This document provides information about the PS-TYRO-ARM7-LPC214X kit from Pantech Prolabs India Pvt Ltd. The kit contains an LPC2148 microcontroller board, power adapter, cables, user guide, and software to help users develop and debug designs using the 32-bit LPC2148 microcontroller. It has features like LEDs, buttons, sensors, I/O pins, and interfaces like USB, UART, and JTAG to connect external devices and program/debug the microcontroller. The kit is intended to help users learn real-time applications and microcontroller programming in C and assembly languages.

1. PART NO: PS-TYRO-ARM7-LPC214X
NXP’s (ARM7) LPC2148, ARM Kit is proposed to
smooth the progress of developing and debugging of
various designs encompassing of High speed 32-bit
Microcontrollers. User can easily engage in development
in this platform, or use it as reference to application
development.
BENEFITS
RTOS Support
Evaluate Real Time Applications
Supports Embedded C, ASM
ISP Programming / JTAG Debugging
Facility to interface external devices
KEY FEATURES
8 Nos. Point LEDs (Logic Output)
8 Nos. Digital Input(DIP Switch)
2 Nos. Analog Input (Potentiometer)
Temperature Sensor(LM35)
RTC with Battery-Backup
2 Nos. UART(RS232)
USB 2.0 device (Virtual Port)
Digital / Analog Output
Interrupts Study, Reset Button
PS/2 (Keyboard Interface)
40-Pin Expansion Connector
JTAG (Program/Debug)
ISP Programming
3 Nos. 20pin- I/O Expansion Connector
PWM Terminations
Pantech Prolabs India Pvt Ltd.,
LPC2148
Devices
Memory
Clock
: LPC2148 (ARM7TDMI Core)
: 512K FLASH - Program
32K+8K SRAM – Data Memory
: 12MHz crystal, Max = 60 MHz
KIT INCLUDES
LPC2148 Evaluation Kit
Power Adaptor
RS232 Cable, USB Cable
User Guide HW/SW
CD Contains:
Examples, ISP Programmer, IDE, Datasheets
