Amazon EC2 Container Service (ECS) is a container management service that supports running and managing Docker containers on a cluster of Amazon EC2 instances. It provides built-in scheduling, cluster management, and orchestration capabilities to help run and scale containerized applications. ECS integrates with other AWS services like Elastic Load Balancing, Elastic Block Store, Virtual Private Cloud, and more. Users define tasks and services in task definitions that specify containers, resources, dependencies, and other configuration.

1. Amazon EC2 Container Service
Tuna
ng.tuna@gmail.com
@ngtuna11
http://www.meetup.com/Docker-Hanoi

2. Docker ecosystem
Scheduling & Orchestration

3. • Run and manage cluster of docker
containers
• Build-in service scheduler, task scheduler
and state manager
• Orchestration system
• Integrate with multiple AWS services.
Amazon EC2 Container Service

4. Elastic Load Balancing
Amazon Elastic Block Store
Amazon Virtual Private Cloud
AWS Identity and Access Management
AWS CloudTrail
AWS CloudFormation
AWS CloudWatch
Designed for use with other AWS services

12. Task Definitions
{
"environment": [],
"name": "simple-demo",
"image": "my-demo",
"cpu": 10,
"memory": 500,
"portMappings": [
{
"containerPort": 80,
"hostPort": 80
}
],
"mountPoints": [
{
"sourceVolume": "my-vol",
"containerPath": "/var/www/my-
vol"
}
],
"entryPoint": [
"/usr/sbin/apache2",
"-D",
"FOREGROUND"
],
"essential": true
},
{
"name": "busybox",
"image": "busybox",
"cpu": 10,
"memory": 500,
"volumesFrom": [
{
"sourceContainer": "simple-demo"
}
],
"entryPoint": [
"sh",
"-c"
],
"command": [
"/bin/sh -c "while true; do
/bin/date > /var/www/my-vol/date; sleep 1; done""
],
"essential": false
}

13. {
"environment": [],
"name": "simple-demo",
"image": "my-demo",
"cpu": 10,
"memory": 500,
"portMappings": [
{
"containerPort": 80,
"hostPort": 80
}
],
"mountPoints": [
{
"sourceVolume": "my-vol",
"containerPath": "/var/www/my-
vol"
}
],
"entryPoint": [
"/usr/sbin/apache2",
"-D",
"FOREGROUND"
],
"essential": true
},
Task Definitions
[
{
"image": "mysql",
"name": "db",
"cpu": 10,
"memory": 500,
"essential": true,
"entryPoint": [
"/entrypoint.sh"
],
"environment": [
{
"name": "MYSQL_ROOT_PASSWORD",
"value": "pass"
}
],
"portMappings": []
}
]
Essential to our Task
Create and mount volumes
Expose port 80 in container
to port 80 on host
10 CPU Units (1024 is full CPU),
500 Megabytes of Memory

14. {
"name": "busybox",
"image": "busybox",
"cpu": 10,
"memory": 500,
"volumesFrom": [
{
"sourceContainer": "simple-demo"
}
],
"entryPoint": [
"sh",
"-c"
],
"command": [
"/bin/sh -c "while true; do
/bin/date > /var/www/my-vol/date; sleep 1; done""
],
"essential": false
}
Task Definitions
[
{
"image": "tutum/wordpress-stackable",
"name": "wordpress",
"cpu": 10,
"memory": 500,
"essential": true,
"links": [
"db"
],
"entryPoint": [
"/bin/sh",
"-c"
],
"environment": [
…
],
"portMappings": [
{
"containerPort": 80,
"hostPort": 80
}
]
},
]
From Docker Hub
Mount volume from other container
Command to exec

15. Tasks
Good for short-lived
containers, e.g.
batch jobs

16. Services
Good for long-
running applications
and services

17. Service Scheduler
• Manage long-running applications and services
• Build-in
• What it does
• Load balacing
• Health management
• Scale-up and scale-down
• Update management
• Drain ELB

19. DIY

21. Architectural Design

22. You want more ???

23. Container-level autoscaling
Amazon Lambda & Amazon
ECS: Excellent !!!
https://aws.amazon.com/blogs/comput
e/scaling-amazon-ecs-services-
automatically-using-amazon-
cloudwatch-and-aws-lambda/

24. Service discovery
Load Balancers
DNS
Service discovery services

25. Service discovery
Load Balancers
ECS Service scheduler

26. Service discovery
DNS
http://weave.works/guides/service
-discovery-with-weave-aws-
ecs.html

27. Service discovery
Service discovery services
https://aws.amazon.com/blogs/co
mpute/service-discovery-via-
consul-with-amazon-ecs

28. Monitoring & logging
Docker logs
Container logs

34. Extensible
Comprehensive APIs
Open source agent
Custom schedulers

35. Questions
