Variable frequency drives (VFDs) control the speed of AC motors by converting AC power to DC and then back to variable voltage/frequency AC. VFDs allow constant torque or variable torque operation depending on the motor load. They provide benefits like energy savings, soft starts, and process control. Rockwell Automation offers their PowerFlex line of VFDs in compact, standard, and premium models for applications from 0.75 kW to 2000 HP. WEG is a global manufacturer of electric motors with a history dating back to 1961. They produce low and medium voltage induction motors from 0.12 kW to 1500 kW for applications in industries like pumps, fans, compressors, and more.
