General mining presentation

1. Surface Mining
Presentation

3. Company Profile
• Established 1925
• Invented grooved piping system
• ISO 9001 Certified Company
• Years of success in multiple markets
– Fire Protection
– HVAC
– Industrial
– Mining
– Wastewater
• Dedicated to product
innovation

4. Surface Applications
• Slurry Handling
• Tailings
• Compressed Air
• Pump Gland Seal Water
• Acids
• Process Water
• Flotation Lines
• Cyclone Piping
• Pneumatic Conveying
• Dust Suppression
• General Utility Piping
• Slurry
• Fire Protection

5. What Is Victaulic ?
• Victaulic is an alternative method of
joining pipe with a faster installation and
lower installed costs over traditional piping
systems, IE: Welded, Flanged, or
Threaded.

6. Welded and Flanged Construction
Labor Material Cost Ratio
Labor Material
70% 30%
• Labor is the least accurate cost or the highest risk
- it usually is a best guesstimate
• Material cost is the most accurate cost or the
lowest risk

7. Victaulic Total System Construction
Labor Material Cost Ratio
Labor Material
30% 70%
• Since labor represents your highest risk, you can
reduce your risk by as much as 40% by transferring
as much labor risk as possible to the lower risk
material side of costs.

8. Innovator of Grooved Piping
•1925 Victaulic introduced first
grooved coupling for WW I
•1945 First field cut groovers on
market
•1957 Introduced roll grooving
•1983 First angled bolt pad rigid
coupling
•1991 Pressfit introduced
•2005 AGS for large diameter
introduced

9. Grooved End Technology
1. Coupling Housing
– ASTM A-536 Grade
65-45-12
2. Bolts & Nuts
– ASTM A-183
tensile 110,000 psi
(7,580 Bar)
3. Gasket
4. Groove

10. Grooved Coupling Assembly

11. Worldwide Approvals

12. Advantages Over Conventional Systems
• Total Installed Cost Savings
• Union at Every Joint
• High Pressure Capabilities
• Fast & Clean
• No HOT WORKS
• Ease of alignment
• Less Re-work $$$
• Ease of Maintenance
• Less Labour Needed on Site
• Safe !!!!

13. No Hot Works

14. Flexible and Rigid Joints

15. Rigidity
•Rigidity is achieved
with standard
couplings
•Angled bolt pad
design of s/07
provides positive
clamping of the pipe
•Resists torsional and
flexural loads

16. Rigid Coupling’s Are Stronger Than
Welded Joints

17. Flexibility
•Accommodates
expansion - contraction
- deflection
•Can design the piping
system to take
advantage of these
features

18. Flexible Coupling’s Used For Deflection

19. Allows for System Access and Expansion
•Provides easy access for
maintenance or system
access.
•Victaulic butterfly valves
provide dead-end shut-off
to isolate equipment.

20. Alignment Ease
•Grooved system allows
full rotation of the pipe
and system components.
•Allows for ease of proper
alignment.

21. Noise and Vibration Attenuation
•Independent grooved
pipe sections reduce noise
and vibration
transmission

22. Seismic Stress Absorption
•Full engagement of the
housing keys in the
grooves provides pressure
restraint and end load
capability

23. Seismic Performance

24. Roll Grooving
• Grooves are formed primarily
by roll grooving (cold forming)
a groove into the pipe.
• No removal of metal.
– Full wall thickness is
maintained.
• Clean, Fast ,Simple and No Hot
Work.

25. Roll Grooving Tools
• Pipes can be grooved
in the shop or in the job site
• Carbon Steel,
Stainless Steel,
Copper, Aluminum & PVC
• Pipe Sizes ¾ – 42”
(20 mm - 1050 mm)
• Wall thickness up to
½” (12.7 mm)

26. Cut Grooving

27. Gaskets
•Victaulic manufactures
our own gaskets
•C- Shaped gasket forms
a triple seal
–between the pipe ends
and the groove
–surrounded, reinforced
and slightly compressed by
the housing
–enhanced by pressure or
vacuum in the line

28. Gaskets

29. Style 07 Rigid Coupling
• Angular bolt pad design resists
flexural and torsional loads
• Sizes 1 - 24 inches
(25 - 600 mm)
• Operating pressures up to
750 PSI (52 Bar)

30. Style 07 Rigid Coupling
•Visual installation
inspection
•No torque requirement
•Coupling halves should
be touching bolt bad to
bolt pad for correct
installation

31. Style 77 Flexible Coupling
• Allows axial movement
and angular deflection at joints
• Sizes ¾ - 24 inches
(20 - 600 mm)
• Operating pressures up to 1000 PSI
(69 Bar)
• Effective stress release &
vibration attenuation capabilities

32. Style 770 Large Diameter
•Pressure rated up to
2580 kPa
•Sizes from
650mm – 1050mm

33. Depend–O–Lok Couplings
• E x E Flexible Coupling
• F x E Fixed x Expansion Coupling
• F x F Fixed x Fixed Coupling
• F x E Flange Adaptor Coupling
• AirMaster
• Fluid Master
• Encapsulating Joints
• Paragon Expansion Joints

34. Depend–O–Lok Couplings
• Can accommodate for pipe ovality
• High or low pressure applications
• Can be used for buried service
• Engineered to specific requirements
• Can be used on the following pipe:
– Carbon Steel
– Stainless Steel
– Ductile Iron
– FRP
– HDPE

35. Depend–O–Lok Couplings

36. Coupling Installation

37. Grooved End Fittings
•Wide range of fittings with grooved ends.
•Flange Adaptors ANSI 150# , 300# , AS2129
•Manufactured from ductile iron to ASTM A-536
Grade 65-45-12.
•Grooved fittings are rated to the coupling
pressure rating.
•Sizes range from 20mm – 1050mm
•Available in standard Orange enamel or Hot dip
galvanized , some fittings can be supplied
electroplated.

38. Hole Cut Fittings

39. Style 926 Mechanical- T

40. Style 926 Mechanical - T
• Provides excellent outlet for tailings disposal
• Allows uniform disposal of tailings in the pond
• Easy installation in existing tailings lines

41. Grooved Valves
•Butterfly Valves 50mm - 600mm
•Vic Check Valves 50mm - 600mm
•Plug Valves 80mm - 450mm
•Ball Valves 40mm - 150mm
•Operating options include:
Actuators, Gear box, Lever, Chain
wheel.

42. Style 365 Plug Valve

43. Style 365 Plug Valve
• Full port valve
• Eccentric plug
excellent in slurry
applications
• Bubble tight sealing up
to 175psi for 3 - 12”
• Sizes from 3 - 18”

44. Style 365 Plug Valve

45. Style 365 Plug Valve

46. Accessories

47. Strainers

48. Plain End Piping System

49. Style 99 Roust-A-Bout Coupling

50. Style 99 Coupling

51. HDPE Piping Products

52. Style 995 - No Flanges , Bolts, Gaskets

53. Style 995 - No fusion machine required

54. Style 995 Plain End HDPE Coupling

55. Style 995 - Easier Access Than a Flange

56. 316 SS Pressfit
• SS 316 SCH5 Pipe ASTM A-312
• 15mm - 50mm
• Elbows, Tees, Reducing Tees, Male
& Female Adapters, Flanges.
• 5 Seconds To Complete A joint
• UL Classified
• ANSI/NSF 61 For Potable Water
• Pressure Rating 300psi (2065kPa)
• ANSI Class 150# (Except Steam)
• “O” Rings – EPDM,Nitrile & Viton

57. 316SS Pressfit
Varied Mining Installations Include
• Plant air
• Instrument air
• Pump gland seal water
• Flocculant
• Emergency eyewash piping
• Make up water

58. Pressfit 316SS
Pressfit Tools
• Electric operated
• Pnuematic
operated
• Hand held
convenience

59. Pressfit Applications

60. Grooved Stainless Steel

61. Grooved Stainless Steel

62. Grooved Stainless Steel - Valves
Style 763 Butterfly Valve
• 2100 kPa bi-directional dead end service
Style 726S Ball Valve
• Two piece end entry floating ball design
• Pressure ratings
– 40mm – 80mm 7000 kPa
– 100mm – 150mm 5600 kPa

63. Victaulic Software Packages
• Vic Blocks 2D – AutoCAD Compatible
• Vic Blocks 3D – AutoCAD Compatible
• Vic Cells 2D – MicroStation Compatible
• Vic Cells 3D – MicroStation Compatible
• Vic Guide Specs – Specification Writing
• Third party Software:
– Aveva (Cadcentre) PDMS
– Bentley AutoPlant
– Bentley Plant Space
– CEA Systems – Plant 4D
– Coade – CADWorx Pipe
– Hydratec – HydraCAD (Fire Protection)
– Intergraph PDS
– QuickPen Pipe Designer 3D

64. Victaulic 3D Piping Software
Allows users to draw 3D pipe within the following
Victaulic modules:
•AWWA
•IPS
•Copper Tubing
•Pressfit
•HDPE
Pipe materials include:
•Carbon Steel
•HDPE
•Copper
•Stainless Steel
•Ductile Iron
•Offers a full range of pipe sizes in both imperial and Metric.
•Includes a bill of material routine that lists pipe cut lengths.
•Currently runs on AutoCAD Release 2004 and later.
•Works in conjunction with Vic Blocks 3D.

65. Thank you
Questions & Answers
