The document discusses a power supply circuit for an EPIC sensor. The circuit will provide regulated 5V power from an input voltage range of 7-24V. It uses a buck converter and voltage regulator to step down the input voltage and provide a stable 5V output to power the EPIC sensor.

Aim of the Project: The project aims to design and analysis of bidirectional dc-dc converter for vehicle-to-grid application in Electric Vehicles. The proposed converter can boost the voltage of an energy-storage system (e.g. from battery management system in EV) to a high-voltage AC bus for a particular load demand, during peak load conditions. When the high-voltage AC bus has excess energy, during low load conditions, this energy-storage module can be charged by the AC bus via inverter & bidirectional dc-dc converter. Problem Statement: A DC-DC converter is essential for exchanging energy between a storage device and the rest of the system and vise-versa. Such a converter should be able to handle bidirectional power flow capability in all the operating modes with flexible control. Thus, design and analysis of bidirectional DC-DC converters is an important aspect. Bidirectional DC-DC Converter: Bidirectional DC-to-DC converter allows power flow in both forward and reverses direction. The bidirectional converter is also called two quadrant converter or four-quadrant converters (if both voltage and current can change direction). It is used as a key device for interfacing the storage device between source and load in renewable energy systems for continuous flow of power because the output of the renewable energy system fluctuates due to changing weather conditions. There are two modes in a bidirectional converter that is the buck converter and the boost converter. In the buck mode, auxiliary storage is located on the high voltage side whereas, in boost mode, it is situated on the low voltage side. Introduction to Electric Vehicle & Vehicle-to-Grid(V2G): Electric Vehicle is an automobile that operates on two or more electric motors powered by a battery pack or combined system of the battery pack and IC engine. There are four types of EVs, as each of them has advantages and disadvantages, they all save fuel and emit fewer GHG than other conventional IC engines. They can also recharge their batteries by the process of regenerative braking, where the electric motor in the EV assists in slowing down the EV and simultaneously recovers portion energy and feeds it to the batteries. Four types of EVs are as follows: (1) Hybrid Electric Vehicle (HEV) (2) Battery Electric Vehicle (BEV) (3) Plug-in Hybrid Electric Vehicle (PHEV) (4) Range Extended Electric Vehicle (REEV) V2G technology can be defined as a system capable enough to control bi-directional flow of electric energy between a vehicle and the electrical grid. The integration of electric vehicles into the power grid is called the vehicle-to-grid system. As conventional converters are unidirectional, they only work in G2V (Grid-to-Vehicle) mode. In V2G technology the grid is feed by the energy stored in the vehicle battery through the bidirectional converter, where power from the vehicle battery is stepped-up by the BDC.
