2. EnterPrice Java:
They are components that can be connected to
form a system
They can represent data
They can represent behavior
Usually, EJBs fall into only one of these
categories
They are typically used in the server tier
EJBs can be persisted
EJBs can interact with other EJBs
3. Advantages:
EJBs are reusable components
• Can be reused in different parts of the system
• Can be packaged into libraries and sold
EJBs Can be combined visually using development IDEs
• E.g. Visual Age, Visual Café
EJBs provide convenient abstractions so it do not require
you to write:
• Multi-threaded, multiple access code
• Database access code (e.g. JDBC)
• Network communication code (i.e. it uses RMI) for client/server
communication
• Network communication code for EJB to EJB communication
• Transaction management code
EJBs from different businesses can interact easily
• This is because of their well-defined interfaces
4. 1. Containers where EJBs (and JSPs and
servlets)
are executed
2.Provide EJB functionality, including:
* Persistence through databases (using JDBC)
* Transactions (using Java Transaction Service)
3. Can provide advanced features, including:
* Load balancing
* Database connection pooling
4.Here are the major application servers:
* SJS AP, WebLogic (BEA), Internet Application
Server or iAS (Oracle), WebSphere (IBM)
5.
6. •Authentication :
The means by which communicating entities (for example,
client and server) prove to one another that they are acting on
behalf of specific identities that are authorized for access.
•Access control for resources:
The means by which interactions with resources are limited to
collections of users or programs for the purpose of enforcing
integrity, confidentiality, or availability constraints.
•Non-repudiation: The means used to prove that a user
performed some action such that the user cannot reasonably
deny having done so.
7. •Data integrity:
The means used to prove that information has not been modified
by a third party (some entity other than the source of the
information). For example, a recipient of data sent over an open
network must be able to detect and discard messages that were
modified after they were sent.
•Confidentiality or Data Privacy: The means used to ensure
that information is made available only to users who are
authorized to access it.
•Auditing: The means used to capture a tamper-resistant record
of security related events for the purpose of being able to
evaluate the effectiveness of security policies and mechanisms.
8. Client Components
A Java EE application can be web-based or non-web-
based. An application client executes on the client
machine for a non-web-based Java EE application, and a
web browser downloads web pages and applets to the
client machine for a web-based Java EE application.
Application Clients
An application client runs on a client machine and
provides a way for users to handle tasks such as Java EE
system or application administration. It typically has a
graphical user interface created from Project Swing or
Abstract Window Toolkit (AWT) APIs, but a command-line
interface is certainly possible.
Application clients directly access enterprise beans
running in the business tier. However, if the Java EE
application client requirements warrant it, an application
client can open an HTTP connection to establish
communication with a servlet running in the web tier.
9. Web Browsers
The user's web browser downloads static or dynamic Hypertext Markup
Language (HTML), Wireless Markup Language (WML), or Extensible Markup
Language (XML) web pages from the web tier. Dynamic web pages are
generated by servlets or JSP pages running in the web tier.
Applets
A web page downloaded from the web tier can include an embedded applet.
An applet is a small client application written in the Java programming
language that executes in the Java VM installed in the web browser. However,
client systems will likely need Java Plug-in and possibly a security policy file
so the applet can successfully execute in the web browser.
Applets that run in other network-based systems such as handheld devices
or car phones can render Wireless Markup Language (WML) pages generated
by a JSP page or servlet running on the Java EE server. The WML page is
delivered over Wireless Application Protocol (WAP) and the network
configuration requires a gateway to translate WAP to HTTP and back again.
The gateway translates the WAP request coming from the handheld device to
an HTTP request for the Java EE server, and then translates the HTTP server
response and WML page to a WAP server response and WML page for
display on the handheld device.
10. Container Types
The deployment process installs Java EE application
components in the following types of Java EE containers. The
Java EE components and container addressed in this tutorial
are shown in Figure 5.
1. An Enterprise JavaBeans (EJB) container manages the
execution of all enterprise beans for one Java EE
application. Enterprise beans and their container run on the
Java EE server.
2. A web container manages the execution of all JSP page
and servlet components for one Java EE application. Web
components and their container run on the Java EE server.
3. An application client container manages the execution of
all application client components for one Java EE
application. Application clients and their container run on
the client machine.
4. An applet container is the web browser and Java Plug-in
combination running on the client machine.
12. Scripts
Script Description
j2ee Start and stop the Java EE server.
cloudscape Start and stop the default database.
cloudIJ Run the interactive SQL tool. This is an
unsupported tool.
j2eeadmin Add JDBC drivers, JMS destinations, and
connection factories for various
resources.
keytool Create public and private keys and
generate X509 self-signed certificates.
realmtool Import certificate files. Add Java EE users
to and remove Java EE users from the
authentication and authorization list for a
Java EE application.
13. packager Package Java EE application
components into EAR, EJB JAR,
application client JAR, and WAR files.
verifier Verify that EAR, EJB JAR, application
client JAR, and WAR files are well-formed
and comply with the Java EE
specification.
runclient Run a Java EE application client.
cleanup Remove all deployed applications from the
Java EE server.
