Getting some errors when trying to run this program, can anyone help.pdf

Getting some errors when trying to run this program, can anyone help fix?
import java.awt.Color;
import java.awt.Dimension;
import java.awt.FlowLayout;
import java.awt.Font;
import java.awt.GridLayout;
import java.awt.Toolkit;
import java.awt.event.ActionEvent;
import java.awt.event.ActionListener;
import java.awt.event.FocusEvent;
import java.awt.event.FocusListener;
import java.awt.event.KeyAdapter;
import java.awt.event.KeyEvent;
import java.util.ArrayList;
import java.util.Arrays;
import java.util.Collections;
import javax.swing.BorderFactory;
import javax.swing.BoxLayout;
import javax.swing.ImageIcon;
import javax.swing.JButton;
import javax.swing.JFrame;
import javax.swing.JLabel;
import javax.swing.JOptionPane;
import javax.swing.JPanel;
import javax.swing.JTextField;
/**
* Sudoku program that validates and finds a solution.
* @author
* @
*
*/
public class SudokuSolver extends JFrame implements ActionListener {
/** UID */
private static final long serialVersionUID = 3883151525928534467L;
/** Contains UI for cells */

private SudokuCell[][] sudokuCells;
/** Contains integers representing values in cells. */
private int[][] cellValues;
/**
* Constructor.
* Set up the components and initialize Sudoku.
*/
public SudokuSolver() {
super("Sudoku Solver");
prepareSudokuUI();
// JFrame property
setLayout(new FlowLayout(FlowLayout.CENTER));
setDefaultCloseOperation(JFrame.EXIT_ON_CLOSE);
pack();
Dimension d = Toolkit.getDefaultToolkit().getScreenSize();
setLocation((d.width / 2 - 175), (d.height / 2 - 275));
setResizable(false);
setVisible(true);
}
/**
* Set up the UI for application.
*/
private void prepareSudokuUI() {
// Used to align the title, Sudoku grid, and button panels vertically
JPanel panel = new JPanel();
panel.setLayout(new BoxLayout(panel, BoxLayout.Y_AXIS));
// Title panel
JPanel title = new JPanel();
title.add(new JLabel(new ImageIcon(getClass().getResource("/resources/title.png"))));
// Sudoku grid panel
JPanel sudokuPanel = new JPanel();

sudokuPanel.setLayout(new GridLayout(3, 3, 1, 1));
// Set up 9 3x3 box panels
JPanel[] boxes = new JPanel[9];
boxes = prepare3x3BoxUI(sudokuPanel, boxes);
// Set up SudokuCells
cellValues = new int[9][9];
sudokuCells = new SudokuCell[9][9];
prepareSudokuCellsUI(boxes);
// Bottom part containing buttons
// First row of buttons
JPanel buttonsPanel = new JPanel();
JButton submitButton = new JButton("Submit"); // Submit to validate the Sudoku
JButton solveButton = new JButton("Solve"); // Solve the Sudoku
JButton eraseButton = new JButton("Erase"); // Clear the cells that are not fixed
JButton eraseAllButton = new JButton("Erase All"); // Clear all cells including fixed ones
buttonsPanel.add(submitButton);
buttonsPanel.add(solveButton);
buttonsPanel.add(eraseButton);
buttonsPanel.add(eraseAllButton);
// Second row of buttons
JPanel buttonsPanel2 = new JPanel();
JButton presetButton = new JButton("Mark As Preset"); // Set filled cells as preset (not
editable)
buttonsPanel2.add(presetButton);
submitButton.addActionListener(this);
solveButton.addActionListener(this);
presetButton.addActionListener(this);
eraseButton.addActionListener(this);
eraseAllButton.addActionListener(this);
panel.add(title);

panel.add(sudokuPanel);
panel.add(buttonsPanel);
panel.add(buttonsPanel2);
add(panel);
}
/**
* Set up 9 3x3 panels for Sudoku panel.
* Use 9 panels to align as 3x3 boxes.
* @param sudokuPanel
* @param boxes 3x3 box panels to be added on Sudoku panel.
* @return instantiated 3x3 box panels.
*/
private JPanel[] prepare3x3BoxUI(JPanel sudokuPanel, JPanel[] boxes) {
for (int i = 0; i < 9; i++) {
boxes[i] = new JPanel();
boxes[i].setLayout(new GridLayout(3, 3, 0, 0));
boxes[i].setBorder(BorderFactory.createMatteBorder(1, 1, 1, 1, Color.BLACK));
sudokuPanel.add(boxes[i]);
}
return boxes;
}
/**
* Set up cells UI(SudokuCell) for input and add them to the panels.
* SudokuCells have to be added to proper panels meaning left-right and top-bottom order
within 3x3 box.
* @param boxes
*/
private void prepareSudokuCellsUI(JPanel[] boxes) {
int index = 0;
// Adjust current row
for (int i = 0; i < 9; i++) {
if (i <= 2)

index = 0;
else if (i <= 5)
index = 3;
else
index = 6;
for (int j = 0; j < 9; j++) {
sudokuCells[i][j] = new SudokuCell(i, j);
boxes[index + (j / 3)].add(sudokuCells[i][j]);
}
}
}
@Override
public void actionPerformed(ActionEvent event) {
JButton button = (JButton) event.getSource();
String buttonType = button.getText();
if (buttonType.equals("Submit"))
submitSudoku();
else if (buttonType.equals("Solve"))
startSolving();
else if (buttonType.equals("Erase"))
erase();
else if (buttonType.equals("Erase All"))
eraseAllIncludingPresetCells();
else
checkPresetCells();
}
/**
* Submit current Sudokue to validate for completeness.
*/
private void submitSudoku() {
if (isSudokuSolved())
JOptionPane.showMessageDialog(getRootPane(),

"Congratulations!
Sudoku has been Completed!",
"Sudoku Validation", JOptionPane.INFORMATION_MESSAGE);
else
"Failed!
Sudoku is not complete!",
"Sudoku Validation", JOptionPane.INFORMATION_MESSAGE);
}
/**
* Start working on the Sudoku if it is ready.
*/
private void startSolving() {
// Don't do anything if Sudoku is already full
if (isSudokuFull()) {
"There are no cells open to start from.",
"Solving Sudoku", JOptionPane.ERROR_MESSAGE);
return;
}
// Validate before starting
if (isValidToStart()) {
markAsPresetCells();
if (!solve(0, 0))
"Unable to solve.",
} else // Don't start solving if Sudoku is not valid at the start
"This is not a valid Sudoku to start.",
}
/**

* Erase all editable cells.
*/
private void erase() {
for (int i = 0; i < 9; i++)
for (int j = 0; j < 9; j++) {
if (cellValues[i][j] != 0) {
if (sudokuCells[i][j].editable) {
sudokuCells[i][j].setText("");
cellValues[i][j] = 0;
}
}
}
}
/**
* Erase all cell values including those with fixed values.
*/
private void eraseAllIncludingPresetCells() {
for (int i = 0; i < 9; i++)
for (int j = 0; j < 9; j++) {
if (cellValues[i][j] != 0) {
if (!sudokuCells[i][j].editable) {
sudokuCells[i][j].editable = true;
sudokuCells[i][j].setEditable(true);
sudokuCells[i][j].setForeground(Color.BLACK);
}
sudokuCells[i][j].setText("");
cellValues[i][j] = 0;
}
}
}
/**
* Evaluate cells before making pre filled cells fixed.
*/
private void checkPresetCells() {

// Validate the current state and make the filled cells fixed
if (!isValidToStart())
"This is not a valid Sudoku to start.",
"Sudoku Solver", JOptionPane.ERROR_MESSAGE);
else
markAsPresetCells();
}
/**
* Check if the Sudoku puzzle is solved correctly.
* @return true if Sudoku is correct.
*/
private boolean isSudokuSolved() {
for (int i = 0; i < 9; i++) {
int[] aRow = new int[9];
int[] aCol = new int[9];
for (int j = 0; j < 9; j++) {
// If this cell is empty, quit because it's not complete
if (cellValues[i][j] == 0)
return false;
aRow[j] = cellValues[i][j];
aCol[j] = cellValues[j][i];
// Check if the value in this cell is duplicated in 3x3 box
if (isContainedIn3x3Box(i, j, cellValues[i][j]))
return false;
}
// Check rows and columns
if (!isRowColumnCorrect(aRow, aCol))
return false;
}

return true;
}
/**
* Check if specified row and column are correct.
* Used when submitting the puzzle.
* @param aRow 9 numbers in a row.
* @param aCol 9 numbers in a column.
* @return true if this row and column are correct.
*/
private boolean isRowColumnCorrect(int[] aRow, int[] aCol) {
Arrays.sort(aRow);
Arrays.sort(aCol);
for (int i = 0; i < 9; i++)
if (aRow[i] != i + 1 && aCol[i] != i + 1)
return false;
return true;
}
/**
* Check if Sudoku is in valid condition to start.
* @return true if Sudoku is ready to start.
*/
private boolean isValidToStart() {
for (int i = 0; i < 9; i++)
for (int j = 0; j < 9; j++)
if (cellValues[i][j] != 0)
if (isContainedIn3x3Box(i, j, cellValues[i][j]) ||
isContainedInRowColumn(i, j, cellValues[i][j]))
return false;
return true;
}

/**
* Make the filled cells fixed.
*/
private void markAsPresetCells() {
for (int i = 0; i < 9; i++)
for (int j = 0; j < 9; j++)
if (cellValues[i][j] != 0)
if (!isContainedIn3x3Box(i, j, cellValues[i][j]) &&
!isContainedInRowColumn(i, j, cellValues[i][j])) {
sudokuCells[i][j].editable = false;
sudokuCells[i][j].setEditable(false);
sudokuCells[i][j].setForeground(new Color(150, 150, 150));
}
}
/**
* Check if a value contains in its 3x3 box for a cell.
* @param row current row index.
* @param col current column index.
* @return true if this cell is incorrect or duplicated in its 3x3 box.
*/
private boolean isContainedIn3x3Box(int row, int col, int value) {
// Find the top left of its 3x3 box to start validating from
int startRow = row / 3 * 3;
int startCol = col / 3 * 3;
// Check within its 3x3 box except its cell
for (int i = startRow; i < startRow + 3; i++)
for (int j = startCol; j < startCol + 3; j++)
if (!(i == row && j == col))
if (cellValues[i][j] == value)
return true;
return false;
}
/**

* Check if a value is contained within its row and column.
* Used when solving the puzzle.
* @param value value in this cell.
* @return true if this value is duplicated in its row and column.
*/
private boolean isContainedInRowColumn(int row, int col, int value) {
for (int i = 0; i < 9; i++) {
// Don't check the same cell
if (i != col)
if (cellValues[row][i] == value)
return true;
if (i != row)
if (cellValues[i][col] == value)
return true;
}
return false;
}
/**
* Check if all cells are filled up.
* @return true if Sudoku is full.
*/
private boolean isSudokuFull() {
for (int i = 0; i < 9; i++)
for (int j = 0; j < 9; j++)
if (cellValues[i][j] == 0)
return false;
return true;
}
/**
* Solve Sudoku recursively.

* @return false if Sudoku is not solved. true if Sudoku is solved.
*/
private boolean solve(int row, int col) {
// If it has passed through all cells, start quitting
if (row == 9)
return true;
// If this cell is already set(fixed), skip to the next cell
if (cellValues[row][col] != 0) {
if (solve(col == 8? (row + 1): row, (col + 1) % 9))
return true;
} else {
// Random numbers 1 - 9
Integer[] randoms = generateRandomNumbers();
for (int i = 0; i < 9; i++) {
// If no duplicates in this row, column, 3x3, assign the value and go to the next
if (!isContainedInRowColumn(row, col, randoms[i]) &&
!isContainedIn3x3Box(row, col, randoms[i])) {
cellValues[row][col] = randoms[i];
sudokuCells[row][col].setText(String.valueOf(randoms[i]));
// Move to the next cell left-to-right and top-to-bottom
if (solve(col == 8? (row + 1) : row, (col + 1) % 9))
return true;
else {
// Initialize the cell when backtracking (case when the value in the next cell was
not valid)
cellValues[row][col] = 0;
sudokuCells[row][col].setText("");
}
}
}
}

return false;
}
/**
* Generate 9 unique random numbers.
* @return array containing 9 random unique numbers.
*/
private Integer[] generateRandomNumbers() {
ArrayList randoms = new ArrayList();
for (int i = 0; i < 9; i++)
randoms.add(i + 1);
Collections.shuffle(randoms);
return randoms.toArray(new Integer[9]);
}
/**
* A SudokuCell represents a cell for input.
*
*
*/
private class SudokuCell extends JTextField {
/** UID */
private static final long serialVersionUID = 4690751052748480438L;
/** Determine if this cell can accept input. */
private boolean editable;
/**
* Constructor
* @param row index for row of this cell.
* @param col index for column of this cell.
*/
public SudokuCell(final int row, final int col) {
super(1);

editable = true;
setBackground(Color.WHITE);
setBorder(BorderFactory.createLineBorder(Color.GRAY));
setHorizontalAlignment(CENTER);
setPreferredSize(new Dimension(35, 35));
setFont(new Font("Lucida Console", Font.BOLD, 28));
addFocusListener(new FocusListener(){
@Override
public void focusGained(FocusEvent arg0) {
// Change colors of fields located in vertical, horizontal, and 3x3 fields
for (int i = 0; i < 9; i++) {
// Horizontal
sudokuCells[i][col].setBackground(new Color(255, 227, 209));
// Vertical
sudokuCells[row][i].setBackground(new Color(255, 227, 209));
}
// 3x3 box
sudokuCells[i][j].setBackground(new Color(255, 227, 209));
}
@Override
public void focusLost(FocusEvent arg0) {
// Set the previous color of fields back to white
// Reset focus (set background color back to white)
for (int i = 0; i < 9; i++) {
// Horizontal
sudokuCells[i][col].setBackground(Color.WHITE);
// Vertical

sudokuCells[row][i].setBackground(Color.WHITE);
}
// 3x3 box
sudokuCells[i][j].setBackground(Color.WHITE);
}
});
addKeyListener(new KeyAdapter() {
@Override
public void keyPressed(KeyEvent e) {
// Only allow numeric input
if (editable)
if (e.getKeyChar() >= '1' && e.getKeyChar() <= '9') {
setEditable(true);
setText(""); // Keep it 1 letter
cellValues[row][col] = e.getKeyChar() - 48;
} else if (e.getKeyCode() == KeyEvent.VK_BACK_SPACE) {
setEditable(true);
setText("0"); // Avoid beep sound
cellValues[row][col] = 0;
} else
setEditable(false);
// Navigation by arrow keys
switch (e.getKeyCode()) {
case KeyEvent.VK_DOWN:
sudokuCells[(row + 1) % 9][col].requestFocusInWindow();
break;
case KeyEvent.VK_RIGHT:
sudokuCells[row][(col + 1) % 9].requestFocusInWindow();
break;

case KeyEvent.VK_UP:
sudokuCells[(row == 0)? 8 : (row - 1)][col].requestFocusInWindow();
break;
case KeyEvent.VK_LEFT:
sudokuCells[row][(col == 0)? 8 : (col - 1)].requestFocusInWindow();
break;
}
}
});
}
}
/**
* @param args
*/
public static void main(String[] args) {
new SudokuSolver();
}
}
Solution
Hi,
When i just copied the code above to eclipse and tried running this is the error i get:
Exception in thread "main" java.lang.NullPointerException
at javax.swing.ImageIcon.(ImageIcon.java:205)
at SudokuSolver.prepareSudokuUI(SudokuSolver.java:67)
at SudokuSolver.(SudokuSolver.java:45)
at SudokuSolver.main(SudokuSolver.java:550)
That is the only error i got
And the reason for the error is
title.add(new JLabel(new ImageIcon(getClass().getResource("/resources/title.png")))); this
perticular line in private void prepareSudokuUI() function. we should give a image file to the
program so give a correct path where you have copied the image file.
my suggestion is that u keep a image file in the same folder where you have this perticular .java
file and just replace the path with image file name

name. title.add(new JLabel(new ImageIcon(getClass().getResource("myimage.png")))); That
will work :)
if you are getting any other error you should specify in the question. Anyfurther clarification
needed comment below.

Getting some errors when trying to run this program, can anyone help.pdf

Recommended

Recommended

More Related Content

Similar to Getting some errors when trying to run this program, can anyone help.pdf

Similar to Getting some errors when trying to run this program, can anyone help.pdf (20)

More from mohammedfootwear

More from mohammedfootwear (20)

Recently uploaded

Recently uploaded (20)

Getting some errors when trying to run this program, can anyone help.pdf
