Docker is an open source containerization platform that allows applications to be easily deployed and run across various operating systems and cloud environments. It allows applications and their dependencies to be packaged into standardized executable units called containers that can be run anywhere. Containers are more portable and provide better isolation than virtual machines, making them useful for microservices architecture, continuous integration/deployment, and cloud-native applications.

1. Mr. Mohan Pawar

2.  What is Docker ?
 Containers Vs Virtual Machines
 Docker terminology
◦ Docker engine
◦ Images
◦ Containers
◦ Registry
◦ Docker Hub
◦ Docker Cloud
Introduction to Images
Getting started with Containers

3.  It’s all about data…

4.  There’s rock, paper, scissors
and then there’s information.

7.  Docker is an open source engine that
automates the deployment of any application
as a lightweight, portable and self-sufficient
that will run virtually anywhere.
 Package your application into a standardized
unit of software development.

8.  Provide a uniformed wrapper around a
software package: «Build, Ship and Run Any App,
Anywhere»
◦ Similar to shipping containers: The
container is always the same, regardless
of the contents and thus fits on all trucks,
cranes, ships, ...

10.  libvirt: Platform Virtualization
 LXC (LinuX Containers): Multiple isolated
Linux systems (containers) on a single host
 Layered File System

11.  2013-03: Releases as Open Source
 2013-09: Red Hat collaboration (Fedora,
RHEL, OpenShift)
 2014-03: 4th most starred GitHub project
 2014-05: JAX Innovation Award (most
innovative open technology)

12. 12
Run Platforms
 Various Linux distributions
(Ubuntu, Fedora, RHEL, Centos,
openSUSE, ...)
 Cloud (Amazon EC2, Google
Compute Engine, Rackspacem,
Azure)
 2016-12: Microsoft announces
plans to integrate Docker with
next release of Windows Server

13.  Docker is the world’s
leading software
containerization platform.

14. Simple Command - Ad-Hoc Container
 docker run ubuntu echo Hello World
◦ docker images [-a]
◦ docker ps –a

15.  If you change a single line in your
project, how much time is required to
deploy it in production ?

16.  Persisted snapshot that can be run
◦ images: List all local images
◦ run: Create a container from an image and execute
a command in it
◦ tag: Tag an image
◦ pull: Download image from repository
◦ rmi: Delete a local image
 This will also remove intermediate images if no longer
used

17.  Runnable instance of an image
◦ ps: List all running containers
◦ ps –a: List all containers (incl. stopped)
◦ top: Display processes of a container
◦ start: Start a stopped container
◦ stop: Stop a running container
◦ pause: Pause all processes within a container
◦ rm: Delete a container
◦ commit: Create an image from a container

18. Container
cid4
Container
cid3
18
Image vs. Container
Base Image
ubuntu:latest
Container
cid1
run
Container
cid1
cmd  new state
New Image
iid1
commit
base image
Container
cid2
run

19.  Create images automatically using a build
script: «Dockerfile»
 Can be versioned in a version control system
like Git or SVN, along with all dependencies
 Docker Hub can automatically build images
based on dockerfiles on Github

20.  Dockerfile:
◦ FROM ubuntu
ENV DOCK_MESSAGE Hello My World
ADD dir /files
CMD ["bash", "someScript"]
 docker build [DockerFileDir]
 docker inspect [imageId]

21.  docker run –ti –v /hostLog:/log
ubuntu
 Run second container: Volume can be shared
◦ docker run –ti --volumes-from
firstContainerName ubuntu

22.  docker run –t –p 8080:80 ubuntu nc –l
80
◦ Map container port 80 to host port 8080
◦ Check on host: nc localhost 8080
 Link with other docker container
◦ docker run -ti --link containerName:alias
ubuntu
◦ See link info with set

23.  Docker Images: Docker Hub
 Vagrant: «Docker for VMs»
 Automated Setup
◦ Puppet, Chef, Ansible, ...
 Docker Ecosystem
◦ skydock / skydns
◦ fig

24.  Public repository of Docker images
◦ https://hub.docker.com/
◦ docker search [term]
 Automated: Has been automatically built from
Dockerfile
◦ Source for build is available on GitHub

25.  top / ps / free -m
 Start 100 WebServer containers
◦ docker run -d -p $hostPort:5000 -e
"PROVIDER=$provider" training/webapp
 docker ps [containerId]
 top / ps / free -m

26.  Development Environment
 Environments for Integration Tests
 Quick evaluation of software
 Microservices
 Multi-Tenancy
 Unified execution environment (dev  test 
prod (local, VM, cloud, ...)
e.g. BookMyShow transfer their 3 servers to
docker.

28.  All IT companies are migrating their servers
with docker.
 Micro-service architecture
 Serverless computing.

29.  Docker homepage: https://www.docker.com/
◦ Introduction:
https://www.docker.com/whatisdocker/
◦ Online tutorial: https://www.docker.com/tryit/
◦ Installation and user guide:
https://docs.docker.com/
 InfTec TecBoard:
https://inftec.atlassian.net/wiki/display/TEC/
Docker

30.  https://bitbucket.org/inftec/vagrant-
playground/branch/docker-demo
 Multi-Container-Setup
◦ Logging-Container
◦ Echo-Container
◦ Client-Container

31.  https://dockerinfo.wordpress.com/
 http://mohan08p.strikingly.com/
 https://www.quora.com/profile/Mohan-
Pawar-1
 https://github.com/mohan08p
 https://in.linkedin.com/in/mohan-pawar-
91a5432a

32.  Containerization is the fastest, most resource
effective, and most secure setup we know to
date and docker is drifting the IT world in
more agile way to achieved easy to create
architecture.
