Biotec dental implants are manufactured at our own state-of-the-art, in-house production facilities in Germany and comply with the highest standards. Our full Product Catalogue contains implants, prosthetics, CAD/CAM abutments as well as kits & tools. Download: http://biotec-implant.com
Spine Implants: Porous Coatings vs. Porous Materials vs. Additive ManufacturingApril Bright
Spine implant materials and surface characteristics are popular topics among engineers and surgeons. How do surface technologies relate to spine implants and bone integration and fusion? What are the pros and cons of various materials and surfaces? In this interactive session, members of industry and academia reviewed and presented research related to use of
• porous plasma spray coating,
• porous PEEK, and
• additive manufactured titanium in spinal devices.
