Building Efficient Multi-Threaded Filters for Faster SQL Queries
QuestDB is a time series database focused on optimizing SQL queries through multi-threaded filters that improve performance. The implementation utilizes various advanced techniques such as JIT compilation and efficient memory management, allowing for concurrent searches on data chunks. While the system achieves notable performance gains, its complexity and potential race conditions present challenges.
More Related Content
Similar to Building Efficient Multi-Threaded Filters for Faster SQL Queries
Building Efficient Multi-Threaded Filters for Faster SQL Queries
- 1. Brought to youby Building efficient, multi-threaded filters for faster SQL queries Vlad Ilyushchenko Co-Founder and CTO of QuestDB
- 2. Vlad Ilyushchenko Co-founder, CTO,QuestDB ■ Turned a side hustle into a company ■ I am interested in human psychology and high performance computing in equal measure ■ Away from work I mostly play hide and seek with my kids
- 3.
- 4. QuestDB is atime series database
- 5. What are wesolving?
- 6. What is theproblem? Most queries for time series include filters to: ■ Find a time series from table of multiple time series where symbol = ‘value’ ■ Find outlier records in a time series where value > 10.5 ■ Find tagged records in a time series where tag = ‘value’ and rate < 0.4
- 7. Fast column scan Somebenefits: ■ Single data structure - multiple queries ■ Reduces disk space usage ■ No impact on ingestion ■ Full scan algorithm scales well with “sparse” indexes
- 8.
- 9. Software components ■ JITcompilation ■ Linear memory access ■ SIMD ■ Efficient multi-core execution ■ Efficient memory management ■ SQL execution order optimization
- 10. How did weimplement it?
- 11. Filter function … wherelat > 10 and lon < 100: … where rowid in fn(lat, lon): uint64_t[] fn(double[] lat, double[] lon, uint64_t size)
- 12. Assembling filter function Functionis assembled using AsmJit. ■ AsmJit vs LLVM ■ IR - the Intermediate Representation ● Expression is parsed to IR by Java ● IR is bytecode, lives in native memory ● IR is passed to JIT ■ AVX2 assembly ● JIT processes the IR and emits AVX2 assembly instructions ● JIT uses AsmJit for cross-platform function abstraction and register allocation ■ Combining predicates ● JIT generated code has to combine results of a > 10 and b < 3
- 13. Calling search function Callsearch function from Java: ■ Prepare arguments, memory mapped columns of data ■ Call search function via JNI ■ Filter rows in batches benefiting from tight loop ■ Expose data via “row” API
- 14. Concurrency Chained concurrency. Twogoals: ■ Perform searches on multiple data chunks concurrently ■ Begin offloading search results before the search fully completes ■ Queue based - share nothing
- 15. Concurrency Filter function isstateless*, in that it only uses stack. So we can call it from multiple threads. ■ Fork - synchronous ● Chunk the data - prepare Data Frames ● Queue the execution tasks ■ Reduce - performed on thread pool ● Call search function concurrently for multiple Data Frames ● Store row ids in reusable “arena” ■ Join - performed by caller ● Translate row ids into data ● Submit for further processing * non-JIT filter functions can be stateful
- 16.
- 17. Single Writer Principle Singlewriter per table, Multi-Version Concurrency Control. ■ Append-only table versions ■ Transaction commit bumps tx watermark ■ Order by time before commit ■ Late data triggers new version creation
- 18.
- 19.
- 20. Inter-thread messaging framework MPSequencepubSeq = new MPSequence(); MCSequence subSeq = new MCSqeuence(); pubSeq.then(subSeq).then(pubSeq); // publisher thread pubSeq.next() // consumer thread subSeq.next(); Pub Sequence Sub Sequence
- 21. Work stealing Publisher becomesconsumer when queue is full. Consuming behaviour can be adjusted to prioritise publishing. ■ Publisher does not waste time ■ Pub/Sub system can work on 1 thread ■ Consumer thread does other things when queue is empty long cur = pubSeq.next() if (cur > -1) { // publish } else { cur = subSeq.next(); if (cur > -1) { // consume } }
- 22. Circuit breaker ■ Wecan interrupt long running execution ● On timeout ● On connection drop ● If we detect we have done enough work (LIMIT N / LIMIT -N) ■ Circuit breaker is an atomically executed code injected into every queue slot
- 23. Other nuances We employa number of techniques to reduce wait, contention and memory consumption: ■ Fixed worker pool ■ Tagged fork-join sequences ■ Sharded bounded queues ■ Reusable row id “arena”
- 24. What did welearn?
- 25. Conclusion ■ Pros: ● Niceperformance gains ● Faster than index where index size is larger than column scanned ● Full scan works well with sparse indexes ■ Cons: ● Implementation is quite complex and indirect ● It was hard to find all of many race conditions ● Lots of “fuzz” tests
- 26. Further Resources ■ Livedemo: https://demo.questdb.io/ ■ Blog: How we built a SIMD JIT compiler for SQL in QuestDB ■ Blog: 4Bn rows/sec query benchmark: Clickhouse vs QuestDB vs Timescale ■ Blog: How we built inter-thread messaging from scratch ■ Blog: My journey making QuestDB We 💕 All Contributions github.com/questdb/questdb
- 27.
- 28. Brought to youby Vlad Ilyushchenko vlad@questdb.io @ilyushvl
