1. The security of on premise data & the advantages of cloud- HYBRID
Last Mile Data Center Delivered to You in a Box
Designed as complete plug and
play solution for use by carriers
who want last mile computing
and companies wanting on
premise computing with the
advantages of the cloud in an
hardened fault tolerant data
center
9600 mm x 3400 mmx 3225
mm complete computing data
center environment with
70kWh (242 u’s) of capacity
and 40kWh of Azure Stack IoT
Hub installed, configured and
supported
The Solution for Telecom Industry
• Lower backhaul costs
• Lower latency of network
• Add/Optimize content management services for
clients with our Compute at Edge Solution. Make your
cell sites intelligent
The Solution for Companies
• Security of your own private network with
cloud service advantages
• Faster response from previous cloud reliant
applications
• Manage AWS, Google Cloud and Azure from
a single place
The security of having your
computing and data on
premise in a hardened data
center infrastructure with the
advantages could services
provide
Compute at Edge Content Management
Solution by SmarterCity.Tech
• Telecom tower sites can now become intelligent content providers
and manage ONE copy of data with our Compute at Edge solution
• Access a content delivery network that pushes content physically closer to users to improve performance.
While such applications are widely distributed our solution allows you to manage them simultaneously.
• Allows the most complex applications possible to be run at the edge
• Industry leading security features reduces chances of data leaks. The unmatched speed at which the
environment operates, combined with isolated sandboxing technology, reduces the risk of accidental data
leakage. With a“burn-after-reading”approach to request memory, entire classes of vulnerabilities are
eliminated.
• Instant scale, around the globe: Code is run around the world instead of a single region. This allows
reduction in code execution latency and further optimize the performance
Outside
Inside
Module is designed to achieve re resistance EI 60 (Fire from
the inside out). The equipped module’s dimensions are
Module 9594 mm x 3400 mm x 3225 mm (LxWxH) and the
module is constructed with single-door (Mechanical, Panic
bar/Handle) entry. Dimensioned cooling units CRV25
provide in-row cooling technology. Cooling redundancy n
+1 is achieved with 5 cli-mate units. Solution contains
externally flush mounted, air cooled condenser unit, HCR33,
with nominal capacity 33 kW.
The enclosure is equipped with 7 pcs Miracel racks 600 mm x
1100 mm x 2000 mm (LxDxH) . Each rack contains 2 Moni-
tored, 3 x 32 A PDUs (14 pcs total). All of the electrical
equipment are dimensioned for site line voltage 400 V and
site line frequency 50 Hz. Electrical toplogy n+1 is achieved
with 1 x 90 kW + 30 kW modular UPS and with extra battery
cabinets 1pcs. Configuration includes main distribution
board (MDB), 1 pcs and Automatic transfer switch cabinet
(ATSC) 1 pcs. The solution supports a backup time of 10
minutes at a 70 kW IT Load via batteries. Installation
infrastructure-Unit IT comes with preinstalled cable tray for
copper data cables, 4x4 fiber optics channel with Single
spillouts, module cable management system, dual busway
system and hot/cold aisle separation with door.
40kWh or 4+ racks provide enterprise level Azure
Height
1200 mm
Width Depth600 mm800 mm
1100 mm
2000 mm / 42 U
Dell EMC Cloud for Microsoft Azure Stack is an on-premises
hybrid cloud platform for delivering infrastructure and platform
as a service with a consistent Azure experience on-premises or in
the public cloud. Innovate with cloud-native apps to digitally
transform your business.
Mike Maziarka
Smart City Technology
www.smartercity.tech
maziarka@smartercity.tech
www.novapole.com
Designed for Carriers by the company that delivers the aesthetically best 5G Nova CellTech small cell smart
pole with its 11x13x83 inch enclosure for as many as 12 devices .
From the providers of the Nova CellTech solution for 5G small cell deployments
Contact Info:
For those who want to simplify complex and distributed environments across on-premises, edge and multicloud,
Azure Arc enables deployment of Azure services anywhere and extends Azure management to any infrastructure.
Azure Arc is an advancement in hybrid computing, providing a set of technologies that unlocks new hybrid scenarios for
customers by bringing Azure services and management to any infrastructure and across environments—from cloud to
datacenter to edge, and enabling cloud security anywhere.
Azure Arc to Manage Microsoft cloud, AWS and Google cloud
For use by:
• Wireless Carriers who want solution on their network for interconnect, client smart city and edge data
services.
• For companies and municipalities that want or require private on-premise data management
• For smart city solution providers who have technologies that require high end edge computing
• For tower companies and telecommunication equipment manufacturers who want deliver last mile
computing services
• For geographies where large data centers are not available
