𝗔𝗡𝗜𝗦𝗢𝗠𝗘𝗧𝗥𝗢𝗣𝗜𝗔 𝗔𝗡𝗗
𝗔𝗡𝗜𝗦𝗘𝗜𝗞𝗢𝗡𝗜𝗔
𝗕𝗬 – MUSHAHID RAZA
B. Optom
𝗔𝗡𝗜𝗦𝗢𝗠𝗘𝗧𝗥𝗢𝗣𝗜𝗔
• The optical state with equal refraction in two eyes is termed
‘ɪsᴏᴍᴇᴛʀᴏᴘɪᴀ ’. When the total refraction of the two eyes is unequal
the condition is called ‘ ᴀɴɪsᴏᴍᴇᴛʀᴏᴘɪᴀ ’.
• An anisometropia up to 2.5 D is well tolerated and that between 2.5
and 4 D can be tolerated depending upon the individual sensitivity.
However, if it is more than 4D , it is not tolerated and is a matter of
concern.
𝗘𝗧𝗜𝗢𝗟𝗢𝗚𝗬
𝟭- 𝗖𝗼𝗻𝗴𝗲𝗻𝗶𝘁𝗮𝗹 𝗮𝗻𝗱 𝗱𝗲𝘃𝗲𝗹𝗼𝗽𝗺𝗲𝗻𝘁𝗮𝗹 𝗮𝗻𝗶𝘀𝗼𝗺𝗲𝘁𝗿𝗼𝗽𝗶𝗮
𝟮- 𝗔𝗰𝗾𝘂𝗶𝗿𝗲𝗱 𝗮𝗻𝗶𝘀𝗼𝗺𝗲𝘁𝗿𝗼𝗽𝗶𝗮
𝟭- 𝗖𝗼𝗻𝗴𝗲𝗻𝗶𝘁𝗮𝗹 𝗮𝗻𝗱 𝗱𝗲𝘃𝗲𝗹𝗼𝗽𝗺𝗲𝗻𝘁𝗮𝗹 𝗮𝗻𝗶𝘀𝗼𝗺𝗲𝘁𝗿𝗼𝗽𝗶𝗮 – occurs due to
differential growth of the two eyeballs.
𝟮- 𝗔𝗰𝗾𝘂𝗶𝗿𝗲𝗱 𝗮𝗻𝗶𝘀𝗼𝗺𝗲𝘁𝗿𝗼𝗽𝗶𝗮 – it may occur due to asymmetric age
change, Uniocular Aphakia aftet removal of cataractous lens or due
to implantation of IOL of wrong power.
𝗖𝗟𝗜𝗡𝗜𝗖𝗔𝗟 𝗧𝗬𝗣𝗘𝗦
𝟷- sɪᴍᴘʟᴇ ᴀɴɪsᴏᴍᴇᴛʀᴏᴘɪᴀ
𝟸- ᴄᴏᴍᴘᴏᴜɴᴅ ᴀɴɪsᴏᴍᴇᴛʀᴏᴘɪᴀ
𝟹- ᴍɪxᴇᴅ ᴀɴɪsᴏᴍᴇᴛʀᴏᴘɪᴀ
𝟺- sɪᴍᴘʟᴇ ᴀsᴛɪɢᴍᴀᴛɪsᴍ ᴀɴɪsᴏᴍᴇᴛʀᴏᴘɪᴀ
𝟻- ᴄᴏᴍᴘᴏᴜɴᴅ ᴀsᴛɪɢᴍᴀᴛɪsᴍ ᴀɴɪsᴏᴍᴇᴛʀᴏᴘɪᴀ
𝟭. 𝗦𝗶𝗺𝗽𝗹𝗲 𝗔𝗻𝗶𝘀𝗼𝗺𝗲𝘁𝗿𝗼𝗽𝗶𝗮 –
In this conditions, one eye is normal ( emmetropic) and the other
either myopic ( sɪᴍᴘʟᴇ ᴍʏᴏᴘɪᴄ ᴀɴɪsᴏᴍᴇᴛʀᴏᴘɪᴀ) or hypermetropic
( sɪᴍᴘʟᴇ ʜʏᴘᴇʀᴍᴇᴛʀᴏᴘɪᴄ ᴀɴɪsᴏᴍᴇᴛʀᴏᴘɪᴀ) .
𝟮. 𝗖𝗼𝗺𝗽𝗼𝘂𝗻𝗱 𝗔𝗻𝗶𝘀𝗼𝗺𝗲𝘁𝗿𝗼𝗽𝗶𝗮 -
In this conditions, both eyes are either hypermetropic ( ᴄᴏᴍᴘᴏᴜɴᴅ
ʜʏᴘᴇʀᴍᴇᴛʀᴏᴘɪᴄ ᴀɴɪsᴏᴍᴇᴛʀᴏᴘɪᴀ) or myopic ( ᴄᴏᴍᴘᴏᴜɴᴅ ᴍʏᴏᴘɪᴄ
ᴀɴɪsᴏᴍᴇᴛʀᴏᴘɪᴀ) , but one eye is having higher refractive error than
the other.
𝟯. 𝗠𝗶𝘅𝗲𝗱 𝗔𝗻𝗶𝘀𝗼𝗺𝗲𝘁𝗿𝗼𝗽𝗶𝗮 –
In this conditions, one eye is myopic and the other eye is
hypermetropic. This is called also “ 𝘼𝙉𝙏𝙄𝙈𝙀𝙏𝙍𝙊𝙋𝙄𝘼 „ .
𝟰. 𝗦𝗶𝗺𝗽𝗹𝗲 𝗔𝘀𝘁𝗶𝗴𝗺𝗮𝘁𝗶𝘀𝗺 𝗔𝗻𝗶𝘀𝗼𝗺𝗲𝘁𝗿𝗼𝗽𝗶𝗮 –
In this conditions, one eye is normal and the other eye has either
simple myopic or hypermetropic astigmatism.
𝟱. 𝗖𝗼𝗺𝗽𝗼𝘂𝗻𝗱 𝗔𝘀𝘁𝗶𝗴𝗺𝗮𝘁𝗶𝘀𝗺 𝗔𝗻𝗶𝘀𝗼𝗺𝗲𝘁𝗿𝗼𝗽𝗶𝗮 –
In this conditions, both eyes are asthmatic but of unequal
degree.
𝗦𝘁𝗮𝘁𝘂𝘀 𝗼𝗳 𝗯𝗶𝗻𝗼𝗰𝘂𝗹𝗮𝗿 𝘃𝗶𝘀𝗶𝗼𝗻 𝗶𝗻
𝗔𝗻𝗶𝘀𝗼𝗺𝗲𝘁𝗿𝗼𝗽𝗶𝗮
𝟭. 𝗕𝗶𝗻𝗼𝗰𝘂𝗹𝗮𝗿 𝘀𝗶𝗻𝗴𝗹𝗲 𝘃𝗶𝘀𝗶𝗼𝗻 - is present in small degree of
anisometropia ( 𝙡𝙚𝙨𝙨 𝙩𝙝𝙖𝙣 3𝘿 )
𝟮. 𝗨𝗻𝗶𝗼𝗰𝘂𝗹𝗮𝗿 𝘃𝗶𝘀𝗶𝗼𝗻- when refractive error in one eye is of high
degree, that eye is suppressed and develops
Anisometropia Amblyopia thus the pt. Has
Only uniocular vision.
𝟯. 𝗔𝗹𝘁𝗲𝗿𝗻𝗮𝘁𝗲 𝘃𝗶𝘀𝗶𝗼𝗻 – one eye is hypermetropic and other myopic
The hypermetropic eye is used for distant vision
and myopic for near vision.
𝗗𝗜𝗔𝗚𝗡𝗢𝗦𝗜𝗦
1- Retinoscopic examination
2- Testing for state of binocular vision
a- FRIEND test
b- Worth’s four – dot test
𝗧𝗥𝗘𝗔𝗧𝗠𝗘𝗡𝗧
𝟭. 𝗚𝗹𝗮𝘀𝘀𝗲𝘀
𝟮. 𝗖𝗼𝗻𝘁𝗮𝗰𝘁 𝗹𝗲𝗻𝘀
𝟯. 𝗔𝗻𝗶𝘀𝗲𝗶𝗸𝗼𝗻𝗶𝗰 𝗴𝗹𝗮𝘀𝘀𝗲𝘀
𝟰. 𝗥𝗲𝗳𝗿𝗮𝗰𝘁𝗶𝘃𝗲 𝗰𝗼𝗿𝗻𝗲𝗮𝗹 𝘀𝘂𝗿𝗴𝗲𝗿𝘆
𝟱. 𝗣𝗵𝗮𝗸𝗶𝗰 𝗿𝗲𝗳𝗿𝗮𝗰𝘁𝗶𝘃𝗲 𝗹𝗲𝗻𝘀𝗲𝘀 ( 𝗣𝗥𝗟)
𝟭- 𝗚𝗟𝗔𝗦𝗦𝗘𝗦 – the corrective spectacles can be tolerated up to a
maximum difference of 4D . After that there occur
Diplopia.
𝗖𝗼𝗻𝘁𝗮𝗰𝘁 𝗹𝗲𝗻𝘀𝗲𝘀- are advised for higher degree of anisometropia.
Contact lenses may be very useful in young children with high
anisometropia.
𝗔𝗻𝗶𝘀𝗲𝗶𝗸𝗼𝗻𝗶𝗰 𝗴𝗹𝗮𝘀𝘀𝗲𝘀 – are also available, but their clinical results
Are often disappointing.
𝗥𝗲𝗳𝗿𝗮𝗰𝘁𝗶𝘃𝗲 𝗰𝗼𝗿𝗻𝗲𝗮𝗹 𝘀𝘂𝗿𝗴𝗲𝗿𝘆 - for unilateral high myopia, astigmatism
And hypermetropia.
𝗔𝗡𝗜𝗦𝗘𝗜𝗞𝗢𝗡𝗜𝗔
ANISEIKONIA is defind as a Condition wherein the image projected to
the visual cortex from the two retinae are abnormally unequal size or
shape.
Aniseikonia = Unequal images
ANAMOLY OF BINOCULAR VISION, WHERE OCULAR IMAGES ARE
UNEQUAL IN SIZE OR SHAPE OR BOTH.
𝗘𝘁𝗶𝗼𝗹𝗼𝗴𝗶𝗰𝗮𝗹 𝘁𝘆𝗽𝗲𝘀
𝟭. 𝗢𝗽𝘁𝗶𝗰𝗮𝗹 𝗔𝗻𝗶𝘀𝗲𝗶𝗸𝗼𝗻𝗶𝗮 – May occur due to either inherent
Or acquired anisometropia of high degree.
𝟮. 𝗥𝗲𝘁𝗶𝗻𝗮𝗹 𝗔𝗻𝗶𝘀𝗲𝗶𝗸𝗼𝗻𝗶𝗮 - May develop due to –
• Displacement of retinal elements towards the nodal point in the
one eye and
• Stretching or Oedema of the retina.
𝟯. 𝗖𝗼𝗿𝘁𝗶𝗰𝗮𝗹 𝗔𝗻𝗶𝘀𝗲𝗶𝗸𝗼𝗻𝗶𝗮 -
𝗖𝗟𝗜𝗡𝗜𝗖𝗔𝗟 𝗧𝗬𝗣𝗘𝗦
𝟭. 𝗦𝘆𝗺𝗺𝗲𝘁𝗿𝗶𝗰𝗮𝗹 𝗮𝗻𝗶𝘀𝗲𝗶𝗸𝗼𝗻𝗶𝗮
a. Spherical – image may be magnified or minified equally in both
meridians.
b. Cylindrical – image is magnified or minified symmetrical in one
meridians.
𝟮. 𝗔𝘀𝘆𝗺𝗺𝗲𝘁𝗿𝗶𝗰𝗮𝗹 𝗮𝗻𝗶𝘀𝗲𝗶𝗸𝗼𝗻𝗶𝗮
a. Prismatic . b. Pin- cushion .
c. Barrel distortion . d. Oblique distortion.
A. PRISMATIC – difference increases progressively in one direction
B. PIN- CUSHION – distortion increases progressively in both direction
C. BARREL DISTORTION – distortion decrease progressively in both
direction as seen with high (-) correction.
Oblique DISTORTION –the size of image is same but there occurs
an oblique distortion of shape.
𝗧𝘆𝗽𝗲𝘀 𝗼𝗳 𝗔𝗻𝗶𝘀𝗲𝗶𝗸𝗼𝗻𝗶𝗮
𝗦𝘆𝗺𝗽𝘁𝗼𝗺𝘀
Asthenopia – eyeache browache and tiredness of eyes.
Diplopia - due to difficult binocular vision when the difference in
Images of two eyes is more than 5% .
Difficulty in depth perception is often noticed.
𝗧𝗥𝗘𝗔𝗧𝗠𝗘𝗡𝗧
• 1 optical - Aniseikonia may be corrected by aniseikonic glasses,
Contact lenses, Intraocular lenses or other refractive
Surgery depending upon the situation.
• 2 Retinal Aniseikonia may be corrected by treating the cause.
• 3 Cortical Aniseikonia is very difficult to treat.
Binocular optical defects
