This document discusses processing large graphs in Hadoop. It describes Google's Pregel framework, which takes a vertex-centric approach to iterative graph processing. Pregel computations occur over multiple supersteps, with vertices sending messages to each other between steps. The document also covers Apache Giraph, an open-source implementation of Pregel built on Hadoop. Giraph allows graph processing jobs to leverage Hadoop features like HDFS and MapReduce. An example shortest path algorithm is provided to illustrate Pregel's message passing model.

1. Processing Large
Graphs in Hadoop
Dani Solà

2. Index
● The Problem
● Google's Pregel
● Example
● Apache Giraph

3. The Problem
● Processing graphs in MR is not practical:
– Most algorithms are iterative
– Each iteration is mapped to a MR Job
– Takes too long if many iterations are required
– Writing MR for graph processing is not easy

4. Google's Pregel
● Framework for iterative large graph processing
● Inspired by Bulk Synchronous Parallel model
● Computation is distributed among N+1 nodes
– N workers that do the actual work
– 1 master that synchronizes them
● Takes a vertex-centric approach
– Is much easier to focus on the algorithm
http://kowshik.github.io/JPregel/pregel_paper.pdf

5. Pregel Main Concepts
● Computations are a sequence of supersteps
● Vertices are randomly distributed among nodes
● Vertices have values and directed edges to
other vertices
● Vertices can send messages to other vertices
● Messages sent at superstep S are received at
superstep S + 1

6. Computation Life Cycle
● Initially, all vertices are active
● Inactive vertices activate again on receiving
messages
● In each superstep, active vertices:
– Receive messages from the previous superstep
– Can change their value depending on their state
– Can check the value of their neighbors
– Can send messages to other vertices
– Can vote to halt, becoming inactive
● When all vertices are inactive, computation ends

7. Ex: Shortest Path A D→
● Single source shortest paths example
● Want to find the shortest path from A to D
● For simplicity, edges have value 1

8. Ex: Shortest Path A D→
A: 0
B: ∞
C: ∞ D: ∞
E: ∞
Superstep 0:
All vertices active, A sends messages and halts
0+1
0+1
0+1

9. Ex: Shortest Path A D→
A: 0
B: 1
C: 1 D: ∞
E: 1
Superstep 1:
B, C, E get the messages and update their values
1+1
1+1

10. Ex: Shortest Path A D→
A: 0
B: 1
C: 1 D: 2
E: 1
Superstep 2:
E gets mssge from B, but doesn't change its value

11. Ex: Shortest Path A D→
A: 0
B: 1
C: 1 D: 2
E: 1
Superstep 3:
All vertices have halted and the computation ends

12. Apache Giraph
● Open-source implementation of Pregel
● Started by Yahoo, used by FB, LinkedIn, Twitter
● Built on top Hadoop & Zookeeper:
– Mappers are used as nodes: N workers + 1 master
– Master-worker coordination via Zookeeper
– Natively reads and writes to HDFS
– Natively reads and writes Writables
– Can use counters, distributed cache, etc.
https://giraph.apache.org/

13. Apache Giraph
● Pros:
– Integrates well with Hadoop
– Has many examples included
– Much better tool for processing graphs than raw MR
● Cons:
– Documentation could be better
– Still evolving: API changes in Giraph 1.1.0
– Not as used as other Hadoop projects

14. GiraphVertex API
public class MyVertex
extends Vertex<IntWritable, IntWritable, NullWritable, IntWritable> {
@Override
public void compute(Iterable<IntWritable> msgs) throws IOException {
int superstep = getSuperstep(); // Current superstep
setValue(val); // Modifies vertex value
sendMessage(neighbor, value); // Sends message to a neighbor
sendMessageToAllEdges(value); // Sends message to all neighbors
}
}
Vertex ID Type
Vertex Value Type
Edge Value Type
Message Value Type

15. GiraphVertex API
● Look at the shortest path source code:
– SimpleShortestPathsVertex.java (v1.0.0)

16. Giraph Input/Output
● You can read vertex oriented (adjacency list) or
edge oriented (pairs of vertices) files
● Many formats already available:
– VertexInputFormat / VertexOutputFormat
– HiveVertexInputFormat / HiveVertexOutputFormat
– …
● You can easily read any format extending
VertexInputFormat / EdgeInputFormat

17. Thanks!
