This document provides an introduction and overview of using the Evernote iOS SDK. It discusses setting up the development environment with Xcode and Cocoapods. It then outlines 5 practices for using the Evernote SDK, including initializing the SDK, listing notebooks and notes, rendering note content in a UIWebView, and sharing notes to social networks. It also shares some of the author's experiences working with the Evernote SDK, such as considerations around syncing, rate limits, notebook types, and limitations for writing notes to Evernote.

1. Evernote iOS SDK
introduction
GoLater Developer MaoYang
Twitter @GoLaterApp E-Mail my@esast.com

2. About Me
• 5 years Mac Device Driver/Application developer
• 10 years Enterprise grade software development
tools consultant
• Now -> iOS/Android app developer

3. Today’s Goal
• iOS App development setup -> Xcode 5.x +
Cocoapods
• Evernote iOS SDK introduction
• 5 Evernote iOS SDK practices

4. Evernote SDK
• https://github.com/evernote/evernote-sdk-ios
• Evernote Cloud SDK detail spec ->http://
dev.evernote.com

5. EasyShare for Evernote
• Practice-1 : Development environment setup and
using Evernote OAuth API
• Practice-2 : List all of notebooks in your Evernote
account
• Practice-3 : List all of notes in a notebook
• Practice-4 : Render note content in UIWebView
• Practice-5 : Share your note to social network

6. Practice-1 SDK setup &
OAuth
• Xcode 5.x +
• cocoapods installation—> sudo gem install
cocoapods
• Create an iOS project named EasyShare by Xcode

7. Evernote SDK setup
• create a file named Podfile in your root of project
plateform :iOS , ‘7.0’
pod ‘Evernote-SDK-iOS’, ‘1.3.1’
• pod install
• Open EasyShare.xcworkspace in Xcode

8. Setup URL Scheme

9. Initialize SDK -1
#import "EvernoteSDK.h"!
!
- (BOOL)application:(UIApplication *)application didFinishLaunchingWithOptions:
(NSDictionary *)launchOptions!
{!
// Initial development is done on the sandbox service!
// Change this to BootstrapServerBaseURLStringUS to use the production Evernote
service!
// Change this to BootstrapServerBaseURLStringCN to use the Yinxiang Biji production
service!
// Bootstrapping is supported by default with either BootstrapServerBaseURLStringUS or
BootstrapServerBaseURLStringCN!
// BootstrapServerBaseURLStringSandbox does not support the Yinxiang Biji service!
NSString *EVERNOTE_HOST = BootstrapServerBaseURLStringUS; //使⽤用Production Server!
!
// Fill in the consumer key and secret with the values that you received from Evernote!
// To get an API key, visit http://dev.evernote.com/documentation/cloud/!
NSString *CONSUMER_KEY = @"your key";!
NSString *CONSUMER_SECRET = @"your secret";!
!
// set up Evernote session singleton!
[EvernoteSession setSharedSessionHost:EVERNOTE_HOST!
consumerKey:CONSUMER_KEY !
consumerSecret:CONSUMER_SECRET];!
}

10. Initialize SDK -2
(BOOL)application:(UIApplication *)application openURL:(NSURL
*)url sourceApplication:(NSString *)sourceApplication annotation:
(id)annotation {!
BOOL canHandle = NO;!
if ([[NSString stringWithFormat:@"en-%@", [[EvernoteSession
sharedSession] consumerKey]] isEqualToString:[url scheme]] ==
YES) {!
canHandle = [[EvernoteSession sharedSession]
canHandleOpenURL:url];!
}!
return canHandle;!
}

11. Initialize SDK-3
- (void)applicationDidBecomeActive:(UIApplication
*)application!
{!
// Restart any tasks that were paused (or not yet
started) while the application was inactive. If the
application was previously in the background, optionally
refresh the user interface.!
[[EvernoteSession sharedSession]
handleDidBecomeActive];!
}

12. SingleTon need to know in
this practice
• [EvernoteSession sharedSession], responsible
for login/logout, login status

13. UI would look like

14. OAuth
• if(![[EvernoteSession sharedSession]
isAuthenticated){}
• [[EvernoteSession sharedSession]
authenticateWithViewController:self
completionHandler:^(NSError *error){}]

15. Sample code
• http://goo.gl/KzUK8W

16. Practice-2 List all of your
own notebooks

17. SingleTon & Class need to
know in this practice
!
• [EvernoteStore noteStore] -> For ever note
related operation
• EDAMNotebook -> Class of Notebook object

18. Query Notebook
• [[EvernoteNotesStore noteStore]
listNotebooksWithSuccess:^(NSArray *notebooks){
for(EDAMNotebook *notebook in notebooks){} }
failure:^(NSError *error){}];

19. Sample code
• http://goo.gl/I9fNpb

20. Practice-3 List all of notes in
a notebook

21. Classes need to know in this
practice
• EDAMNoteFilter -> setup filter condition for query
notes
• EDAMNotesMetadataResultSpec -> Setup which
note metadata fields would return from cloud
• EDAMNoteMetadata -> Class of note metadata!
• EDAMNotesMetadataList , Container for notes
object array

22. Filter
• EDAMNoteFilter *filter = [[EDAMNoteFilter alloc]
initWithOrder:NoteSortOrder_UPDATED
ascending:NO words:nil notebookGuid:nil
tagGuid:nil timeZone:nil inActive:NO
emphasized:NO]
• Filter full api spec doucment—>http://
dev.evernote.com/doc/reference/
NoteStore.html#Struct_NoteFilter

23. Metadata fields
• EDAMNotesMetadataResultSpec *resultSpec =
[[EDAMNotesMetadataResultSpec alloc]
initWithIncludeTitle:YES
includeContentLength:YES includeCreated:YES
includeUpdated:YES includeDeleted:YES
includeUpdateSequenceNum:YES
includeNotebookGuid:YES includeTagGuids:YES
includeAttributes:YES
includeLargestResourceMime:NO
includeLargestResourceSize:YES];

24. Query
• [[EvernoteNoteStore noteStore]
findNotesMetadataWithFilter:filter offset:0
maxNotes:10 resultSpec:resultSpec
success:^(EDAMNotesMetadataList *metalist)
{if(metalist.notes.count > 0)….}failure:^(NSError
*error){ } ];

25. Sample code
• http://goo.gl/D2G3G6

26. Practice-4 Render note
content in UIWebView

27. Classes need to know in this
practice
• ENMLUtility->Convert ENML to HTML
• EDAMNote -> Class of note object

28. Download note content
• [[EDAMNoteStore noteStore]
getNoteWithGuid:note.guid withContent:YES
withResourcesData:YES
withResourceRecognition:NO
withResourceAlternateData:NO
success:^(EDAMNote *note){} failure:^(NSError
*error{}]

29. ENML->HTML
• ENMLUtility *utility = [[ENMLUtility alloc] init]
• [utilty convertENMLToHTML:note.content
withResources:note.resources
completion:^(NSString *html,NSError *error){}

30. Sample code
• http://goo.gl/tUzfQH

31. Practice-5 Share note to Social network

32. setup pod would use in this
practice
• pod ‘LINEActivity’, ‘~>0.2’
• pod update

33. Classes need to know in this
practice
• [EvernoteUserStore userStore], For fetching user
related information like shardid
• EDAMUser Class of user object

34. Sharing note URL
generated by Evernote
• http://www.evernote.com/shard/{shardid}/sh/
{noteguid}/{notekey}

35. How to get user’s shard id?
• [[EvernoteUserStore userStore]
getUserWithSuccess:^(EDAMUser *user){}
failure:^(NSError *error){ NSString *shardId =
user.shardId}];

36. Share note then get note’s
sharing key
• [[EvernoteNoteStore noteStore]
shareNoteWithGuid:note.guid success:^(NSString
*key){} failure:^(NSError *error){}]

37. iOS Share Activity for note
sharing url
• NSURL *shareURL = [NSURL
URLWithString:shareurlstr]
• NSArray *activityItems = @[shareurlstr,shareURL]
• NSArray *applicationActivities = @[[LINEActivity alloc]
init]
• UIActivityViewController *activity =
[[UIActivityViewController alloc]
initWithActivityItems:activityItems
applicationActivities:applicationActivities]

38. Sample code
• http://goo.gl/wGXMrb

39. Share some of My
experience …

40. To Sync or not to ?
• Evernote Sync API is another topic, Sync API like
Mail IMAP protocol which sync all of cloud changes
set to your App
• Do you need all of notebook/notes in your App?

41. Rate Limit
• Limit for API calling for each hours
• Implement Cache in your App for reducing Rate
Limit exception
• Detail-> http://dev.evernote.com/doc/articles/
rate_limits.php

43. Note thumbnails
• Note include in Evernote iOS SDK, Need to use
HTTP request to fetch each note’s thumb image
• Please refer to http://dev.evernote.com/doc/articles/
thumbnails.php

44. Notebook
• User’s own Notebook->EDAMNotebook
• Notebook shared by friend ->EDAMLinkbook
• Business Notebook
• Take care about differences between each
notebook interface

45. Limitations for Writing to
Evernote
• Note content body need to be ENML format,
EDAMWriter class could help you
• EDAMLimits.h & EDAMLimits.m has a lot of Regular
express for checking your input data

46. Q & A
