Flushing after the HEAD
... <!-- css, js -->
</head>
<?php flush(); ?>
<body>
... <!-- content -->
• Yahoo! search
31
32. 16. Use GET for AJAX Requests
• POST in the browsers as a two-step process:
– sending the headers first,
– then sending data.
• Best to use GET.
• POST without posting any data behaves like
GET.
• GET is meant for retrieving information
• POST is for sending data to be stored server-
side.
32
33. 17. Post-load Components
• What's absolutely required in order to render the page initially?
• The others can wait.
• Post-loading should include
– drag and drop
– animations
– hidden content
– images below the fold.
• Load them in the onLoad event.
• Tools
– YUI Image Loader
– YUI Get utility
• Yahoo! Home Page
33
34. Post-Onload Script
• inline in front page
window.onload = downloadComponents;
function downloadComponents() {
var elem = document.createElement("script");
elem.src = "http://.../file1.js";
document.body.appendChild(elem);
...
}
• speeds up secondary pages
34
35. 18. Preload Components
• Preload what you’ll need in the future.
• Unconditional preload
• Conditional preload - make an educated guess
• Anticipated preload - preload in advance
before redesign
35
36. 19. Reduce the Number of DOM
Elements
• The number of DOM elements:
document.getElementsByTagName('*').length
• More bytes to download and slower DOM access.
• Using nested tables for layout purposes?
• Are you throwing in more <div>s only to fix layout
issues?
• Try YUI CSS utilities: grids.css, fonts.css and reset.css
• And how many DOM elements are too many?
• The Yahoo! Home Page is a pretty busy page and still
under 700 elements (HTML tags).
36
37. 20. Split Components Across Domains
• Maximize parallel downloads.
• 2-4 sub-domains only because of the DNS
lookup penalty
– static1.example.org,
– static2.example.org
• Maximizing Parallel Downloads in the Carpool
Lane
37
38. 21. Minimize the Number of iframes
• Pros
– Helps with slow third-party content like badges
and ads
– Security sandbox
– Download scripts in parallel
• Cons
– Costly even if blank
– Blocks page onload
– Non-semantic
38
40. 23. Reduce Cookie Size
• Authentication and personalization only
GET /index.html HTTP/1.1 HTTP/1.1 200 OK
Host: www.example.org Content-type: text/html
Set-Cookie: name=value
Set-Cookie: name2=value2; Expires=Wed,
GET /spec.html HTTP/1.1 09 Jun 2021 10:18:14 GMT
Host: www.example.org
Cookie: name=value; name2=value2
Accept: */*
• Small impact on the response time.
• When the Cookie Crumbles
– Eliminate unnecessary cookies
– Keep cookie sizes small
– Setting cookies at the appropriate domain level
– Set an Expires date appropriately
40
42. 24. Use Cookie-free Domains for
Components
• Create www site and subdomain
– that subdomain is cookie-free
• Buy a whole new domain if already set on
domain without www.
– Yahoo! uses yimg.com,
– YouTube uses ytimg.com,
– Amazon uses images-amazon.com and so on.
• Some proxies might refuse to cache the
components that are requested with cookies.
42
43. 25. Minimize DOM Access
• Accessing DOM elements is slow
– Cache references
– Update nodes "offline" and add them later
– Avoid fixing layout with JavaScript
• High Performance Ajax Applications
43
44. 26. Develop Smart Event Handlers
• Using event delegation is a good approach.
• Use DOMContentLoaded event instead.
• High Performance Ajax Applications
44
45. 27. Choose <link> over @import
• One of the previous best practices states that
CSS should be at the top in order to allow for
progressive rendering.
• In IE @import behaves the same as using
<link> at the bottom of the page, so it's best
not to use it.
45
46. 28. Avoid Filters
• It blocks rendering and freezes the browser
while the image is being downloaded.
• It also increases memory consumption and is
applied per element, not per image.
• Avoid AlphaImageLoader completely and use
gracefully degrading PNG8 instead, which are
fine in IE.
46
47. 29. Optimize CSS Sprites
• Arranging the images horizontally (makes the
smaller file size).
• Combining similar colors in a sprite helps you
keep the color count low, ideally under 256
colors so to fit in a PNG8.
• Don't leave big gaps between the images in a
sprite.
– It makes the user agent requires less memory.
47
48. 30. Don't Scale Images in HTML
• Don't use a bigger image than you need.
• If you need
<img width="100" height="100" src="mycat.jpg"
alt="My Cat" />
then mycat.jpg should be 100x100px.
48
49. 31. Make favicon.ico Small and
Cacheable
• Browser will always request it, better not to
respond 404.
– Cookies are sent every time it's requested.
– Also interferes with the download sequence in IE.
• Solutions
– Make it small, preferably under 1K.
– Set Expires header when you feel comfortable.
• Imagemagick can help you create small
favicons
49
50. 32. Keep Components under 25K
• iPhone won't cache components > 25K
(uncompressed size).
• Minification is important because gzip alone
may not be sufficient.
• Performance Research, Part 5: iPhone
Cacheability - Making it Stick
50
51. 33. Avoid Empty Image src
• Image with empty string src attribute occurs more than one will
expect. It appears in two form:
– Straight HTML
<img src="">
– JavaScript
var img = new Image();
img.src = "";
• Browser makes another request to your server.
• Cripple your servers by sending a large amount of unexpected
traffic.
• Waste server computing cycles.
• Possibly corrupt user data.
• HTML5 instruct browsers not to make an additional request.
• Empty image src can destroy your site
51
