This document summarizes a presentation given by Steve Frank of EtherWAN, a manufacturer of Ethernet networking devices. EtherWAN focuses on producing environmentally hardened Ethernet switches and media converters for applications in transportation infrastructure, security/surveillance, and smart grid utilities. Their devices are designed to operate in extreme temperatures and withstand vibration. EtherWAN provides managed and unmanaged switches with features like VLAN tagging, QoS, port security, and fast recovery from link failures. Their hardened devices are suited for network edge applications requiring reliability.

1. Enabling Intelligent Communications in the ITS infrastructureSteve Frank, West Region Sales Manager2010

2. Company OverviewGlobal manufacturer of Ethernet networking devicesTaiwan – Engineering & Manufacturing

3. Anaheim – Corporate, Sales In house production, DVT, support30+ R&D Engineers9+ SW developersOwn source codeExtensive Ethernet ExperienceProven Core CompetenciesField tested and deployedExtreme port flexibilityBalanced Value & Feature benefitsKey market sectorsITS / Transportation 1st to MarketSecurity & SurveillanceUtilities / Energy – Smart Grid

4. CustomersCity of St Charles Public Works

5. ITS Exposure

6. Technology FocusTransport Medium(FE / GbE / Coax / POT / FX / LX)Form FactorHardened / Extended Industrial / Commercial Modular / DIN Rail / Rack / PanelEthernetConnectivityMedia ConversionEthernet Extension(Managed / Un-managed MM – SM – WDM – SFP)Layer 2 Ethernet Switches(Managed / Un-managed / PoE / 4 – 24 ports)

7. Core Design Focus – Environmentally HardenedWide operating range: -40°C to 75°C (-40°F to 167°F)High electrostatic discharge immunity & surge protectionRedundant Power – Term Block inputs & locking DC jackInterference Protection (EMI / RFI)Beyond-Industrial-Grade CertificationsHigh Shake, Rattle & Roll TolerancesFast Link-Fault Recovery for seamless network operations

8. Environmentally Hardened Devices - MarketsCost versus Feature analysis – Environment is a FeatureEnvironmental factors – heat/cold, dust, vibration, interferenceAny user that requires a step above approach to device design, build and supportEdge to End Quality – not just the environmentHardened typically equates to higher qualityFront loaded cost > Back End higher ROI

9. Edge to End SolutionsBackbone SwitchManaged Field SwitchUn-managed Field SwitchEthernet SwitchesSerial-to-Ethernet Intelligent EthernetGbE ConverterFiber to Cat5/6PoE ConverterMedia ConversionEthernet Extender over Coax / STPSmall Form Factor

10. Designed for ITS – Hardened EthernetVersatile / Flexible / RobustEX71000IEC61850-3 & IEEE1613

11. NERC CIP Compliant

12. Fully Managed Layer 2

13. IEEE802.1x, SSL / SSH

14. SNMP v3

15. Per Port MAC Locking

16. Bandwidth Rate Control

17. 802.1Q VLAN & GVRP

18. -ring technology < 15ms recovery timeEX72000 EX73000EX77000 ED3141

19. Hardened Device Family for ITSEX71000EL900EX72000EX73000EX74000EX77000EX78000EX87000EL9000ED3341ED3141Hardened Managed SwitchesHardened Media Converters& Ethernet Extenders

20. EtherWAN Features & Applications

21. Managed DevicesAllows more control over your LAN traffic and offer advanced features to control that traffic; enables port configuration, prioritize traffic, create VLAN’s, bandwidth allocation per port, access & security, etc.AdvantagesHighly robust management features

22. Total Cost of Ownership can be reduced by creating VLANs (increasing port footprint)

23. Aggregated bandwidth across the network can be controlled

24. Port and User security is addressed and maintainedDisadvantagesCost is typically higher than an un-managed or web-managed device
