flags registers in assembly language

1. TOPIC
FLAG USAGE
Presented by :
Saman iftikhar
Hira Nasir
Shahwana Fida
Presented to:
Dr. Fouzia jabeen

2. TABLE OF CONTENT
• Define flag
• Kind of flag
• Status Flag
• Control flag
• Discuss 16bits of flag
• Examples
12/28/2017
Computer organization and Assembly Language
2

3. FLAG REGISTER
• Flag register contains 16 bits that show the status of some activities
• Instructions that involve comparison and arithmetic will change the flag status

4. KINDS OF FLAGS
• The status flags are set/reset depending on the results of some arithmetic or logical
operations during program execution
• The control flags to control the operation of CPU
12/28/2017
Computer organization and Assembly Language
4

5. FLAGS
X X X X OF DF IF TF SF ZF X AF X PF X CF
Bits marks X is
undefined
direction Trap Zero
Auxiliary
parity Carry
interrupt
Sign
overflow
 6 are status flags
 3 are control flags
12/28/2017 5

6. • Status flags
CF
AF
SF
ZF
PF
OF
12/28/2017
Computer organization and Assembly Language
6

7. control flags
DF TF
IF
12/28/2017 Computer organization and Assembly Language 7

8. CARRY FLAG
• When there is last carry out : 1
• When there is not last carry out: 0
12/28/2017
Computer organization and Assembly Language
8

9. ZERO FLAG (ZF)
• Set to 1 when result is 0.
• For non zero result this flag is set to 0.
12/28/2017
Computer organization and Assembly Language
9

10. SIGN FLAG(SF)
• Set to 1 when result is negative.
• When result is positive it is set to 0.
12/28/2017
Computer organization and Assembly Language
10

11. OVERFLOW FLAG(OF)
• When result is to big to fit in the destination: 1
• When result is not to big to fit in the destination: 0
12/28/2017
Computer organization and Assembly Language
11

12. PARITY FLAG(PF)
• This flag is set to 1 when there is even number of one bits in result
• And to 0 when there is odd number of one bits.
12/28/2017
Computer organization and Assembly Language
12

13. AUXILIARY FLAG(AF)
• Every third bit will handle by Auxiliary flag
• When 3rd bit carry exits: 1
• When 3rd bit carry does not exits: 0
12/28/2017
Computer organization and Assembly Language
13

14. INTERRUPT FLAG(IF)
When interrupt is called : 1
When interrupt is not called : 0
12/28/2017
Computer organization and Assembly Language
14

15. DIRECTION FLAG(DF)
• This flag is used by some instructions to process data chains:
• when this flag is set to 0, the processing is done forward,
• when this flag is set to 1 the processing is done backward.
12/28/2017
Computer organization and Assembly Language
15

16. TRAP FLAG:
• System use it when debugging is required;
• When single step mode( debugging) is needed: 1
• When single step mode( debugging) is not needed: 0
12/28/2017
Computer organization and Assembly Language
16

17. HOW INSTRUCTION EFFECT THE
FLAG
Instructions
MOV/ XCHG
ADD/SUB
INC/DEC
Affect flag
None
All
All except CF
12/28/2017
Computer organization and Assembly Language
17

18. •Example of Zero Flag
12/28/2017 Computer organization and Assembly Language 18

19. 12/28/2017 Computer organization and Assembly Language 19

22. Example of Sign Flag
12/28/2017 Computer organization and Assembly Language 22

23. 12/28/2017 Computer organization and Assembly Language 23

24. 12/28/2017 Computer organization and Assembly Language 24

25. 12/28/2017 Computer organization and Assembly Language 25

26. •Example of Parity Flag
12/28/2017 Computer organization and Assembly Language 26

27. 12/28/2017 Computer organization and Assembly Language 27

28. 12/28/2017 Computer organization and Assembly Language 28

29. 12/28/2017 Computer organization and Assembly Language 29

30. •Example of Carry flag
12/28/2017 Computer organization and Assembly Language 30

31. 12/28/2017 Computer organization and Assembly Language 31

32. 12/28/2017 Computer organization and Assembly Language 32

33. 12/28/2017 Computer organization and Assembly Language 33

34. 12/28/2017 Computer organization and Assembly Language 34

35. •Example of overflow
12/28/2017
Computer organization and Assembly Language
35

36. 12/28/2017 Computer organization and Assembly Language 36

37. 12/28/2017 Computer organization and Assembly Language 37

38. 12/28/2017 Computer organization and Assembly Language 38

39. SUMMARY
• We have discussed flag register and kinds of flag
• Flag register contains bits that show the status
• 9 of its 16bits indicate the current status of the computer and the
result of processing

40. ANY QUESTION?
