The document provides recommendations for commissioning testing of medium voltage cables, including sheath testing, withstand testing, and partial discharge (PD) testing. It recommends test voltage levels and durations for different cable types, and evaluates PD measurement results to determine if cables pass or require replacement. The recommendations aim to fulfill safety requirements and quality control by detecting workmanship issues not found during initial testing.
VLF Testing of Cables Using IEEE 400.2. Presentation by John Densley that describes the in situ testing of distribution cables using very low frequency (VLF) voltages according to IEEE Standard 400.2. The Standard includes criteria to assess the condition of XLPE, EPR and paper insulated cable circuits. How the criteria were established and their limitations will be discussed, along with Partial Discharge (PD) testing using VLF.
John, the President of ArborLec Solutions Inc. has worked on electrical ageing mechanism and diagnostics techniques in electrical insulation for more than 35 years. He has a sound practical and theoretical knowledge of ageing and failure mechanisms of insulation systems in high voltage equipment such as medium and high voltage cables, transformers and switchgears.
Results of 10 years after installation tests with partial discharge detection...HighVoltageDUT
In 2004 Alliander decided to add partial discharge (PD) measurements in their after installation test policy. Over the last years, dozens of accessories and a few cable parts were taken out of the tested cables, based on PD activity, measured during after installation test. In many cases severe abnormalities were found, threatening the reliability of the cable system, but also cases were found where the reason for PD was not clear. It is also discovered that cable systems can contain PD’s in accessories but still survive the after installation test.
